YitaHome CZWRL-V3 User manual

FTPLFP-0001
FTPLFP-0002
CZWRL-V3
PYRAMID OUTDOOR PATIO HEATER
ASSEMBLY INSTRUCTIONS

1
1.Two or more people are required for the assembly.
2.Your heater was designed and approved for outdoor use only. Do NOT use inside a
building, garage, or any other enclosed area.
3.Make sure surrounding areas are free of combustible materials, gasoline, and other
flammable vapors or liquids.
4.Ensure that there is no obstruction to air ventilation. Be sure that all gas connections
are tight and that there are no leaks.
5.Be sure the cylinder cover is clear of debris. Ensure that any component removed during
assembly or servicing is replaced and fastened prior to operation.
6.Heater should be thoroughly inspected annually before each use by a qualified service
person. If relighting a hot heater, always wait at least 5 minutes.
7.Inspect the hose assembly for evidence of excessive abrasion, cuts, or wear. Suspected
areas should be leak tested. If the hose leaks, it must be replaced prior to operation.
Only use the replacement hose assembly specified by manufacturer.
8.Professional installation is highly recommended.
ASSEMBLY INSTRUCTIONS
Do not attempt to operate until you have read and understood all General
Safety Information in this manual and all assembly is complete with leak
checks performed!

X1
X1
2
A
B
X4C
X4D
X1
E
X1F
X2G
X4H
X1
J
X2
X1K
Exploded View
Ｉ
ASSEMBLY INSTRUCTIONS

3
Item no.Reference Image Qty.
Reflector
Damper
Upper Support
Wireguard
Glass Tube
Middle plate
AX1
BX1
CX4
DX4
EX1
FX1
Side Panel
GX2
ASSEMBLY INSTRUCTIONS

Fixing Bracket
Knob
X4
X1
4
Item no.Reference Image Qty.
Lower Support
Front Panel
Base
Control box
Screw
M3x16
HX4
X2
JX1
KX1
X64
Ｉ
AA
BB
CC
ASSEMBLY INSTRUCTIONS

5
Item no.Reference Image Qty.
Stability Ring
Cover
Wheels
Rubber Ring
X1
X1
X1
X1
Relfector Stud
X3
Washer
X6
Wing Nut
X3
DD
EE
FF
GG
HH
ＩＩ
JJ
ASSEMBLY INSTRUCTIONS

6
1pc
FF
11pc
J
J
FF
Note: The connecting screws have been pre-fixed on part ,
unscrew them in order to proceed with assembly.
FF
ASSEMBLY INSTRUCTIONS

7
2
Note: The connecting screws have been pre-fixed on part ,
unscrew them in order to proceed with assembly.
90°
J
1pc
DD
ASSEMBLY INSTRUCTIONS
DD
DD

8
1pc
F4pcs H
3
H
H
H
H
F
F
H
H
J
20pcs
AA
AA
AA
ASSEMBLY INSTRUCTIONS
H

9
41pc
B4pcs C24pcs
AA
ASSEMBLY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS
10
5
4
Note: Make sure the positions marked by
are facing the same direction.

11
61pc
A3pcs
JJ
3pcs
HH 6pcs ＩＩ
JJ
ＩＩ
HH
ASSEMBLY INSTRUCTIONS

12
71pcE1pc
GG
1
2
GG
E
ASSEMBLY INSTRUCTIONS
WARNING!
The rubber ring must be in place
prior to operating the heater.

13
84pcs
D
D
D
4pcs
AA 4pcs BB
BB
AA
ASSEMBLY INSTRUCTIONS

14
2pcs
G
9
G
G
G
12pcs
AA
AA
AA AA
AA AA
AA
AA
AA
AA
AA
AA
AA
ASSEMBLY INSTRUCTIONS

15
10
CC
CC
1
2
3
1pc
CC
Ｉ
Ｉ
2pcs
Ｉ
ASSEMBLY INSTRUCTIONS

16
Installation Complétée
Installazione Completata
Instalación Completada
Installation Abgeschlossen
Installation Completed
ASSEMBLY INSTRUCTIONS
11 1pc
EE
EE
Cover the fire pit with cover(EE) when not in use or after the appliance
completely cools down. This is to protect it from the elements.

ASSEMBLY INSTRUCTIONS
17
Standard 20 lb. tank
1.Connect the hose to the hose connector in the control box.
2.Connect hose and regulator to cylinder.
Propane Only - Proper Hose Connection.
WARNING!
Connect the hose to the hose connector in the control box.
Propane Only - Proper Hose Connection.
Ensure the hose does not touch any high temperature surfaces,
or it may melt and leak, resulting in a fire.
Always test the hose and connections for leak with soapy water at the
end of all connections.
Tank need to be purchased separately！
LIGHTING INSTRUCTIONS
Check and ensure that a AA battery
（prepare in advance） containing power is
inside the ignition chamber and has power.
Make sure the anode(+) side of the battery is
facing outside. Prepare in advance
12

18
ASSEMBLY INSTRUCTIONS
13
Leak Check
1. Make 2-3 oz. of leak check solution (one part liquid dishwashing detergent and three parts water).
2. Apply several drops of solution where hose attaches to regulator.
3. Apply several drops of solution where regulator connects to cylinder.
4. Make sure all patio heater and light valves are OFF.
5. Turn cylinder valve ON.
If bubbles appear at any connection, there is a leak.
1. Turn cylinder valve OFF.
2. If leak is at hose/regulator connection: tighten connection and perform another leak test. If bubbles
continue appearing, the hose should be returned to the place of purchase.
3. If leak is located at regulator and cylinder valve connection: disconnect, reconnect, and perform
another leak check. If you continue to see bubbles after several attempts, cylinder valve is defective
and should be returned to the place of purchase.
If NO bubbles appear at any connection, the connections are secure.
NOTE: Whenever gas connections are loosened or removed, you must perform a complete leak test.
Regulator / Cylinder
connection
Hose / Regulator
connection
WARNING
• Perform all leak tests outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the heater until all connections have
been leak tested and confirmed to have no leak.

19
ASSEMBLY INSTRUCTIONS
14
1.Ensure the control knob is OFF then slowly open the
gas cylinder valve.
2.Press and turn the control knob to LIGHT. Push the igniter
to generate a spark while keeping the control knob pressed.
3.Check for the pilot flame through the glass tube. If the pilot
flame does not light, turn the control knob to the OFF position
and wait for at least two minutes then try again. Several
attempts may be necessary.
4.With the pilot light lit, keep the control knob pushed down
for 15 seconds then turn the control knob to LOW.
5.For maximum heat, turn the control knob to HIGH.
6.To turn the heater off, turn the control knob to OFF.
7.Close the valve on gas cylinder or regulator after use.
1.To enjoy outstanding heating performance for years, make sure to perform the following
maintenance activities on a regular basis:
● Keep exterior surfaces clean.
-Use warm soapy water for cleaning. Never use flammable, corrosive or abrasive cleaners.
-While washing your unit, be sure to keep the area around the burner and pilot assembly dry at all
time. If the gas control is exposed to water in any way, do NOT try to use it, and it must be replaced.
● After a long break from operation, the unit should be inspected for spiders, spider webs and
other insects.
● Air flow must be unobstructed. Keep controls, burner and circulating air passageways clean.
Signs of possible blockage include:
-Gas odor with extreme yellow flame tipping.
-Heater does NOT reach the desired temperature.
-Heater’s glow is excessively uneven.
-Heater makes popping noises.
● Spider and insects can nest in burner or orifices.
This dangerous situation can damage heater and render it unsafe for use.
Clean burner holes with a heavy-duty pipe cleaner.
Compressed air may help clear away smaller particles.
● Carbon deposits may create a fire hazard. Clean the inside of reflector and glass tube with
soapy water if any carbon deposits develop. Always be careful when cleaning the glass tube.
CLEANING AND MAINTENANCE:
OFF
LIGHT
LOW
HIGH
OFF
LO
HI
