Parrot Products S100 User manual

User Manual
Tel: (RSA) 010 140 4900 / Email: [email protected]
www.parrot.co.za
Paper Shredder 5 Sheets
6.8mm Strip Cut
- S100

Read instructions before use.
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Do not insert foreign objects into
the paper entry slot.
Do not spray or keep any
aerosol products in or around the
shredder.
Keep loose clothing or jewelry
away from the paper entry slot.
Avoid getting hair near the
paper entry slot.
This shredder does not shred
paper clips.
• Always turn the shredder off and unplug the power cord from the AC outlet when
not in use, before cleaning it, moving it, or emptying the waste basket.
• RISK OF FIRE. Never use any petroleum based or flammable oils or lubricants in or
around the machine, as some oils may combust causing serious injury.
• Never shred large paper clips, window or insulated envelopes, continuous forms, newsprint,
bound pages (e.g: notepads, magazines, etc...), transparencies,
laminated documents, cardboard, any items with adhesives, hard materials or
plastic (except Credit Cards).
• Do not allow wastebasket to become full. This will lead to shredded material being pulled back up into
the shredder and cause paper jams.
• Never place the shredder near water or any heat source.
• Do not use the shredder if the power cord is damaged in any way.
• Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturers warranty.
• Never try to clean or clear the shredder blades.
• Never shred beyond the specified sheet capacity. This may result in extensive damage to the machine.
* ONE FOLDED SHEET OF PAPER EQUATES TO 2 SHEETS OF PAPER
Heavier paper, humidity or other than rated voltage may reduce shredding capacity.
1
Safety Instructions

1. Mount the shredder securely to the rim of the waste basket. (FIGURE 1)
2. A socket-outlet should be near the equipment and be easily accessible.
3. Connect the power cord to any standard 120 volt AC outlet.
Shredders may have very sharp exposed blades on the underside.
Use care when mounting the shredder on the wastebasket.
! Caution:
FIGURE 1
2
Contents
Installation
Security level
Cut size
Cut type
Paper feed width
Shred capacity
Waste basket capacity
7mm
5 sheets
Low Security (P2)
Strip cut
220mm
10 Litres
Speed per minute 3.8m per minute
Continuous run time
Overheat protection
Auto start/stop Yes
Manual forward / reverse Yes
2 minutes
Yes
Dimensions 297 x 145 x 278mm
Shreds credit cards
Shreds cd’s / dvd’s No
No
Castor wheels
No
Specifications
• Installation
• Operation
• Maintenance
• Troubleshooting
Cool down time 45 minutes
Extendable Arm: Extends to 68mm to accommodate shredding over large waste bins

Control Switch
Using the switch located on the unit, select one of the following settings by sliding the switch
either left or right. (FIGURE 2)
AUTO / ON:
This setting allows the shredder to be automatically started by inserting
paper into the feed slot. Always feed the paper in as straight
as possible. When the paper has passed through, the shredder will
automatically stop.
OFF:
This setting turns off all features of the shredder. For safety reasons,
we recommend that you leave the shredder in the “Off” position
whenever the shredder is unattended or not in use.
REV (REVERSE):
In the event of a paper jam, the reverse setting can be used
to help clear the cutters of paper that did not pass through. Never
attempt to clear a jam by using the reverse function until you have
emptied the wastebasket.
FIGURE 2
3
Operation
1
Paper Entry:
Never shred plastic, any hard materials, continuous forms,
newsprint, or anything with adhesives including labels and envelopes.
It is recommended that you remove staples from paper whenever possible
in order to extend the life of your shredder.
Only shred credit cards by feeding them vertically within the designated area.
Never feed more than one credit card at a time.
2
1

4
Maintenance
Warning: Failure to properly maintain your shredder will void the warranty.
Oil the shredder blades every month with basic Parrot Products shredder oil. Follow oiling
procedure below (FIGURE 3). This ensures the cutting blades run smoothly.
Oiling procedure:
1. Turn off shredder.
2. Apply shredder oil across paper entry.
3. Turn shredder in reverse mode for 3~5 seconds.
Note: lubricating oil is NOT included.
• Do not spray or keep any aerosol products
in or around shredder.
• DO NOT USE CANNED AIR ON SHREDDER.
CLEANING:
• ALWAYS UNPLUG THE SHREDDER BEFORE CLEANING!
• Only clean the shredder by carefully wiping the unit with a dry soft cloth or towel.
• Do not clean or immerse shredder in water.
• Never use anything flammable to clean the shredder. This may result in serious injury or
FIGURE 3
DO NOT USE
AEROSOL PRODUCTS!
! Caution:
damage to the product.
S100

5
Troubleshooting
If there is a problem with your shredder, check below for the troubleshooting and steps to resolve. If you
continue to have problems, contact customer support. DO NOT ATTEMPT TO REPAIR BY OPENING
THE SHREDDER HEAD. This will completely void the product warranty.
• The shredder does not work at all.
1) Make sure the unit is plugged in and that the power outlet is in good working order.
2) Overheating with extended use: In the event that the shredder has shred continuously
beyond the maximum running time and overheated, the unit will automatically shut off. If this happens,
switch the shredder Off for 15 minutes or longer before resuming normal operation.
3) If using a plastic bag to line the wastebasket, please remove it. This may cause the shredder not to
operate properly.
4) The activation sensor of the shredder is located near the center of the feed slot. Be sure to feed
directly into the center area to activate the machine (especially applies to smaller pieces of paper
or credit cards).
• The shredder runs in "Rev (Reverse)" mode but not in "Auto (On)" mode.
1) While in "Auto" mode, the motor will not start running until paper is inserted into the feed slot. Set
the unit to "Auto" and insert paper to shred. The sensor that activates the shredder in Auto mode is
located directly in the center of the slot. If the paper you are inserting is narrow, it may not be
activating the sensor. It is also possible that the feed slot has become blocked with paper. Insert an
index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly in the
center of the feed slot, while applying force to help push the jammed paper through. This will usually
clear any paper blockage.
• How to clear a paper jam in the shredder.
1) Switch the shredder over into Reverse (REV) mode. While in Reverse, the shredder will back up and
loosen the jammed paper. If required, you may need to tug and remove several sheets to effectively
clear the machine. When jammed paper is loosened or removed, switch back to the Auto-On mode
to continue shredding. Repeat steps if needed.
2) With stubborn situations where the reverse function does not help, you may loosen the jammed
paper with Parrot Products shredder oil (nothing aerosol). Start by drizzling oil into the
feed slot where the paper is jammed. Let it soak for about 30 minutes to completely saturate. Return
the shredder back to Auto-On mode. If required, an index card or a rigid sheet of cardstock
(old greeting card or folded file folder) can be fed into the shredder to help push the
jammed paper through.

MAINTENANCE
6
Troubleshooting
• The shredder is constantly running while in “Auto (On)” mode.
1) It is possible that the activation sensor, which starts the shredder, has become blocked with paper.
Insert an index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly
in the center of the feed slot, while applying force to help push the jammed paper through. This will
usually clear any paper blocking the activation sensor and feed entry.
Power switch in auto position
Use thick paper stock or greeting card
to push the jam through
