1.0 WARRANTY INFORMATION
Patton Electronics warrants all Model 2173R components to be free
from defects, and will—at our option—repair or replace the product
should it fail within one year from the first date of the shipment.
This warranty is limited to defects in workmanship or materials, and does
not cover customer damage, abuse or unauthorized modification. If this
product fails or does not performs as warranted, your sole recourse shall
be repair or replacement as described above. Under no condition shall
Patton Electronics be liable for any damages incurred by the use of this
product. These damages include, but are not limited to, the following: lost
profits, lost savings and incidental or consequential damages arising
from the use of or inability to use this product. Patton Electronics spe-
cifically disclaims all other warranties, expressed or implied, and the
installation or use of this product shall be deemed an acceptance of
these terms by the user.
Note Conformity documents of all Patton products can be viewed
online at www.patton.com under the appropriate product page.
1.1 COMPLIANCE
EMC Compliance:
• FCC Part 15, Class A
• EN55022, Class A
• EN55024
• A-tick
Low-Voltage Direcive (Safety):
• IEC/EN60950-1, 2nd Edition
• AS/NZS 60950-1, A-tick
PSTN:
• This device is not intended nor approved for connection to the PSTN.
1.2 RADIO AND TV INTERFERENCE (FCC PART 15)
This equipment generates and uses radio frequency energy, and if not
installed and used properly—that is, in strict accordance with the manu-
facturer's instructions—may cause interference to radio and television

5
reception. This equipment has been tested and found to comply with the
limits for a Class A computing device in accordance with the specifica-
tions in Subpart B of Part 15 of FCC rules, which are designed to provide
reasonable protection from such interference in a commercial installa-
tion. However, there is no guarantee that interference will not occur in a
particular installation. If the equipment causes interference to radio or
television reception, which can be determined by disconnecting the
cables, try to correct the interference by one or more of the following
measures: moving the computing equipment away from the receiver, re-
orienting the receiving antenna, and/or plugging the receiving equipment
into a different AC outlet (such that the computing equipment and
receiver are on different branches).
1.3 CE DECLARATION OF CONFORMITY
We certify that the apparatus described above conforms to the require-
ments of Council Directive 2004/108/EC on the approximation of the
laws of the member states relating to electromagnetic compatibility; and
Council Directive 2006/95/EC on the approximation of the laws of the
member states relating to electrical equipment designed for use within
certain voltage limits.
The safety advice in the documentation accompanying this product shall
be obeyed. The conformity to the above directive is indicated by the CE
sign on the device.
1.4 AUTHORIZED EUROPEAN REPRESENTATIVE
D R M Green, European Compliance Services Limited.
Avalon House, Marcham Road, Abingdon, Oxon OX14 1UD, UK
1.5 SERVICE
All warranty and non-warranty repairs must be returned freight prepaid
and insured to Patton Electronics. All returns must have a Return Materi-
als Authorization number on the outside of the shipping container. This
number may be obtained from Patton Electronics Technical Services at:
•Tel:[phone]
•Email:[e-mail]
• URL: http://www.patton.com
Note Packages received without an RMA number will not be
accepted.

6
1.6 SAFETY WHEN WORKING WITH ELECTRICITY
• This device contains no user serviceable parts. This
device can only be repaired by qualified service per-
sonnel.
• Do not open the device when the power cord is con-
nected. For systems without a power switch and without
an external power adapter, line voltages are present
within the device when the power cord is connected.
• For devices with an external power adapter, the power
adapter shall be a listed Limited Power Source. The
mains outlet that is utilized to power the device shall be
within 10 feet (3 meters) of the device, shall be easily
accessible, and protected by a circuit breaker in com-
pliance with local regulatory requirements.
• For AC powered devices, ensure that the power cable
used meets all applicable standards for the country in
which it is to be installed.
• For AC powered devices which have 3 conductor
power plugs (L1, L2 & GND or Hot, Neutral & Safety/
Protective Ground), the wall outlet (or socket) must
have an earth ground.
• For DC powered devices, ensure that the interconnect-
ing cables are rated for proper voltage, current, antici-
pated temperature, flammability, and mechanical
serviceability.
• WAN, LAN & PSTN ports (connections) may have haz-
ardous voltages present regardless of whether the
device is powered ON or OFF. PSTN relates to inter-
faces such as telephone lines, FXS, FXO, DSL, xDSL,
T1, E1, ISDN, Voice, etc. These are known as “hazard-
ous network voltages” and to avoid electric shock use
caution when working near these ports. When discon-
necting cables for these ports, detach the far end con-
nection first.
• Do not work on the device or connect or disconnect
cables during periods of lightning activity.
WARNING

7
In accordance with the requirements of council direc-
tive 2002/96/EC on Waste of Electrical and Electronic
Equipment (WEEE), ensure that at end-of-life you sepa-
rate this product from other waste and scrap and deliver
to the WEEE collection system in your country for recy-
cling.
This device is NOT intended nor approved for connec-
tion to the PSTN. It is intended only for connection to
customer premise equipment.
When the 2173R is mounted, it shall be secured in such
a way as to withstand a vertical shear force of 50N or 14
pounds.
Electrostatic Discharge (ESD) can damage equipment
and impair electrical circuitry. It occurs when electronic
printed circuit cards are improperly handled and can
result in complete or intermittent failures. Do the fol-
lowing to prevent ESD:
• Always follow ESD prevention procedures when
removing and replacing cards.
• Wear an ESD-preventive wrist strap, ensuring that it
makes good skin contact. Connect the clip to an
unpainted surface of the chassis frame to safely chan-
nel unwanted ESD voltages to ground.
• To properly guard against ESD damage and shocks,
the wrist strap and cord must operate effectively. If no
wrist strap is available, ground yourself by touching the
metal part of the chassis.
WARNING
WARNING
WARNING

8
2.0 GENERAL INFORMATION
Thank you for your purchase of this Patton Electronics product. This
product has been thoroughly inspected and tested and is warranted for
one year for parts and labor. If any questions or problems arise during
installation or use of this product, contact Patton Electronics Technical
Support at [phone].
2.1 FEATURES
• Variable rate CopperLINK extender - Easy to configure
• Auto-MDIX Ethernet
• Configurable 10/100, Full/Half, and Auto-Negotiating Ethernet
• Extends network connections up to 5,500 ft (1.6 km) over 2-wire 24-
AWG unconditioned lines
• Auto-Rate line rates up to 100 Mbps downstream/70 Mbps upstream
• Symmetric or asymmetric settings via DIP switch
• Transparent operation
• LED indicators for Power, Link, Ethernet Link & Activity, and Remote/Local
2.2 DESCRIPTION
The Patton Electronics Model 2173R Ruggedized Ethernet Extender
provides high-speed LAN connections between peered Ethernet LANs,
remote PCs, or any other network enabled 10/100Base-T device.
Operating in pairs, one Model 2173R or 2173 isconfigured as the (L) Local
unit located at one end of the LAN extension and the other Model 2173R
or 2173 is configured as the (R) Remote unit at the other end. These units
can automatically forward LAN broadcasts, multicasts, and frames across
a 2-wire voice-grade twisted-pair link. The data is passed transparently
(unmodified) through the 2173Rs or 2173s. The 2173Rs automatically add
and delete MAC addresses, only passing packets across the CopperLINK
link that are meant for the remote peered LAN.

9
Figure 1. Typical application
The pair of 2173R and 2173 models work together to create a transparent
extension between two peered Ethernet LANs. Figure 1 shows a typical
point-to-point application.
3.0 INSTALLATION
To install the 2173R Ethernet Extender, do the following:
1. Connect the line interface between the units (refer to section 3.1,
“Connecting the Twisted-Pair Line Interface” on page 10)
Note See Figure 2 for the standalone unit’s rear panel arrangements.
2. Connect the Ethernet interface (refer to section 3.2, “Connecting the
10/100Base-T Ethernet Interface” on page 11).
3. Connect the power plug (refer to section 3.3, “Connecting Power” on
page 12).
The Interconnecting cables shall be acceptable for
external use and shall be rated for the proper applica-
tion with respect to voltage, current, anticipated tem-
perature, flammability, and mechanical serviceability.
CAUTION

10
Figure 2. Model 2173R panel
3.1 CONNECTING THE TWISTED-PAIR LINE INTERFACE
The Model 2173R supports communication between two peer Ethernet
LAN sites over a distance of up to 5,500 ft (1.6 km) over 24 AWG
(0.5 mm) twisted-pair wire.
Note Actual distance and link performance may vary depending on
the environment and type/gauge of wire used.
Follow the steps below to connect the Model 2173R CopperLINK Inter-
faces.
Note The Model 2173R units work in pairs. One of the units must be
configured as a (L) Local unit, and the other unit must be config-
ured as a (R) Remote unit. It does not matter which end is the L
and which is the R. The link is always initiated by the R unit. As
long as the L unit is powered on, the R unit can establish a link
by being powered on or by having its power reset.
1. To function properly, the two Model 2173Rs must be connected
together using twisted-pair, unconditioned, dry, metal wire, between
19 (0.9mm) and 26 AWG (0.4mm). Leased circuits that run through
signal equalization equipment are not acceptable.
The Interconnecting cables shall be acceptable for
external use and shall be rated for the proper applica-
tion with respect to voltage, current, anticipated tem-
perature, flammability, and mechanical serviceability.
CopperLINK
twisted-pair
RJ-45 interface
2173R
(RJ-45)
Power
jack
Ethernet
port 1
Ethernet
port 2
Ethernet 1
Link
Power
CopperLink 2173R
Ruggedized Ethernet Extender
Ethernet
2 1
Power
5V; 0.6A
Line
Ethernet 2
Remote
Local
CAUTION

11
2. The Model 2173R is equipped with either an RJ-45 interface jack that
can be used on the CopperLINK interface. These CopperLINK inter-
faces are a two-wire interface. Observe thesignal/pin relationships on
the Model 2173R's CopperLINK interface jacks.
The RJ-45 connector on the Model 2173R's twisted pair interface is
polarity insensitive and is wired for a two-wire interface. The signal/pin
relationship is shown in Figure 3.
Figure 3. Model 2173R (RJ-45) twisted pair line interface.
3.2 CONNECTING THE 10/100BASE-T ETHERNET INTERFACE
The shielded RJ-45 port labeled Ethernet is the Auto-MDIX10/100Base-
T interface. This port is designed to connect directly to a 10/100Base-T
network. Figure 4 shows the signal/pin relationships on this interface.
You may connect this port to a hub or PC using a straight through or
crossover cable that is up to 328 ft long.
The Interconnecting cables shall be acceptable for
external use and shall be rated for the proper applica-
tion with respect to voltage, current, anticipated tem-
perature, flammability, and mechanical serviceability.
1 (no connection
)
2 (no connection
)
3 (no connection
)
4 (RING)
5 (TIP)
6 (no connection
)
7 (no connection
)
8 (no connection
)
1
2
3
4
5
6
7
8
CAUTION

12
Figure 4. Model 2173R 10/100Base-T RJ-45 Connector Pinout.
3.3 CONNECTING POWER
The Model 2173R does not have a power switch, so it powers up as
soon as it is plugged in.
An external AC or DC power supply is available separately. This connec-
tion is made via the barrel jack on the rear panel of the Model 2173R. No
configuration is necessary for the power supply (See Appendix B for
domestic and international power supply and cord options).
DC power (supplied via the power supply jack to the 2173R) must meet
the following requirements; DC power supplied must be regulated
+5VDC ±5%, 1.0A minimum. Center pin is +5V. The barrel type plug has
a 2.5/5.5/10mm I.D./O.D./Shaft Length dimensions.
4.0 CONFIGURATION
The Model 2173 has four DIP switches (S1) for configuring the unit for a
wide variety of applications. This section describes switch locations and
explains the different configurations..
4.1 CONFIGURING THE HARDWARE DIP SWITCHES
Using a small flat-tip screwdriver, remove the protective cover located on
the underside of the Model 2173R (see Figure 5).
The Interconnecting cables shall be acceptable for
external use and shall be rated for the proper applica-
tion with respect to voltage, current, anticipated tem-
perature, flammability, and mechanical serviceability.
1 TX+/RX+
2 TX-/RX-
3 RX+/TX+
4 (no connection)
5 (no connection)
6 RX-/TX-
7 (no connection)
8 (no connection)
1
2
3
4
5
6
7
8
CAUTION

13
Figure 5. Removing protective cover
Figure 6 on page 13 shows the orientation of the DIP switches in the On
and Off positions.
Figure 6. DIP switch orientation
High-Speed
Ethernet Extender
ON
OFF
Ruggedized High Speed Ethernet Extender
S1
1234
ON
Push toggle up
for ON position
Switch toggle
Push toggle
down for
OFF position
1234
ON
S1
S1

14
4.2 CONFIGURING DIP SWITCH S1
DIP switchS1 is where you configurethe CopperLINK line. The following
tables describe the configuration for the 2173.
S1-2: Impulse Noise Protection
•Fast Mode: Direct data transmission with latency less than 1ms
•Interleave Mode: Provides data transmission protection for up to 250
ms impulse noise with latency less than 6 ms
S1-3: Rate Limit
S1-4: General Protection (Signal to Noise Ratio)
•6dB: Original line noise protection with 6dB SNR
•9dB: Better line noise protection with SNR up to 9dB
5.0 OPERATION
Once the Model 2173Rs are properly installed, they should operate
transparently. No user settings required. This section describes reading
the LED status monitors.
5.1 POWER UP
Before applying power to the Model 2173R, please review section 3.3,
“Connecting Power” on page 12 to verify that the unit is connected to the
appropriate power source.
Table 1: 2173 Firmware Configuration
Position
S1-1 S1-2 S1-3 S1-4
Master/
Slave Mode Rate SNR
ON Slave
(CPE) Fast Auto 6dB
OFF Master
(CO) Interleave 25/25 9dB
S1-3 Rate
OFF 25/25
ON Auto

15
5.2 FRONT PANEL LED STATUS MONITORS
The Model 2173R features six front panel LEDs that monitor power, the
Ethernet signals, the CopperLINK connection, and the remote/local set-
ting. Figure 7 shows the front panel location of each LED. Table 2 on
page 15 describes the LED functions.
Figure 7. Model 2173R front panel
Table 2: Front panel LED description
LED Status Description
Power Green The device is powered on.
Off The device is powered off.
CopperLink Green The port is connected.
Blinking Green Data transceiving.
Off No valid link on this port.
Ethernet Green The port is connected.
*
Blinking Green
*. Once the unit connects to a power source, the Link LED will
blink as the 2173R automatically looks for the other unit in
the pair.
Data transceiving.
Local Green The device acts in Local mode.
Off Local mode is off.
Remote Green The device acts in Remote mode.
Off Remote mode is off.
Ethernet 1 LED
Link LED
Power LED
Ethernet 1
Link
Power
CopperLink2173R
RuggedizedEthernet Extender
Ethernet
2 1
Power
5V; 0.6A
Line
Ethernet 2
Remote
Local
Ethernet 2 LED
Remote LED
Local LED

16
APPENDIX A
SPECIFICATIONS
A.1 LAN CONNECTION
• Two shielded RJ-45, 10/100Base-T, IEEE 802.3 Ethernet
• CopperLINK Connection: Shielded RJ-45
A.2 TRANSMISSION LINE
Two-wire unconditioned twisted pair.
A.3 COPPERLINK LINE RATE AND COPPERLINK DISTANCE
• Line Rate: Up to 155 Mbps aggregate (upstream/downstream) via
Auto Rate; and 25/25 Mbps via DIP switch settings.
• Distance: Up to 5,500 ft (1.6 km)
Note Distances depend on line rate and line conditions.
A.4 LED STATUS INDICATORS
• Power (Green)
• CopperLINK: Link (Green)
• Ethernet: Link (Green) & Activity (Flashing Green)
• Remote (Green)
• Local (Green)
A.5 POWER SUPPLY
External AC and DC options:
• AC: 120 VAC, 220 VAC, and UI (120–240 VAC)
• DC: 12 VDC, 24 VDC and 48 VDC
• Power consumption: 860mA at 5V
A.6 TEMPERATURE RANGE
-40 to 85°C
A.7 HUMIDITY
Standard:Up to 90% non-condensing
A.8 DIMENSIONS
1.5H x 4.13W x 3.75D in.(3.81H x 10.5W x 9.53D cm)

17
APPENDIX B
MODEL 2173R FACTORY
REPLACEMENT PARTS AND ACCESSORIES
*Only required with optional UI power supply (08055DCUI)
Patton Model # Description
Base Models
2173R/E CopperLINK Multi Rate 100 Mbps Ethernet Extender;
No power supply
2173R/E-2PK CopperLINK Multi Rate 100 Mbps Ethernet Extender Kit (2 units
preset to local and remote); No power supply
2173R/EUI-2PK CopperLINK Multi Rate 100 Mbps Ethernet Extender Kit (2 units
preset to local and remote); 110-240VAC
07M2173R-UM User Manual
Power Supplies
08055DCUI
08055-120-5-1 100-240VAC (+5V reg. DC/2A) Universal Input Adapter. 120 VAC (+5V reg. DC/1A) Input Adapter
12V-PSM 12 VDC Input Adapter
24V-PSM 24 VDC Input Adapter
48V-PSM 48 VDC Input Adapter
Power Cords*
0805US American Power Cord
0805EUR European Power Cord CEE 7
0805UK United Kingdom Power Cord
0805AUS Australian Power Cord
0805DEN Denmark Power Cord
0805FR France/Belgium Power Cord
0805IN India Power Cord
0805IS Israel Power Cord
0805JAP Japan Power Cord
0805SW Switzerland Power Cord

18
APPENDIX C
MODEL 2173R INTERFACE PIN ASSIGNMENT
C.1 10/100BASE-T INTERFACE
RJ-45
• Pin 1: TX+
• Pin 2: TX-
• Pin 3: RX+
• Pin 6: RX-
• Pins 4, 5, 7, 8: no connection
C.2 COPPERLINK INTERFACE
RJ-45
• Pin 4: RING
• Pin 5: TIP
• Pins 1, 2, 3, 6, 7, 8: no connection

19
APPENDIX D
SAMPLE RATES/DISTANCE CHART, BASED ON 24 AWG (0.5 MM)
Note The actual distance and link performance may vary depending
on the environment and type/gauge of wire used.
Note DS = downstream, US = upstream
Rate Mode Distance in
Feet (km)
Throughput
at Max
Distance
(megabits per
second)
4/1 Fast 5,500
(1.6 km) 4.00 (DS) 1.00 (US)
4/1 Interleave 5,500
(1.6 km) 4.00 (DS) 1.00 (US)
100/70 Fast 500 ft
(0.15 km) 83 (DS) 69.5 (US)
100/70 Interleave 250
(0.07 km) 83 (DS) 69.5 (US)
25/25
*
*. For the 25/25 rate, set S1-3 to the OFF position.
Interleave 2,250
(0.6 km) 24.89 (DS) 24.89 (US)
50/50 Fast 1,750
(0.5 km) 49.78 (DS) 49.78 (US)
50/50 Interleave 1,750
(0.5 km) 49.78 (DS) 49.78 (US)
70/70 Fast 1,750
(0.5 km) 51 (DS) 51 (US)
70/70 Interleave 1,750
(0.5 km) 51 (DS) 51 (US)

20
Copyright © 2012
Patton Electronics Company
All Rights Reserved.
