Patton electronics IPLink 2802 User manual

Patton’s IPLink Managed VPN Routers
are a family of next generation appli-
ances that address both the security
and the traffic prioritization needs of enter-
prises. VPN routers enable the secure com-
munication of remote offices, home offices,
and mobile users across insecure IP net-
works such as the Internet. IPLink VPN
Routers take it one step further and integrate
quality of service (QoS) to optimize business
traffic flows, allowing dual use (business and
leisure) of broadband connections without
impacting the quality of business communi-
cations.
IPLink VPN Routers implement a comprehen-
sive security environment. It all starts with
IPSec. By supporting ESP as well as AH,
IPLink VPN Routers provide data integrity,
authentication, anti-replay and data confiden-
tiality to any traffic flow. DES, 3DES, and AES
provide standard encryption up to 256 bits.
Firewall capabilities of the IPLink VPN
Routers include Access Control Lists (ACLs),
IP address and port filtering, and protection
against Denial of Service (DoS) attacks.
Likewise, PPPoE protocols include support
for PAP and CHAP authentication.
QoS features include
ToS/DiffServ marking
and the configuration of
eight service class tags
per IEEE 802.1p/Q. With
traffic scheduling and
shaping, create dedicat-
ed bandwidth guarantees, configurable burst
tolerance, and policing to include excess traf-
fic discard. IP fragmentation is configurable
to help minimize jitter in traffic flows.
Advanced IP features include RIPv1 & RIPv2
routing and static route configuration. Static
and dynamic NAT, NAPT, DNS resolver and
relay, dynamic DNS, and DHCP server further
add to the capabilities of the IPLink VPN
Router. All IPLink VPN routers can be man-
aged via a web browser (HTTP), command
line interface (Telnet), or an SNMP manage-
ment platform.
For more information, visit us at
www.patton.com.
Patton IPLink Managed VPN Routers promote business/dual use of broadband access networks
by applying VPN encryption AND QoS/CoS traffic management to traffic flows.
IPLink Managed VPN Routers
Model 2802 & 2805
IP Access Products
QoS/CoS Profiles
Configurable burst tolerance, bandwidth guaran-
tees plus reduce per flow traffic jitter as required
by the application.
Configurable Security Profiles
Built-in IP address and IP port filtering, ACLs and
DoS attack detection creates a comprehensive
security environment.
Enhanced IP Services
DNS resolver and relay, NAT/NAPT, dynamic
DNS, and DHCP server, eases integration.
Strong Encryption
DES, 3DES, and AES offer standards based
encryption algorithms from 56 to 256 bits.
VPN Tunnels
Standard IPSec with AH and ESP ensures maxi-
mum protection when traversing
unsecured networks.
10/100 Ethernet
Dual 10/100 Ethernet and 5 port Ethernet switch.
Special Rates
Available
Call for Details
SNMP/HTTP Management
Easily manage the IPLink VPN Routers via a sim-
ple web browser interface.
Internal/external
and AC/DC
power
VPN & QoS software comes standard
10/100 LAN Ethernet
switch with full-
duplex and auto
MDI/MDI-X
operation
10/100 Ethernet WAN
with full-duplex and
auto MDI/MDI-X
operation
Front panel LEDs
show operational
status at a glance
Proven Patton design

07M2800-ENET-DS2
Features
Specifications*
Patton is a registered trademark of Patton
Electronics Company in the United States and
other countries.
* Specifications subject to change without notice.
IPLink VPN Routers are next-generation security appliances that address the needs of business
users by integrating QoS into a one-box solution. By including QoS, broadband connections
can be put to dual-use without impacting the quality of business data flows.
✔VPN tunneling secures IP network tra-
versal.
•IPSec encryption supporting AH and ESP
provides data integrity, authentication,
anti-replay and data confidentiality.
✔256-bit encryption protects data.
•With support for DES, 3DES, and AES,
data can be encrypted using 56 to 256-
bit algorithms, right-sizing security to
resources.
✔QoS/CoS profiles
•QoS/CoS guarantees traffic priority.
•ToS/DiffServ labeling
•Eight service class tags per IEEE
802.1p/Q
•Per flow bandwidth guarantees
•Hierarchical traffic classes
•Configurable burst tolerance
•Excess traffic discard
•Configurable packet and frame frag-
mentation to minimize jitter.
WAN Ethernet port
2802 & 2805: 10/100BaseT (RJ-45 con-
nector); auto-negotiating; half/full duplex
operation with automatic MDI/MDI-X
LAN Ethernet Ports
2802: 10/100BaseT (RJ-45 connector);
auto-negotiating; half or full duplex oper-
ation with automatic MDI/MDI-X
2805: 4 port 10/100BaseT switch (RJ-45
connector); auto-negotiating; half/full
duplex operation with automatic
MDI/MDI-X
Management
CLI via Telnet; TFTP for Software
upgrade and configuration upload;
SNMPv1; HTTP/web browser
Protocols
IP (RFC 741), TCP (RFC 793), UDP (RFC
768), ICMP & ICMP Redirect (RFC 792),
ARP (RFC 826). IP Router with RIPv1
(RFC 1058), RIPv2 (RFC 2453), pro-
grammable static routes. Integrated
DHCP Server (RFC 2131), DNS Relay
(RFC 1631), IEEE 802.1p VLAN Tagging,
NAT/NAPT (RFC 1631/2391)
Security
IPSec including AH and ESP. DES, 3DES,
and AES encryption. Access Control
Lists (ACLs). IP port and address filter-
ing both by source and destination. DoS
Detection. Password protected system
management with a username/password
for console and virtual terminal.
Power Supplies
External universal 90–260 VAC input or
48 VDC input. (Optional Internal univer-
sal 90–260 VAC input.)
Compliance
CE Mark; Safety: UL60950-1, CSA 22.2
6095001, IEC/EN60950-1. Universal AC
units are US NRTL Listed; EMC
Emissions: FCC Part 15 Class A;
EN55022 Class A; EMC Immunity:
EN55024
Environment
Operating temperature: 0-40°C (32-104
°F); Humidity: 5-80% non-condensing
Dimensions & Weight
7.3W x 1.6H x 6.1D in.
(18.5H x 4.1W x 15.5D cm)
30.5 oz./500g (models with internal
power); 24.4 oz./400g (models with
external power; no power supply)
2802/UI
2802/EUI
2805/UI
2805/EUI
Order Information
