PCE Instruments PCE-DPS 25 User manual

© PCE Instruments
Laboratory Balance PCE-DPS 25
Quick Start Guide
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Last change: 9 April 2021
v1.0
English

© PCE Instruments
Contents
1Safety notes........................................................................................... 1
2Specifications........................................................................................2
3Switchig on and weighing.................................................................... 2
4Counting function ................................................................................. 3
4.1 Determining individual weights with the balance............................................................... 3
4.2 Determine individual weight via keyboard......................................................................... 3
5Quantity check function.......................................................................3
5.1 Specify number of pieces as target quantity..................................................................... 3
5.2 Checking the piece quantity - check function with alarm................................................... 3
5.3 Back to normal piece counting.......................................................................................... 4
6Contact................................................................................................. 4
7Disposal ................................................................................................. 4

© PCE Instruments
1
1 Safety notes
Please read this quick start guide carefully and completely before you use the device for the first
time. The device may only be used by qualified personnel and repaired by PCE Instruments
personnel. Damage or injuries caused by non-observance of the guide are excluded from our
liability and not covered by our warranty.
•The device must only be used as described in this quick start guide. If used otherwise,
this can cause dangerous situations for the user and damage to the meter.
•The instrument may only be used if the environmental conditions (temperature, relative
humidity, …) are within the ranges stated in the technical specifications. Do not expose
the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
•Do not expose the device to shocks or strong vibrations.
•The case should only be opened by qualified PCE Instruments personnel.
•Never use the instrument when your hands are wet.
•You must not make any technical changes to the device.
•The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,
no abrasives or solvents.
•The device must only be used with accessories from PCE Instruments or equivalent.
•Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
•Do not use the instrument in explosive atmospheres.
•The measurement range as stated in the specifications must not be exceeded under
any circumstances.
•Non-observance of the safety notes can cause damage to the device and injuries to
the user.
We do not assume liability for printing errors or any other mistakes in this guide.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.

© PCE Instruments
2
2 Specifications
Weighing plate 1
Measurement range
25 kg / 55 lbs
Measurement accuracy
±2 g
Resolution
0.5 g
Weighing plate dimensions
345 x 260 mm / 13.6 x 10.2 in
Weighing plate 2
Measurement range
1 kg / 2.2 lbs
Measurement accuracy
±0.08 g
Resolution
0.02 g
Weighing plate dimensions
114 x 114 mm / 4.5 x 4.5 in
Further specifications
Interfaces
USB-A (connection to PC)
SUB D9 female (connection of an external measuring cell)
SUB D9 male (RS232)
Power supply mains adaptot
Primary: 100 ... 240 VAC, 50/60 Hz, 0.5 A
Secondary: 12 VDC, 1 A
Built-in battery
2000 mAh
Dimensions
320 x 120 x 480 mm / 12.6 x 4.7 x 18.9 in
Operating conditions
0 ... 40 °C / 32 ... 104°F
Weight
8,6 kg / 19 lbs
3 Switchig on and weighing
- The on/off switch is located on the back of the balance.
- The SCALE key switches between platform S1, S2 and S3.
- Confirm selection with ENTER.
Attention!
The total weight is displayed in kilogrammes and the individual weight in grammes.

© PCE Instruments
3
4 Counting function
4.1 Determining individual weights with the balance
- Place any quantity of pieces on the balance as a reference.
- Enter the number of pieces via the keyboard.
- Press the SAMPLE key.
- under UNIT WEIGHT, the determined individual weight is displayed
a) Count immediately with this single weight
- Remove reference quantity
- Place container on platform and tare with >T< key.
- Fill quantity to be counted into container.
- Total weight, individual weight and number of pieces are displayed.
b) Save single weight
- Press the SAVE key.
- The indication "(01)" for memory item 01 appears under Weight.
- Change memory item number (01) to (16) with the key.
- Confirm with ENTER.
c) Retrieve individual weight from memory
- Type in the memory item number.
- Press the READ key.
- The saved individual weight appears under UNIT WEIGHT.
4.2 Determine individual weight via keyboard
- Enter individual weight via keyboard.
- Delete wrong values with C key.
- Press the UNIT key to count immediately
- Continue as under 4.1 b) and 4.1 c).
5 Quantity check function
5.1 Specify number of pieces as target quantity
- Press the key, CH=OFF appears under Weight.
- Press the key twice so that the 0 flashes under Total.
- Enter target quantity via keyboard, e. g. 25.
- Press to return to CH=OFF.
- Press the key - all displays return to 0.
5.2 Checking the piece quantity - check function with alarm
- The check function must be set to CH=ON.
- Press the key, change with ENTER,
- Back with key.
- Place the weighing container on the platform and tare with >T<.
- Enter individual weight as under chapter 4.1 or 4.2.
- Add quantity to be checked.
- The current number of pieces is displayed and if the preset number of pieces is exceeded, an
alarm sounds.

© PCE Instruments
4
5.3 Back to normal piece counting
- The check function must be set to CH=OFF.
- Press key; switch to CH=OFF with ENTER.
- Return to normal weighing mode with key.
6 Contact
If you have any questions, suggestions or technical problems, please do not hesitate to contact
us. You will find the relevant contact information at the end of this user manual.
7 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.
