PCchips M922ULR User manual

Preface
Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without written consent of the au-
thor.
Version 3.0
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of the manu-
facturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi-
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
− Reorient or relocate the receiving antenna.
− Increase the separation between the equipment and the receiver.
− Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
− Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.

Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the follow-
ing conditions:
− This device may not cause harmful interference, and
− This device must accept any interference received, including interference
that may cause undesired operation.
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interference-
causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouilieur du Canada.
About the Manual
The manual consists of the following:
Chapter 1
Introducing the Mainboard
Describes features of the mainboard,
and provides a shipping checklist.
Go to ⇒page 1
Chapter 2
Installing the Mainboard
Describes installation of mainboard
components.
Go to ⇒page 7
Chapter 3
Using BIOS
Provides information on using the BIOS
Setup Utility.
Go to ⇒page 27
Chapter 4
Using the Mainboard Software
Describes the mainboard software.
Go to ⇒page 52
ii

T
TA
AB BL LE E O OF F C
CO
ON NT TE EN NT TS S
Preface i
CHAPTER 1 1
Introducing the Mainboard 1
Introduction.................................................................................................1
Checklist .....................................................................................................1
Standard Items ................................................................................................. 1
Features .....................................................................................................2
Choosing a Computer Case .......................................................................4
Mainboard Components .............................................................................5
CHAPTER 2 7
Installing the Mainboard 7
Safety Precautions......................................................................................7
Quick Guide................................................................................................7
Installing the Mainboard in a Case..............................................................8
Checking Jumper Settings..........................................................................8
Setting Jumpers ............................................................................................... 8
Checking Jumper Settings ............................................................................... 9
Jumper Settings ............................................................................................... 9
Connecting Case Components.................................................................10
The Panel Connectors.....................................................................................11
Installing Hardware ...................................................................................13
Installing the Processor.................................................................................. 13
Installing Memory Modules .......................................................................... 16
Installing a Hard Disk Drive/CD-ROM......................................................... 17
Installing a Floppy Diskette Drive................................................................. 19
Installing Add-on Cards................................................................................. 19
Connecting Optional Devices........................................................................ 21
Connecting I/O Devices ............................................................................25
External Connector Color Coding ................................................................. 26
CHAPTER 3 27
Using BIOS 27
About the Setup Utility ..............................................................................27
The Standard Configuration .......................................................................... 27
Entering the Setup Utility .............................................................................. 28
Updating the BIOS ........................................................................................ 28
Using BIOS...............................................................................................29
Standard CMOS Features .............................................................................. 30
Advanced BIOS Setup Option....................................................................... 32
Advanced Chipset Features Option ............................................................... 34
iii

Integrated Peripherals Option ........................................................................ 38
Power Management Setup Option ................................................................. 42
PNP/PCI Configuration Option ..................................................................... 46
PC Health Status Option................................................................................ 48
Frequency/Voltage Control............................................................................ 49
Load Fail-Safe Defaults Option..................................................................... 50
Load Optimized Defaults Option................................................................... 50
Set Password Option...................................................................................... 50
Save & Exit Setup Option ............................................................................. 51
Exit Without Saving ...................................................................................... 51
CHAPTER 4 52
Using the Mainboard Software 52
About the Software CD-ROM ...................................................................52
Drivers and Software Installation ..............................................................52
Utility Software Reference ........................................................................53
iv

C
Ch ha ap pt te er r 1 1
Introducing the Mainboard
I
In nt tr ro od du uc ct ti io on n
Thank you for choosing KOB P4X266a NDSUX mainboard. The KOB
P4X266a NDSUX mainboard is an ATX mainboard that uses a 4-layer printed
circuit board and measures 305 mm x 190 mm. The mainboard features a
Socket 478 that accommodates Intel Pentium 4 processors supporting system
bus (FSB) speeds of 400 MHz.
The KOB P4X266a NDSUX incorporates the VIA VT8753A Northbridge and
VT8233A (or VT8233) Southbridge chipsets which supports the AC 97 audio
codec, which combines support for DDR (Double Data Rate) SDRAM up to 3
GB.
Note: SDRAM provides 800 MBps or 1 GBps data transfer depending on whether
the bus is 100 MHz or 133 MHz. Double Data Rate SDRAM (DDR SDRAM)
doubles the rate to 1.6 GBps or 2.1 GBps by transferring data on both the ris-
ing and falling edges of the clock. DDR SDRAM uses additional power and
ground lines and requires 184-pin DIMM modules rather than the 168-pin
DIMMs used by SDRAM.
C
Ch he ec ck kl li is st t
Compare the mainboard’s package contents with the following checklist:
Standard Items
• One mainboard
• One diskette drive ribbon cable
• One IDE drive ribbon cable
• One Retention Module
• Software support CD
• This user’s manual

F
Fe ea at tu ur re es s
Processor The KOB P4X266a NDSUX mainboard includes a Socket 478
that has the following features:
• Supports up to a 400/533 MHz system bus (FSB)
• Accommodates Intel Pentium 4 processors.
Chipset There are VT8753A Northbridge and VT8233A Southbridge in
this chipset in accordance with an innovative and scalable
architecture with proven reliability and performance. A few of
the chipset’s advanced features are:
• An advanced V-Link memory controller architecture that
provides the 266 MB/s bandwidth and performance nec-
essary for even the most demanding Internet and 3D
graphics
• Support for a 4xAGP interface providing vivid 3D graphics
and video performance
• An ATA 133 interface on the chipset, which helps boost
system performance by providing a high-speed connec-
tion to ATA 133 Hard Disk Drives, delivering maximum
sustained data transfer rates of 133 MB/sec
Additional key features include support for four USB ports, an
AC 97 link for audio and modem, hardware monitoring, and
ACPI/OnNow power management.
Note: This mainboard incorporates either VT8233A or
VT8233 Southbridge chipset.
Memory The mainboard supports DDR 266 SDRAM. It accommodates
three unbuffered 2.5V 184-pin slots. Each slot supports up to 1
GB with a total maximum capacity of 3 GB.
AGP The KOB P4X266a NDSUX includes a 4xAGP slot that pro-
vides eight times the bandwidth of the original AGP
specification. AGP technology provides a direct connection
between the graphics sub-system and the processor so that
the graphics do not have to compete for processor time with
other devices on the PCI bus.
AC’ 97 Audio
Codec
The AC’ 97 Audio codec is compliant with the AC 97 2.2 speci-
fication, and supports 18-bit ADC (Analog Digital Converter)
and DAC (Digital Analog Converter) resolution as well as 18-bit
stereo full-duplex codec with independent and variable sam-
pling rates. Further features include support for four analog
line-level stereo inputs.
USB USB 1.1
The VT8233A or VT8233 Southbridge chipset features the
USB 1.1 specification which can support for four USB ports.
However, if the mainboard comes with VIA VT6202, then the
mainboard supports the USB 2.0 specification.
USB 2.0 (optional)
The VIA VT6202 PCI USB 2.0 Controller is compliant with
Universal Serial Bus Specification Revision 2.0.
The USB 2.0 su
pp
orts data transfer rates u
p
to 480MB/sec for
2

high-speed devices and specifies a microframe that will be
1/8th of a 1msec frame. This allows the USB 2.0 devices to
have small buffers even at high data rates.
The USB 1.1 connectors and other full speed cables can sup-
port the higher speed of USB 2.0 without any changes.
The chipset has the following advanced USB features:
• Compliant with Enhanced Host Controller Interface
(EHCI) Specification Revision 0.95 and Universal Host
Controller Interface (UHCI) Specification Revision 1.1
• PCI multi-function device consists of two UHCI Host Control-
lers for full/low-speed signaling and one EHCI Host
• Controller core for high-speed signaling
• Supports PCI-Bus Power Management Interface Specifi-
cation release 1.1
• Legacy support for all downstream facing ports
Expansion
Options
KOB P4X266a NDSUX has four 32-bit PCI slots, an AGP slot,
a CNR (Communications and Networking Riser) slot, and an
onboard PCI LAN interface (optional).
The KOB P4X266a NDSUX PCI slots are capable of Ultra
DMA bus mastering with transfer rates of 33/66/100/133
MB/sec.
Note: If the mainboard incorporates the VT8233A
Southbridge chipset, the Ultra DMA bus master-
ing can support up to 133 MB/sec transfer rate.
For VT8233 Southbridge chipset, the transfer rate
can support up to 100MB/sec only.
Integrated I/O The mainboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• Two serial port
• One parallel port
• One MIDI/game port
• Two USB ports
• Audio jacks for microphone, line-in and line-out
BIOS
Firmware
This mainboard uses Award BIOS that enables users to con-
figure many system features including the following:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
The firmware can also be used to set parameters for different
processor clock speeds.
3

C
Ch ho oo os si in ng g a a C Co om mp pu ut te er r C Ca as se e
There are many types of computer cases on the market. The mainboard com-
plies with the specifications for the ATX system case. Some features on the
mainboard are implemented by cabling connectors on the mainboard to indi-
cators and switches on the system case. Ensure that your case supports all
the features required. The mainboard can support one or two floppy diskette
drives and four enhanced IDE drives. Ensure that your case has sufficient
power and space for all the drives that you intend to install.
Most cases have a choice of I/O templates in the rear panel. Make sure that
the I/O template in the case matches the I/O ports installed on the rear edge
of the mainboard.
This mainboard has an ATX form factor of 305 x 190 mm. Choose a case that
accommodates this form factor.
4

M
Ma ai in nb bo oa ar rd d C Co om mp po on ne en nt ts s
5

Table of Mainboard Components
LSJ1* Single color LED header
Label Component
LUSB1* Connector for front panel USB ports
AGP1 Accelerated Graphics Port
ATX1
PANEL Front panel header
PCI1 ~ PCI4
Power connector
AUDIO
Four 32-bit add-on card slots
SIR
Mic/speaker-out header
BAT1
Serial infrared cable header
SJI
Three volt realtime clock battery
CASFAN1 Case fan connector 1
Single-color MSG (message) LED
SMART IO Connector used with media storage devices
CD1 Primary CD-in connector
USB2 Connector for front panel USB ports
CD2 Secondary CD-in connector
WOL1 Wake On LAN wakeup connector
CNR1 Communications Network Riser (CNR) slot
WOM1 Wake On Modem wakeup connector
CPU SOCKET Micro PGA 478-pin socket for Pentium 4 CPUs
* For OEM use only
Note: LED1 is usually connected to a light that indicates that the computer is
powered on. Do not install hardware or disconnect power cables while the
LED is on.
CPUFAN1 Cooling fan for CPU
This concludes Chapter 1. The next chapter explains how to install the main-
board.
DIMM1 ~ DIMM3 Three 184-pin DIMM sockets
FDD1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
JP1 Clear CMOS jumper
JP3 BIOS protect jumper
JP5 FSB speed select jumper
LAUDIO* MIC/speaker-out header
LPANEL* Second front panel header
6

C
Ch ha ap pt te er r 2 2
Installing the Mainboard
S
Sa af fe et ty y P Pr re ec ca au ut ti io on ns s
Follow these safety precautions when installing the mainboard:
• Wear a grounding strap attached to a grounded device to avoid
damage from static electricity.
• Discharge static electricity by touching the metal case of a safely
grounded object before working on the mainboard.
• Leave components in the static-proof bags they came in.
• Hold all circuit boards by the edges. Do not bend circuit boards.
Q
Qu ui ic ck k G Gu ui id de e
This Quick Guide suggests the steps you can take to assemble your system
with the mainboards.
The following table provides a reference for installing specific components:
Locating Mainboard Components Go to page 5
Installing the Mainboard in a Case Go to page 8
Setting Jumpers Go to page 8
Installing Case Components Go to page 10
Installing the CPU Go to page 13
Installing Memory Go to page 16
Installing a HDD and CD-ROM Drive Go to page 17
Installing a Floppy Disk Drive Go to page 19
Installing Add-on Cards Go to page 19
Connecting Options Go to page 21
Connecting Peripheral (I/O) Devices Go to page 25

I
In ns st ta al ll li in ng g t th he e M Ma ai in nb bo oa ar rd d i in n a a C Ca as se e
Refer to the following illustration and instructions for installing the mainboard
in a case:
This illustration shows an ex-
ample of a mainboard being
installed in a tower-type case:
Note: Do not overtighten
the screws as this
can stress the main-
board.
Most system cases have
mounting brackets installed in
the case, which correspond to
the holes in the mainboard.
Place the mainboard over the
mounting brackets and secure
the mainboard onto the mount-
ing brackets with screws.
2.
S
ecure the mainboard with
screws where appropriate.
1. Place the mainboard
over the mounting brackets.
Ensure that your case has an I/O template that supports the I/O ports and
expansion slots on your mainboard.
C
Ch he ec ck ki in ng g J Ju um mp pe er r S Se et tt ti in ng gs s
This section explains how to set jumpers for correct configuration of the main-
board.
Setting Jumpers
Use the mainboard jumpers to set system configuration options. Jumpers with
more than one pin are numbered. When setting the jumpers, ensure that the
jumper caps are placed on the correct pins.
The illustrations below show a 2-pin jumper.
When the jumper cap is placed on both pins,
the jumper is SHORT. If you remove the
jumper cap, or place the jumper cap on just
one pin, the jumper is OPEN.
This illustration shows a 3-pin
jumper. Pins 1 and 2 are SHORT.
Short
123
Open
8

Checking Jumper Settings
The following illustration shows the location of the mainboard jumpers. Pin 1 is
labeled.
Jumper Settings
Jumper Type Description Setting (default)
JP1 3-pin Clear CMOS
jumper
1-2: Normal
2-3: Clear CMOS
JP1
1
JP3
1
JP5
JP3 3-pin BIOS flash pro-
tection jumper
1-2: Unprotected
2-3: Protected
JP5 2-pin FSB speed se-
lect jumper
Short: Auto-detect
(400 or 533MHz)
Open: 533MHz
Jumper 1 – This jumper enables you to reset BIOS. Follow these instructions:
1. Turn the system off.
2. Short pins 2 and 3 on JP1.
3. Return the jumper to the normal setting.
9

4. Turn the system on. The BIOS is returned to the default set-
tings.
Jumper 2 – This jumper is used to protect the BIOS from being unintention
ally flashed. Enable this jumper for protection and disable this
jumper when you want to flash the BIOS.
Jumper 5 – This jumper enables to select the FSB speed.
C
Co on nn ne ec ct ti in ng g C Ca as se e C Co om mp po on ne en nt ts s
After you have installed the mainboard into a case, you can begin connecting
the mainboard components. Refer to the following:
1. Connect the case
power supply
connector to ATX1.
2. Connect the CPU
cooling fan cable to
CPUFAN1.
3. Connect the case
cooling fan connector
to CASFAN1.
4. Connect the case
LED cable to SJI or
LSJI.
SJ1: Single color LED header
This header allows the user to install a LED indicator to indicate when the
computer is in Suspend to RAM (STR) mode or normal mode.
Pin Signal Name
1
2
3
SUSLED-G
SUSLED-G
5VSB
ACPI LED function:
S0 S1 S3 S4/S5
SJ1
1Light Blinking Blinking Dark
10

LSJ1: Single color LED header
This header which is specially designed for OEM customers allows the user to
install a LED indicator to indicate when the computer is in Suspend to RAM
(STR) mode or normal mode.
Pin Signal Name
1
2
5 VSB
SUSLED-Y
ACPI LED function:
S0 S1 S3 S4/S5
Dark
LSJ1
Dark Light Dark
The Panel Connectors
The panel connector (PANEL and LPANEL) provides a standard set of switch
and LED connectors commonly found on ATX or micro-ATX cases. The
LPANEL1 connector is designed specially for OEM customers that comply
with the OEM specifications. Refer to the table below for information:
PANEL
Device Pins
N/C 10
Empty 9
Power ON/OFF 6, 8
Reset Switch 5, 7
Green LED
Indicator
2, 4
HDD LED +1, -3
N/C
(Pin 10)
9 10
Power Switch
(Pins 6, 8)
Reset Switch
(Pins 5, 7)
Empty
(Pin 9)
HDD LED
(Pins 1, 3)
1 2
Green LED
(Pins 2, 4)
11

LPANEL
Device Pins
Empty 13
Reset Switch +12, -14
Power Switch +9, -11
Speaker +4, -6, -8, 10
Power LED -3 (Y), -5 (G), +7
HDD LED +1, -2
HDD LED
(Pins +1, -2)
13 14
Reset Switch
(Pins +12, -14)
Speaker
(Pins +4, -6,
-8
,
10
)
Empty
(Pin 13)
1 2
Power Switch
(Pin +9, -11)
Power LED
(Pin -3, -5, +7)
Note: The plus sign (+) indicates a pin which must be connected to a positive
voltage.
12

I
In ns st ta al ll li in ng g H Ha ar rd dw wa ar re e
Installing the Processor
Caution: When installing a CPU heatsink and cooling fan make sure that
you DO NOT scratch the mainboard or any of the surface-mount resistors
with the clip of the cooling fan. If the clip of the cooling fan scrapes
across the mainboard, you may cause serious damage to the mainboard
or its components.
On most mainboards, there are small surface-mount resistors near the
processor socket, which may be damaged if the cooling fan is carelessly
installed.
Avoid using cooling fans with sharp edges on the fan casing and the
clips. Also, install the cooling fan in a well-lit work area so that you can
clearly see the mainboard and processor socket.
Before installing the Processor
This mainboard automatically determines the CPU clock frequency and sys-
tem bus frequency for the processor. You may be able to change these
settings by making changes to jumpers on the mainboard, or changing the
settings in the system Setup Utility. We strongly recommend that you do not
overclock processors or other components to run faster than their rated
speed.
Warning: Overclocking components can adversely affect the reliability of
the system and introduce errors into your system. Overclocking can per-
manently damage the mainboard by generating excess heat in
components that are run beyond the rated limits.
This mainboard has a Socket 478 processor socket. When choosing a proc-
essor, consider the performance requirements of the system. Performance is
based on the processor design, the clock speed and system bus frequency of
the processor, and the quantity of internal cache memory and external cache
memory.
13

CPU Installation Procedure
The following illustration shows CPU installation components:
Note: The pin-1 corner is marked with an arrow
Follow these instructions to install the Retention Module and CPU:
1. Remove the existing retention module (if applicable).
2. Position the backplate
against the underside of
the mainboard, secure
the 4 screws firmly on
the retention module.
Note: Do not over tighten
the screws.
3. Install your CPU. Pull up
the lever away from the
socket and lift up to 90-
degree angle.
14

4. Locate the CPU cut
edge (the corner with the
pinhole noticeably miss-
ing). Align and insert the
CPU correctly.
5. Press the lever down.
6. Apply thermal grease on top of the CPU.
7. Put the CPU Fan down
on the retention module
and snap the four reten-
tion legs of the cooling
fan into place.
8. Flip the levers over to lock the heat sink in place.
9. Connect the CPU Cool-
ing Fan power cable to
the CPUFAN1 connec-
tor. This completes the
installation.
Note: CPU fan and heatsink installation procedures may vary with the type of
CPU fan/heatsink supplied. The form and size of fan/heatsink may also
vary.
15

Installing Memory Modules
This mainboard accommodates 184-pin 2.5V unbuffered Double Data Rate
(DDR) SDRAM memory modules. The memory bus runs at 133 MHz.
The mainboard accommodates three memory modules. You must install at
least one module in any of the three slots. Each module can be installed with
32 MB to 1 GB of memory; total memory capacity is 3 GB.
Do not remove any memory module from its antistatic packaging until
you are ready to install it on the mainboard. Handle the modules only by
their edges. Do not touch the components or metal parts. Always wear
a grounding strap when you handle the modules.
Installation Procedure
Refer to the following to install the memory modules.
1. This mainboard supports unbuffered DDR SDRAM only. Do not attempt to
insert any other type of DDR SDRAM into the slots.
2. Push the latches on each side of the DIMM slot down.
3. Align the memory module with
the slot. The DIMM slots are
keyed with notches and the
DIMMs are keyed with cutouts
so that they can only be in-
stalled correctly.
4. Check that the cutouts on the
DIMM module edge connector
match the notches in the
DIMM slot.
5. Install the DIMM module into
the slot and press it firmly
down until it seats correctly.
The slot latches are levered
upwards and latch on to the
edges of the DIMM.
6. Install any remaining DIMM modules.
16
