PASCO PS-3214 User manual

012-16026A [email protected] | 1|
PASCO Wireless Drop Counter PS-3214 www.pasco.com - (800) 772-8700
Software: SPARKvue or PASCO Capstone
Power: Rechargeable Battery
Connection: or USB
Connection: or USB
012-16026A [email protected] | 1|
Software: SPARKvue or PASCO Capstone
Power: Rechargeable Battery
PASCO Wireless Drop Counter PS-3214 www.pasco.com - (800) 772-8700
INITIAL STEP - Charge it: On the bottom of the sensor, pry open the
rubber cover to reveal the Micro USB Port. Use the included micro
USB cable to connect the sensor to a USB port or a USB charger (such
as PS-2575). If the cable is connected to a USB port, the Battery LED
shines yellow to show that the battery is charging. When the battery
is charged, the Battery LED shines green. If the cable is connected to
a USB charger, the Battery LED shines yellow and the Bluetooth sta-
tus LED blinks red to indicate that the sensor is ready to connect to a
device (such as a computer or tablet).
1. Make the Connection: Start the PASCO data collection software.
• For USB connection to a USB port: Make sure the USB cable is
connected. In SPARKvue: Click or Touch the “Sensor Data” icon in
the Welcome Screen. In PASCO Capstone, select ‘Hardware Setup”
and check that the sensor appears in the “Hardware Setup” window.
• For Bluetooth connection: If the sensor is not already on, press
the ON button at the top of the sensor to turn it on. (NOTE: The following procedure also works if the sensor is connected to a USB charger.) In
SPARKvue: Touch or Click the Sensor Data icon in the Welcome Screen. In the “Connected Devices” list, select the correct address that matches
the XXX-XXX Device ID number found on the sensor. Select a measurement, and then select a “Template” to open a data display. In PASCO
Capstone, select “Hardware Setup” in the “Tools” palette. Select the desired sensor type that matches the Device ID XXX-XXX number on the
sensor. Close the “Hardware Setup” window.
2. Set Up the Sensor: Arrange the sensor with the included syringe holder, syringe, and drop dispenser so that drops will pass through the Drop
Window into a receptacle below.
3. Collect Data: In SPARKvue, Select the “Start” button. In PASCO Capstone: Select a display, set up the measurement in the display, and select
“Record”. 4. Analyze the Data: Use the PASCO Data Collection software (SPARKvue or Capstone) to interpret the data.
Battery LED
Micro
USB
Cable
Charging Time:
About 3 hours
Top view
For Temperature Sensor
For pH Sensor
Bluetooth LED
Drop Indicator LED
Drop Window
Device ID
For Support
Rod
ON/OFF
USB Port Cover on
the Bottom of the
Sensor
INITIAL STEP - Charge it: On the bottom of the sensor, pry open the
rubber cover to reveal the Micro USB Port. Use the included micro
USB cable to connect the sensor to a USB port or a USB charger (such
as PS-2575). If the cable is connected to a USB port, the Battery LED
shines yellow to show that the battery is charging. When the battery
is charged, the Battery LED shines green. If the cable is connected to
a USB charger, the Battery LED shines yellow and the Bluetooth sta-
tus LED blinks red to indicate that the sensor is ready to connect to a
device (such as a computer or tablet).
1. Make the Connection: Start the PASCO data collection software.
• For USB connection to a USB port: Make sure the USB cable is
connected. In SPARKvue: Click or Touch the “Sensor Data” icon in
the Welcome Screen. In PASCO Capstone, select ‘Hardware Setup”
and check that the sensor appears in the “Hardware Setup” window.
• For Bluetooth connection: If the sensor is not already on, press
the ON button at the top of the sensor to turn it on. (NOTE: The following procedure also works if the sensor is connected to a USB charger.) In
SPARKvue: Touch or Click the Sensor Data icon in the Welcome Screen. In the “Connected Devices”list, select the correct address that matches
the XXX-XXX Device ID number found on the sensor. Select a measurement, and then select a “Template” to open a data display. In PASCO
Capstone, select “Hardware Setup” in the “Tools” palette. Select the desired sensor type that matches the Device ID XXX-XXX number on the
sensor. Close the “Hardware Setup”window.
2. Set Up the Sensor: Arrange the sensor with the included syringe holder, syringe, and drop dispenser so that drops will pass through the Drop
Window into a receptacle below.
3. Collect Data: In SPARKvue, Select the “Start” button. In PASCO Capstone: Select a display, set up the measurement in the display, and select
“Record”. 4. Analyze the Data: Use the PASCO Data Collection software (SPARKvue or Capstone) to interpret the data.
Battery LED
Micro
USB
Cable
Charging Time:
About 3 hours
Top view
For Temperature Sensor
For pH Sensor
Bluetooth LED
Drop Indicator LED
Drop Window
Device ID
For Support
Rod
ON/OFF
USB Port Cover on
the Bottom of the
Sensor
012-16026A support@pasco.com | 2|
012-16026A [email protected] | 2|
Features: The Wireless Drop Counter Sensor measures the number of drops of fluid that fall through the Drop Window. It is typically used in con-
junction with a pH Sensor and other equipment to perform a titration. The Wireless Drop Counter includes a 60 cc syringe, a syringe holder, two
stopcock valves, a drip tip, and a micro stir bar. The Sensor can be mounted on a support rod and includes two probe holders for a Temperature
Sensor and a pH Sensor.
USB connection to USB port:Bluetooth ( ) connection USB connection to USB charger:
More Information: Wireless Drop Counter Sensor Reference Guide: For more information about the
sensor, go to the PASCO Web site at www.pasco.com/manuals. Enter PS-3214 under “Enter Product Num-
ber*” and select “Submit”. The Reference Guide is a complete, multi-page users manual to download in
PDF format. (Contact Technical Support for a printed copy of the document).
Calibration: For calibration information, go to www.PASCO.com/calibration
The Wireless Drop Counter Sensor is designed by PASCO in California. It is assembled in China.
For Technical Support
FCC Statement: This digital device complies with part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Battery: If the Battery status LED blinks red, connect the sensor to a USB port or charger with the micro USB
cable.
Battery Status Status Battery Status Status Battery Status
OFF Y ON Charging R blink Ready to pair R blink Low power R blink Ready to pair Y ON Charging
G ON Charged G blink Connected G blink Connected G ON Charged
Phone: +1 916 462 8384 or 800-772-8700 (U.S.)
Web www.pasco.com/support
Syringe
Holder
Syringe
Stopcock
Valves
Drip Tip
Features: The Wireless Drop Counter Sensor measures the number of drops of fluid that fall through the Drop Window. It is typically used in con-
junction with a pH Sensor and other equipment to perform a titration. The Wireless Drop Counter includes a 60 cc syringe, a syringe holder, two
stopcock valves, a drip tip, and a micro stir bar. The Sensor can be mounted on a support rod and includes two probe holders for a Temperature
Sensor and a pH Sensor.
USB connection to USB port:Bluetooth ( ) connection USB connection to USB charger:
More Information: Wireless Drop Counter Sensor Reference Guide: For more information about the
sensor, go to the PASCO Web site at www.pasco.com/manuals. Enter PS-3214 under “Enter Product Num-
ber*” and select “Submit”. The Reference Guide is a complete, multi-page users manual to download in
PDF format. (Contact Technical Support for a printed copy of the document).
Calibration: For calibration information, go to www.PASCO.com/calibration
The Wireless Drop Counter Sensor is designed by PASCO in California. It is assembled in China.
For Technical Support
FCC Statement: This digital device complies with part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Battery: If the Battery status LED blinks red, connect the sensor to a USB port or charger with the micro USB
cable.
Battery Status Status Battery Status Status Battery Status
OFF Y ON Charging R blink Ready to pair R blink Low power R blink Ready to pair Y ON Charging
G ON Charged G blink Connected G blink Connected G ON Charged
Phone: +1 916 462 8384 or 800-772-8700 (U.S.)
Web www.pasco.com/support
Syringe
Holder
Syringe
Stopcock
Valves
Drip Tip
