Parr Instrument 4871 Instruction Manual

4871
Process Controller
Supplemental Operating Instruction Manual

4871 Process Controller Supplemental Instructions
2
IMPORTANT INFORMATION
This manual supplement contains important operating and safety information. Users should study
all of these instructions located here and on the USB Flash Drive which accompanied the
controller. The 4871 Process Controller is a complex piece of equipment and will require some time
to understand its capabilities. You must carefully read and understand the contents of this manual
prior to the use of this equipment. For safe operation, please pay attention to the alert signals
throughout the manual.
PC REQUIREMENTS
OPERATING
SYSTEM
• Windows 10 (32 bit & 64 bit)
• Windows 8, 8.1 (32 bit & 64 bit)
• Windows 7 (32 bit & 64 bit)
• Windows Vista (32 bit), Vista 64 has shown some instability.
• Windows Server 2003, 2008, 2012 (32 bit & 64 bit)
• Windows XP (32 bit & 64 bit)
Note: SpecView does not work on Windows 8 RT (as found on some
Microsoft Surface tablets).
MINIMUM
SYSTEM
REQUIREMENTS
• Intel Pentium processor or equivalent AMD
• 1GB RAM minimum
• (2GB or more recommended, as Windows takes most of this
minimum)
• 1G hard disk space to install SpecView and related utilities
• Additional disk space for data logging (varies depending on how
much and how often you log data)
• Display adapter capable of operating at 1024 x 768 pixels and at
least 16-bit color
• 2 USB ports
• A wired Ethernet port (4871 Controller only)
IDEAL SYSTEM • Intel Core i5 (or Celeron / AMD equivalent) 2.6Ghz
• 2GB RAM
• 500GB hard disk + enough space for Data Logging
• Display adapter capable of operating at 1024 x 768 pixels and at
least 16-bit color
• 2 USB ports
• A wired Ethernet port (4871 Controller only)

4871 Process Controller Supplemental Instructions
3
EXPLANATION OF SYMBOLS
This CAUTION symbol may be present on the Product Instrumentation and
literature. If present on the product, the user must consult the appropriate part of
the accompanying product literature for more information.
This CAUTION symbol indicates that the surface may be hot.
Protective Earth (PE) terminal. Provided for connection of the Protective Earth
(green or green/yellow) supply system conductor.
Earth Ground. Functional earth connection. This connection shall be bonded to
Protective earth at the source of supply in accordance with national and local
electrical code requirements.
SAFETY INFORMATION
To avoid electrical shock, always:
1. Use a properly grounded electrical outlet of
correct voltage and current handling capabil-
ity.
2. Ensure that the equipment is connected to
electrical service according to local national
electrical codes. Failure to properly connect
may create a fire or shock hazard.
3. For continued protection against possible
hazard, replace fuses with same type and
rating of fuse.
4. Disconnect from the power supply before
maintenance or servicing.
To avoid personal injury:
1. Do not use in the presence of flammable
or combustible materials; fire or explosion
may result.This device contains components
which may ignite such material.
2. Refer servicing to qualified personnel.
GENERAL SPECIFICATIONS
Electrical Ratings
115VAC, 5.0 Amps, 50/60 Hz
230VAC, 5.0 Amps, 50/60 Hz
Before connecting the components of the 4871
Process Controller, the user must be sure that
the line, load, and other characteristics of the
installation do not exceed the following limits:
Voltage. The line voltage should not differ from
the rated voltage shown on the nameplate of
the 4871 by more than 10 percent.
Frequency. This system can be operated from
either a 50 or 60 Hertz power supply without
affecting their operation or calibration.
Current. Loads drawn from the back of the 4871
must not exceed 5 amperes.
Thermocouple. Unless otherwise specified,
all 4871 Process Controllers operate with a
Type-J (Iron-Constantan) thermocouple. The
total resistance of the thermocouple and the
lead wires should not exceed 100 ohms. If the
resistance of the thermocouple circuit is higher,
it will not function properly.

4871 Process Controller Supplemental Instructions
4
ENVIRONMENTAL CONDITIONS
CAUTION!
Do not use in hazardous atmospheres.
Operating: 15 °C to 30 °C; maximum relative
humidity of 80% non-condensing.
Installation Category II (overvoltage) in
accordance with IEC 664.
Pollution degree 2 in accordance with IEC 664.
Altitude Limit: 2,000 meters.
Storage: -25 °C to 65 °C; 10% to 85% relative
humidity.
PROVISIONS FOR LIFTING & CARRYING
Before moving the instrument, disconnect all
connections from the rear of the apparatus. Lift the
instrument by grabbing underneath each corner.
INTENDED USAGE
This apparatus is to be used indoors. This
system has been designed for use with
equipment provided by
Company. It has been designed, built, and
tested to strict physical and electrical standards.
However, it is the user’s responsibility to
install and operate it in conformance with local
pressure and electrical codes. If this equipment
is used in a manner beyond its intended usage,
the protection provided by the equipment may
be impaired.
UNPACK CAREFULLY
Unpack the equipment carefully and check all
the parts against the packing list. If shipping
damage is discovered, report it immediately to
the delivering carriers. Examine the components
closely for any loose parts or shipping damage
and be sure to check all layers of packing
materials thoroughly so as not to overlook any
parts which might otherwise be discarded.
CLEANING AND MAINTENANCE
Wipe exterior surfaces with lightly dampened
cloth containing mild soap solution. The
replacement of protective fuses and backup AA
size, 3.6 V battery for the 4871 Controller are
the only internal maintenance procedures that
should be performed by qualified personnel.
Otherwise, there are no user serviceable parts
inside the Series 4871 Controller. Advanced
troubleshooting instructions can be obtained
by calling the Company
to determine which parts may need to be
replaced or serviced. Proper fuse rating should
be discussed with Company
Technical Support.
INSTALLATION
The 4871 Process Controller requires a suitable
electric outlet and a PC for operation. The
instructions for installing and operating the
software for the 4871 are located on the
USB Flash Drive which accompanied the
controller. On the top level, there will be a file
entitled “readmefirst_4871.htm”.

4871 Process Controller Supplemental Instructions
5
CONTROLLER SETUP
1. Connect Ethernet cable from 4871 to PC
&21),*85$7,21
3257
(7+(51(7
3257
32:(5
,1387
56
3257
2. Identify the 6 digit order/project number on the paperwork.
• The last two digits of the project/order number will identify the IP address of the 4871.
Example: Order/Project Number: 912345 = IP address: 10.1.50.45
3. Install SpecView onto PC.
• A USB Flash Drive is located in the SpecView box that
accompanied the 4871.
• Go to “/SpecView/SV3”
• Run the setup.exe file and install according to instructions.
4. Copy the configuration file to the C:\SV3 folder.
• On the USB Flash Drive, go to “\app_specific\SpecView”
• There is a configuration folder there labeled “4871-912345-rx3”
or something similar.
• Copy this entire folder to “C:\SV3”

4871 Process Controller Supplemental Instructions
6
5. Set up network to communicate with 4871.
• Go to Start > Control Panel > Network and Internet > Network and Sharing Center.
• In the left-hand column, click Change adapter settings. A new screen will open with a list of
network connections.
• Locate the Local Area Connection that is connected to the 4871.
• Right click on this icon and go to Properties.
• Click on “TCP/IPv4” and set the following:
IP address: 10.1.50.##
Note: where “##” must be different than the last two digits of the project/order number
identified in step 2.
• Subnet mask: 255.255.0.0
• Click OK and set changes.
6. Insert SpecView Dongle.
• The SpecView Dongle is located in the SpecView box along with the USB Flash Drive.
• DO NOT LOSE THIS DONGLE! This is the license for the software, and without it SpecView
will be limited to 10-minutes of run time.
• Insert into an open USB slot.
• The driver for the dongle should auto install.

4871 Process Controller Supplemental Instructions
7
7. Open SpecView.
• When SpecView opens, select
“Select/Create Project”.
• The configuration which was copied
in to the C:\SV3 folder in step 4 will
appear.
• Select it and click on “go online”.
8. SpecView main screen
• SpecView should show
the configured screen
with proper values.
It is a good idea to
connect the reactor to
the 4871 at this time to
check readings.
