PCB Piezotronics 123B User manual

Model 123B
Rocket motor pressure probe, 3000 psi, 1 pC/psi, Helium bleed, water-cooled, M14 x 1.25 thd
(replaceable tubes)
Installation and Operating Manual
This manual contains the 5631-01 installation and operating manuals that comprise a Model
123B Rocket motor pressure probe, 3000 psi, 1 pC/psi, Helium bleed, water-cooled, M14 x
1.25 thd (replaceable tubes) kit.
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: [phone]
E-mail: [email protected]
Web: www.pcb.com

Manual 21354 Rev E
ECN 50523
Repair and Maintenance
PCB guarantees Total Customer Satisfaction through its
“Lifetime Warranty Plus” on all Platinum Stock Products
sold by PCB and through its limited warranties on all other
PCB Stock, Standard and Special products. Due to the
sophisticated nature of our sensors and associated
instrumentation, field servicing and repair is not
recommended and, if attempted, will void the factory
warranty.
Beyond routine calibration and battery replacements
where applicable, our products require no user
maintenance. Clean electrical connectors, housings, and
mounting surfaces with solutions and techniques that will
not harm the material of construction. Observe caution
when using liquids near devices that are not hermetically
sealed. Such devices should only be wiped with a
dampened cloth—never saturated or submerged.
In the event that equipment becomes damaged or ceases
to operate, our Application Engineers are here to support
your troubleshooting efforts 24 hours a day, 7 days a
week. Call or email with model and serial number as well
as a brief description of the problem.
Calibration
Routine calibration of sensors and associated
instrumentation is necessary to maintain measurement
accuracy. We recommend calibrating on an annual basis,
after exposure to any extreme environmental influence,
or prior to any critical test.
PCB Piezotronics is an ISO-9001 certified company whose
calibration services are accredited by A2LA to ISO/IEC
17025, with full traceability to SI through N.I.S.T. In
addition to our standard calibration services, we also offer
specialized tests, including: sensitivity at elevated or
cryogenic temperatures, phase response, extended high
or low frequency response, extended range, leak testing,
hydrostatic pressure testing, and others. For more
information, contact your local PCB Piezotronics
distributor, sales representative, or factory customer
service representative.
Returning Equipment
If factory repair is required, our representatives will
provide you with a Return Material Authorization (RMA)
number, which we use to reference any information you
have already provided and expedite the repair process.
This number should be clearly marked on the outside of
all returned package(s) and on any packing list(s)
accompanying the shipment.
Contact Information
PCB Piezotronics, Inc.
3425 Walden Ave.
Depew, NY14043 USA
Toll-free: [phone]
24-hour SensorLine: [phone]
General inquiries: in[email protected]
Repair inquiries: [e-mail]
For a complete list of distributors, global offices and sales
representatives, visit our website, www.pcb.com.
Safety Considerations
This product is intended for use by qualified personnel
who recognize shock hazards and are familiar with the
precautions required to avoid injury. While our equipment
is designed with user safety in mind, the protection
provided by the equipment may be impaired if equipment
is used in a manner not specified by this manual.
Discontinue use and contact our 24-Hour Sensorline if:
Assistance is needed to safely operate equipment
Damage is visible or suspected
Equipment fails or malfunctions
For complete equipment ratings, refer to the enclosed
specification sheet for your product.
Definition of Terms and Symbols
The following symbols may be used in this manual:
DANGER
Indicates an immediate hazardous
situation, which, if not avoided, may
result in death or serious injury.

Manual 21354 Rev E
ECN 50523
CAUTION
Refers to hazards that could damage
the instrument.
NOTE
Indicates tips, recommendations and
important information. The notes
simplify processes and contain
additional information on particular
operating steps.
The following symbols may be found on the equipment
described in this manual:
This symbol on the unit indicates that
high voltage may be present. Use
standard safety precautions to avoid
personal contact with this voltage.
This symbol on the unit indicates that
the user should refer to the operating
instructions located in the manual.
This symbol indicates safety, earth
ground.

Manual 21354 Rev E
ECN 50523
PCB工业监视和测量设备 - 中国RoHS2公布表
PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table
部件名称
有害物质
铅(Pb)
汞
(Hg)
镉
(Cd)
六价铬(Cr(VI))
多溴联苯 (PBB)
多溴二苯醚(PBDE)
住房
O
O
O
O
O
O
PCB板
X
O
O
O
O
O
电气连接器
O
O
O
O
O
O
压电晶体
X
O
O
O
O
O
环氧
O
O
O
O
O
O
铁氟龙
O
O
O
O
O
O
电子
O
O
O
O
O
O
厚膜基板
O
O
X
O
O
O
电线
O
O
O
O
O
O
电缆
X
O
O
O
O
O
塑料
O
O
O
O
O
O
焊接
X
O
O
O
O
O
铜合金/黄铜
X
O
O
O
O
O
本表格依据 SJ/T 11364 的规定编制。
O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。
CHINA RoHS COMPLIANCE

Manual 21354 Rev E
ECN 50523
Component Name
Hazardous Substances
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Chromium VI
Compounds
(Cr(VI))
Polybrominated
Biphenyls (PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
Housing
O
O
O
O
O
O
PCB Board
X
O
O
O
O
O
Electrical Connectors
O
O
O
O
O
O
Piezoelectric Crystals
X
O
O
O
O
O
Epoxy
O
O
O
O
O
O
Teflon
O
O
O
O
O
O
Electronics
O
O
O
O
O
O
Thick Film Substrate
O
O
X
O
O
O
Wires
O
O
O
O
O
O
Cables
X
O
O
O
O
O
Plastic
O
O
O
O
O
O
Solder
X
O
O
O
O
O
Copper Alloy/Brass
X
O
O
O
O
O
This table is prepared in accordance with the provisions of SJ/T 11364.
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB/T 26572.
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above the limit
requirement of GB/T 26572.
Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.

Drawing Number: 21091 ECO: 52570
Revision: B
OPERATION MANUAL FOR
HELIUM BLEED WATER-COOLED
PRESSURE SENSORS
123 Series
1
1.0 INTRODUCTION
The series of sensors described in this guide is
designed to measure dynamic pressures in intense
thermal environments typified by rocket engine
combustion chambers.
These sensors feature acceleration-compensated
piezoelectric pressure probes mounted in a helium
bleed adaptor with water cooling.
The helium gas, applied from a 1500 psi source, is
metered by a built-in orifice and flows around the
probe body and out the passage of the adaptor head of
the probe diaphragm. The helium gas flowing out the
passage protects the sensor diaphragm from the hot
gasses as well as increasing the natural frequency of
the passage by a factor of approximately three to one.
2.0 DESCRIPTION
The charge-mode models contain a one pC/psi
pressure probe (sensor) and is designed to be used
with electrostatic charge amplifiers.
The ICP®Models contain built-in impedance
converter electronics circuits which convert the high-
impedance voltage from the quartz crystal to a low-
impedance voltage signal that can be fed directly into
most common indicating or recording instruments.
The 123 Series sensors contain a 10 micro helium
filter contained in a fitting threaded onto the helium
input tube. The purpose of this filter is to prevent
particles in the helium supply from plugging the
metering orifice.
The outer body of this series is 17-4 PH hardened
stainless steel and features a ceramic-coated tip for
protection against erosion by hot gasses when the
sensor is flush-mounted directly in combustion
chambers.
The probes in all models are electrically ground
isolated from the outer housing.
NOTE: The sensor probe in this series is factory
installed at a precise depth in the outer body. Do not
attempt removal of this probe. Contact the factory
should any questions or problems arise concerning
the sensor probe.
123 Series: Water- Cooled & Helium Bleed
Rocket Motor, ICP®and Charge Sensors
3.0 INSTALLATION
Prepare mounting port in accordance with
instructions on the installation drawing
Inspect the mounting port for burrs and tool marks at
the seal surface.
Use recommended mounting torque when installing
sensors. Do not over torque as damage to seal
surface could result.
NOTE: When attaching helium supply hose, do not
torque hose fitting through helium tube on sensor.
Back up fitting with wrench on 3/8 hex on helium
hose fitting. (Refer to note 3 on installation drawing.)
Especially in the presence of high vibration, support
helium supply tubes by clamping to rigid surfaces
with adequate strain relief loop to avoid stressing
helium tube on sensor.
Follow the same procedures and apply similar
precautions when installing the water supply and
drain hoses. Either water tube may be used as the

Drawing Number: 21091 ECO: 52570
Revision: B
OPERATION MANUAL FOR
HELIUM BLEED WATER-COOLED
PRESSURE SENSORS
123 Series
2
inlet tube. Use at least a 50 psi source of clean water
for cooling.
For charge-mode models, connect 4 ft. cable to
charge amplifier and switch to "LONG" time constant
position and check for drift.
Clean cable connections with Trycloror equivalent
solvent to restore insulation resistance.
It is good practice to depress ground button (or place
switch in "GND" position) on the charge amplifier
while attaching input cables to the amplifier. This
will prevent spurious charges which may accumulate
on sensors and cables from blowing out the input
circuitry of the charge amplifier.
Since the charge output sensors are susceptible to
decreased insulation resistance, use care to keep cable
connections clean by use of shrink tubing wherever
possible.
The ICP®Series Sensors use low-output impedance
probes (ICP) and will not require the insulation
resistance cautions previously described for the
charge-mode models.
Connect the sensor cable to the appropriate ICP
power unit and check the front panel monitor meter to
check cable connections and internal amplifier.
Consult Guide G-0001B, "General Guide to ICP
Instrumentation" for installation and usage hints for
ICPinstruments.
4.0 OPERATION
4.1 CHARGE OUTPUT MODEL
For the charge-mode, it is only necessary to select the
proper range on the charge amplifier and proceed
with the measurement.
The probe sensitivity is approximately 1.0 pC/psi.
(The exact sensitivity is given on the calibration
certificate supplied with each instrument.)
Sensor connection for ICP®operation
EXAMPLE: The dynamic pressure expected is 500
psi and the desired output voltage for this pressure is
1 volt.
Simply set the range switch of the charge amplifier to
500 units per volt and dial the standardization pot to
the exact sensor sensitivity at 500 psi (from
calibration graph).
The system will then yield exactly 1 volt for 500 psi
of input pressure (dynamic).
4.2 TIME CONSTANT
During in-place calibration static methods (dead
weight tester) may be used in a drift-free system by
placing the charge amplifier in "LONG TC" position.
However, during actual use, the TC mode switch
should be in "SHORT" position for two reasons.
Often times, the dynamic pressure being measured
exists superimposed upon a higher static level. The
short TC position will allow the effect of this static

Drawing Number: 21091 ECO: 52570
Revision: B
OPERATION MANUAL FOR
HELIUM BLEED WATER-COOLED
PRESSURE SENSORS
123 Series
3
level to zero out quickly without effect on the
dynamic level indicated.
Also, the influx of large amounts of thermal energy,
as in rocket combustion measurements, can cause the
sensor to generate spurious transient outputs of
considerable magnitude. Using the charge amplifier
on "SHORT" TC alleviates this problem by shunting
these longer term charge outputs to ground while
measuring the faster dynamic pressure pulses.
4.3 OPERATION - ICPMODELS
Consult Guide G-0001B for a complete description of
the low-impedance concept in instrumentation.
All PCB power units designed for ICPuse contain
built-in fault monitor meters to aid in locating circuit
faults (shorts or opens) and to identify normal
operation of the miniature impedance-converting
amplifier built into the sensor.
Do not attempt to apply voltage directly to the input
pin of the sensor from any other power source. The
input current must be limited to 20 mA maximum and
the input voltage must not be higher than 28 VDC.
Consult the factory if it is desired to build a power
unit rather than to use one of those available from
PCB.
NOTE: Full-scale range is 1imited by the helium
source pressure. The applied helium source pressure
level must be at least twice the peak combustion
pressure (not to exceed 15,000 psi), and not more
than 10 times the lowest expected peak combustion
pressure. This is true for all models, charge or ICP.
5.0 CALIBRATION
5.1 CHARGE MODEL
To calibrate this model, install in pressure port of
dead weight tester and apply various static pressures,
recording corresponding outputs at each pressure of
interest.
Discharge the charge amplifier before each reading
and return pressure to zero before each new pressure
input. Use the charge amplifier on “LONG” time
constant and keep cables and connections clean to
avoid drift. A DC digital voltmeter is ideal for
readout during calibration.
NOTE: The helium tube must be plugged with a
pressure-tight seal before attempting to calibrate to
avoid losing pressure through the helium tube.
If a hydraulic calibration system is used, be sure to
remove all traces of oil from the diaphragm passage
after calibration. Pneumatic systems are preferred for
calibration.
5.2 ICPMODELS
Because of the shorter time constants built into these
models, static calibration methods are much more
difficult to use. Pressures must be applied rapidly
and readout must be made with fast recording devices
such as light beam oscillographs or storage
oscilloscopes.
A pneumatic (compressed air or hydrogen) system
with quick opening valve and reference gage is an
excellent method of calibrating these sensors.
MAINTENANCE
The sealed construction and miniature size of these
sensors make field repair impractical.
The helium filter element should be cleaned should
the flow rate decrease. Remove the element and
ultrasonically agitate in solvent for 15 minutes, then
dry.
Should the orifice become plugged, back pressure the
orifice by applying air pressure to diaphragm end of
sensor with filter off and helium tube vented to
atmosphere.
The only maintenance possible on the probe is
maintaining of insulation resistance of the charge
mode models. Clean connectors with suitable solvent
and dry.
Contact factory for assistance should problems arise.
ICP is a registered trademark of PCB Piezotronics

Model Number
123B CHARGE OUTPUT PRESSURE SENSOR Revision: A
ECN #: 53892
Performan ce EN GL ISH SI
Sensitivity(± 20 %) 1.1 pC/psi 0.159 pC/kPa
Measurement Range 3,000 psi 20,685 kPa
Maximum Pressure 5,000 psi 34,475 kPa
Resolution 0.02 psi 0.138 kPa [1]
Resonant Frequency ≥ 25 kHz ≥ 25 kHz [2]
Rise Time(Reflected) ≤ 20 µ sec ≤ 20 µ sec [2]
Non-Linearity ≤ 1 % FS ≤ 1 % FS [3]
Environm en tal
Acceleration Sensitivity ≤ 0.002 psi/g ≤ 1.41E-3 kPa/(m/s²)
Temperature Range(Operating) -100 to +500 °F -73 to +260 °C
Temperature Coefficient of Sensitivity ≤ 0.01 %/°F ≤ 0.018 %/°C
Maximum Flash Temperature 10,000 °F 5,538 °C
Maximum Shock 10,000 g pk 98,070 m/s² pk
Electrical
Capacitance 150 pF 150 pF [4]
Electrical Isolation ≥ 108 Ohm ≥ 108 Ohm
Insulation Resistance(at room temp) ≥ 1012 Ohm ≥ 1012 Ohm
Ph ysical
Sensing Element Quartz Quartz
Sensing Geometry Compression Compression
Housing Material 17-4 Stainless Steel 17-4 Stainless Steel
Diaphragm Invar Invar
Sealing Epoxy Epoxy
Electrical Connector Integral Cable Integral Cable
Cable Length 4 ft 1.2 m
Helium Flow Rate(at 1,500 psi) 40 scf/hr 1.13 m³/hr
Water Flow Rate(at 50 psi) 1.2 gal/min 4.5 L/min
Weight(with cable) 5.54 oz 157 gm
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
OPTION A L VERSION S
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
NOTES:
[1]Resolution dependent on range setting and cable length used in charge system.
[2]With helium flow.
[3]Zero-based, least-squares, straight line method.
[4]Typical; with cable.
[5]See PCB Declaration of Conformance PS158 for details.
Date: 06/05/2023 Date: 06/05/2023 Date: 06/05/2023 Date: 06/05/2023 72185
Entered: ND Engineer: AK Sales: RWM Approved: RPF Spec Number:
Phone: [phone]
Fax: [phone]
E-Mail: i[email protected]
3425 Walden Avenue, Depew, NY 14043
SUPPLIED ACCESSORIES:
Model 065A15 Seal, .624" OD x .553" ID x .080", brass (3)
Model 065A72 Water cooling tubes (o-ring sealed) (2)
Model 070A08 Cable adaptor (micro 10-32 jack to BNC jack) (1)

Model 5631-01
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: [phone]
E-mail: [email protected]
Web: www.pcb.com

Manual 21354 Rev E
ECN 50523
Repair and Maintenance
PCB guarantees Total Customer Satisfaction through its
“Lifetime Warranty Plus” on all Platinum Stock Products
sold by PCB and through its limited warranties on all other
PCB Stock, Standard and Special products. Due to the
sophisticated nature of our sensors and associated
instrumentation, field servicing and repair is not
recommended and, if attempted, will void the factory
warranty.
Beyond routine calibration and battery replacements
where applicable, our products require no user
maintenance. Clean electrical connectors, housings, and
mounting surfaces with solutions and techniques that will
not harm the material of construction. Observe caution
when using liquids near devices that are not hermetically
sealed. Such devices should only be wiped with a
dampened cloth—never saturated or submerged.
In the event that equipment becomes damaged or ceases
to operate, our Application Engineers are here to support
your troubleshooting efforts 24 hours a day, 7 days a
week. Call or email with model and serial number as well
as a brief description of the problem.
Calibration
Routine calibration of sensors and associated
instrumentation is necessary to maintain measurement
accuracy. We recommend calibrating on an annual basis,
after exposure to any extreme environmental influence,
or prior to any critical test.
PCB Piezotronics is an ISO-9001 certified company whose
calibration services are accredited by A2LA to ISO/IEC
17025, with full traceability to SI through N.I.S.T. In
addition to our standard calibration services, we also offer
specialized tests, including: sensitivity at elevated or
cryogenic temperatures, phase response, extended high
or low frequency response, extended range, leak testing,
hydrostatic pressure testing, and others. For more
information, contact your local PCB Piezotronics
distributor, sales representative, or factory customer
service representative.
Returning Equipment
If factory repair is required, our representatives will
provide you with a Return Material Authorization (RMA)
number, which we use to reference any information you
have already provided and expedite the repair process.
This number should be clearly marked on the outside of
all returned package(s) and on any packing list(s)
accompanying the shipment.
Contact Information
PCB Piezotronics, Inc.
3425 Walden Ave.
Depew, NY14043 USA
Toll-free: [phone]
24-hour SensorLine: [phone]
General inquiries: in[email protected]
Repair inquiries: [e-mail]
For a complete list of distributors, global offices and sales
representatives, visit our website, www.pcb.com.
Safety Considerations
This product is intended for use by qualified personnel
who recognize shock hazards and are familiar with the
precautions required to avoid injury. While our equipment
is designed with user safety in mind, the protection
provided by the equipment may be impaired if equipment
is used in a manner not specified by this manual.
Discontinue use and contact our 24-Hour Sensorline if:
Assistance is needed to safely operate equipment
Damage is visible or suspected
Equipment fails or malfunctions
For complete equipment ratings, refer to the enclosed
specification sheet for your product.
Definition of Terms and Symbols
The following symbols may be used in this manual:
DANGER
Indicates an immediate hazardous
situation, which, if not avoided, may
result in death or serious injury.

Manual 21354 Rev E
ECN 50523
CAUTION
Refers to hazards that could damage
the instrument.
NOTE
Indicates tips, recommendations and
important information. The notes
simplify processes and contain
additional information on particular
operating steps.
The following symbols may be found on the equipment
described in this manual:
This symbol on the unit indicates that
high voltage may be present. Use
standard safety precautions to avoid
personal contact with this voltage.
This symbol on the unit indicates that
the user should refer to the operating
instructions located in the manual.
This symbol indicates safety, earth
ground.

Manual 21354 Rev E
ECN 50523
PCB工业监视和测量设备 - 中国RoHS2公布表
PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table
部件名称
有害物质
铅(Pb)
汞
(Hg)
镉
(Cd)
六价铬(Cr(VI))
多溴联苯 (PBB)
多溴二苯醚(PBDE)
住房
O
O
O
O
O
O
PCB板
X
O
O
O
O
O
电气连接器
O
O
O
O
O
O
压电晶体
X
O
O
O
O
O
环氧
O
O
O
O
O
O
铁氟龙
O
O
O
O
O
O
电子
O
O
O
O
O
O
厚膜基板
O
O
X
O
O
O
电线
O
O
O
O
O
O
电缆
X
O
O
O
O
O
塑料
O
O
O
O
O
O
焊接
X
O
O
O
O
O
铜合金/黄铜
X
O
O
O
O
O
本表格依据 SJ/T 11364 的规定编制。
O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。
CHINA RoHS COMPLIANCE

Manual 21354 Rev E
ECN 50523
Component Name
Hazardous Substances
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Chromium VI
Compounds
(Cr(VI))
Polybrominated
Biphenyls (PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
Housing
O
O
O
O
O
O
PCB Board
X
O
O
O
O
O
Electrical Connectors
O
O
O
O
O
O
Piezoelectric Crystals
X
O
O
O
O
O
Epoxy
O
O
O
O
O
O
Teflon
O
O
O
O
O
O
Electronics
O
O
O
O
O
O
Thick Film Substrate
O
O
X
O
O
O
Wires
O
O
O
O
O
O
Cables
X
O
O
O
O
O
Plastic
O
O
O
O
O
O
Solder
X
O
O
O
O
O
Copper Alloy/Brass
X
O
O
O
O
O
This table is prepared in accordance with the provisions of SJ/T 11364.
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB/T 26572.
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above the limit
requirement of GB/T 26572.
Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.

Model Number
44986-01 PRESSURE ELEMENT Revision: NR
ECN #: 52201
Performan ce EN GL ISH SI
Sensitivity 0.00 pC/psi 0.00 pC/kPa
Measurement Range 10,000 psi 34,475 kPa [1]
Cycle Pressure 16,000 psi 110,000 kPa
Maximum Pressure(Total) 15,000 psi 103,421 kPa
Environm en tal
Temperature Range(Operating) -100 to +275 °F -73 to +135 °C
Electrical
Output Polarity(Positive) Positive Positive
Capacitance 7 to 15 pF 7 to 15 pF
Insulation Resistance(Room Temp.) ≥ 1012 Ohm ≥ 1012 Ohm
Ph ysical
Sensing Element Quartz Quartz
Sensing Geometry Compression Compression
Housing Material 17-4 Stainless Steel 17-4 Stainless Steel
Diaphragm Invar Invar
Sealing Epoxy Epoxy
Electrical Connector 10-32 Coaxial Jack 10-32 Coaxial Jack
Mounting Torque 23 to 35 in-lb 26.4 to 40.3 kg-cm [2]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
OPTION A L VERSION S
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
NOTES:
[1]Calibration step: 5,000 psi.
[2]When used with standard mounting hardware.
Date: 11/08/2021 Date: 11/08/2021 Date: Date: 11/08/2021 72709
Entered: ND Engineer: NJL Sales: Approved: RPF Spec Number:
PCB Internal Use Only

Model 123B
Rocket motor pressure probe, 3000 psi, 1 pC/psi, Helium bleed, water-cooled, M14 x 1.25 thd
(replaceable tubes)
Installation and Operating Manual
This manual contains the 5631-01 installation and operating manuals that comprise a Model
123B Rocket motor pressure probe, 3000 psi, 1 pC/psi, Helium bleed, water-cooled, M14 x
1.25 thd (replaceable tubes) kit.
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: [phone]
E-mail: [email protected]
Web: www.pcb.com

Manual 21354 Rev E
ECN 50523
Repair and Maintenance
PCB guarantees Total Customer Satisfaction through its
“Lifetime Warranty Plus” on all Platinum Stock Products
sold by PCB and through its limited warranties on all other
PCB Stock, Standard and Special products. Due to the
sophisticated nature of our sensors and associated
instrumentation, field servicing and repair is not
recommended and, if attempted, will void the factory
warranty.
Beyond routine calibration and battery replacements
where applicable, our products require no user
maintenance. Clean electrical connectors, housings, and
mounting surfaces with solutions and techniques that will
not harm the material of construction. Observe caution
when using liquids near devices that are not hermetically
sealed. Such devices should only be wiped with a
dampened cloth—never saturated or submerged.
In the event that equipment becomes damaged or ceases
to operate, our Application Engineers are here to support
your troubleshooting efforts 24 hours a day, 7 days a
week. Call or email with model and serial number as well
as a brief description of the problem.
Calibration
Routine calibration of sensors and associated
instrumentation is necessary to maintain measurement
accuracy. We recommend calibrating on an annual basis,
after exposure to any extreme environmental influence,
or prior to any critical test.
PCB Piezotronics is an ISO-9001 certified company whose
calibration services are accredited by A2LA to ISO/IEC
17025, with full traceability to SI through N.I.S.T. In
addition to our standard calibration services, we also offer
specialized tests, including: sensitivity at elevated or
cryogenic temperatures, phase response, extended high
or low frequency response, extended range, leak testing,
hydrostatic pressure testing, and others. For more
information, contact your local PCB Piezotronics
distributor, sales representative, or factory customer
service representative.
Returning Equipment
If factory repair is required, our representatives will
provide you with a Return Material Authorization (RMA)
number, which we use to reference any information you
have already provided and expedite the repair process.
This number should be clearly marked on the outside of
all returned package(s) and on any packing list(s)
accompanying the shipment.
Contact Information
PCB Piezotronics, Inc.
3425 Walden Ave.
Depew, NY14043 USA
Toll-free: [phone]
24-hour SensorLine: [phone]
General inquiries: in[email protected]
Repair inquiries: [e-mail]
For a complete list of distributors, global offices and sales
representatives, visit our website, www.pcb.com.
Safety Considerations
This product is intended for use by qualified personnel
who recognize shock hazards and are familiar with the
precautions required to avoid injury. While our equipment
is designed with user safety in mind, the protection
provided by the equipment may be impaired if equipment
is used in a manner not specified by this manual.
Discontinue use and contact our 24-Hour Sensorline if:
Assistance is needed to safely operate equipment
Damage is visible or suspected
Equipment fails or malfunctions
For complete equipment ratings, refer to the enclosed
specification sheet for your product.
Definition of Terms and Symbols
The following symbols may be used in this manual:
DANGER
Indicates an immediate hazardous
situation, which, if not avoided, may
result in death or serious injury.

Manual 21354 Rev E
ECN 50523
CAUTION
Refers to hazards that could damage
the instrument.
NOTE
Indicates tips, recommendations and
important information. The notes
simplify processes and contain
additional information on particular
operating steps.
The following symbols may be found on the equipment
described in this manual:
This symbol on the unit indicates that
high voltage may be present. Use
standard safety precautions to avoid
personal contact with this voltage.
This symbol on the unit indicates that
the user should refer to the operating
instructions located in the manual.
This symbol indicates safety, earth
ground.

Manual 21354 Rev E
ECN 50523
PCB工业监视和测量设备 - 中国RoHS2公布表
PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table
部件名称
有害物质
铅(Pb)
汞
(Hg)
镉
(Cd)
六价铬(Cr(VI))
多溴联苯 (PBB)
多溴二苯醚(PBDE)
住房
O
O
O
O
O
O
PCB板
X
O
O
O
O
O
电气连接器
O
O
O
O
O
O
压电晶体
X
O
O
O
O
O
环氧
O
O
O
O
O
O
铁氟龙
O
O
O
O
O
O
电子
O
O
O
O
O
O
厚膜基板
O
O
X
O
O
O
电线
O
O
O
O
O
O
电缆
X
O
O
O
O
O
塑料
O
O
O
O
O
O
焊接
X
O
O
O
O
O
铜合金/黄铜
X
O
O
O
O
O
本表格依据 SJ/T 11364 的规定编制。
O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。
CHINA RoHS COMPLIANCE

Manual 21354 Rev E
ECN 50523
Component Name
Hazardous Substances
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Chromium VI
Compounds
(Cr(VI))
Polybrominated
Biphenyls (PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
Housing
O
O
O
O
O
O
PCB Board
X
O
O
O
O
O
Electrical Connectors
O
O
O
O
O
O
Piezoelectric Crystals
X
O
O
O
O
O
Epoxy
O
O
O
O
O
O
Teflon
O
O
O
O
O
O
Electronics
O
O
O
O
O
O
Thick Film Substrate
O
O
X
O
O
O
Wires
O
O
O
O
O
O
Cables
X
O
O
O
O
O
Plastic
O
O
O
O
O
O
Solder
X
O
O
O
O
O
Copper Alloy/Brass
X
O
O
O
O
O
This table is prepared in accordance with the provisions of SJ/T 11364.
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB/T 26572.
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above the limit
requirement of GB/T 26572.
Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.
