PASCO PS-3224 Guide




PASCO Form Number Description Date Revision
013-17362 PS-3224 Battery Replacement Instructions 05-05-22 Page 1 of 6 A

PS‐3224:WirelessODOBatteryReplacementInstructions
Reference:Batterypartnumber540‐113;Li‐Poly1000mAH
RecommendedEquipment:(PS‐3299;BatteryReplacementToolSet)

Step1:Unscrewthetopclearplastictopandsetaside.








PASCO Form Number Description Date Revision
013-17362 PS-3224 Battery Replacement Instructions 05-05-22 Page 2 of 6 A

Step2:LocateandremovetheQty=2TorxT5Screws.

 
Step3:Whileholdingthetopandthebottomshaft,wigglethetwohalvesapartasshown.







PASCO Form Number Description Date Revision
013-17362 PS-3224 Battery Replacement Instructions 05-05-22 Page 3 of 6 A

Step4:Unplugthetwoconnectorstoaccessthebatterycompartment.


Step5:Unscrewtheqty=2T5Torxbatterystrapscrewswhereshown,andremovethe
batterystrap.Removethebatteryandreplacewiththenewbattery.StartReversingthe
assemblystepsperinstructionsbelow.











PASCO Form Number Description Date Revision
013-17362 PS-3224 Battery Replacement Instructions 05-05-22 Page 4 of 6 A

Step6:Securethebatterystrapandplugintheconnectorsasshown.



Step7:Thetwohalvesarekeyed,andthus,youcanvisuallyalignthekeysandpressdown
firmlytobottomouttheassemblyandaddthemountingscrews.







PASCO Form Number Description Date Revision
013-17362 PS-3224 Battery Replacement Instructions 05-05-22 Page 5 of 6 A

Step7b :Alternatively,youcanlineuptheassemblyperthebelowinstructions.



Complete








PASCO Form Number Description Date Revision
013-17362 PS-3224 Battery Replacement Instructions 05-05-22 Page 6 of 6 A

Step8:Screwintheclearplastictopanddisposeoftheoldbatteryproperlyperthe
instructions.




Ifyouneedfurtherassistance,pleasecontactTechnicalSupportat[email protected]or
throughwww.pasco.comonchat.Toaccesschatthroughyourbrowser,pleaseenableall
cookiesonourwebsite.
