Hating Mantle PCE-HMA Series
User Manual
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Last change: 17 April 2018
v1.0
English

© PCE Instruments
Contents
1Introduction ........................................................................................... 1
2Technical specifications ...................................................................... 2
3Safety notes........................................................................................... 4
4Operation ............................................................................................... 6
5Maintenance ..........................................................................................7
6Warranty.................................................................................................8
7Disposal ................................................................................................. 8

© PCE Instruments
1
1 Introduction
Thank you for choosing to purchase a heating mantle of the HMA series from PCE Instruments.
The heating mantles of the PCE-HMA series are handmade. You have a heating mantle made of
“crocheted” glass silk. The PCE-HMA series is exclusively intended for heating liquids in round-
bottomed flasks made of glass.
The heat conductor ismade of the NiCr alloy 8020. The conductor is covered by a fibreglass hose
and crocheted into the inner sheath of the heating mantle with a yarn made of glass silk to ensure
that the heat is conducted evenly to the glass flask. The fibreglass hose and theglass yarn provide
further insulation. To ensure proper insulation of the outer sheath, the heating mantle is insulated
from inside with glass wool.
The heating mantles meet these standards:
DIN EN 61010-1: 2011-07 Part 1
DIN EN 61010-2-010: 2015-05
The heating mantles are available in 13 different sizes from 25 ml to 20 l.
The sizes from 25 ml to 250 ml have a closed outer sheath without a bottom hole.
The sizes from 500 ml have a bottom hole with a diameter of 60 mm.
The sizes from 25 ml to 100 ml are supplied with 4 split pins as standard.
The sizes from 250 ml come with 4 fastening hooks, enabling use with a tripod.
The power supply required for operation of the heating mantles is 230 V, 50/60 Hz. The heating
conductor temperature must not exceed of 450 ° C.
The heating mantles are supplied with a safety plug incl. a 1.50 m fixed cable.
All heating mantles are baked out prior to delivery. Discolouration of the glass cloth can occur due
to technical reasons and does not mean that the quality is bad.
In some cases, during first use, a technically induced smoke formation can occur, which is due to
the sizing agent being baked out. If this happens, do not prevent the smoke discharge with a
hermetic cover.
The heating mantles have protection class I, and correspond to IP 00.
All models are supplied with an external RCCB protection switch.

© PCE Instruments
2
2 Technical specifications
PCE-HMA 25 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
25 ml
Maximum diameter of round-bottomed flask
41 mm
No. of heating zones
1
Power supply
230 V / 500 W
Bottom hole
no
RCCB protection
yes, external
PCE-HMA 50 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
50 ml
Maximum diameter of round-bottomed flask
51 mm
No. of heating zones
1
Power supply
230 V / 70 W
Bottom hole
no
RCCB protection
yes, external
PCE-HMA 100 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
100 ml
Maximum diameter of round-bottomed flask
64 mm
No. of heating zones
1
Power supply
230 V / 110 W
Bottom hole
no
RCCB protection
yes, external
PCE-HMA 250 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
250 ml
Maximum diameter of round-bottomed flask
85 mm
No. of heating zones
2
Power supply
230 V / 200 W
Bottom hole
no
RCCB protection
yes, external
PCE-HMA 500 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
500 ml
Maximum diameter of round-bottomed flask
105 mm
No. of heating zones
2
Power supply
230 V / 280 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
PCE-HMA 1000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
1000 ml
Maximum diameter of round-bottomed flask
131 mm
No. of heating zones
2
Power supply
230 V / 450 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external

© PCE Instruments
3
PCE-HMA 2000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
2000 ml
Maximum diameter of round-bottomed flask
165 mm
No. of heating zones
2
Power supply
230 V / 700 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
PCE-HMA 3000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
3000 ml
Maximum diameter of round-bottomed flask
185 mm
No. of heating zones
2
Power supply
230 V / 760 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
PCE-HMA 4000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
4000 ml
Maximum diameter of round-bottomed flask
207 mm
No. of heating zones
2
Power supply
230 V / 860 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
PCE-HMA 5000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
5000 ml
Maximum diameter of round-bottomed flask
223 mm
No. of heating zones
2
Power supply
230 V / 1100 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
PCE-HMA 6000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
6000 ml
Maximum diameter of round-bottomed flask
236 mm
No. of heating zones
2
Power supply
230 V / 1300 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
PCE-HMA 10000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
10000 ml
Maximum diameter of round-bottomed flask
279 mm
No. of heating zones
2
Power supply
230 V / 2000 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external

© PCE Instruments
4
PCE-HMA 20000 ml round-bottomed flask
Maximum temperature
+450 °C
Maximum capacity of round-bottomed flask
20000 ml
Maximum diameter of round-bottomed flask
345 mm
No. of heating zones
2
Power supply
230 V / 2800 W
Bottom hole
yes, 60 mm
RCCB protection
yes, external
3 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The
device may only be used by qualified personnel and repaired by PCE Instruments personnel.
Damage or injuries caused by non-observance of the manual are excluded from our liability and
not covered by our warranty.
•The device must only be used as described in this instruction manual.If used otherwise,
this can cause dangerous situations for the user and damage to the meter.
•The instrumentmay only be usedif the environmental conditions (temperature, relative
humidity, …) are within the ranges stated in the technical specifications. Do not expose
the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
•Do not expose the device to shocks or strong vibrations.
•The case should only be opened by qualified PCE Instruments personnel.
•Never use the instrument when your hands are wet.
•You must not make any technical changes to the device.
•The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,
no abrasives or solvents.
•The device must only be used with accessories from PCE Instruments or equivalent.
•Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
•Do not use the instrument in explosive atmospheres.
•The measurement range as stated in the specifications must not be exceeded under
any circumstances.
•Non-observance of the safety notes can cause damage to the device and injuries to
the user.
We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.
Intended use
The intended use of our heating mantles is heating non-explosive and non-flammable liquids in a
glass flask in the laboratory and in technical applications. The size of the flexible heater must
correspond to the size of the glass flask.
The operation of our heating mantles is exclusively permitted if the included RCCB
protection switch is used!
In addition to the safety instructions listed in this manual, you also need to observe the general
safety and accident prevention regulations.

© PCE Instruments
5
Mains connection of the heating mantle
The heating mantle with a RCCB protection switch must only be
connected to a 230 V socket with a protective earth terminal. This socket
must be near the heating mantle and easily accessible.
The heating mantle must only be connected to the mains if it is in a
technically flawless condition. The heating mantle must not have any
damage, in particular, no exposed heat conductors and it must not be
damp or wet.
The heating mantle may only be connected with the supplied RCCB protection switch.
Please note the steps listed below when connecting the heating mantle:
- Turn off the heating mantle
- Plug the RCCB protection switch into the socket
- Insert the power plug of the heating mantle in the RCCB protection switch.
- Turn on the heating mantle
- Check the RCCB protection switch
To check the RCCB protection switch, thoroughly follow the instructions of its separate manual.
We recommend to use an additional power controller. If an external power controller or an
external temperature control unit are used, observe the following steps:
- Turn off the heating mantle
- Turn off the external power controller or external temperature control unit
- Plug the RCCB protection switch into the socket
- Insert the power plug of the heating mantle into the external power controller or the
temperature control unit
- Insert the power plug of the external power controller or temperature control unit into
the RCCB protection switch
- Turn on the heating mantle and external power controller or temperature control unit
- Check the RCCB protection switch
Technical specifications of the RCCB protection switch
Nominal voltage 230 V / 50 Hz
Nominal current 16 A
Fault current 30mA
Protection class IP44
Response time <30 ms
Ambient temperature -25 …+ 40 °C

© PCE Instruments
6
4 Operation The heating mantle may only be operated with the supplied RCCB
protection switch! We also recommend using the optional power
controller (temperature controller) to avoid overheating of the
heating mantles.
Before each use of the heating mantle, check the RCCB protection switch.
Follow the instructions from the separate manual!
If the test fails or if the RCCB protectionswitch is triggered during the usage of the heating mantle,
this indicates a defect in the heating mantle, which means that it must not be used anymore. The
plug of the heating mantle must be removed off the mains immediately and the heating mantle
must be checked by a qualified electrician.
The heating mantles may only be used for heating liquids in glass flasks. Neither flammable or
explosive liquids may be heated, nor those that, when heated, can produce hazardous flammable
or explosive mixtures.
The dimensions of the round-bottomed flask must correspond to the data of the heating mantle.
The signs and instructions attached to the heating mantle and the power cord must not be
removed.
The heating mantle may not be left unattended during operation.
If no optional power controller is operated with the heating mantle, the temperature can be
reduced as follows:
Models with capacities of 250 ml …20 l (2 heating zones)
Models with capacities of 25 …100 ml (1 heating zone)
Position Heating zone 2 Heating zone 1
3 100 % 100 %
2 off 100 %
1 25 % 25 %
0 off off
In case of continuous operation of the heating mantle, an external power controller or an external
temperature control unit must be connected as otherwise the maximum permissible temperature
can be exceeded.
If the heating mantle becomes wet as a result of glass breakage or spills of liquids, it must be
ensured that the heating mantle is not touched. The heating mantle must be disconnected from
the mains.
Afterwards, the heating mantle must be dried at a maximum temperature of 60 °C in a drying
cabinet for at least 5 hours.
No round-bottomed flasks made of metal or plastic must be heated in the heating mantle.

© PCE Instruments
7
Danger of burns
The heatingmantles develop high temperatures and must not be touched
during use and when they are switched on. Both the inner part and the
upper edge of the heating mantle can cause burns. At the end of the
heating operation, the heating mantle must be disconnected from the
mains. It is recommended to let the heating mantle cool down for at least
30 minutes.
In order to achieve an optimum heating of the round-bottomedflask, the current liquid level should
always be checked, also during operation.
The liquid level in the glass flask must always be above the upper
heating conductor.
When the liquid level is decreasing, the heating zone should be
reduced. This means that in case of the mantles with a capacity of
250 ml …20 l, it is necessaryto switch from heating zone 2 to heating
zone 1 or to turn off the heating mantle. For the smaller heating
mantles with capacities between 25 ml and 100 ml, the heating mantle
must basically be turned off.
5 Maintenance
The examination of installations subject to monitoring is regulated by your local Industrial Safety
Ordinance. Please observe your local accident prevention regulations for testing electrical
installations and equipment.
Heating mantles must be checked before first use and every 6 months. Instructions and
specifications can be found in your local regulations.
It is also necessary to carry out a visual inspection and to check if sufficient protective measures
against electric shock are in place. A functional test is also required. The RCCB protection switch
must be included in this test.
Maintenance of the heating mantles must only be carried out by qualified electricians.
Heating mantles may only be repaired by the manufacturer to prevent serious injury or even death
by electric shock.

© PCE Instruments
8
6 Warranty
You can read our warranty terms in our General Business Terms which you can find here:
https://www.pce-instruments.com/english/terms.
7 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.

© PCE Instruments
9
PCE Instruments contact information
Germany France Spain
PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L.
Im Langel 4 23, rue de Strasbourg Calle Mayor, 53
D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete)
Deutschland France España
Tel.: [phone] Téléphone: [phone] Tel. : [phone]
Fax: [phone] Numéro de fax: [phone] Fax: [phone]
[email protected] [email protected] [email protected]
www.pce-instruments.com/deutsch www.pce-instruments.com/french www.pce-instruments.com/espanol
United States of America United Kingdom Italy
PCE Americas Inc. PCE Instruments UK Ltd PCE Italia s.r.l.
711 Commerce Way suite 8 Unit 11 Southpoint Business Park Via Pesciatina 878 / B-Interno 6
Jupiter / Palm Beach Ensign Way, Southampton 55010 LOC. GRAGNANO
33458 FL Hampshire CAPANNORI (LUCCA)
USA United Kingdom, SO31 4RF Italia
Tel: [phone] Tel: [phone] Telefono: [phone]
Fax: [phone] Fax: [phone] Fax: [phone]
[email protected] [email protected] i[email protected]
www.pce-instruments.com/us www.pce-instruments.com/english www.pce-instruments.com/italiano
The Netherlands Chile Hong Kong
PCE Brookhuis B.V. PCE Instruments Chile S.A. PCE Instruments HK Ltd.
Institutenweg 15 RUT: 76.154.057-2 Unit J, 21/F., COS Centre
7521 PH Enschede Santos Dumont 738, local 4 56 Tsun Yip Street
Nederland Comuna de Recoleta, Santiago, Chile Kwun Tong
Telefoon: [phone] Tel. : [phone] Kowloon, Hong Kong
Fax: +31 (0) 53 - 430 36 46 Fax: [phone] Tel: [phone]
[email protected] [email protected] [email protected]
www.pce-instruments.com/dutch www.pce-instruments.com/chile www.pce-instruments.cn
China Turkey
PCE (Beijing) Technology Co.,Ltd PCE Teknik Cihazları Ltd.Şti.
1519 Room, 6 Building Halkalı Merkez Mah.
Men Tou Gou Xin Cheng, Pehlivan Sok. No.6/C
Men Tou Gou District 34303 Küçükçekmece - İstanbul
102300 Beijing Türkiye
China Tel: [phone]
Tel: [phone] Faks: 0212 705 53 93
[email protected] [email protected].tr
www.pce-instruments.cn www.pce-instruments.com/turkish
