Payne PA13NAZ Operation manual

PA13NAZ
Product Data
DUCTED CONDENSING UNITS
Sizes 018 To 060
1.5 To 5 Nominal Tons
A08379
INDUSTRY LEADING
FEATURES / BENEFITS
Energy Efficiency
S13 -- 14.5 SEER/ 11 -- 12 EER
Sound
SLevels as low as 70 dBA
Design Features
SSmall footprint, same as old model and “stackable”
SAll steel cabinet construction
SBaked on powder paint
SMesh coil guard
Reliability, Quality and Toughness
SScroll compressor
SFactory--supplied filter drier
SHigh pressure switch
SLine lengths up to 250 ft (76 m)
SLow ambient operation (down to --20_F/--28.9_C) with
low ambient accessories.

2
MODEL NUMBER NOMENCLATURE
PA13 N AA
018
Air Conditioner
Electrical Supply
N--- 208/230 ---60 ---1
P--- 208/230 ---60 ---3
E--- 4 6 0 --- 6 0 --- 3
Variations
Nominal Capacity
018 --- 1 --- 1 / 2 To n
024 --- 2 To n s
030 --- 2 --- 1 / 2 To n s
036 --- 3 To n s
048 --- 4 To n
060 --- 5 To n
A
Refrigerant
A --- R---410a
A
Variations
A
Series
000
000 --- V a r i a t i o n s
00G --- D e n s e G r il l e
Z
Z --- C M X
PHYSICAL DATA
UNIT PA13NAZ 018--B 024 --B 030--A 036--A 048--B 060 --B
NOMINAL CAPACITY (Tons) 1.5 2.0 2.50 3.0 4.0 5.0
OPERATING WEIGHT lb (kg) 155 (70.3) 180 (81.6) 200 (90.7) 218 (98.9) 284 (128.8) 294 (133.4)
REFRIGERANT TYPE R--- 410A
METERING DEVICE TXV
CHARGE lb (kg) 6.3 (2.86) 6.0 (2.73) 8.7 (3.95) 8.7 (3.95) 11.5 (5.23) 12.0 (5.45)
COMPRESSOR
Type Scroll
O i l C h a r g e ( P O E --- o z ) 25.0 25.0 25.0 25.0 42.0 42.0
Crankcase Heater (watts) — — 40 40 40 40
OUTDOOR FAN
Rpm/Cfm 840/1720 840/1720 850/3900 850/3900 850/3900 850/3900
Diameter in. (mm) 18 (457) 18 (457) 24 (610) 24 (610) 24 (610) 24 (610)
No. Blades 3 3 3 3 3 3
Motor hp (w) 1/8 (93) 1/8 (93) 1/4 (187) 1/4 (187) 1/4 (187) 1/4 (187)
OUTDOOR COIL
Face Area (sq ft) 5.8 7.3 12.1 12.1 14.1 14.1
No. Rows 2 2 2 2 2 2
FPI 20 20 20 20 20 20
HIGH PRESSURE SWITCH
Cut --- In (psig) Cutout (psig) 420 ±25
650 ±10
420 ±25
650 ±10
420 ±25
650 ±10
420 ±25
650 ±10
420 ±25
650 ±10
420 ±25
650 ±10
REFRIGERANT LINES
Connection Type Sweat
Max. Liquid Line* (in.) OD 3/8 3/8 3/8 3/8 3/8 3/8
Rated Vapor Line†(in.) OD 5/8 5/8 3/4 3/4 7/81 --- 1 / 8 * *
CONTROLS
Control Voltage}24 vac
System Voltage 208/230 v 208/230 v 208/230 v 208/230 v, Single and 3 Phase, 460 v, 3 Phase
FINISH Gray
*SeeLiquid Line Sizing For Cooling Only Systems with R --- 410A Refrigerant tables.
{Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
}24 v and a minimum of 40 va is provided in the fan coil unit.
** Vapor connection size is 7/8 inch.
FPI --- Fins Per Inch
POE --- Po l y o l E s t e r
PA13NAZ

3
REFRIGERANT PIPING LENGTH LIMITATIONS
Liquid Line Sizing and Maximum Total Equivalent Lengths{for Cooling Only Systems with R--410A Refrigerant:
The maximum allowable length of a residential split system depends on the liquid line diameter and vertical separation between indoor and
outdoor units.
See Table below for liquid line sizing and maximum lengths :
Maximum Total Equivalent Length
Outdoor Unit BELOW Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with R--- 410A Refrigerant Maximum Total Equivalent Length{: Outdoor unit BELOW Indoor
Vertical Separation ft (m)
0 --- 5
(0---1.5)
6 --- 1 0
(1.8--- 3.0)
11---20
(3.4--- 6.1)
21---30
(6.4--- 9.1)
31---40
(9.4--- 12.2)
41---50
(12.5---15.2)
51---60
(15.5---18.3)
61---70
(18.6---21.3)
71---80
(21.6---24.4)
018
AC with
R---410A
3/8
1/4 150 150 125 100 100 75 --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 225* 150
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
024
AC with
R---410A
3/8
1/4 75 75 75 50 50 --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 225* 175 125 100
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
030
AC with
R---410A
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 175 225* 200 175 125 100 75 --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
036
AC with
R---410A
3/8 5/16 175 150 150 100 100 100 75 --- --- --- ---
3//8 250* 250* 250* 250* 250* 250* 250* 250* 250*
048
AC with
R---410A
3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---
060
AC with
R---410A
3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
Maximum Total Equivalent Length
Outdoor Unit ABOVE Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/ TXV
AC with R--- 410A Refrigerant Maximum Total Equivalent Length{: Outdoor unit ABOVE Indoor
Vertical Separation ft (m)
25
(7.6)
26---50
(7.9--- 15.2)
51---75
(15.5---22.9)
76---100
(23.2---30.5)
101---125
(30.8---38.1)
126---150
(38.4---45.7)
151---175
(46.0---53.3)
176---200
(53.6---61.0)
018
AC with
R---410A
3/8
1/4 175 250* 250* 250* 250* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
024
AC with
R---410A
3/8
1/4 100 125 175 200 225* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
030
AC with
R---410A
3/8
1/4 30 --- --- --- --- --- --- --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
036
AC with
R---410A
3/8 5/16 225* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
048
AC with
R---410A
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
060
AC with
R---410A
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
PA13NAZ

4
REFRIGERANT CHARGE ADJUSTMENTS
Liquid Line Size R --- 410A Charge oz/ft (g/m)
3/8 0.60 (17.74)
(Factory charge for lineset = 9 oz / 266.16 g)
5/16 0.40 (11.83)
1/4 0.27 (7.98)
Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz (266.16 g). When using other length
or diameter liquid lines, charge adjustments are required per the chart above.
Charging Formula:
[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment
Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?
Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.
Net result is to remove 4.95 oz of refrigerant from the system
Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?
Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.
Net result is to add 9 oz of refrigerant to the system
LONG LINE APPLICATIONS
An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a system as long line
depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and outdoor units.
For Air Conditioner systems, the chart below shows when an application is considered Long Line.
AC WITH R--410ArREFRIGERANT LONG LINE DESCRIPTION ft (m)
Beyond these lengths, long line accessories are required
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
1/4 No accessories needed within allowed
lengths
No accessories needed within allowed
lengths 175 (53.3)
5/16 120 (36.6) 50 (15.2) vertical or 120 (36.6) total 120 (36.6)
3/8 80 (24.4) 35 (10.7) vertical or 80 24.4) total 80 (24.4)
Note: SeeLongLineGuidelinefordetails
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for AC systems with R--410A refrigerant:
Vapor Line Sizing and Cooling Capacity Losses — R--410ArRefrigerant 1--Stage Air Conditioner Applications
Unit
Nominal
Size (Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In. OD)
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
26 --- 50
(7.9--- 15.2)
51 --- 80
(15.5---24.4)
81 --- 100
(24.7---30.5)
101 --- 125
(30.8---38.1)
126 --- 150
(38.4---45.7)
151 --- 175
(46.0---53.3)
176 --- 200
(53.6---61.0)
201 --- 225
(61.3---68.6)
226 --- 250
(68.9---76.2)
018
1Stage
AC with
R --- 410A
3/8
1/2 1 2 3 5 6 7 8 9 11
5/8 0 1 1 1 2 2 2 3 3
3/4 0 0 0 0 1 1 1 1 1
024
1Stage
AC with
R --- 410A
3/8
5/8 0 1 2 2 3 3 4 5 5
3/4 0 0 1 1 1 1 1 2 2
7/8 0 0 0 0 0 1 1 1 1
030
1Stage
AC with
R --- 410A
3/8
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
036
1Stage
AC with
R --- 410A
3/8
5/8 1 2 4 5 6 8 9 10 12
3/4 0 1 1 2 2 3 3 4 4
7/8 0 0 0 1 1 1 1 2 2
048
1Stage
AC with
R --- 410A
3/8
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
11/8 0 0 0 0 0 0 0 1 1
060
1Stage
AC with
R --- 410A
3/8
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
11/8 0 0 0 1 1 1 1 1 1
Applications in this area may be long line and may have height restrictions. See the Residential Piping and Long Line Guideline.
PA13NAZ

5
ACCESSORIES
KIT NUMBER KIT NAME 018 024 030 036 048 060
KAACH1401AAA Crankcase Heater XXXX
KAACH1201AAA Crankcase Heater X X
KAACS0201PTC PTC Kit XXXXXX
KAAFT0101AAA Evaporator Freeze Stat XXXXXX
KAAHI0501PUR High Press. Switch XXXXXX
KAALP0401PUR Low Press. Switch XXXXXX
KAALS0201LLS Solenoid Valve XXXXXX
KAATD0101TDR Time Delay Relay XXXXXX
KAAWS0101AAA Winter Start Kit
(for low ambient) XXXXXX
KSACY0101AAA Cycle Protector XXXXXX
KSAHS1501AAA Hard Start Kit XXXXXX
KSASH1801COP Sound Blanket XXXX
KSASH0601COP Sound Blanket X X
KSALA0401410 Low Ambient Kit XXXXXX
KSATX0201PUR TXV XXX
KSATX0301PUR TXV X
KSATX0401PUR TXV X
KSATX0501PUR TXV X
5 3 D S --- 9 0 0 --- --- --- 0 7 0 Wind Baffle X
5 3 D S --- 9 0 0 --- --- --- 0 8 7 Wind Baffle X
5 3 D S --- 9 0 0 --- --- --- 0 7 1 Wind Baffle X X
5 3 D S --- 9 0 0 --- --- --- 0 8 8 Wind Baffle X X
5 3 D S --- 9 0 0 --- --- --- 0 7 5 Stacking Kit X X
5 3 D S --- 9 0 0 --- --- --- 0 7 6 Stacking Kit XXXX
5 3 D S --- 9 0 0 --- --- --- 0 7 7 Wall Mounting Kit X X
5 3 D S --- 9 0 0 --- --- --- 0 7 8 Wall Mounting Kit XXXX
X = Accessory, S = Standard
PA13NAZ

6
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW---AMBIENT
COOLING APPLICATIONS
(Below 55°F/12.8_C)
REQUIRED FOR
LONG LINE
APPLICATIONS*
(Over80ft./24.4m)
REQUIRED FOR
SEA COAST APPLICATIONS
(Within 2 miles / 3.2 km)
Compressor Start Assist Capacitor and Relay Ye s Ye s No
Crankcase Heater Ye s Ye s No
Evaporator Freeze Thermostat Ye s No No
Hard Shutoff TXV Ye s Ye s Ye s
Liquid Line Solenoid Valve No See Longline
Application Guideline No
Low---ambient Control Ye s No No
Winter Start Control Ye s No No
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 35 ft. (10.7 m) vertical differential, refer to Residential Piping and Longline Guideline.
Accessory Description and Usage (Listed Alphabetically)
1. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
2. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
3. Low--Ambient Control
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F±10_F (37.8_C±
5.5_C).
Usage Guideline:
A Low Ambient Controller must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
4. Outdoor Air Temperature Sensor
Designed for use with Payne Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Payne thermostats listed in this
publication.
5. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Accessory required to meet ARI rating and system
reliability, where indoor not equipped.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
6. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
Accessory required to meet ARI rating, where indoor
not equipped.
7. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
PA13NAZ

7
ELECTRICAL DATA
PA13NAZ
UNIT
SIZE V --- P H --- H z
VOLTAGE RANGE* COMPRESSOR OUTDOOR FAN MOTOR MIN
CKT
AMPS
FUSE/CKT
BKR AMPS
Min Max RLA LRA FLA NEC
Hp
kW
Out
018---A 208/230---1---60 187 253 9.0 48.0 0.8 0.125 0.09 12.1 20
024---B 208/230---1---60 187 253 13.5 58.3 0.8 0.125 0.09 17.7 25
030---A 208/230---1---60 187 253 14.1 73.0 1.5 0.250 0.19 19.1 30
036---A
208/230--- 1--- 60 187 253 14.1 77.0 1.5 0.250 0.19 19.1 30
208/230--- 3--- 60 187 253 9.2 71.0 1.5 0.250 0.19 13.0 20
4 6 0 --- 3 --- 6 0 414 506 5.6 38.0 0.8 0.250 0.19 7.9 10
048---B
208/230--- 1--- 60 187 253 19.9 109.0 1.5 0.250 0.19 26.4 40
208/230--- 3--- 60 187 253 13.1 83.1 1.5 0.250 0.19 17.9 25
4 6 0 --- 3 --- 6 0 414 506 6.1 41.0 0.8 0.250 0.19 8.4 15
060---B
208/230--- 1--- 60 187 253 26.4 134.0 1.5 0.250 0.19 34.5 60
208/230--- 3--- 60 187 253 15.0 110.0 1.5 0.250 0.19 21.5 30
4 6 0 --- 3 --- 6 0 414 506 7.8 52.0 0.8 0.250 0.19 10.6 15
* Permissible limits of the voltage range at which the unit will operate satisfactorily
FLA --- F u l l L o a d A m p s
HACR --- Heating, Air Conditioning, Refrigeration
LRA --- L o c k e d R o t o r A m p s
NEC --- National Electrical Code
RLA ---RatedLoadAmps(compressor)
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER LEVEL
Unit Size
Standard
Rating
(dBA)
Standard
Rating
(dBA)
With Sound
Blanket
Typical Octave Band Spectrum (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018 70 51.5 56.5 63.5 62.5 60.5 57.0 45.5
69 50.0 57.0 60.5 62.0 60.0 56.0 44.5
024 73 59.5 64.0 65.5 68.5 61.0 57.0 46.0
72 56.0 64.0 66.0 69.0 62.5 58.0 47.5
030 74 58.5 62.0 65.5 66.5 66.5 65.0 58.0
73 59.0 62.5 65.5 66.5 67.0 65.0 58.0
036 74 59.0 64.5 70.5 70.5 67.0 65.0 56.5
73 59.0 63.0 64.5 69.5 66.5 64.5 56.0
048 74 63.0 64.5 67.5 67.5 65.5 63.0 55.0
73 63.0 64.5 67.5 67.5 65.5 63.0 55.0
060 74 60.5 62.5 65.5 64.5 64.0 62.5 53.5
73 60.5 62.0 65.0 64.0 63.5 62.0 53.5
NOTE: Tested in accordance with ARI Standard 270---08 (not listed in ARI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE ---VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C)
018---A 12 (6.7)
024---B 12 (6.7)
030---A 12 (6.7)
036---A 12 (6.7)
048---B 12 (6.7)
060---B 12 (6.7)
PA13NAZ

8
DIMENSIONS -- ENGLISH
H
G
L
A
B
1"
8"
41/2"
1 7/16"
SERIES ELECTRICAL AB C D E F G H J KLMNP
OPERATING
WEIGHT(lbs)
SHIPPING
WEIGHT(lbs)
A X O O O 25 1/8" 36 15/16" 14 9/16" 16" 23 7/16" 17 3/16" 17 1/8" 22" 13" 6 5/8" 11 1/4" 5/8" 2 15/16" 6" 155 171
A,B X O O O 31 1/8" 36 15/16" 14 9/16" 16" 23 7/16" 17 3/16" 23 1/8" 28" 14" 6 3/4" 11 5/8" 5/8" 2 15/16" 6" 180 198
A X O O O 37 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 29 3/16" 34 1/16" 13 11/16" 8 1/8" 15 7/8" 3/4" 3 7/16" 6 1/2" 200 223 A X O X X 37 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 29 3/16" 34 1/16" 13 11/16" 8 1/8" 15 7/8" 3/4" 3 7/16" 6 1/2" 218 240
A,B X O X X 43 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 35 3/16" 40 1/16" 14 1/2" 8 1/2" 18 7/8" 7/8" 3 7/16" 6 1/2" 284 309 A,B X O X X 43 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 35 3/16" 40 1/16" 14 1/2" 8 1/2" 18 7/8" 7/8" 3 7/16" 6 1/2" 294 319 18,24 23" X 42"
30,36,48,60 24" X 50"
11/2"
FIELD CONTROL SUPPLY WIRE ENTRY 7/8" HOLE W/GROMMET
F, MAX. 125
X = YES O=NO
FEMALE SWEAT CONN.
VAPOR LINE CONN.
M
JUNCTION BOX FOR POWER SUPLLY AND CONTROL CONNECTIONS
4 3/16"
11/16"
J
K
N
P
E
FDC
71/2" 21/2"
N
AIR
AIR
PA13NAZ

9
DIMENSIONS -- SI
H
G
L
A
B
25.4
203.2
38.1
114.3
36.5
UNIT SERIES ELECTRICAL
CHARACTERISTICS AB C D E F G H J KLMNP
OPERATING
WEIGHT(KG)
SHIPPING
WEIGHT(KG)
SHIPPING
PA13AZ18 A X O O O 638.2 938.2 369.9 406.4 595.3 436.6 435.0 558.8 330.2 168.3 285.8 15.9 74.6 152.4 70.4 77.7 PA13AZ24 A,B X O O O 790.6 938.2 369.9 406.4 595.3 436.6 587.4 711.2 355.6 171.5 295.3 15.9 74.6 152.4 81.8 90.0 PA13AZ30 A X O O O 944.6 1131.9 433.4 468.3 774.7 498.5 741.4 865.2 347.7 206.4 403.2 19.0 87.3 165.1 90.9 101.4 PA13AZ36 A X O X X 944.6 1131.9 433.4 468.3 774.7 498.5 741.4 865.2 347.7 206.4 403.2 19.0 87.3 165.1 99.0 109.0 PA13AZ48 A,B X O X X 1097.0 1131.9 433.4 468.3 774.7 498.5 893.8 1017.6 368.3 215.9 479.4 22.2 87.3 165.1 129.0 140.4
A,B X O X X 1097.0 1131.9 433.4 468.3 774.7 498.5 893.8 1017.6 368.3 215.9 479.4 22.2 87.3 165.1 133.6 145.0
18,24
30,36,48,60
460-3-60
FIELD CONTROL SUPPLY WIRE ENTRY 22.22 HOLE W/GROMMET
9.53 LIQUID LINE
FEMALE SWEAT CONN.
X = YES O=NO
C, MAX. 51.7
FEMALE SWEAT CONN.
VAPOR LINE CONN.
M
JUNCTION BOX FOR POWER SUPLLY AND CONTROL CONNECTIONS
106.4
17.5
J
K
N
P
E
FDC
190.5 63.5
AIR
AIR
PA13NAZ

10
AHRI* COMBINATION RATINGS
ARI Ref. No. Model Number Indoor Model Furnace Model Capacity EER @ A** SEER
3092030 PA13NAZ18---A †CNPV*1814A**+TDR 17,000 11.0 13.0
3092031 PA13NAZ18---A CAP**1814A** PG8*EA024045 17,000 11.5 14.0
3092033 PA13NAZ18---A CAP**2414A** PG8*EA024045 17,400 12.0 14.5
3092032 PA13NAZ18---A CAP**2414A**+TDR 17,400 11.0 13.0
3095625 PA13NAZ18---A CAP**2417A** PG9MXA036060 17,400 12.0 14.5
3092034 PA13NAZ18---A CAP**2417A**+TDR 17,400 11.0 13.0
3092042 PA13NAZ18---A CNPF*2418A**+TDR 17,400 11.0 13.0
3092040 PA13NAZ18---A CNPH*2417A** PG8*EA024045 17,400 12.0 14.5
3092605 PA13NAZ18---A CNPH*2417A** PG9MTAV36050*A** 17,400 12.0 14.5
3092041 PA13NAZ18---A CNPH*2417A** PG9MTAV36075*A** 17,400 12.0 14.5
3095412 PA13NAZ18---A CNPH*2417A** PG9MXA036060 17,400 12.0 14.5
3092039 PA13NAZ18---A CNPH*2417A**+TDR 17,400 11.0 13.0
3092035 PA13NAZ18---A CNPV*1814A** PG8*EA024045 17,000 11.5 14.0
3092037 PA13NAZ18---A CNPV*2414A** PG8*EA024045 17,400 12.0 14.5
3092036 PA13NAZ18---A CNPV*2414A**+TDR 17,400 11.0 13.0
3095626 PA13NAZ18---A CNPV*2417A** PG9MXA036060 17,400 12.0 14.5
3092038 PA13NAZ18---A CNPV*2417A**+TDR 17,400 11.0 13.0
3092044 PA13NAZ18---A CSPH*2412A** PG8*EA024045 17,400 12.0 14.5
3092045 PA13NAZ18---A CSPH*2412A** PG9MTAV36050*A** 17,400 12.0 14.5
3092046 PA13NAZ18---A CSPH*2412A** PG9MTAV36075*A** 17,400 12.0 14.5
3095413 PA13NAZ18---A CSPH*2412A** PG9MXA036060 17,400 12.0 14.5
3092043 PA13NAZ18---A CSPH*2412A**+TDR 17,400 11.0 13.0
3092049 PA13NAZ18---A FF1ENP024 17,400 11.0 13.0
3092047 PA13NAZ18---A PF4MNA019 17,000 11.5 14.0
3092048 PA13NAZ18---A PF4MNA025 17,400 12.0 14.5
3466392 PA13NAZ24---B †CNPV*2414A**+TDR 23,400 11.0 13.0
3466394 PA13NAZ24---B CAP**2414A** PG8*EA024045 23,400 11.5 14.0
3466393 PA13NAZ24---B CAP**2414A**+TDR 23,400 11.0 13.0
3466396 PA13NAZ24---B CAP**2417A** PG9MXA036060 23,400 11.5 14.0
3466397 PA13NAZ24---B CAP**2417A** PG9MXA036080 23,400 11.5 14.0
3466395 PA13NAZ24---B CAP**2417A**+TDR 23,400 11.0 13.0
3466399 PA13NAZ24---B CAP**3014A** PG8*EA024045 23,600 12.0 14.5
3466398 PA13NAZ24---B CAP**3014A**+TDR 23,600 11.0 13.0
3466401 PA13NAZ24---B CAP**3017A** PG9MXA036060 23,600 12.0 14.5
3466402 PA13NAZ24---B CAP**3017A** PG9MXA036080 23,600 12.0 14.5
3466400 PA13NAZ24---B CAP**3017A**+TDR 23,600 11.0 13.0
3466428 PA13NAZ24---B CNPF*2418A**+TDR 23,400 11.0 13.0
3466413 PA13NAZ24---B CNPH*2417A** PG8*EA024045 23,400 11.5 14.0
3466416 PA13NAZ24---B CNPH*2417A** PG9MTAV36050*A** 23,400 11.5 14.0
3466417 PA13NAZ24---B CNPH*2417A** PG9MTAV36075*A** 23,400 11.5 14.0
3466418 PA13NAZ24---B CNPH*2417A** PG9MTAV60100*A** 23,400 11.5 14.0
3466419 PA13NAZ24---B CNPH*2417A** PG9MTAV60125*A** 23,400 11.5 14.0
3466414 PA13NAZ24---B CNPH*2417A** PG9MXA036060 23,400 11.5 14.0
3466415 PA13NAZ24---B CNPH*2417A** PG9MXA036080 23,400 11.5 14.0
3466412 PA13NAZ24---B CNPH*2417A**+TDR 23,400 11.0 13.0
3466421 PA13NAZ24---B CNPH*3017A** PG8*EA024045 23,600 12.0 14.5
3466424 PA13NAZ24---B CNPH*3017A** PG9MTAV36050*A** 23,600 12.0 14.5
3466425 PA13NAZ24---B CNPH*3017A** PG9MTAV36075*A** 23,600 12.0 14.5
3466426 PA13NAZ24---B CNPH*3017A** PG9MTAV60100*A** 23,600 12.0 14.5
3466427 PA13NAZ24---B CNPH*3017A** PG9MTAV60125*A** 23,600 12.0 14.5
3466422 PA13NAZ24---B CNPH*3017A** PG9MXA036060 23,600 12.0 14.5
3466423 PA13NAZ24---B CNPH*3017A** PG9MXA036080 23,600 12.0 14.5
3466420 PA13NAZ24---B CNPH*3017A**+TDR 23,600 11.0 13.0
3466403 PA13NAZ24---B CNPV*2414A** PG8*EA024045 23,400 11.5 14.0
3466405 PA13NAZ24---B CNPV*2417A** PG9MXA036060 23,400 11.5 14.0
3466406 PA13NAZ24---B CNPV*2417A** PG9MXA036080 23,400 11.5 14.0
3466404 PA13NAZ24---B CNPV*2417A**+TDR 23,400 11.0 13.0
3466408 PA13NAZ24---B CNPV*3014A** PG8*EA024045 23,600 12.0 14.5
3466407 PA13NAZ24---B CNPV*3014A**+TDR 23,600 11.0 13.0
3466410 PA13NAZ24---B CNPV*3017A** PG9MXA036060 23,600 12.0 14.5
3466411 PA13NAZ24---B CNPV*3017A** PG9MXA036080 23,600 12.0 14.5
3466409 PA13NAZ24---B CNPV*3017A**+TDR 23,600 11.0 13.0
3466872 PA13NAZ24---B CNPV*3117A** PG9MXA036060 23,800 12.0 14.5
3466873 PA13NAZ24---B CNPV*3117A** PG9MXA036080 23,800 12.0 14.5
3466871 PA13NAZ24---B CNPV*3117A**+TDR 23,800 11.0 13.0
3466430 PA13NAZ24---B CSPH*2412A** PG8*EA024045 23,400 11.5 14.0
3466433 PA13NAZ24---B CSPH*2412A** PG9MTAV36050*A** 23,400 11.5 14.0
3466434 PA13NAZ24---B CSPH*2412A** PG9MTAV36075*A** 23,400 11.5 14.0
3466435 PA13NAZ24---B CSPH*2412A** PG9MTAV60100*A** 23,400 11.5 14.0
3466436 PA13NAZ24---B CSPH*2412A** PG9MTAV60125*A** 23,400 11.5 14.0
3466431 PA13NAZ24---B CSPH*2412A** PG9MXA036060 23,400 11.5 15.0
3466432 PA13NAZ24---B CSPH*2412A** PG9MXA036080 23,400 11.5 14.0
3466429 PA13NAZ24---B CSPH*2412A**+TDR 23,400 11.0 13.0
3466438 PA13NAZ24---B CSPH*3012A** PG8*EA024045 23,600 12.0 14.5
3466441 PA13NAZ24---B CSPH*3012A** PG9MTAV36050*A** 23,600 12.0 14.5
3466442 PA13NAZ24---B CSPH*3012A** PG9MTAV36075*A** 23,600 12.0 14.5
3466443 PA13NAZ24---B CSPH*3012A** PG9MTAV60100*A** 23,600 12.0 14.5
3466444 PA13NAZ24---B CSPH*3012A** PG9MTAV60125*A** 23,600 12.0 14.5
See notes on page 21
PA13NAZ
