Parsun F9.8BM User manual

OUTBOARD MOTOR
OWNER’S MANUAL
F9.8BM
F8BM
F6BM
SUZHOU PARSUN POWER MACHINE CO., LTD
https://www.boat-manuals.com/

Thank you for owning a PARSUN outboard motor.
Thank you for your trust in our company and products.
“PARSUN” outboard motors are powerful, economic and safe, manufactured with
advanced technology.
Please read this manual carefully before operating your outboard motor. A through
understanding of the manual will help you to know this product for proper operation, maintenance
and care. This will ensure that your outboard motor operates well under all conditions.
“PARSUN” seeks continuous improvement in product quality. Therefore, while this
manual contains the most current product information available at the time of printing, there may
be minor discrepancies between your machine and this manual. If there is any question
concerning the manual, please consult your local PARSUN dealer.
Data, illustrations or explanations in this Owner’s Manual do not constitute base for any
legal claim against our company.
SUZHOU PARSUN POWER MACHINE CO., LTD
https://www.boat-manuals.com/

Engine Identification Numbers
Outboard motor serial number
The outboard motor serial number is marked on the label. The label can be found on the bracket left
assembly or on the upper part of the bracket swivel.
Record your outboard motor serial number in the spaces provided to assist you in ordering spare parts from
your Parsun dealer, or for reference in case your outboard motor is stolen.
1. Outboard motor serial number location
Serial number as follows:
Engine serial number
The engine serial number is carved on the aluminum casting of engine.
Serial number as follows:
SN
1
https://www.boat-manuals.com/

Manufacturer’s Declaration
This outboard motor complies with the requirements of Directive 2003/44/EC in relation to the exhaust and noise
emissions. The following installation and maintenance instructions, if applied, guarantee that the outboard motor
will remain in compliance with:
1. Exhaust emissions limits throughout the normal life or the engine (350 hours or 10 years, whichever occurs first)
and under normal conditions of use.
2. Noise emissions limits under normal conditions of use.
High Altitude Warning
Operation at High Altitude
The density of air at high altitude is lower than at sea level. Engine power is reduced as the air mass and air
fuel ratio decrease. Outboard motor output will be reduced. This is a natural trend and cannot be changed by
adjusting the engine. At sufficiently high altitudes increased exhaust emissions can also result due to the
increased enrichment of the air fuel ratio. Other high altitude issues can include hard starting, increased fuel
consumption and spark plug fouling.
To alleviate high altitude issues other than the natural power loss, dealer can provide a high altitude
carburetor main jet. The alternative main jet and installation instructions can be obtained by contacting
Customer Support.
https://www.boat-manuals.com/

The part number and recommended minimum altitude for the application of the high altitude carburetor main
jet are listed in the table below.
MODEL MAIN JET PART NUMBER ALTITUDE
F6/8 Standard Main Jet H170-1A-S 2000 Feet (609.6 Meters)
Altitude Main Jet H170×1.35
F9.8 Standard Main Jet H170-1A-S 2000 Feet (609.6 Meters)
Altitude Main Jet H170×2.7
Operating the engine with the wrong engine configuration at a given altitude may increase its
emissions and decrease fuel efficiency and performance. When the carburetor has been modified for
high altitude operation, the air-fuel mixture will be too lean for low altitude use. Operation at altitudes
below 609.6 meters (2,000 feet) with a modified carburetor may cause the engine to overheat and
result in serious engine damage. For use at low altitudes, have your dealer return the carburetor to
original factory specifications.
WARNING
https://www.boat-manuals.com/

Table of contents
1. Main components and General information………………………………………………………1
1.1. Main components……………………………………………………………………………………1
1.2. General information…………………………………………………………………………………3
1.2.1. Specification ………………………………………………………………………………………3
1.2.2. Fueling instructions ………………………………………………………………………………4
1.2.3. Propeller selection…………………………………………………………………………………5
2. Operation………………………………………………………………………………………………6
2.1. Installation……………………………………………………………………………………………6
2.1.1 Mounting height……………………………………………………………………………………7
2.1.2 Clamping the outboard motor……………………………………………………………………8
2.2 Breaking in engine …………………………………………………………………………………9
2.3 Pre-operation Checks………………………………………………………………………………10
2.4 Filling fuel……………………………………………………………………………………………11
2.5 Starting engine………………………………………………………………………………………12
2.6 Warming up engine…………………………………………………………………………………16
2.7 Shifting………………………………………………………………………………………………17
2.7.1 Forward……………………………………………………………………………………………17
2.7.2 Reverse……………………………………………………………………………………………18
2.8. Tiller…………………………………………………………………………………………………19
2.9 Stopping engine……………………………………………………………………………………21
2.10 Trimming outboard motor…………………………………………………………………………22
2.11 Tilting up and down………………………………………………………………………………23
2.11.1 Tilting up…………………………………………………………………………………………23
2.11.2 Tilting down ……………………………………………………………………………………25
2.12 Cruising in other conditions ……………………………………………………………………26
2.12.1 Cruising in shallow water ……………………………………………………………………26
2.12.2 Cruising in salt water …………………………………………………………………………26
https://www.boat-manuals.com/

3. Maintenance…………………………………………………………………………………………27
3.1. Greasing……………………………………………………………………………………………27
3.2. Cleaning and adjusting spark plug………………………………………………………………28
3.3. Checking fuel system ……………………………………………………………………………28
3.4. Inspecting idling speed……………………………………………………………………………29
3.5. Changing engine oil………………………………………………………………………………30
3.6. Checking wiring and connectors ………………………………………………………………31
3.7. Checking propeller ………………………………………………………………………………32
3.8.1. Removing the propeller…………………………………………………………………………33
3.8.2. Installing the propeller …………………………………………………………………………33
3.9. Changing gear oil…………………………………………………………………………………33
3.10. Cleaning fuel tank…………………………………………………………………………………35
3.11. Checking and replacing anode(s) ………………………………………………………………35
3.12. Checking top cowling ……………………………………………………………………………36
3.13. Maintenance table…………………………………………………………………………………36
4. Transporting and storing outboard motor…………………………………………………………39
4.1. Transporting…………………………………………………………………………………………39
4.2. Storing………………………………………………………………………………………………40
5. Action in emergency………………………………………………………………………………43
5.1. Impact damage……………………………………………………………………………………43
5.2. Starter will not operate……………………………………………………………………………43
5.3. Treatment of submerged motor…………………………………………………………………45
6. Troubleshooting……………………………………………………………………………………47
7. Circuit diagram……………………………………………………………………………………50
https://www.boat-manuals.com/

1. Main components and General information
1.1 Main components
1. Top cowling
8. Clamp bracket
14. Throttle grip
2. Top cowling lock handle
9. Tiller handle
15. Throttle friction adjuster
3. Anti-cavitation plate
10. Engine stop button/
16. Clamp bolt
4. Propeller
Engine stop lanyard switch
17. Drain screw
5. Cooling water inlet
11. Starter handle
18. Gear shift lever
6. Trim rod
12. Fuel joint
19. Fuel tank
7. Steering friction bolt
13. Warning indicator(s)
1
https://www.boat-manuals.com/

A portable fuel tank includes parts as follows:
1. Fuel tank cap 3. Air vent screw
2. Fuel joint 4. Fuel gauge
WARNING:
The fuel tank supplier with this engine could only be used as supply of fuel for its running
and must not be as a fuel storage container.
2
3
1
2 4
https://www.boat-manuals.com/

1.2 General information
1.2.1Specification
Main technical data
Items
Data
Items
Data
Type of engine
4-stroke L
Transom height
（
S
）
381mm
Displacement
209cm
3
Transom height
（
L
）
508mm
Bore X stroke
55mm
×
44mm
Recommended fuel
Unleaded regular gasoline
Gear ratio
2.08
（
27/13
）
Fuel tank capacity
12L
Overall length
965mm
Recommended engine oil
SAE10W30 orSAE10W40
Overall width
364mm
Engine oil quantity
0.8L
Overall height
（
S
）
1039mm
Recommended gear oil
Hypoid gear oil SAE
﹟
90
Overall height
（
L
）
1166mm
Gear oil quantity
320cm
3
Weight
（
S
）
38Kg
Spark plug
DPR7EA-9
Weight
（
L
）
39.5Kg
Spark plug gap
0.8
～
0.9mm
Performance
Items
data
Items
data
Maximum output
7.2Kw/5500Rpm (9.8HP)
Valve clearance IN(cool engine)
0.13
～
0.17mm
5.9Kw/5500Rpm(8HP) Valve clearance EX(cold engine) 0.18～0.22mm
4.4Kw/5000Rpm(6HP) Tightening
torque for
engine
Spark plug 18.0Nm
Full throttle
operating range
5000
～
6000Rpm (9.8/8HP)
Engine oil drain bolt 28.0Nm
4500
～
5500Rpm(6HP)
Idling speed
(in neutral)
950±50Rpm
3
https://www.boat-manuals.com/

1.2.2 Fueling instruction
Fueling instructions：
Recommended gasoline:
Regular unleaded gasoline, If it is not
available, then premium gasoline.
If knocking or pinging occurs, use a different brand of gasoline or premium unleaded fuel. If leaded gasoline is
usually used, engine valves and related parts should be inspected after every 100 hours of operation.
WARNING:
Do not smoke when refueling, and keep away from sparks, flames, or other sources of
ignition.
Stop engine before refueling.
Refuel in a well-ventilated area; refuel portable fuel tanks off the boat.
Do not overfill the fuel tank.
Take care not to spill gasoline, if gasoline spills, wipe it up immediately.
Tighten the filler cap securely after refueling.
If you should swallow some gasoline, inhale gasoline vapor, or get gasoline in your eye,
get immediate medical attention.
If any gasoline spills onto your skin, immediately wash with soap and water. Change
clothing if gasoline spill s on it.
Touch the fuel nozzle to metal components to prevent electrostatic sparks.
4
https://www.boat-manuals.com/

CAUTION:
Use only new clean gasoline which has been stored in clean containers and is not contaminated with
water or foreign matter.
Engine oil:
Recommended engine oil: 4-stroke outboard motor oil SAE10W30 and SAE10W40 (0.8L)
.
WARNING:
Do not start the engine when the oil level is low. Serious damage might occur.
Always check the oil level before starting the engine.
CAUTION:
All 4-stroke engines are shipped from the factory without engine oil.
1.2.3 Propeller selection
The performance of your outboard motor will be critically affected by your choice of propeller, as an
incorrect choice could adversely affect performance. The outboard motor is fitted with propeller chosen
to perform well over a range of applications, but there may be uses where a propeller with a different
pitch would be more appropriate. PARSUN dealers stock a range of propellers and can advise you
and install a propeller on your outboard that is best suited to your application.
For a greater boat load and a low engine speed, a smaller-pitch propeller is more suitable.
Conversely, a large-pitch propeller is more suitable for a smaller operating load as it enables the correct
engine speed to be maintained.
5
https://www.boat-manuals.com/

2 Operation
2.1 Installation
Mount the outboard motor on the center line (keel line) of the boat. For boats without a keel or which are
asymmetrical, consult your dealer.
1
1. center line (keel line)
NOTE:
During water testing check the buoyancy of the boat, at rest, with its maximum load. Check that the
static water level on the exhaust housing is low enough to prevent water entry into the power head,
when water rises due to waves when the outboard is not running.
WARNING:
Overpowering a boat could cause severe instability. Do not install an outboard motor with more
horsepower than the maximum rating on the capacity plate of the boat. If the boat does not have a
capacity plate, consult the boat manufacturer.
Improper mounting of the outboard motor could result in dangerous conditions and injury. Your dealer
or other person experienced in proper rigging should mount the motor. If you are mounting the motor
yourself, you should be trained by an experienced person.
The information presented in this section is intended as reference only. Proper mounting depends in
part on experience and the specific boat and motor combination.
6
https://www.boat-manuals.com/

(0-1in)
0～25mm
2.1.1 Mounting height
The mounting height of the outboard motor greatly affects your boat running efficiency. If the
mounting height is too high, cavitation tends to occur, thus reducing the propulsion. If the mounting
height is too low, the water resistance will increase and thereby reduce engine efficiency. Mount the
outboard motor so that the anti-cavitation plate is between the bottom of the boat and a level 25mm
below it.
NOTE:
The optimum mounting height of the outboard motor is affected by the boat and motor
combination and the desired use. Test runs at a different height can help determine the optimum
mounting height. For further information, consult your PARSUN
dealer or boat manufacturer.
7
https://www.boat-manuals.com/

2.1.2 Clamping the outboard motor
1. Tighten the transom clamp screw evenly and securely. Occasionally check the clamp screws
for tightness during operation of the outboard motor because they could become loose due to
engine vibration.
CAUTION:
Outboards that use clamp bracket screws alone are INSUFFICIENT to properly and safely
secure the outboard to the Transom. Proper installation of the outboard includes bolting the
engine to the boat through the transom.
WARNING
：
Loose clamp screws could allow the outboard motor to fall off or move on the transom. This
could cause loss of control. Make sure the clamp screws are tightened securely, occasionally
check the screws for tightness during operation.
2. If the engine restraint cable attachment is equipped on your
engine, an engine restraint cable or chain should be used.
Attach to a secure mounting point on the boat to avoid the
engine being completely lost if it accidentally falls off the
transom.
8
https://www.boat-manuals.com/

3. Secure the clamp bracket to the transom using the appropriate bolts. For details, consult your
PARSUN dealer.
WARNING:
Avoid using bolts, nuts or washers inappropriate. After tightening, test run the engine and
check their tightness.
2.2 Breaking in engine
Your new engine requires a period of breaking to allow mating surfaces of moving parts to wear
in evenly.
CAUTION:
Failure to follow the break-in procedure could result in reduced engine life or even severe engine
damage.
1．For the first hour of operation:
Run the engine at 2000r/min or at approximately half throttle.
2．For the second hour of operation:
Run the engine at 3000r/min or at approximately three-quarter throttle.
3．For the next eight hours of operation:
Avoid continuous operation at full throttle for more than five minutes at a time.
4. Operate the engine normally.
9
https://www.boat-manuals.com/

2.3 Pre-operation checks
Fuel
Check to be sure you have plenty of fuel for your trip.
Make sure there are no fuel leaks or gasoline fumes.
Check fuel line connections to be sure they are tight
Be sure the fuel tank is positioned on a secure, flat surface, and that the fuel line is not twisted
or flattened, or likely to contact sharp objects.
Controls
Check throttle, shift and steering for proper operation before starting the engine.
The controls should work smoothly, without binding or unusual free play.
Look for loose or damaged connections.
Check operation of the starter and stop switches when the outboard motor is in the water.
CAUTION:
Do not start the engine out of water. Overheating and serious engine damage can occur.
Check the engine and engine mounting.
Look for loose or damaged fasteners.
Check the propeller for damage.
Checking the engine oil level
1. Put the outboard motor in an upright position (not tilted).
10
https://www.boat-manuals.com/

2. Check the oil level using the dipstick to be sure the level falls between the upper and lower
marks. Fill with oil if it is below the lower mark, or drain to the specified level if it is above the
upper mark.
1．Oil dipstick 3. Lower level mark
2．Upper level mark
CAUTION:
Be sure to completely insert the dipstick into the dipstick guide.
2.4 Filling fuel
WARNING:
Gasoline and its vapors are highly flammable and explosive. Keep away from sparks,
cigarettes, flames, or other sources of ignition.
1. Remove the fuel tank cap.
2. Carefully fill the fuel tank.
11
1
2
3
https://www.boat-manuals.com/

3. Securely close the cap after filling the tank. Wipe up any spilled fuel.
2.5 Starting engine
1. Connect fuel joints securely after loosing the air vent screw on the fuel tank cap (2 or 3 turns).
2. Connect fuel joints securely and squeeze the primer pump with the outlet end up until you feel it
becomes firm .
12
https://www.boat-manuals.com/

3. Place the gear shift lever in neutral.
NOTE:
The start-in-gear protection device prevents the engine from starting except when in neutral.
Attach the engine stop switch lanyard to secure place on your clothing, or your arm or leg. Then
install the lock plate on the other end of the lanyard into the engine stop switch.
WARNING:
The engine must be started in neutral, otherwise damage to the engine can occur.
Do not attach the lanyard to clothing that could tear loose. Do not route the lanyard
where it could become entangled and preventing it from
functioning.
Avoid accidentally pulling the lanyard during normal
operation. Loss of engine power means the loss of
steering control. Also, without engine power, the boat
could slow rapidly. This could cause people and objects
in the boat to be thrown forward.
13
https://www.boat-manuals.com/
