patioSchwank electricSchwank Series User manual

SAVE THIS MANUAL FOR FUTURE REFERENCE
Page
Warnings - IMPORTANT - Read First 2
Installation Instructions 3
Specications 3
Wiring Instructions 3
Mounting Instructions 4
Replacement Element Installation 5
Replacement Parts 5
Heater Coverage Areas 6
General Notes 6
Maintenance Instructions 6
Troubleshooting 7
Location Suggestions 7
Warranty 8
For warranty purposes and ordering replacement parts, record the following information:
Model #: _________________________________________ Serial #: ____________________________________________
Date of Purchase: _________________________________ Purchased From: _____________________________________
patioSchwank
electricSchwank Series EL/ELD Series
QUARTZ ELECTRIC INFRARED RADIANT HEATER
For Indoor/Outdoor Use: Patios, Spectator Venues, Commercial/Industrial Spaces
INSTALLATION MANUAL
Electric I&O Manual IM111116 RL:2A AUG 2018

Electric I&O Manual IM111116 RL:2A AUG 2018
2
MOUNTING HEIGHT/CLEARANCES
READ ALL INSTRUCTIONS BEFORE USING HEATER
Unit may be a source of possible shock. NEVER attempt to service heater without disconnecting its power source.
Source of possible ignition - maintain clearances from combustible materials.
WARNING: If not installed, operated and maintained in accordance with the manufacturer’s instructions, this
product can expose you to chemicals including nickel, which are known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov.
High Temperature, risk of re, keep electrical cords, drapery, furnishings and other combustibles at least 3' [0.9m]
from the front of heater and away from sides and rear.
▪ Wall-Mounting: Do not install heater closer than 18" [45.7 cm] from adjacent walls and 6" [15.2 cm] from ceiling
and do not install less than 8' [2.4 m] from oor.
▪Ceiling-Mounting: Do not install heater closer than 18" [45.7 cm] from adjacent walls and 6" [15.2 cm] from
ceiling and do not install less than 8' [2.4 m] from oor.
- For heater angled greater than 30° from horizontal, use spacers above mounting brackets to provide
minimum 6” [15.2 cm] clearance above heater to combustible ceiling.
▪ Adjacent Heaters to be installed no less than 3' [0.9 m] apart.
▪ Do NOT operate within 25' [7.6 m] of ammable/explosive material.
▪Never block heater.
▪ Heaters greater than 240 Volts are for “Commercial Use Only. Risk of re. Do not use as a residential or
household heater.”
▪A means for disconnection of the appliance must be incorporated in accordance with local wiring codes.
▪Do not use if the heating element is damaged or cracked.
“IMPORTANT INSTRUCTIONS”
“SAVE THESE INSTRUCTIONS”
CLEARANCE FROM HEATER SURFACES TO COMBUSTIBLES:
WARNINGS
CAUTION
MIN. 6" [15.2 CM]
CLEARANCE
BEHIND HEATER
MIN. 18" [45.7 CM]
FROM SIDES AND
ENDS OF HEATER
MIN. 36" [91.4 CM]
FRONT / BELOW
HEATER

Electric I&O Manual IM111116 RL:2A AUG 2018
INSTALLATION INSTRUCTIONS
SPECIFICATIONS
This heater must be permanently installed and hard wired by a licensed electrician in accordance with local
electrical codes. Assembly procedure must be performed with no electrical power to unit.
Step 1: Check UL/CUL/CE rating label on heater for proper voltage.
Step 2: Follow supplied wiring instructions. [See wiring instructions below]
Step 3: Heater must be mounted with reector angled down [maximum 60° from horizontal].
Step 4: All electrical connections must be in compliance with the National Electric Code [NEC] and local codes
for outdoor wiring.
Step 5: Use only wiring components UL/CUL/CE listed for outdoor use with IPX4 minimum rating.
3
WIRING INSTRUCTIONS
The heater is drilled and threaded for standard 1/2" conduit ttings. The installing electrician will need to provide
the appropriate rigid metallic, exible or liquid tight conduit for the installation location.
▪Observe local electrical code regulations.
▪ Remove cover plate from junction box.
▪Attach conduit.
▪ Use only copper wire suitable for 90°C.
▪Replace cover plate.
TYPICAL WIRING OPTIONS
TYPICAL 120V
WIRING
FOR A SINGLE
POLE SWITCH
TYPICAL 240V
WIRING FOR
A TWO POLE
SWITCH
WIRING FOR OPTIONAL 120V/240V
CONTROLS
Connect power with exible
conduit or appropriate cord to
allow heater to be swiveled.
Junction Box on top of the heater has a gasket side access cover.
The Junction Box inlet hole is sized for
a standard ½"weather tight conduit
tting and has a locknut located on the
inside of the box for fastening.
GREEN GROUND
WIRE SCREW HEATING ELEMENT
OFF
ON
OFF
ON
HEATER
TOP
P L1 L2
H2H1
HEATER
FOR 115V. PILOT
LIGHT IF USED
11/32" (0.9 CM) INSIDE NUT
SNUG TO CERAMIC
11/32" (0.9 CM) OUTSIDE NUT
REAR VIEW OF
CONTROLLER FOR
MAX. 15 AMP
LOAD ONLY
"TOP" MARKED ON
REAR OF CONTROL
MUST BE INSTALLED
IN AN UP POSITION
240 V.
240 V.
WHITE
BLACK 115 V.
MODEL WATTS LENGTH VOLTS/AMPS PHASE SHIPWGT. [lb/kg]
ES/EL-519 500 19.5" 120 / 4.2 Single 10 / 4.5
ES/EL-719 750 19.5" 120 / 6.3 Single 10 / 4.5
ES/EL-1033 1000 33" 120 / 8.3 Single 12 / 5.4
ES/EL-1533 1500 33" 120 / 12.5 208 / 7 240 / 6.3 Single 12 / 5.4
ES/EL-2039 2000 39" 208 / 10 240 / 8.3 277 / 7 480 / 4 Single 13 / 5.9
ES/EL-2539 2500 39" 208 / 12 240 / 10.4 277 / 9 480 / 5 Single 13 / 5.9
ESD/ELD-3033 3000 33" 208 / 14 240 / 12.5 277 / 11 480 / 6 Single 13 / 5.9
ES/EL-3061 3000 61.25" 208 / 14 240 / 12.5 277 / 11 480 / 6 Single 20 / 9.1
ESD/ELD-4039 4000 39" 208 / 19 240 / 16.7 277 / 14 480 / 8.3 Single 14 / 6.4
ES/EL-4061 4000 61.25" 208 / 19 240 / 16.7 277 / 14 480 / 8.3 Single 20 / 9.1
ESD/ELD-5039 5000 39" 208 / 24 240 / 20.8 277 / 18 480 / 10.4 Single 14 / 6.4
ESD/ELD-6061 6000 61.25" 208 / 28.8 240 / 25 277 / 21.7 480 / 12.5 Single 21 / 9.5

Electric I&O Manual IM111116 RL:2A AUG 2018
MINIMUM
18"
[45.7 CM]
FROM
SIDE
MINIMUM
18"
[45.7 CM]
FROM SIDE
96" [244 CM] MINIMUM
HEIGHT FROM FLOOR
6-3/8" [15.2 CM]
LEVEL HERE
4
MOUNTING INSTRUCTIONS
Heater must be installed with the Quartz horizontally level. For maximum tube life, use a carpenter’s level tool to
nd the optimum level position for the heater’s body. Always maintain the minimum clearances from the heater
body to any combustible materials.
6"
[15.2 CM]
3" [7.6 CM]
8-3/16"
[20.2 CM]
9-3/8" [23.8 CM]
5-3/8"
[13.6 CM]
SWIVEL MOUNTING
BRACKETS [CEILING
OR WALL MOUNT]
LENGTH VARIES
BY MODEL
INSULATED HOUSING
These models may be chain or bracket mounted to any ceiling or horizontal surface. Installation must be such that
18" [45.7 cm] minimum clearance is maintained around the heater on all 4 sides and 36" [91.4 cm] directly in front/
below. Aminimum of 6" [15.24 cm] of clearance provided by mounting brackets is required behind the plane of the
face. Heater can be hung using chains or custom brackets. Heater must be level along length, but can be rotated
around its horizontal axis.
Electric I&O Manual IM111116 RL:1B May 2017
MINIMUM
18"
[45.7 cm]
FROM
SIDE
MINIMUM
18"
[45.7 cm]
FROM SIDE
96" [244 cm] MINIMUM
HEIGHT FROM FLOOR
6-3/8" [15.2 cm]
LEVEL HERE
4
WALL
60º MAX.
AIM POINT
CEILING
60º MAX.
MOUNTING INSTRUCTIONS
Heater must be installed with the Quartz horizontally level. For maximum tube life, use a carpenter’s level tool to
find the optimum level position for the heater’s body. Always maintain the minimum clearances from the heater
body to any combustible materials.
6"
[15.2 cm]
3" [7.6 cm]
8-3/16"
[20.2 cm]
9-3/8" [23.8 cm]
5-3/8"
[13.6 cm]
SWIVEL MOUNTING
BRACKETS [CEILING
OR WALL MOUNT]
LENGTH VARIES
BY MODEL
INSULATED HOUSING
These models may be chain or bracket mounted to any ceiling or horizontal surface. Installation must be such
that 18" [45.7 cm] minimum clearance is maintained around the heater on all 4 sides and 36" [91.4 cm] directly
in front/below. A minimum of 6" [15.24 cm] of clearance provided by mounting brackets is required behind the
plane of the face. Heater can be hung using chains or custom brackets. Heater must be level along length, but
can be rotated around its horizontal axis.
6”
[15.2 cm]
MINIMUM
6”
[15.2 cm]
MINIMUM
HEATER ANGLE GREATER THAN 30°:
SPACERS REQUIRED ABOVE BRACKETS
TO PROVIDE 6” [15.2 cm] CLEARANCE
ABOVE HEATER.
ENSURE STRENGTH AND INTEGRITY
OF MOUNTING

Electric I&O Manual IM111116 RL:2A AUG 2018 5
REPLACEMENT ELEMENT INSTALLATION
11/32" OUTSIDE NUT
11/32" INSIDE NUT: SNUG TO CERAMIC;
HOLD FIRMLY TO TIGHTEN OUTSIDE NUT
Consult the
label on back of
heater for proper
watts, voltage,
and replacement
element part
number.
Need help?
To order
replacement
elements for your
heating system,
please contact us
via phone or visit
our website.
REPLACEMENT ELEMENTS [277 & 480 VOLTAGES ALSO AVAILABLE]
PART NUMBER LENGTH WATTS VOLTS FITS
JE-0550-12 16.5" [0.4 m] 500 120 ES-0519-12, EL-0519-12
JE-0551-12 16.5" [0.4 m] 750 120 ES-0719-12, EL-0719-12
JE-0552-12 30" [0.8 m] 1000 120 ES-1033-12, EL-1033-12
JE-0553-12 30" [0.8 m] 1500 120 ES-1533-12, EL-1533-12
JE-0554-20 16-1/2" [0.4 m] 2000 208 ES-2039-20, ES-4039-20/EL-2039-20, EL-4039-20
JE-0555-20 30" [0.8 m] 2500 208 ES-2539-20, ES-5039-20/EL-2539-20, EL-5039-20
JE-0556-20 30" [0.8 m] 3000 208 ES-3061-20, ES-6061-20/EL-3061-20, EL-6061-20
JE-0557-20 36" [0.9 m] 4000 208 ES-4061-20/EL-4061-20
JE-0554-24 36" [0.9 m] 2000 240 ES-2039-24, ES-4039-24/EL-2039-24, EL-4039-24
JE-0555-24 58" [1.5 m] 2500 240 ES-2539-24, ES-5039-24/EL-2539-24, EL-5039-24
JE-0556-24 58" [1.5 m] 3000 240 ES-3061-24, ES-6061-24/EL-3061-24, EL-6061-24
JE-0557-24 58" [1.5 m] 4000 240 ES-4061-24/EL-4061-24
REPLACEMENT PARTS
PART NUMBER PART DESCRIPTION QUANTITY
JE-0570-XX Single Element End Reector [Set of 2] 1
JE-0571-XX Dual Element End Reector [Set of 2] 1
JE-0573-XX, JE-0574-XX, JE-0575-XX Body Reector – Fits 33" [0.8 m], 39" [1.0 m], 61-1/4" [1.6 m] 1
JE-0577-XX, JE-0578-XX, JE-0579-XX Grill Guard – Fits 33" [0.8 m], 39" [1.0 m], 61-1/4" [1.6 m] 1
JE-0581-XX, JE-0582-XX, JE-0583-XX Lead Wire Set – Fits 33" [0.8 m], 39" [1.0 m], 61-1/4" [1.6 m]* 1
JE-0585-XX Stainless Steel Mounting Bracket [Set of 2] 1
* Note: Dual Element Heaters require 2 Lead Wire Sets per Heater
Disconnect the power at the breaker. Remove the grill by grasping it in the middle, ex grill up and lift it off.
Unscrew and remove both end reectors. Unhook element clips at each end of the heater and remove nuts from
end of element to remove the existing Quartz. Carefully install the new element. Remove one nut from end of the
new element. Install wire by sliding high temperature ring terminal onto element screw and replace nut. Use a thin
11/32" wrench to hold inside nut. Nuts must make a tight connection. Close element clips over tube, reinstall end
reectors, then snap protective grill back in place.
NOTE: Hold ceramic element rmly while
tightening nut to prevent damage to element.
Nut should be tightened snug. A loose
connection can cause the element to short
or fail prematurely.

Electric I&O Manual IM111116 RL:2A AUG 2018
6
PART NUMBER WATTS MOUNTING HEIGHT AVERAGE COLD PROTECTED
ESD/ELD-4039-24 4,000 8' - 12' [2.4 m - 3.7 m] 8' x 10' [2.4 m x 3.0 m] 6' x 8' [1.8 m x 2.4 m] 10' x 12' [3.0 m x 3.7 m]
ESD/ELD-5039-24 5,000 8' - 12' [2.4 m - 3.7 m] 9' x 10' [2.7 m x 3.0 m] 7' x 8' [2.1 m x 2.4 m] 11' x 12' [3.4 m x 3.7 m]
ESD/ELD-6061-24 6,000 10' - 14' [3.0 m - 4.3 m] 11' x 11' [3.4 m x 3.4 m] 10' x 10' [3.0 m x 3.0 m] 12' x 12' [3.7 m x 3.7 m]
DUAL ELEMENT TYPICAL AREA COVERAGE - feet [m]
SINGLE ELEMENT TYPICAL AREA COVERAGE - feet [m]
PART NUMBER WATTS MOUNTING HEIGHT AVERAGE COLD PROTECTED
ES/EL-1533-20 1,500 6' - 8' [1.8 m - 2.4 m] 5' x 5' [1.5 m x 1.5 m] 3' x 3' [.91 m x .91 m] 7' x 7' [2.1 m x 2.1 m]
ES/EL-2039-24 2,000 7' - 9' [2.1 m - 2.7 m] 6' x 6' [1.8 m x 1.8 m] 4' x 4' [1.2 m x 1.2 m] 8' x 8' [2.4 m x 2.4 m]
ES/EL-2539-24 2,500 7' - 9' [2.1 m - 2.7 m] 7' x 7' [2.1 m x 2.1 m] 5' x 5' [1.5 m x 1.5 m] 9' x 9' [2.7 m x 2.7 m]
ES/EL-3061-24 3,000 7' - 9' [2.1 m - 2.7 m] 8' x 8' [2.4 m x 2.4 m] 6' x 6' [1.8 m x 1.8 m] 10' x 10' [3.0 m x 3.0 m]
ES/EL-4061-24 4,000 8' - 11' [2.4 m - 3.4 m] 10' x 10' [3.0 m x 3.0 m] 8' x 8' [2.4 m x 2.4 m] 12' x 12' [3.7 m x 3.7 m]
GENERAL NOTES
electricSchwank [ES/ESD] and EL/ELD Series heaters are furnished with wall/ceiling mount swivel brackets.
These brackets may be discarded when the heater is suspended with chains, or other special bracketing.
See 'Specications' page 2 for full listing of models, voltages, and amperages. At times, especially when the
mounting height might be quite low, a greater quantity of smaller heaters can help prevent overheating.
Heaters up to 15 AMPS can be controlled with a simple INF controller. This low cost controller, which is actually
an innite switch, gently pulses the heat on and off at regular intervals when not on full power.
Dual Element Heaters can be wired with Duplex/Stack Switch, which enables the ability to operate each element
independently, providing for two-stage [half power/full power] capability.
For best comfort heat, heat from two sides rather than from just one side. However, there are site conditions where
this is not practical.
Coverage areas indicated above are typical approximate dimensions and will vary depending on outdoor
temperature, wind velocity, and personal comfort levels.
Indoor and well-protected environments will generally exceed the average chart values. Heaters will provide less
than average coverage in extremely cold/windy conditions.
MAINTENANCE INSTRUCTIONS
Before performing any maintenance or cleaning, power must be disconnected and the heater cool to touch.
Heater housing, reectors, and heating element can be rinsed with a hose or wiped down with isopropyl
alcohol, acetone, or glass cleaner. Use a clean, scratch-free rag or paper towel. Any oxidation, surface rust, or
discoloration can be removed with a stainless steel cleaner or metal polish on the bare metal surface.
Make sure all water, solvents, or cleaners are removed and the heater is dry before reconnecting the power.

Electric I&O Manual IM111116 RL:2A AUG 2018 7
PROBLEM
Heater does not glow
Low heat output
Heater does not work
WHAT TO DO
TROUBLESHOOTING
Unless heaters are installed over 12' [3.7 m] high, it is generally recommended that all radiant heaters be mounted
on an angle to assure that radiant warmth is distributed from the sides rather than straight down on the heads and
shoulders of the people being warmed.
Install xture to heat the area from the “cold side” if possible.
This helps compensate for increased body heat losses due
to exposure. Warm oors reradiate heat. Warmer air rises
from oor. Some heat reects from oor. Mounting a heater
directly over a table or other
obstruction will block the
energy, primarily heating
the object. It is best to move
heater to the side, allowing
complete body and oor
coverage.
When outdoors, hang heater under protective roof or weather cover whenever
possible. Even though heater is all-weather construction, it will last longer and look
better if it is protected from rain and snow.
Angle xture 30º to 60º from horizontal face
down. Best angle is approximately 45º.
LOCATION SUGGESTIONS
OUTDOORS
INSTALLATION DIRECTIONRECOMMENDED POSITIONING
▪Check supply voltage to conrm it matches voltage of heating element.
▪A 240V element connected to 110V or 208V will warm, but not glow orange
or generate sufcient heat for typical applications [Matching your voltage is
extremely important]. If element is visibly orange, but there is insufcient
heat, refer to the areas covered with respect to conditions and mounting heights.
▪Replace or clean dirty or non reective reectors.
▪Disconnect power and check element with ohm meter for continuity. If there is
any continuity across the bulb, the problem is in the wiring/controls.
▪Check that there is proper voltage to the heater.
▪Check that the control/switch is working.
▪Check main power circuit breaker.
▪Check wiring for a loose connection or burned wire.

Electric I&O Manual IM111116 RL:2A AUG 2018
LIMITED PRODUCT WARRANTY
USA: 2 Schwank Way, Waynesboro, GA 30830
CANADA: 5285 Bradco Blvd., Mississauga, ON L4W 2A6
TEL [phone] FAX [phone]
patioSchwank
www.patioSchwank.com www.Infrasave.com
Important: Please retain original proof of purchase to establish warranty period.
electricSchwank and EL/ELD Series Electric Powered Radiant Heaters:
The Manufacturer warrants that this product is free from defects in material or workmanship under normal use and
service subject to the terms of this document.
TWO YEAR WARRANTY
Subject to the conditions and limitations stated herein, during the term of this limited warranty, we will supply any
component part (at our option a new or repaired component part) of the heater as dened below, excluding any labor,
which the Manufacturer’s examination determines to be defective in workmanship or material for a period of two years
(2 years) from the date of installation, unless otherwise specied below. This warranty applies to the heater’s original
own-er, and subsequent transferees and only if the unit is installed and operated in accordance with the printed
instructions accompanying the unit and in compliance with all applicable installation codes and good trade practices.
WHAT IS NOT COVERED
The Manufacturer shall not be responsible for any expenses, including service, labor, diagnosis, analysis, material or
transportation charges incurred during removal or reinstallation of this product, or any of its components or parts. All
labor or service charges shall be paid by the owner. This warranty does not cover heating products improperly installed,
misused, exposed to or damaged by negligence, accident, corrosive or contaminating atmosphere, water, excessive
thermal shock, impact, abrasion, normal wear due to use, alteration or operation contrary to the owner’s manual or if
the serial number has been altered, defaced or removed. This warranty shall not apply if the input to the heating product
varies by more than 10% of the rated input on the rating plate. The Manufacturer shall not be liable for any default or
delay in performance by its warranty caused by any contingency beyond its control, including war, government restrictions
or restraints, strikes, re, ood, acts of God, or short / reduced supply of raw materials or products.
WARRANTY PROCEDURE
To establish the installation date for any purpose under this Limited Warranty, you must retain the original records
that can establish the installation date of your unit. If you do not provide such documents, the start date of the term
of this Limited Warranty will be based upon the date of unit manufacture, plus thirty (30) days. Failure to maintain the
equipment through regular annual service maintenance by a qualied service technician shall void the warranty.
LIMITATIONS AND EXCLUSIONS
This document contains all warranties made by the Manufacturer and may not be varied, altered or extended by any
person. There are no promises, or agreements extending from the Manufacture other than the statements contained
herein. THIS WARRANTY IS IN LIEU OF ALL WARRANTIES EXPRESSED OR IMPLIED, TO THE EXTENT
AUTHORIZED BY THE LAWS OF THE JURISDICTION, INCLUDING SPECIFICALLY THE WARRANTIES OR
MERCHANTIBILITY OF FITNESS FOR A PARTICULAR PURPOSE.
It is understood and agreed that the Manufacturer’s obligation hereunder is limited to repairing or replacing parts
determined to be defective as stated above. In no event shall the Manufacturer be responsible for any alleged personal
injuries or other special, incidental or consequential damages. As to property damages, contract, tort or other claim the
Manufacturer’s responsibility shall not exceed the purchase priced paid for the product. All replacement parts will be
warranted for the unused portion of the warranty coverage period remaining on the applicable unit.
Some Authorities do not allow certain warranty exclusions or limitations on duration of warranty or the exclusions or
limitations of incidental or consequential damages. In such cases, the above limitations or exclusions may not apply to
you and are not intended to do so where prohibited by law. This warranty gives you specic legal rights. You may also
have other rights which vary by jurisdiction.
8
