PARMIDA PLED-DHWL100W-OR User manual

INSTALLATION GUIDE
DUAL-HEAD MULTI-DIRECTIONAL LED WORK LIGHT
CAUTION: Read all instructions and warnings before operating! SAVE THESE INSTRUCTIONS!
WARNING: To avoid serious injury or death from electrical shock or re:
1. DO NOT handle this xture or try to plug it in when your hands are wet or damp or when standing on a wet or damp surface or in water.
2. This xture MUST ALWAYS BE USED in accordance with all electrical and safety codes and ordinances, including the most recent National Electric Code
(NEC) and with the Occupational Safety and Health Administration (OSHA) Volume 1 on General Industry Standards and interpretations.
3. ALWAYS make certain that the power source conforms to the rating on the xture.
4. ALWAYS disconnect the power before servicing or inspecting the xture for any reason.
5. This xture IS ONLY FOR USE ON 110-120V and is equipped with an approved 3 conductor cord with a 3-prong, grounded plug. TO REDUCE THE RISK OF
ELECTRICAL SHOCK, it should only be plugged into a properly grounded 3-prong outlet.
6. This xture is suitable for indoor/outdoor use. The xture can be used outdoor in rain or damp conditions.
7. CAUTION: RISK OF ELECTRIC SHOCK. Do not use in or near standing water, or where water may accumulate. Keep this xture at least 16 feet from pools
or spas. Keep plug dry. DO NOT IMMERSE THIS FIXTURE.
8. Ground Fault Circuit lnterrupter (GFCI) should be provided on the circuit or outlet to be used in a wet location or outdoor use.
9. This xture is not explosive-proof. DO NOT use in potentially dangerous locations, such as in ammable or explosive atmospheres.
10. Always keep the work light away from any ammable surface or materials.
11. NEVER operate the light with the clear protective glass broken or removed.
12. NEVER LOOK DIRECTLY INTO LIGHT SOURCE. LEDs are extremely bright and can damage eyes with prolonged exposure.
13. KEEP AWAY from heating vents, radiators, or other sources of heat.
14. KEEP OUT OF REACH OF CHILDREN.
15. Always check damaged or worn-out parts before using the work light.
16. Do not use a pressure washer to clean this product.
17. Do not modify the work light in any way.
[email protected] www.parmida.com
PLED-DHWL100W-OR | PLED-DHWL50W-OR

1. Use hex wrench (included) to remove the screws from the lamp
mounting bar. Place the carrying handle on the lamp mounting bar and
align with screw hole, then place the screws back and tighten them to
hold the handle.
2. Attach working light heads to the lamp mounting bar, using the mounting
knobs.
3. Push down the bolts on three tripod legs and pull the three legs out and
down to a desired position. The bolts will automatically be locked once
you release them.
4. To adjust the height of the Tripod Stand, loosen the Height Adjustment
Knob and raise or lower the center post until the desired height is
achieved, then tighten the knob until the center post is locked into place.
5. Place the stand on a rm level surface. CAUTION: Never place the tripod
on a steep incline or unstable surface. The tripod may tip causing injury.
6. Place the upper work light assembly on the tripod mounting bracket.
Align the bottom bar with the hole on tripod bracket. Insert the knob with
threaded bolt through the handle and into the tripod bracket. Twist and
tighten the knob until snug.
7. Plug power cord into 110-120V standard wall outlet. Push the red
switch at the bottom of enclosure to turn the light on. Each of the light
heads has an ON/OFF switch. Always turn each light head off before
unplugging the work light.
8. To adjust the direction of the LED light heads. Loosen the knobs to
swivel or knobs to tilt the LED light heads to the desired position.
Re-tighten the knob(s) to hold the position.
STEPS FOR ASSEMBLY AND USE
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
DISCONNECT MAIN POWER AT FUSE OR CIRCUIT BREAKER
BEFORE INSTALLING OR SERVICING THE LIGHT
DO NOT USE ANY OTHER DRIVER EXCEPT PARMIDA LIGHTING
DRIVER THAT IS INCLUDED WITH THE FIXTURE.
[email protected] www.parmida.com
CARRY
HANDLE
MOUNTING
BAR
TRIPOD MOUNT
BRACKET
HEIGHT
ADJUSTMENT
KNOB
TRIPOD LEGS
ON/OFF SWITCH
110-120V OUTLET
SWIVEL KNOB
TILT KNOB
THREADED
BOLT
TRIPOD MOUNT
BRACKET
UPPER
WORK LIGHT
ASSEMBLY
LIGHT HEADS
MOUNTING BAR
MOUNTING KNOBS
STEP 1
STEP 3 - 5
STEP 7 STEP 8
STEP 6
STEP 2
