Parmco HX-2-6NF-ZLIND User manual

Installation
and Operating
Instructions
For your convenience, we recommend to attach
the serial number label HERE.
Model:
HX-2-6NF-ZLIND
727626112018

727626112018

Dear Valued Customer,
Thank you and congratulations on purchasing your new Parmco appliance.
All Parmco products are made to the highest quality and design standards. We are
sure you will enjoy your new appliance.
As a note, please read through these instructions carefully. These will assist you
appliance. Please take special note of all detailed technical information and installation
instructions. It is essential that you follow these instructions to ensure the safety
and reliability of this appliance.
future warranty claims lodged, so please check with Parmco Appliances before any
installation is carried out.
this product or any other products in Parmco’s extensive range, visit us online at
www.parmco.co.nz.
Regards,
The Parmco Team

1
INDEX
Important Safety Warnings
2
Product overview
4
Top view
4
Control panel
4
Inducon Cooking
4
Before using your Inducon Hob
5
Using your Inducon Hob
6
To start cooking
6
When you have finished cooking
7
8
Locking the controls
9
Using the mer
9
Over-Temperature Protecon
11
Detecon of Small Items
11
Auto Shutdown
11
Cooking guidelines
12
Heat sengs
13
Care and cleaning
14
Troubleshoong
15
Fault Codes
16
Technical Specificaons
17
Installaon
17
Using the Bridge

2
Important Safety Warnings
Your safety is important to us. Please read this informaon before using your cooktop.
Important safety instrucons
• Never leave the appliance unaended when in use. Boil-over causes smoking and greasy spillovers
may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• No combusble materials are to be placed on the appliance at any me.
• Do not place or leave any magnesed objects (e.g. credit cards, memory cards) or electronic
devices (e.g. computers, MP3 players) near the appliance, as they may be affected by its
electromagnec field.
• We recommend using plasc or wooden kitchen utensils for cooking with your inducon cooktop.
• Never use your appliance for warming or heang the room.
• Aer use, always turn off the cooking zones and the cooktop as described in this manual (i.e. by
using the touch controls). Do not rely on the pan detecon feature to turn off the cooking zones
when you remove the pans.
• Do not allow children to play, sit, stand, or climb on the appliance.
• Do not store items of interest to children in cabinets above the appliance. Children climbing on
the cooktop could be seriously injured.
• Do not leave children alone or unaended in the area where the appliance is in use.
• Children or persons with a disability which limits their ability to use the appliance should have a
responsible and competent person to instruct/supervise them in its use. The instructor should
be sasfied that they can use the appliance without danger to themselves or their surroundings.
• Do not repair or replace any part of the appliance unless specifically recommended in the
manual. All other servicing should be done by a qualified technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans across the inducon glass surface as this can
scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these
can scratch the glass.
•This appliance is intended to be used in a household or similar environments such as staff kitchen
areas in shops, offices and other residenal environments.
• If the supply cord is damaged, it must be replaced by a special cord or assembly available from the
manufacturer or its service agent.
•WARNING: The appliance and its accessible parts become hot during use.Care should be taken to
avoid touching heang elements.
Children less than 8 years of age should be kept away unless connuously supervised.
•The appliance is not to be used by persons (including children) with reduced physical, sensory or
mental capabilies, or lack of experience and knowledge, unless they have been given supervision or
instrucon children being supervised not to play with the appliance
•WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of an electric
shock,for hob surfaces of glass-ceramic or similar material which protect live parts.
•The appliance is not intended to be operated by means of an external mer or separate
remote-control system.
•CAUTION: The cooking process has to be supervised. A short term cooking process has to be
supervised connuously.
•WARNING: In order to prevent pping of the appliance, it must be stabilised prior to installaon.
Please refer to the installaon instrucons.
•WARNING:Use only hob guards designed by the manufacturer of the cooking appliance or indicated
by the manufacturer of the appliance in the instrucons for use as suitable or hob guards incorporated
in the appliance. The use of inappropriate guards can cause accidents.
•This appliance incorporates an earth connecon for funconal purposes only.
•WARNING: Unaended cooking on a hob with fat or oil can be dangerous and may result in fire.
NEVER try to exnguish a fire with water, but switch off the appliance and then cover flame e.g. with a
lid or a fire blanket.
•WARNING: Danger of fire: do not store items on the cooking surfaces.
NOTICE: The crystallite glass is sll hot aer use, please do not touch!

3
Installaon
Electrical Shock Hazard
•Disconnect the appliance from the main electricity supply before carrying out any work or
maintenance on it.
•Connecon to a good earth wiring system is essenal and mandatory.
•Alteraons to the domesc wiring system must only be made by a qualified technician.
•Failure to follow this advice may result in electrical shock or death.
Important safety instrucons
•Read these instrucons carefully before installing or using this appliance.
•No combusble materials or products should be placed on this appliance at any me.
•Please make this informaon available to the person responsible for installing the appliance as
it could reduce your installaon costs.
•In order to avoid a hazard,this appliance must be installed according to these instrucons for
installaon.
•This appliance must be properly installed and earthed by a qualified technician.
•This appliance should be connected to a circuit which incorporates an isolang switch,
providing full disconnecon from the power supply.
•Failure to install the appliance correctly could void any warranty or liability claims.
Operaon and maintenance
Electrical Shock Hazard
•Do not cook on a broken or cracked cooktop. If the cooktop surface break or crack, switch the
appliance off immediately at the main power supply (wall switch)and contact a qualified
technician.
•Switch the cooktop offat the wall before cleaning or maintenance.
•Failure to follow this advice may result in electrical shock or death.
Health Hazard
•This appliance complies with electromagnec safety standards.
•However, persons with cardiac pacemakers or other electrical implants (such as insulin pumps)
must consult with their doctor or implant manufacturer before using this appliance to make
sure that their implants will not be affected by the electromagnec field.
•Failure to follow this advice may result in death.
Hot Surface Hazard
•During use,accessible parts of this appliance will become hot enough to cause burns.
•Do not let your body,clothing or any other items other than suitable cookware contact the
Inducon glass unl the surface is cool.
•Never leave metal objects (such as kitchen utensils)or empty pans on the cooktop as they can
become hot very quickly.
•Beware: magnesable metal objects worn on the body may become hot in the vicinity of the

4
cooktop. Gold or silver jewellery will not be affected.
•Keep children away.
•Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other
cooking zones that are on. Keep handles out of reach of children.
•Failure to follow this advice could result in burns and scalds.
Product Overview
HX-2-6NF-ZLIND
Top View Control Panel
1. ON/OFF control
2. Cooking zone selecon controls
3. Heat/Timer Regulaon Controls
4. Timer
5. Key/child Lock Controls
6. Le side bridge
7. Right side bridge
Inducon Cooking
Inducon cooking is a safe, advanced,efficient, and economical cooking technology. It works by
electromagnec vibraons generang heat directly in the pan,rather than indirectly through
heang the glass surface. The glass becomes hot only because the pan eventually warms it up.
Iron pot
Magnetic circuit
Ceramic glass plate
Induction coil
Induced currents

 

 



5
Before using your Inducon Hob
•Read this guide,taking special note of the ‘Safety Warnings’ secon.
•Remove any protecve film that may sll be on your Inducon hob.
Using the Touch Controls
•The controls respond to touch,so you do not need to apply any pressure.
•Use the ball of your finger, not its p.
•You will hear a beep each me a touch is registered.
•Make sure the controls are always clean,dry, and that there are no objects (e.g. a utensil or a
cloth)covering them. Even a thin film of water may make the controls difficult to operate.
Choosing the right Cookware
•Only use cookware with a base suitable for inducon cooking. Look
for the inducon symbol on the packaging or on the boom of the
pan.
•You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan. If it is
aracted,the pan is suitable for inducon.
•If you do not have a magnet:
oPut some water in the pan you want to check.
oFollow the steps under ‘To start cooking’ on page 7.
oIf does not flash in the display and the water is heang,the pan is suitable.
•Cookware made from the following materials is notsuitable: pure stainless steel,aluminumor
copper without a magnec base,glass,wood,porcelain,ceramic,and earthenware.

6
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth,sits flat against the glass,and is the same size as the
cooking zone. Use pans with a base diameter that is as large as the graphic of the zone selected. By
using a slightly wider pot,energy will be used at its maximum efficiency. If you use a smaller pot,
the efficiency could be less than expected. Pots less than 140 mm could be undetected by the hob.
Always centre your pan on the cooking zone.
Always li pans offthe Inducon hob – do not slide,as they may scratch the glass.
Using your Inducon Hob
To start cooking
No heang takes place unless there is a suitable pan on the cooking zone.
The display will automacally turn offaer 1 minute,if no suitable pan is placed on it.
1. Place a suitable pan on the cooking zone that
you wish to use.
Make sure the boom of the pan and the surface of the cooking zone are
clean and dry.
•

7
2. Touch the ON/OFF control
Aer switching the power on,the buzzer beeps once. All displays
show “ – “ or “ – – “,indicang that the inducon hob has entered standby mode.
Note: if the display flashes “ “,alternavely with the heat seng,this means:
Pan has not been placed on the correct cooking zone
Pan is not suitable for inducon hob.
Pan is too small and can not be detected,or not posioned correctly.
3. Touch the cooking zone you wish to use.
4. Select a heat seng by touching the “-/+” regulang controls
•
•
•
•
If you do not choose a heat seng within 1 minute,the Inducon hob will
automacally switch back to standby mode. You will need to start again at step 1.
•You can modify the heat seng at any me during cooking.
When you have finished cooking
1. Touch the cooking zone selecon control that you wish to switch off.
2. Turn the cooking zone offby scrolling down to “0 “ using the “-“ regulang
control.
The display will then show “H"
3. Alternavely turn the whole cooktop offby touching the ON/OFF control

•
4. Beware of hot surfaces
“H” will show which cooking zone is sll hot to touch. The signal will disappear when the
surface has cooled down to a safe temperature. It can also be used as an energy
saving funcon -if you want to heat further pans,use the hotplate that is sll hot.
Note: the residual heat indicator will disappear if the main power supply to the hob is turned off.
8
Using the Bridge （Maximum power 3000W）
To Turn On a Bridge:
1. Touch the desired Le/right side bridge.
Indicator to the right of bridge will be illuminated. The heat seng levels for the
cooking areas will default to “0” and can be set from a minimum of “1” to a
maximum of “9.” Any mers that may be running for the cooking areas will turn
off, and 2 dashes “--” will appear in the mer display.
2. Touch the Power / Timer regulang key to change the power level up or
down.The selected heat level will show in the heat level display for each cooking
area using the bridge.
To Turn Off a Bridge:
Touch the bridge for the zone being used.
The bridge cooking areas will resume operaon as 2 separate areas.

9
Locking the Controls
You can lock the controls to prevent unintended use (for example children accidentally turning the
cooking zones on).
When this funcon is acvated,all controls except the ON/OFF control are disabled.
To lock the controls
1. Touch and hold the keylock symbol and the mer indicator display will show “Lo”
To unlock the controls
1. Make sure the hob is turned on.
2. Touch and hold the keylock control to unlock the hob control panel. “Lo” will
disappear from the display.
3. The hob is now unlocked,and you can now start using it.
When the hob is in lock mode,all controls are disabled except the ON/OFF control. In an
emergency,you can turn the inducon hob offwith the ON/OFF buon,but you will have
to unlock the hob first before the next use.
Using the Timer
You can use the mer to turn one or more cooking zones offaer a set amount of me.
Note: The mer can be set for up to 99 minutes for each cooking zone.
The mer will begin to count down immediately aer being set.
Seng the mer to turn one heang zone off
1. Touch the heang zone control that you want to set the mer for.
2. Select the heat level using the “-“ or “+” regulang controls

10
3. Touch the mer control,the display will show “30”
4. Set the me by touching the “-“ or “+” regulang controls.
Hint:Touch the “-“ or “+” controls once and the me will change in
increments
of 1 minute.
Touch and hold the “-“ or “+” control and the me will change in increments of 10
minutes.
If the seng me exceeds 99 minutes,the mer will automacally return to 0 minutes.
Cancelling the mer for a heang zone
1. Press the “-” mer regulang key to reduce the me outstanding to 0.
OR
2. Touch the Timer control to cancel the mer.
3. Display will show “00”
When the selected cooking me has been reached,the corresponding cooking
zone will switch offautomacally.
Other heang zone will keep operang if it had previously been turned on.
•

11
Over-Temperature Protecon
Atemperature sensor can monitor the temperature inside the Inducon hob. When excessive
temperature is detected,the Inducon hob will stop operaon automacally.
Detecon of Small Items
When an unsuitable sized/non-magnec pan,or some other small item (e.g. knife,fork,key)has
been le on the hob,the hob automacally goes on to standby aer 1 minute. The fan will keep
cooling the inducon hob for a further 1 minute.
Auto Shutdown
Auto shutdown is a safety protecon funcon for your inducon hob. It shuts down automacally if
you ever forget to turn offyour cooking. The default working mes for various power levels are
shown in the table below.
Power level
1
2
3
4
5
6
7
8
9
Default working mer (hour)
8
8
8
4
4
4
2
2
2
When the pot is removed,the inducon hob will stop heang immediately and the hob will
automacally switch offaer 1 minutes.
People with a heart pace maker should consult with their doctor before using this unit.

12
Cooking Guidelines
Take care when frying as oils and fats heat up very quickly, At extremely high
temperatures, oils and fats will ignite spontaneously and present a serious fire risk.
Cooking Tips
•When food comes to boil,reduce the temperature seng.
•Using a lid will reduce cooking mes and save energy by retaining the heat.
•Minimise the amount of liquid or fat to reduce cooking mes.
•Start cooking on a high temperature seng and reduce the seng when the food has heated
through.
Simmering, cooking rice
•Simmering occurs below boiling point at around 85˚C when bubbles are just rising occasionally
to the surface of the cooking liquid. It is the key to delicious soups and tender stews because
the flavours develop without overcooking the food. You should also cook egg-based and
flour-thickened sauces below boiling point.
Searing steak
To cook juicy flavoursome steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then
lower the meat onto the hot pan.
4. Turn the steak only once during cooking. The exact cooking me will depend on the thickness of
the steak and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press
the steak to gauge how cooked it is – the firmer it feels the more ‘well done’ it will be.
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relaxand become
tender before serving.

13
For sr-frying
1. Choose an inducon compable flat-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Sr-frying should be quick. If cooking large
quanes,cook the food in several smaller batches.
3. Preheat the pan briefly and add two tablespoons of oil.
4. Cook any meat first, then put it aside and keep warm.
5. Sr-fry the vegetables. When they are hot but sll crisp,turn the cooking zone to a lower
seng,return the meat to the pan and add your sauce.
6. Sr the ingredients gently to make sure they are heated through.
7. Serve immediately.
Heat Sengs
The sengs below are guidelines only. The exact seng will depend on several factors,including
your cookware and the amount you are cooking. Experiment with the inducon hob to find the
sengs that are best suitable for you.
Heat seng Suitability
1 -2 •delicate warming for small amounts of food
•melng chocolate,buer, and foods that burn quickly
•gentle simmering
•slow warming
3 - 4 •reheang
•rapid simmering
•cooking rice
5 -6 •pancakes
7 -8 •sautéing
•cooking pasta
9/P •sr-frying
•searing
•bringing soup to boil
•boiling water

14
Care and Cleaning
What?
How?
Important!
Everyday soiling on glass
(fingerprints, marks,
stains leby food or
non-sugary spillovers on
the glass).
1. Switch the power to the cooktop off.
2. Apply a cooktop cleaner while the
glass is sll warm (but not hot!).
3. Rinse and wipe dry with a clean cloth
or paper towel.
4. Switch the power to the cooktop
back on.
•When the power to the cooktop is switched
off,there will be no ‘hot surface’ indicaon
but the cooking zone may sll be hot!Take
extreme care.
•Heavy-duty scourers,some nylon scourers
and harsh/abrasive cleaning agents may
scratch the glass. Always read the label to
check if your cleaner or scourer is suitable.
•Never leave cleaning residue on the cooktop:
the glass may become stained.
Boilovers, melts,and
hot sugary spills on
the glass.
Remove these immediately with a fish
slice,palee knife or razor blade
scraper suitable for Inducon glass
cooktops,but beware of hot cooking
zone surfaces:
1. Switch the power to the cooktop off
at the wall.
2. Hold the blade or utensil at a 30°
angle and scrape the soiling or spill
to a cool area of the cooktop.
3. Clean the soiling or spill up with a
dish cloth or paper towel.
4. Follow steps 2 to 4 for ‘Everyday
soiling on glass’ above.
•Remove stains leby melts and
sugary food or spillovers as soon
as possible. If leto cool on the
glass,they may be difficult to
remove or even permanently
damage the glass surface.
•Cut hazard: when the safety cover
is retracted,the blade in a scraper
is razor-sharp. Use with extreme
care and always store safely and
out of reach of children.
Spillovers on the
touch controls.
1. Switch the power to the cooktop off.
2. Soak up the spill.
3. Wipe the touch control area with a
clean damp sponge or cloth.
4. Wipe the area completely dry
with a paper towel.
5. Switch the power to the cooktop
back on.
•The cooktop may beep and turn
itself off,and the touch controls
may not funcon while there is
liquid on them. Make sure you wipe the
touch control area dry before turning the
cooktop back on.

15
Troubleshoong
Problem Possible causes What to do
The inducon hob cannot
be turned on.
No power. Make sure the inducon hob is connected
to the power supply and that it is switched
on.
Check whether there is a power outage in
your home or area. If
you have checked everything and the
problem persists,call a qualified technician.
The touch controls are
unresponsive.
The controls are locked.
Unlock the controls. See secon
‘Using your inducon cooktop’ for
instrucons.
The touch controls are
difficult to operate.
There may be a slight film of water
over the controls or you may be using
the p of your finger when touching
the controls.
Make sure the touch control area is dry and
use the ball of your finger when touching
the controls.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable,abrasive scourer or
cleaning products being used.
Use cookware with flat and smooth bases.
See ‘Choosing the right cookware’.
See ‘Care and cleaning’.
Some pans make crackling
or clicking noises.
This may be caused by the
construcon of your cookware
(layers of different metals vibrang
differently).
This is normal for cookware and does not
indicate a fault.
The inducon hob makes
alow humming noise
when used on
a high heat seng.
This is caused by the technology
of inducon cooking.
This is normal,but the noise should quieten
down or disappear completely when you
decrease the heat seng.
Fan noise coming fromthe
inducon hob.
Acooling fan built into your inducon
hob has turned on to prevent the
electronics from overheang. It may
connue to run even aer you’ve
turned the inducon hob off.
This is normal and needs no acon. Do not
switch the power to the inducon hob off
at the wall while the fan is running.
Pans do not become hot.
The induction hob cannot detect the
pan because it is not suitable for
inducon cooking.
The inducon hob cannot detect the
pan because it is too small for the
cooking zone or it is not properly
centred on the zone.
Use cookware suitable for inducon
cooking. See secon ‘Choosing the right
cookware’.
Centre the pan and make sure that its base
matches the size of the cooking zone.

16
The inducon hob or a
cooking zone has turned
itself off
unexpectedly,a tone
sounds and an error code
is displayed
(typically alternang with
one or two digits in the
cooking mer display).
Technical fault. Please note down the error
leers and numbers,switch
the power to the inducon hob
off at the wall,and contact a
qualified technician.
Fault Codes
If an abnormality comes up,the inducon hob will enter a protecve state automacally and
display the corresponding protecve codes:
Problem
Possible causes
What to do
F3-F4 Temperature sensor failure of
inducon coil.
Please contact a technician.
F9-FATemperature sensor failure of the
IGBT.
Please contact a technician.
E1/E2 Abnormal supply voltage. Please inspect whether power supply
is normal. Power on aer the power
supply is normal.
E3 Abnormally high temperature of
inducon coil temperature sensor
Please contact a technician.
E5 Abnormally high temperature of IGBT
temperature sensor
Please restart aer the inducon hob
cools down.
The above are the judgment and inspecon of common failures.
Please do not disassemble the unit by yourself to avoid any dangers and damages to the inducon hob.

HX-2-6NF-ZLIND
17
Technical Specificaon
Cooking Hob
Cooking Zones 4 Zones
Supply Voltage 220-240V~ 50Hz
Power
Product Size L×W×H(mm) 590x520x77mm
Cut Out Dimensions A×B (mm)560x490mm
Dimensions are approximate. Because we connually strive to improve our products we may
change specificaons and designs without prior noce.
Installaon
Selecon of installaon equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installaon and use,a minimum of 50mm space shall be preserved
around the hole.
Be sure the thickness of the work surface is at least 40-50mm. Please select
heat-resistant work surface material to avoid larger deformaon caused by the heat
radiaon from the hotplate.
When installing the hob over drawers,a board must be installed 10mm underneath the
hob. The board must be made of suitable heat resistant materials.
Cauons
1. The inducon hotplate must be installed by qualified personnel or technicians. Never conduct
the installaon by yourself.
2. The hob must not be installed directly above a dishwasher, fridge,freezer, washing machine or
clothes dryer, as the humidity may damage the hob electronics.
3. The wall and induced heang zone above the tabletop must be able to withstand heat.
4. To avoid any damage,the sandwich layer and adhesive must be resistant to heat.
Dear Installer:
Please affix data label provided on the adjacent cupboard near
the appliance for future reference. Thank you.
•
•
•
•
rear le (180mm):1500W
front right (180mm):1500W
front le (180mm):2000W
rear right (180mm):2000W
