Rossofuoco RUBINO Operating instructions
user and maintenance manual
Rev. no. 02 - 25/03/2018
OUTDOOR WOOD PELLET
PATIO HEATERS
Warnings and Manual Keeping pag. 01
Safety pag. 02
Design Description pag. 04
Positioning and Transport pag, 04
Assembly and Installation pag. 05
Functioning of the Heater pag. 08
Initial Operation pag. 08
How to load, re up, unload and reload the Heater pag. 09
Cleaning and Maintenance pag. 11
Operational Problems pag. 12
Technical Data pag. 13
Declaration of Conformity and Applicable Legislation pag. 14
Warranty Card pag. 15
TABLE OF CONTENTS
This manual provides information on transport, installation, correct use and
maintenance of the pyrolytic heater. It is aimed at persons involved in the installation,
use and maintenance of the equipment.
Before carrying out any operation, please read carefully these instructions.
In case of doubts about the correct interpretation of these instructions, contact the
manufacturer or the reseller to obtain the clarications needed.
It is forbidden to carry out any operation without having read and understood the
content of this manual.
Non-compliance, even partially, of the recommendations contained in this handbook
may lead to dangers for the user and possible damage to the equipment.
The manufacturer is not liable for damages or injury resulting from failure to observe
this prohibition.
WARNINGS
This manual is an integral part of the product.
It must always accompany the heater even in case of transfer to other persons.
This document should always be available for sta enabled to install, use and perform
the maintenance of the heater.
It must be kept within reach of the heater.
The document must be preserved in good conditions and easily readable during the
lifetime of the heater.
Consequently:
• keep this manual in a place protected from heat and moisture, away from liquids;
• Use the document without damaging it;
• Do not tear the pages and do not modify the contents of this manual.
In the event that this handbook has damages that may impair its legibility, or is lost,
you will immediately request a replacement copy from the manufacturer or from the
reseller.
MANUAL KEEPING
page 01
page 02
Read carefully the entire manual.
1. The pyrolytic heater is designed exclusively for outdoor heating and should not be used for
any other purposes;
2. the heater is intended for outdoor use only. The operator before using the equipment must
read and know all the safety precautions outlined in this document.
3. all local regulations, including those that refer to national and European law must be
respected when installing or using the unit.
4. the heater must be placed on a oor or platform with load-bearing capacity appropriated to
sustain the weight of the equipment declared by the manufacturer;
5. place any furniture at a distance of more than 30 cm away from the walls of the heater and at
least 50 cm away from the radiation area of the glass tube (mod. RUBINO)
6. use the heater only when equipped with mitts able to provide an adequate protection
against heat;
7. do not touch the heater during normal operation without these protections;
8. WARNING: Accessible parts may become hot during use. Children should be kept away;
9. the heater should be fuelled only with wood pellets; it is strictly forbidden to burn any other
material.
10. it is forbidden to burn woodchips or (for example) pieces of chipboard, “medium density”,
pieces of painted wood, panel pieces that may contain resins, foils ant or other media
nishing of wood;
11. the use of other types of wood dierent from pellets could generate toxic combustion gas
and cause damages to the structure of the heater. The combustion of the mentioned types of
wood is also prohibited by law;
12. the heater must be steadily controlled by the user during its normal operation;
13. the metallic sheating of the glass tube of the model RUBINO as well as the door of the internal
brazier of both models must be always closed during the use of the heater, so that the key of
the door has to be pulled out. Please, make only use of the key in moments of re-lling the
internal brazier;
14. never exceed a maximum pellet load of 7 kg. An usage of more pellets could impair the
functioning of the heater;
15. never introduce paper, plastics or siliconic materials in order to avoid possible generations
of ames.
16. if you see smoke, introduce an other piece of relighter in order to support the combustion;
17. clean the heater regularly and remove any combustion residual from the glass tube of
RUBINO or from the glasses of DIAMANTE, as well as from the internal brazier.
18. neglecting to clean the heater could cause a deterioration of the surface that adversely could
aect the life of the device and lead to dangerous situations. Furthermore, check for eventual
obstructions before using the heater, but in particular after a longer period of inactivity.
19. clean the heater following with attention the instructions given in this manual;
20. After each use the temperature of the heater remains at high values for a longer time. Take
care, not to touch the equipment without mitts before it has reached ambient temperature;
21. it is recommended to discharge the combustion residual after each use. Discharging, please
check for burning or hot combustion material in order to avoid any burn. Make usage of the
underlying internal collecting drawer;
22. any repair, replacement or maintenance must be performed by a qualied technician
authorized by the manufacturer;
23. please contact your authorized retailer or the manufacturer itself for the resolution of
eventual problems;
24. every type of work on the system that may be necessary to install and use the heater, should
SAFETY
page 03
be performed by qualied technicians and in accordance with the laws in force in the country
within which you intend to use the equipment;
25. in case of re, use carbon dioxide (CO2) extinguishers; do not use water or powder
extinguishers;
26. do not ll the brazier with quantities of pellets lower or higher than those indicated;
27. do not open the door of the metallic sheating of the model RUBINO during the use of the
heater;
28. do not move around the heater during the combustion process;
29. before setting aside the heater in any kind of building, discharge the internal brazier and the
internal collecting drawer;
30. use the heater only outdoors or in surroundings partially outdoors;
31. it is furthermore prohibited:
• to install the unit in a dierent manner than the one described in this handbook;
• to install the unit in presence of sources that could cause possible ignition (ames,
cigarettes, sparks etc.);
• to install the equipment in areas with a possibility of water jets;
• to Install and use the unit close to combustible materials, ammable and/or explosive
materials and in places with harzardous atmospheres of re;
• to smoke while using the device or approach with devices that can generate combustion
such as cigarettes or lighted lighters, ames of various kinds, scintillators;
32. do not modify the equipment or perform technical operations that are not authorized by
the manufacturer. Each technical maintenance or repair should always be carried out at
specialized centers authorized by the manufacturer;
33. do not use any accessories other than those supplied;
34. do not use the device in dierent ways and/or for purposes other than those specied in this
manual; in particular the appliance should not be used as an incinerator;
35. do not use fuels other than those recommended, including liquids;
36. do not use the unit in physical, and mental conditions impaired or under the inuence of
alcohol, narcotics or psychotropic drugs;
37. do not cover, damage or remove the license and/or technical plates xed on the oven and
on its accessories.
In case of improper use any form of guarantee is void and the manufacturer declines any
responsibility for damages to persons and/or things.
By improper usage it is meant:
• any use other than the one specied in this manual and any use made in ways or with
techniques other than those permitted within this manual;
• any work on the device contrasting the instructions provided in this manual;
• any use after tampering of components and/or after alteration of safety devices;
• any use after repairs performed with unauthorized components.
IMPROPER USAGE
Model RUBINO:
The heater consists of a base element with an internal brazier installed on two guiding rails and
furthermore, a tube made of borosilicate glass with an metallic sheating around.
Within the base element, situated above the brazier, a slice of rock wool is introduced in order to
facilitate the handling and to protect the surface that is in contact with the glass tube.
At the top end of the device one could nd abordering for the metallic sheating of the glass tube
as well as body made of stainless steel supporting the diusion of heat.
All materials that get in contact with weather eects were treated with additional protections in
order to avoid corrosion and to extent the durability.
Finally, the heater is tted with an internal collecting drawer underlying the brazier.
Model DIAMANTE:
this heater consists of the base element with an internal brazier installed on two guiding rails.
On the base there are four tempered glass that surround the ame.
All materials of RUBINO and DIAMANTE that get in contact with weather eects were treated with
additional protections in order to avoid corrosion and to extent the durability.Finally, both the
heaters are tted with an internal collecting drawer underlying the brazier.
DESIGN DESCRIPTION
For lifting and moving the heater, please use an appropriate equipment able to substain its weight.
After unpacking, do not use a fork lift for moving around the device.
Please avoid a positioning of the heater on uneven and skewed grounds.
Never move the heater during its use.
POSITIONING AND TRANSPORT
page 04
Splice the abordering with the metallic sheating at the
upper end using the 4 screws supplied.
ASSEMBLY AND INSTALLATION
Remove the packaging and detach the base element,
the metallic sheating and - in particular carefully - the
glass tube.
Splice the metallic sheating with the base element
using the 4 screws supplied.
2
3
For the assembly of the model RUBINO, please attend the following instructions
1
page 05
Introduce carefully the glass tube in the metallic
sheating, holding it skewed. It rst has to be introduced
in the aperture of the abordering above and then has
to be deposited on the base element.
Afterwards, splice the stainless steel element and the
roof using the 8 screws supplied.
After the assembly make sure that you have followed all of these steps and catch up on positioning
and use of the heater using this manual.
4
Install the door of the metallic sheating.
6
5
page 06
page 07
Remove the packaging and detach the base element,
the four tempered glasses and the pack with the 8
metal supports to be used for housing the glasses.
For the assembly of the model DIAMANTE please attend the following instructions
1
Insert the eight metal supports in the holes tha are at
the top of the heater xing them the screws given
2
Insert each of the four tempered glasses in the holders,
tightening the locking screws.
3
After the assembly make sure that you have followed all of these steps and catch up on positioning
and use of the heater using this manual.
page 08
The initial operation should be performed completely outdoors and in the absence of not-
authorized persons in order to avoid any disturbances during the execution of the following steps.
Assure yourself that all advices in this manual have been considered and that you have natural
relighters at your disposal.
For the initial operation a usage of 3-4 kg of pellets is sucient.
Loading and rst ring up:
1. please open the front door of the base element;
2. draw out the brazier;
3. ll in 3-4 kg of pellets;
4. place 2-3 pieces of a natural relighter onto the pellets and light them. (remeber that the use
of impropriate relighters could lead to a dysfunctioning of the heater);
5. cover the brazier with the dedicated ame reducer after being sure that their combustion
started well;
6. insert the brazier in the base element of the heater again, lock the door,end remove the key
storing it in a safe place.
It will be necessary to wait for 10 minutes before that the ame starts to come out from the glass
tube (mod. RUBINO) or inside the area surrounded by the glasses (DIAMANTE).
Do not open the door of the base element during the combustion.
Let the heater to operate until the pellets in the burner have completely burned, bearing in mind
that after the diminishing of the ame the heater emits heat for at least 2 hours respectively
corresponding to the quantity of pellets you have used.
INITIAL OPERATION
The combustion of pellets takes
place through pyrolysis, so that
the combustion material burns
top down. Therefore, pellets
should never be relled before
the prior load has burned
down completely. Discharge
the brazier afterwards and only
then rell new combustion
material.
The exclusive system adopted
by ROSSOFUOCO® allows
the discharging and relling
operations to be carried out
much faster.
FUNCTIONING OF THE HEATER
The temperature within the brazier could neither be controlled nor blocked as a natural process of
combustion is taking place.
Combustion
by means of
pyrolysis is a
natural chemical
process generating
biogas. The
process diminishes
the more the
combustion
material exhausts
itself and gets
transformed into
residuals.(CHAR)
Not the pellets
themselves but the
biogas generated
through pyrolysis
brings the rising
ame into being.
CHAR resp. combustion
residual
Area of combustion and
pyrolysis
Combustion material
(PELLET)
Fresh Air
Hot Biogas
THE PYROLYSIS
Please, read carefully the entire instruction manual.
Loanding and ring up:
1. open the front door of the base;
2. extract the burner;
3. load the burner with the desired and allowed quantity of pellet. In the following schedule
there is the help for the correct quantity of pellet;
HOW TO LOAD, FIRE UP, UNLOAD AND
RELOAD THE HEATER
KG PELLET FLAME DURATION
3 kg. about 1,5 hours
4 kg. about 2 hours
5 kg. about 2,5 hours
6 kg. about 3,5 hours
7 kg. about 4,5 hours
4. to re up the Heater you have to use 2/3 pieces of an ecological relighter and re them up
(the use of inappropriate relighter can provoke the malfunction of the system);
5. You make sure that the combustion has started so put the ame-reducer on the burner.
During the ignition you should be ensured that everything is equipped properly for the
correct functioning;
6. Reinsert the burner inside the base of the Heater and lock the door. Put the key in a safe place;
It will be necessary to wait for 10 minutes before that the ame starts to come out from the glass
tube (mod. RUBINO) or inside the area surrounded by the glasses (DIAMANTE).
Especially on the occasion of the rst ignition or of those immediately following it is considered normal
the emission of whitish fumes and odors; this can be also repeated, but gradually less intense, for some
times, but it is normal in the rst heating of a new product.
Discharge at end combustion:
7. Open the front door of the base element;
8. Wearing the appropriated reproof mitts remove the cover of the collecting drawer
underlying the brazier;
9. Keep wearing the reproof mitts and open the brazier at its bottom end in order to discharge
the combustion residual in the drawer;
10. Clean the inside of the breazier, using the poker if necessary, removing any residual pellets
even if still burning.;
11. please check that the edges and the lower door are clean so to have a perfect closing; then
close it;
12. close the drawer with its cover;
Empty out the drawer only if you are sure that the combustion material does not glow or burn
anymore. For the disposal of combustion residuals all local legislative regulations have to be
respected.
Now, after the rst ignition and subsequent cleaning, the heater is ready for normal use.
page 09
page 10
Throughout the combustion do not open the door of the base.
It is recommended to make the heater works for the entire duration of the pellet combustion.
The suggested pellet quantity is roughly calculated because the Heater lled with a few quantity of
pellet produces an higher ame because there is more air inside the burner, but the duration will
be shorter. On the contrary if the Heater is lled with a big quantity of pellet the duration will be
longer but the ame will be lower because of the minor quantity of air inside the burner.
When the ame nishes the Heater keep on heating for at least 2 hours depending on the initial
quantity of pellet which continues to heat also there isn’t open ame.
The Heater can be lled again opening the drawer under the burner, according to the instructions
at the following points from 7 to 12 (unload and cleaning operations) and then following the
instructions at the previous points from 3 to 6 (loading and ring up) for refuelling the burner with
additional pellet.
Once the Heater is on, it will work with a pyrolysis process (g. at page 08) which consists in the
top-down anaerobic combustion of the pellet. This process will transform the combusted pellet in
a completely natural compound, that will be easy to dispose of. Anyway, pay attention to the rules
in force in your country about the separate collection.
Unloading:
7. open the door of the base and extract the burner;
8. Wearing the appropriated reproof mitts, remove the top of the ash drawer;
9. Keep wearing the reproof mitts, you have to operate the opening of the part underneath
the burner so you can drop the combustion residues inside the ash drawer;
10. Clean the inside of the breazier, using the poker if necessary, removing any residual pellets
even if still burning.;
11. please check that the edges and the lower door are clean so to have a perfect closing; then
close it;
12. close the drawer with its cover.
WARNING: THE ASH DRAWER HAS TO BE EMPTIED ONLY WHEN THE COMBUSTION RESIDUES INSIDE WILL BE
COMPLETELY COLD AND OFF. FOR THE DISPOSAL YOU HAVE TO RESPECT THE RULES IN FORCE IN YOUR COUNTRY
ABOUT THE SEPARATE COLLECTION
Reload:
When you executed the operations until the previous point 12, the Heater is ready to be used
again. You have only to repeat the load procedure restarted from the point 3 of the “LOADING AND
FIRING UP” instructions.
It is reiterated that:
• When the Heater is hot, its functioning and status has to be constantly controlled;
• The operations on the Heater has to be done always with the standard issue protections and
taking the necessary precautions to avoid burns.
• The temperature and the duration of the ame indicated on the previous schedule of this
manual and on the Heater’s brochure are purely indicative and they are directly evaluated
and regulated according to common sense and specic conditions of the Heater’s user and
what kind of pellet used.
• After every ignitions it is recommended to clean well the Heater, to empty the ash drawer
with the opening under the burner using the attention and care recommended previously.
The cleaning of the burner can be done both leaving inside the base the burner, opening
the top of the ash drawer, and extracting the burner and the ash drawer from the Heater.
To clean it is recommended to use cleaning products for glass and cloth. Removing every time
any pellet residuals inside the burner to avoid that the pyrolysis doesn’t occur correctly in the next
ignition.
Every 2/3 usage of the Heater, it is recommended a lubrication of the burner’ sliding guides, to
avoid the malfunction of the system.
Glass tube cleaning (mod. RUBINO):
1. it makes sure that there isn’t ame and the Heater is cold and o;
2. open the heat diuser door;
3. lift upwards the glass to bring it out from the base and extract it from the grate;
4. spray inside with cleaning products;
5. in the tube inserts a big quantity of kitchen towel or a dry cloth;
6. help yourself with a tube or a stick with a smaller diameter than the tube’s one and push the
kitchen towel or the dry cloth until bring them out on the other side of the tube;
7. in the event that the tube would have droplets of humidity or their residues, having been
outdoor, eliminate them with the use of common glass cleaning product. Spray it on the tube
and dry it carefully; for the inner part of the tube you follow the instructions on the point 4.
8. after tube cleaning, you have to reposition the glass tube inclining and reinserting it before
with an upward movement and then with a downward one until you reinsert it correctly in its
place on the base of the Heater;
9. close again the heat diuser door.
Glasses cleaning (mod. DIAMANTE):
10. it makes sure that there isn’t ame and the Heater is cold and o;
11. spray the glasses with cleaning products;
12. clean using kitchen towel or a dry cloth;
13. in the event that the tube would have droplets of humidity or their residues, having been
outdoor, eliminate them with the use of common glass cleaning product. Spray the glasses
and dry them carefully;
14. nel caso in cui i vetri, essendostati all’esterno presentassero goccioline di umidità o loro
residui procedere alla loro eliminazione spruzzandoli con comuni prodotti per la pulizia dei
vetri, pulendoli ed asciugandoli con un panno agendo con la cura l’attenzione dovute;
15. after the cleaning pulizia eettuata check the correct positioning of the glasses.
To avoid that the dust of the combustion will form a crust and it makes the tube or the glasses
impossible to be clean, you have to perform the cleaning after every combustion or at the latest
two combustions.
Structure cleaning:
16. cleaning also the varnished parts with a soft cloth, water and mild soap;
17. cleaning carefully the ash of the Heater as previously described in these instructions.
FOR ANY OPERATIONS OF CLEANING IT IS RECCOMENDED TO NOT USE ABRASIVE OR CORROSIVE PRODUCTS.
CLEANING AND MAINTENANCE
page 11
Always with the previous precautions. For the cleaning operations and products to use make
reference to the indications in the following specic chapter.
page 12
TROUBLE
TROUBLE POSSIBLE CAUSE SOLUTION
The heater does not turn
on
Pyrolysis has not started
correctly
Check that the used ecological igniter has
not been switched o, if it is so to add
more of it so that its quantity is adequate
and turn it on again making sure that its
combustion is well started before closing
everything.
Wet pellet
Change the wood pellets especially if the
package was open for some time, without
throwing it, but maybe reusing it once it
has dried well; place again some ecological
re ignites ensuring their correct ignition.
Failure to comply with the
indications concerning the
installation and use of the
heater
Read carefully this manual and correct
possible errors in installation.
Meticulously follow all instructions.
The ame don’t start up The ame reducer is missing Place the supplied ame reducer on top of
the burner correctly.
Smoke during ignition Unsuitable igniters Be sure to use quality igniters
The ame is too intense there is not enough pellets in
the burner
Do not intervene and do not interrupt the
activity of the heater in its combustion
process, paying close attention to the high
temperatures it could reach.
At the next ignition, load the
recommended quantity of wood pellets.
It is not possible to extract
the burner
The drawer slide guides have
not been lubricated.
Lubricate the burner drawer guides;
perform this procedure after every 2/3 use.
combustion residues or foreign
bodies prevent it from owing
Check for any residues or foreign bodies
and remove them.
GENERAL INFORMATION DESCRIPTION
Manufacturer ROSSOFUOCO s.r.l. unipersonale
Via Cavalieri di V. Veneto, 21
61045 PERGOLA (PU)
Tel. 0721/735926 - fax 0721/737107
Manufacturer’s Brand Rossofuoco
Model Pyrolitic heater
DIMENSIONS AND WEIGHT OF THE PYROLITICAL HEATERS
Length x Width x Height and Weight
Pyrolitic outdoor heater RUBINO 500x500x1900 mm; 55 kg
Pyrolitic outdoor heater DIAMANTE 500x500x900 mm; 35 kg
TECHNICAL DATA
CLIMATIC CONDITIONS OF USE
Temperature: 0 – 30 °C
Relative Humidity 10 – 90 %
ANALYTICAL PARAMETERS
Filling per usage 3-7 Kg max.
Emissions CO 48.3 mg/m§
Emissions NOx 171.0 mg/m§
PHYSICAL PARAMETERS
Maximal temperature of Heaters 499 °C
Water vapour content 2.6 %V
Oxygen content 16.0 %V
Carbon dioxide content 4.7 %V
Concentration 0.45 Kg/Em§
ADDITIONAL EQUIPMENT
Collecting drawer, ame reducer, poker, protective glove, manual.
page 13
page 14
The company : ROSSOFUOCO S.r.l. unipersonale
settled in Via Cavalieri di V. Veneto, 21 –
61045 PERGOLA (PU) - ITALY
declares under its own responsibility that the products:
PYROLITIC OUTDOOR HEATERS “RUBINO” AND “DIAMANTE”
are pellet driven and therefore are not covered by the following supranational statutory
provisions:
• Directive 2014/35/ EU on electrical equipment with voltage limits and Directive 2014/30/EU
on electromagnetic compatibility as the Heaters are not in need of any electrical supply;
• Regulation eu No 305/2011 305/2011 stipulating harmonised conditions for the marketing
of construction products and repealing Council Directive 89/106/EEC whereas Indoor pellet
driven ovens come under this law.
DECLARATION OF CONFORMITY AND
APPLICABLE LEGISLATION
Pergola, 13/02/2018 (ROSSOFUOCO s.r.l. unipersonale)
The legal representative
Applicable legislation
Directive 2001/95/EC on the general rules of product safety, implemented with D. Lgs.
206/2005 “Consumer Protection Law” - Partl IV - Security and Quality - Titel I Product Safety
- Titel II - Liability for defective units -
Art. 117 Defective Product:
1. A product is said to be defective if it does not provide the safety that a person is entitled
to expect. Thereto appertain in particular:
a) the way in which the product was put in circulation, its description, its overtcharacteri-
stics, the provided instructions and indications;
b) the usage of the product and behavior patterns that justiably could be expected;
c) the point in time at that the product was put in circulation.
2. A product could not be considered as being defected solely because a better product
was put in circulation in some time.
3. A product has to be considered as being defected if it does not oer the security that
other products of this type normally oer.
WARRANTY CARD
(part to be lled in and stored by the customer)
Model Serial number Date of purchase
Stamp and signature of the dealer
COPY FOR THE COSTUMER
Attention!
The other underlying part of the
warranty coupon must be lled in
and sent as an ordinary letter to
the manufacturer at the address
on the back.
CUSTOMER IDENTIFICATION DATA
Name Surname
Address
ZIP codeCityCounty/region/area
Statephone number/Email
The incomplete coupons or without the stamp and signature of the dealer will not be considered valid
WARRANTY CARD
(part to be lled in and stored by the customer)
Model Serial number Date of purchase
Stamp and signature of the dealer
COPY FO SEND
Attention!
This part of the warranty coupon
must be lled in and sent as an
ordinary letter to the
manufacturer at the address on
the back.
CUSTOMER IDENTIFICATION DATA
Name Surname
Address
ZIP codeCityCounty/region/area
Statephone number/Email
The incomplete coupons or without the stamp and signature of the dealer will not be considered valid
Customer signature
ROSSOFUOCO srl - VIA CAVALIERI DI V. VENETO, 21 - 61045 PERGOLA (PU) - ITALY
The product is guaranteed for two years from the date of purchase indicated on the back and affixed by
the retailer at the time of sale together with its stamp and signature. The manufacturer's warranty covers
the costs of the spare parts; transport costs, labor costs, personnel costs or anything else charged to the
customer; any demolition and / or restoration work is not the responsibility of the manufacturer, but of the
customer.
faults and / or breakages due to carelessness, errors in use, installation, normal wear, natural fire events,
vandalism, tampering, damage during assembly or transport, and in any case all resulting from the
misuse of the equipment, the use of unsuitable fuel and failure to comply with the instructions for
assembly and housing. The manufacturer assumes no further responsibility. To request warranty work
and/or make any repairs, please contact the retailer where you purchased the product.
The product is guaranteed for two years from the date of purchase indicated on the back and affixed by
the retailer at the time of sale together with its stamp and signature. The manufacturer's warranty covers
the costs of the spare parts; transport costs, labor costs, personnel costs or anything else charged to the
customer; any demolition and / or restoration work is not the responsibility of the manufacturer, but of the
customer.
faults and / or breakages due to carelessness, errors in use, installation, normal wear, natural fire events,
vandalism, tampering, damage during assembly or transport, and in any case all resulting from the
misuse of the equipment, the use of unsuitable fuel and failure to comply with the instructions for
assembly and housing. The manufacturer assumes no further responsibility. To request warranty work
and/or make any repairs, please contact the retailer where you purchased the product.
WARRANTY CARD
COPY FOR THE COSTUMER
COPY FO SEND TO THE MANUFACTURER
WARRANTY CARD
Send this part of the coupon in a sealed envelope, as an ordinary
letter to the manufacturer, to the following address
This part of the warranty coupon of being kept by the customer.
Cut out and send the other part below by following the instructions in it.
Table of contents
