PCchips M909G Series User manual

i
MotherboardUser’sGuide
Thispublication,includingphotographs, illustrations and software,
is under the protection of international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without the express written
consent of the manufacturer.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
Intel, Pentium II/III, Pentium 4, Celeron and MMX are registered
trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows 98/ME/NT/2000/XPare
registered trademarks of Microsoft Corporation.
PC-cillin is a trademark of Trend Micro Inc.
AMI is a trademark of American Megatrends Inc.
It has been acknowledged that other brands or product names in
this manual are trademarks or the properties of their respective
owners.
Copyright © 2004
All Rights Reserved
M909G Series, V5.0
I845/August 2004

ii
MotherboardUser’sGuide
Table of Contents
Trademark ................................................................................... i
Static Electricity Precautions............................................................ iii
Pre-Installation Inspection ................................................................ iii
Features and Checklist Translation .................................................... v
Chapter 1: Introduction............................................................ 1
Key Features ........................................................................................2
Package Contents ................................................................................5
Chapter 2: Motherboard Installation ..................................... 6
Motherboard Components................................................................... 7
I/O Ports ...............................................................................................8
Installing the Processor .......................................................................9
Installing Memory Modules ...............................................................10
Jumper Settings ..................................................................................12
Install the Motherboard.....................................................................13
Connecting Optional Devices............................................................14
Install Other Devices..........................................................................17
Expansion Slots..................................................................................20
Chapter 3: BIOS Setup Utility............................................... 29
Running the Setup Utility ..................................................................30
Standard CMOS Setup Page .............................................................31
Advanced Setup Page ........................................................................32
Features Setup Page ..........................................................................33
Power Management Setup Page........................................................35
PCI/Plug and Play Setup Page..........................................................37
Load Optimal Settings .......................................................................38
Load Best Performance Settings ........................................................38
Features Setup Page ..........................................................................39
CPU PnP Setup Page .........................................................................41
Hardware Monitor Page....................................................................42
Change Password and Exit................................................................43
Chapter 4: Software & Applications ..................................... 44
Installing Support Software...............................................................45
Bundled Software Installation...........................................................47
Hyper- Threading CPU ......................................................................48
DualMonitor................................................................................................23

iii
MotherboardUser’sGuide
Static Electricity Precautions
Static electricity could damage components on this motherboard.
Take the following precautions while unpacking this motherboard
and installing it in a system.
1. Don’t take this mainboard and components out of their
original static-proof package until you are ready to install
them.
2. While installing, please wear a grounded wrist strap if
possible. If you don’t have a wrist strap, discharge static
electricity by touching the bare metal of the system chassis.
3. Carefully hold this motherboard by its edges. Do not touch
those components unless it is absolutely necessary. Put this
motherboard on the top of static-protection package with
component side facing up while installing.
Pre-Installation Inspection
1. Inspect this mainboard whether there are any damages to
components and connectors on the board.
2. If you suspect this mainboard has been damaged, do not
connect power to the system. Contact your motherboard
vendor about those damages.

iv
MotherboardUser’sGuide
Notice:
Owing to Microsoft’s certifying schedule is various to every
supplier, we might have some drivers not certified yet by
Microsoft. Therefore, it might happen under Windows XP that
a dialogue box (shown as below) pop out warning you this
software has not passed Windows Logo testing to verify its
compatibility with Windows XP. Please rest assured that our
RD department has already tested and verified these drivers.
Just click the “Continue Anyway” button and go ahead the
installation.

v
Motherboard User’s Guide
Traduction des Caractéristiques & Liste de contrôle
Liste de contrôle
Le coffret de votre carte mère contient les éléments suivants :
• La carte mère
• Le Manuel utilisateur
• Un câble plat pour lecteur de disquette (optionnel)
• Une câble plat pour lecteur IDE
• CD de support de logiciels
Caractéristiques
Prise en charge du Processeur Socket-478
• Supporte le CPU Intel Pentium 4 series avec/sans la Technologie Hyper-
Threading
• Supporte un Bus Avant allant jusqu’à 533/400 MHz
Chipset
Le chipset Intel 845GV/GL contient le Hub de Contrôleur de Mémoire Intel 82845
et le Hub (ICH4) de Contrôleur d’E/S Intel 82801DB I/O conformément à une
architecture novatrice et dimensionnable avec une abilité et des performances
prouvées. Voici une liste de l’organisation des chipset et de leurs caractéristiques
respectives :
Support de Mémoire
Le carte mère possède les caractéristiques suivantes :
AC’97 Codec
Logements d’Extension
• Conforme aux spécications AC’97 2.3
• Codec Full-duplex avec vitesse d’échantillonnage indépendante et variable
• Mémoire tampon d’Ecouteurs Intégrée, SNR jusqu’à 90db
• 6Ch DAC, supporte 6 canaux de sorties haut-parleurs
• Support de gestion d’alimentation avancée
• Un logement AGPro (reportez-vous à la page 20 pour plus de détails)
• Trois slots PCI 32 bits
• Un slot CNR (Communications and Networking Riser)
• Supporte maîtrise de bus Ultra DMA IDE avec vitesse de transfert de 100/
66/33 Mo/sec
Northbridge
845GV
845GL
Fonction
Supporte: CPU FSB: 533/400MHz
Technologie Hyper-Threading
DDR333/266; USB2.0; Ultra ATA 100/66/33
Supporte:CPU FSB: 533*/400MHz
DDR266; USB2.0; Ultra ATA 100/66/33
Ne supporte pas: Technologie Hyper-Threading
*: Surfréquençage
• Deux logements DIMM 184 broches pour DDR SDRAM modules mémoire
• Supporte les DDR jusqu’à 333MHz (845GV) ou le bus mémoire DDR266MHz
(845GL)
• La mémoire maximum installée est 2Go

vi
Motherboard User’s Guide
vii
Motherboard User’s Guide
Ports E/S Internes
La carte mère possède un jeu complet de ports d’E/S et de connecteurs:
• Deux ports PS/2 pour souris et clavier
• Un port série
• Un port VGA
• Un port parallèle
• Six ports USB (quatre ports fond de panier, prises USB internes offrant deux
ports supplémentaires)— USB2.0
• Prises audio pour microphone, ligne d’entrée et ligne de sortie
LAN Fast Ethernet (optionnel)
• Supporte le fonctionnement en 10/100Mb/s
• Fast Ethernet MAC Intégré
• Contrôleur Fast Ethernet à simple puce de bus local PCI
• Compatible à PCI Revision 2.2
• Supporte la gestion d’alimentation ACPI, PCI
• Conforme au standard PC99/PC2001
• Supporte un temporisateur général 32 bits avec l’horloge PCI externe comme
source d’horloge, pour générer l’interruption de temporisation
• Supporte le Contrôle de Flux Full Duplex (IEEE 802.3x)
USB 2.0
• Inclus trois contrôleurs d’hôte UHCI prenant en charge six ports externes
• Nouveau: Inclus un Contrôleur d’Hôte USB 2.0 haute vitesse EHCI prenant en
charge les six ports
• Nouveau: Prend en charge un port de débogage à haute vitesse USB 2.0
• Prend en charge l’éveil à partir des états de veille S1-S5
• Prend en charge le logiciel de clavier/souris patrimonial

vii
Motherboard User’s Guide
Funktionen & Checkliste
Checkliste
Die Verpackung Ihres Motherboards enthält folgende Teile:
• Motherboard
• Handbuch
• Bandkabel für Floppylaufwerke (optional)
• Bandkabel für IDE-Laufwerke
• Software -CD
Ausstattung
Unterstütz Socket-478-Prozessoren
• Unterstützung für Intel Pentium 4-CPUs mit/ohne “Hyper-Threading”-Tech-
nologie
• Unterstützung von bis zu 533/400 MHz Front-Side Bus
Chipsatz
Der Intel 845GV/GL-Chipsatz verfügt über den Intel 82845 Memory Control Hub
und den Intel 82801DB I/O Controller Hub (ICH4). Die Chipsatzarchitektur ist
in einem innovativen und skalierbaren Design gehalten und verspricht sowohl
Zuverlässigkeit als auch Leistungsstärke. Unten stehend nden Sie eine Liste mit
den Chipsatzteilen und deren jeweiligen Funktionen:
Speicherunterstützung
Das Motherboard verfügt über die folgenden Erweiterungsoptionen:
Funktion
Unterstützung für :CPU FSB: 533/400MHz
“Hyper-Threading” -Technologie
DDR333/266; USB2.0; Ultra ATA 100/66/33
Unterstützung für :CPU FSB: 533*/400MHz
DDR266; USB2.0; Ultra ATA 100/66/33
Keine Unterstützung für : “Hyper-Threading” -Technologie
*: Over-Clocking
Northbridge
845GV
845GL
AC’97 Codec
Erweiterungssteckplätze
• Entspricht AC’97 2.3
• Vollduplex-Codec mit unabhängiger und variabler Abtastrate
• Integrierter Kopfhörer-Buffer, SNR bis zu 90db
• 6Ch DAC, unterstützt 6-Kanal-Lautsprecherausgang
• Unterstützung für Advanced Power Management
• Ein AGPro-Slot (siehe Seite 20 für mehr Details)
• Drei 32-Bit PCI-Steckplätze
• Ein CNR-Steckplatz (Communications and Networking Riser)
• Unterstützung für IDE Ultra DMA-Busmastering mit Transferraten von 100/66/
33 MB/Sek
• Zwei 184-pin DIMM Steckplätze für DDR SDRAM Speichermodule
• Unterstützung für DDR bis zu 333MHz (845GV) oder DDR266MHz (845GL)
Speicherbus
• Maximal auf 2GB Speicher erweiterbar

viii
Motherboard User’s Guide
vii
Motherboard User’s Guide
Onboard I/O-Steckplätze
Das Motherboard verfügt über einen kompletten Satz von I/O-Steckplätze und
Anschlüssen:
• Zwei PS/2-Steckplätze für Maus und Tastatur yboard
• Ein serieller Steckplatz
• Ein VGA-Steckplatz
• Ein paralleler Steckplatz
• Sechs USB Ports (vier Ports an der Rückseite, onboard USB-Köpfe, welche
zwei weitere Ports bieten)-USB2.0
• Audioanschlüsse für Mikrofon, line-in und line-out
Fast Ethernet LAN (optional)
• Unterstützt Betrieb mit 10/100 Mb/Sek.
• Integriertes Fast Ethernet MAC
• PCI Local Bus Single-Chip Fast Ethernet-Controller
• Kompatibel mit PCI Revision 2.2
• Unterstützung für ACPI, PCI Power Management
• Kompatibilität mit den standard PC99/PC2001
• Unterstützung für einen 32-Bit General-Purpose Timer, dem der externe PCI-
Takt als Taktquelle zur Erzeugung des Timer-Interrupt dient
• Unterstützung für Vollduplex-Flusskontrolle (IEEE 802.3x)
USB 2.0
• Mit drei UHCI Host-Controller, welche sechs externe Ports unterstützen
• Neu: Mit einem EHCI High-Speed (Hochgeschwindigkeits)-USB 2.0 Host-
Controller welcher alle sechs Ports unterstützt
• Neu: Unterstützt einen USB 2.0 High-Speed Debug-Port
• Aufweckungsunterstützung des Stillstadiums S1-S5
• Unterstützung von Tastatur/Maus-Software

ix
Motherboard User’s Guide
Traduzione Funzioni e Lista
Lista
L’imballo della scheda madre é composto da:
• La scheda madre
• Il manuale
• Una piattina per il collegamento dei drive (opzionale)
• Una piattina IDE
• Il CD con il Software di supporto
Caratteristiche
Dotata di Socket-478 per Processori
• Supporta CPU Intel Pentium serie 4 con/senza Tecnologia Hyper-
Threading
• Supporta no a 533/400 MHz Front Side Bus
Chipset
l chipset Intel 845GV/GL incorpora il Hub di controllo memIoria Intel 82845 a
il Hub (ICH4) di controllo I/O Intel 82801DB in conformità ad un’architettura
innovativa e scalabile dalle prestazioni e afdabilità dimostrate. Segue una lista
con i chipset e le rispettive funzioni:
AC’97 Codec
Opzioni di espansione
• Conforme con le speciche AC`97 2.3
• Codec full-duplex con frequenza di campionamento indipendente
e variabile
• Memoria tampone integrata per auricolare, SNR no a 90db
• 6 CanDAC, supporto di 6 uscite per le casse
• Supporto per gestione energetica avanzata.
• Uno slot AGPro (fare riferimento alla pagina 20 per ulteriori dettagli)
• Tre slot a 32-bit PCI
• Uno slot CNR (Communications and Networking Riser)
• Supporta gestione di canali IDE Ultra DMA con percentuali di campionamento
di 100/66/33/MB/sec.
• Due slot DIMM a 184 pin per moduli di memoria DDR SDRAM
• Supporta DDR no a 333MHz (845GV) o bus di memoria DDR266MHz
(845GL)
• Quantità massima di memoria installabile, 2GB
Memoria Supporta
La scheda madre dotata delle seguenti opzioni di espansione:
Funzione
Supporta: CPU FSB: 533/400MHz
Tecnologia Hyper-Threading
DDR333/266;USB2.0; Ultra ATA 100/66/33
Supporta: CPU FSB: 533*/400MHz
DDR266 ; USB2.0; Ultra ATA 100/66/33
Non supporta: Tecnologia Hyper-Threading
*: Overclocking
Northbridge
845GV
845GL

x
Motherboard User’s Guide
vii
Motherboard User’s Guide
Onboard I/O Porta
La scheda madre è dotata da una serie completa di porte e connettori I/O:
• Due porte PS/2 per tastiera e mouse
• Una porta seriale
• Una porta VGA
• Una porta parallela
• Sei porte USB (quattro porte sul pannello posteriore; installati due headers
USB che consentono di avere due porte supplementari)-USB2.0
• Jack audio per microfono, ingresso linea e uscita linea
Fast Ethernet LAN (supplementare)
• Supporto delle operazioni 10/100Mbps
• Fast Ethernet MAC integrato
• Controller Fast Ethernet PCI con chip singolo
• Conforme a PCI Revisione 2.2
• Supporta risparmio energetico ACPI, PCI
• Conforme allo standard PC99/PC2001
• Supporta un timer per uso universale a 32-bit con clock PCI esterno come
sorgente clock per generare gli interrupt da timer.
• Supporta controllo di usso Full Duplex (IEEE 802.3x)
USB 2.0
• Include tre host controller UHCI che supportano sei porte esterne
• Nuovo: include un host controller USB 2.0 EHCI ad alta velocità in grado di
supportare tutte e sei le porte
• Nuovo: supporta una porta di debug USB 2.0 ad alta velocità
• Supporta wake-up dallo stato di risveglio (sleeping) S1-S5
• Supporta software legacy per tastiera/mouse

xi
Motherboard User’s Guide
Traducción de Características & Lista
LISTA DE VERIFICACIÓN
El paquete de su placa principal contiene los sigtes. ítems:
• La placa principal
• El Manual del Usuario
• Un cable cinta para el lector de disquete (optativo)
• Un cable cinta para el lector IDE
• CD de Software de soporte
Características
Soporte de Procesador Socket-478
• Soporta CPU de Intel Pentium 4 con/sin la Tecnología Hyper -Threading
• Soporta hasta Bus de Lado Frontal de 533/400 MHz
Chipset
El chipset Intel 845GV/GL contiene Hub de Controlador de Memoria Intel 82845 y
Hub (ICH4) de Controlador Intel 82801DB I/O según una arquitectura innovadora
y escalable con la abilidad y rendimiento aprobados. He aquí una lista del arreglo
del chipset y sus respectivas características:
Función
Soporta: CPU FSB: 533/400MHz
Tecnología Hyper-Threading
DDR333/266; USB2.0; Ultra ATA 100/66/33
Soporta: CPU FSB: 533*/400MHz
DDR266 ; USB2.0; Ultra ATA 100/66/33
No soporta: Tecnología Hyper-Threading
*: Sobre-cronometraje
Northbridge
845GV
845GL
AC’97 Codec
Ranuras de Expansión
• Conforme con la especicación AC’97 2.3
• Full-duplex Codec con índice de muestreo independiente y variable
• Buffer de Audífono Incorporado, SNR hasta 90db
• 6Ch DAC, soporte de altoparlante de 6 canales
• Soporte de administración de energía avanzada
• Una ranura AGPro (reera a la pg 20 para más detalles)
• Tres ranuras 32-bit PCI
• Una ranura CNR (Communications and Networking Riser)
• Soporta mastering de bus IDE Ultra DMA con índices de transferencia de
100/66/33 MB/seg
• Dos ranuras 184-pin DIMM para módulos de memoria DDR SDRAM
• Soporta DDR hasta bus de memoria de 333MHz (845GV) o DDR266MHz
(845GL)
• Memoria máxima instalada es 2GB
Soporte de Memoria
La placa principal viene con las sigtes. opciones de expansión:

xii
Motherboard User’s Guide
vii
Motherboard User’s Guide
Puertos I/O Abordos
La placa principal tiene un juego completo de puertos I/O y conectores:
• Dos puertos PS/2 para ratón y teclado
• Un puerto serial
• Un puerto VGA
• Un puerto paralelo
• Seis puertos USB (cuatro puertos del panel trasero, los cabezales USB
abordo provee dos puertos extras)-USB2.0
• Clavijas de sonido para micrófono, entrada y salida de línea
Fast Ethernet LAN (optativo)
• Soporta la operación de 10/100Mbps
• Fast Ethernet MAC Integrado
• Controlador de Fast Ethernet de chip singular de bus local PCI
• Conforme con PCI Revisión 2.2
• Soporta administración de suministro ACPI, PCI
• Conforme con la norma PC99/PC2001
• Soporta un cronómetro de todo propósito 32-bit con el reloj PCI externo
como fuente de reloj, para generar interrupción de cronómetro
• Soporta Control de Flujo Full Duplex (IEEE 802.3x)
USB 2.0
• Incluye tres controladores antriones UCHI que soporta seis puertos externos
• Nuevo: Incluye un Controlador Anstrión USB 2.0 de EHCI alta velocidad que
soporta todos los seis puertos
• Nuevo: Soporta un puerto de debug de USB 2.0 alta velocidad
• Soporta despertar de los estados de dormir S1-S5
• Soporta software teclado/ratón de legado

xiii
Motherboard User’s Guide
Tradução da Lista & Características
Lista de vericação
A embalagem da sua placa principal contém os seguintes itens:
• A placa principal
• O Manual do Utilizador
• Um cabo para a unidade de disquetes (opcional)
• Um cabo para a unidade IDE
• CD de suporte para o software
Características
Suporte do Processador Socket-478
• Suporta CPU série Intel Pentium 4 com/sem Tecnologia Hyper-Threading
• Suporta até 533/400 MHz Front-Side Bus
Chipset
Há chipsets Intel 845GV/GL contendo Intel 82845 Memory Controller Hub (ICH4)
e Intel 82801DB I/O Controller Hub de acordo com uma arquitetura inovativa
escalável com performance e conabilidade comprovada. Aqui ca uma lista da
organização do chipset e das respectivas características:
Função
Suporta: CPU FSB: 533/400MHz
Teconologia Hyper-Threading, DDR333/266
USB2.0; Ultra ATA 100/66/33
Suporta: CPU FSB: 533*/400MHz
DDR266; USB2.0; Ultra ATA 100/66/33
Não suporta: Teconologia Hyper-Threading
*: Overclocking
Northbridge
845GV
AC’97 Codec
Slots de expansão
• Compatível com a especicação AC’97 2.3
• Full-duplex Codec com razão de amostra variável independente
• Buffer de Fone de Ouvido embutido, SNR até 90db
• 6 canais DAC, suporta 6 canais de altifalantes
• Suporte de gerenciamento de força avançado
• Uno slot AGPro (fare riferimento alla pagina 20 per ulteriori dettagli)
• Três encaixes 32-bit PCI slots
• Um encaixe para CNR (Communications and Networking Riser)
• Suporta IDE Ultra DMA bus mastering com razão de transferência de 100/66/
33 MB/seg
• Dois sockets DIMM com 184 pinos para módulos de memória DDR SDRAM
• Suporta no máximo DDR até 333MHz (845GV) ou bus de memória
DDR266MHz (845GL)
• A memória máxima instalada é de 2GB
Suporte de memória
A placa principal possui as seguintes slots de expansão:
845GL

xiv
Motherboard User’s Guide
vii
Motherboard User’s Guide
Portas I/O na placa
A placa principal possui um conjunto completo de portas e conectores I/O:
• Duas portas PS/2 para o rato e teclado
• Uma porta série
• Uma porta VGA
• Uma porta paralela
• Seis portas USB (quatro portas de painel de interconexão, suportes USB
onboard fornecendo duas portas extra)-USB2.0
• Jacks audio para microfone, line-in e line-out
Ethernet Rápida LAN (opcional)
• Suporta o funcionamento 10/100Mb/s
• Fast Ethernet MAC integrado
• Controlador PCI bus local de chip único Fast Ethernet
• PCI Revision 2.2 complacente
• Suporta gerenciamento de força ACPI, PCI
• Padrão PC99/PC2001 complacente
• Suporta um cronômetro de 32-bit com propósito geral, relógio externo PCI
como fonte do relógio, para gerar interrupção do cronômetro
• Suporta Controle de Fluxo Full Duplex (IEEE 802.3x)
USB 2.0
• Incluiu três controladores host UHCI que suportam seis portas externas
• Novo: Incluiu um Controlador Host USB 2.0 de alta velocidade EHCI que
suporta todas as seis portas
• Novo: Suporta uma porta de depuração de alta velocidade USB 2.0
• Suporta sistema de despertar de estados de adormecimento S1-S5
• Suporta software herdado de teclado/rato

xv
Motherboard User’s Guide
功能和检查单翻译
检查单
您的主板包装含有以下项目：
• 主板
• 用户手册
• 一根磁盘驱动器扁平电缆（可选）
• 一根 IDE 驱动器扁平电缆
• 软件支持 CD
功能
支持 Socket-478 处理器
• 支持带有/不带有多线程技术的 Intel Pentium 4 系列 CPU
• 支持 533/400 MHz 前端总线
芯片组
Intel 845GV/GL 芯片组包含 Intel 82845 存储控制器 Hub (ICH4)和 Intel 82801DB
I/O 控制器 Hub，它基于一种新型的、可扩展的架构，能提供已经证明的可靠性和
高性能。以下是芯片组和它们的功能：
AC'97 编解码器
扩展槽
• 兼容 AC’97 2.3 规格
• 具有独立和可调采样速率的全双工编解码器
• 内建耳机缓冲，SNR 到 90db
• 6路DAC，支持6路扬声器输出。
• 支持高级电源管理
• 1 个 AGPro 插槽（参见第 2０ 页获取详细信息）
• 3个 32 位 PCI 扩展插槽
• 一个通信网络转接 (CNR) 插槽
• 支持 IDE Ultra DMA 总线控制，传输速率可达 100/66/33 MB/sec。
• 2个用于 DDR SDRAM 内存条的 184-pin DIMM 插槽
• 支持 DDR 到 333MHz (845GV) 或 DDR266MHz (845GL)存储总线
• 内存最多可达 2GB
内存支持
此主板提供如下扩展选项：
功能
支持: CPU FSB: 533/400MHz
多线程技术
DDR333/266; USB2.0; Ultra ATA 100/66/33
支持: CPU FSB: 533*/400MHz
DDR266; USB2.0; Ultra ATA 100/66/33
不支持：多线程技术
*: 超频
北桥
845GV
845GL

xvi
Motherboard User’s Guide
vii
Motherboard User’s Guide
集成 I/O 端口
此主板具有完整的 I/O 端口和插孔：
• 2 个用于连接鼠标和键盘的 PS/2 端口
• 1 个串口
• 1 个 VGA 端口
• 1 个并口
• 6 个 USB 端口（主板后面板带 4 个接口，板上 USB 接口提供其它 2 个端
口）— USB2.0
• 麦克风、线入和线出声音插孔
快速以太网 LAN (可选)
• 10 Mb/s 和 100 Mb/s 工作
• 集成高速以太网 MAC
• PCI 局域总线单芯片高速以太网控制器
• 兼容 PCI 2.2 版本
• 支持 ACPI，PCI 电源管理
• 符合 PC99/PC2001 标准
• 支持 32 位多用途定时器（带有外部 PCI 时钟作为时钟脉冲源），可以产生
定时中断
• 支持全双工流控制 (IEEE 802.3x)
USB 2.0
• 包括 3 个UHCI 主控器，支持 6 个外部端口
• 新功能：包括 1 个 EHCI 高速 USB 2.0 主控器，支持所有 6 个端口
• 新功能：支持 1 个 USB 2.0 高速调试端口
• 支持从休眠状态 S1-S5 的唤醒功能
• 支持传统键盘/鼠标软件

1
Chapter1:Introduction
Chapter 1 Introduction
This motherboard has a Socket-478 supporting Intel Pentium 4/
Prescott with Hyper-Threading Technology processors with
Front-Side Bus (FSB) speeds up to 533/400 MHz. Hyper-
Threading Technology, designed to take advantage of the
multitasking features in Windows XP, gives you the power to do
more things at once.
Note: It supports Hyper-Threading Technology only when the
Intel 845GV is installed. Intel 845GL supports FSB 533 MHz
only by overclocking.
This motherboard has the Intel 845GL/GV chipset that contains
Intel 82845 Memory Controller Hub and Intel 82801 I/O Control-
ler Hub. It supports built-in USB 2.0 providing higher bandwidth.
It implements Universal Serial Bus Specification Revision 2.0
and includes three UHCI host controllers that support six external
ports. This motherboard supports AC’ 97 audio codec and
provides Ultra DMA 100/66/33 function.
This motherboard has one CNR (Communications and Network-
ing Riser), three 32-bit PCI slots and one AGPro slot. There is a
full set of I/O ports including two PS/2 ports for mouse and
keyboard and audio jacks for microphone, line-in and line-out.
There are one serial port, one VGA port, one parallel port, one
LAN port(optional), and six USB ports (USB2.0)–four back-
panel ports and onboard USB header USB3 providing two extra
ports by connecting the Extended USB Module to the
motherboard.
This motherboard is a Micro ATX motherboard that uses a 4-
layer printed circuit board and measures 244 x 220mm.

2
MotherboardUser’sGuide
Key Features
The key features of this motherboard include:
Socket-478 Processor
Supports Intel Pentium 4 series CPU with/without
Hyper-Threading Technology
Supports up to 533/400 MHz Front-Side Bus
Chipset
There are Intel 845GV/GL chipsets that contain Intel 82845
Memory Controller Hub and Intel 82801 I/O Controller
Hub(ICH4) in accordance with an innovative and scalable
architecture with proven reliability and performance. Here is a list
of the chipset arrangement and their respective features:
Memory Support
Two 184-pin DIMM sockets for DDR SDRAM memory
modules
Note: You must initiate the HT CPU function through BIOS
setup. It is strongly recommended you refer to Page 48 for
related details.
Function
Support: CPU FSB: 533/400MHz
Hyper-Threading Technology
DDR333/266; USB2.0; Ultra ATA 100/66/33
Support: CPU FSB: 533*/400MHz
DDR266; USB 2.0; Ultra ATA 100/66/33
Doesn’t support:Hyper-Threading Technology
* Supports FSB 533 MHz only by over-clocking
Northbridge
845GV
845GL

3
Chapter1:Introduction
Support DDR up to 333MHz (845GV) or DDR266MHz
(845GL) memory bus
Maximum installed memory is 2GB
AC’97 Codec
Compliant withAC’97 2.3 specification
Full-duplex Codec with independent and variable sampling
rate
Earphone Buffer Built-In, SNR up to 90db
6Ch DAC, support 6-channel speak-out
Advanced power management support
Expansion Options
The motherboard comes with the following expansion options:
One AGPro slot (refer to page 20 for more details)
Three 32-bit PCI slots
One CNR (Communications and Networking Riser) slot
Support IDE Ultra DMA bus mastering with transfer rates
of 100/66/33 MB/sec
Onboard I/O Ports
The motherboard has a full set of I/O ports and connectors:
Two PS/2 ports for mouse and keyboard
One serial port
One VGA port
One parallel port
Six USB 2.0 ports (four back-panel and onboard USB
header providing two extra ports)
Audio jacks for microphone, line-in and line-out
Fast Ethernet LAN (optional)
10 Mb/s and 100 Mb/s operation
Integrated Fast Ethernet MAC
PCI local bus single-chip Fast Ethernet controller
−Compliant to PCI Revision 2.2
−Supports ACPI, PCI power management

4
MotherboardUser’sGuide
Compliant to PC99/PC2001 standard
Supports a 32-bit general-purpose timer with the external
PCI clock as clock source, to generate timer-interrupt
Supports Full Duplex Flow Control (IEEE 802.3x)
USB 2.0
Includes three UHCI host controllers that support six
external ports
New: Includes one EHCI high-speed USB 2.0 Host Con-
troller that supports all six ports
New: Supports a USB 2.0 high-speed debug port
Supports wake-up from sleeping states S1-S5
Supports legacy keyboard/mouse software
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure
many system features including the following:
Power management
Wake-up alarms
CPU parameters and memory timing
CPU and memory timing
The firmware can also be used to set parameters for different
processor clock speeds.
Bundled Software


PC-Cillin provides automatic virus protection under
Windows 98/ME/NT/2000/XP


Adobe Acrobat Reader is the software to help users read
PDF files.
Dimensions
MicroATX form factor of 244 x 220mm
