PCAN-USB Hub
All-in-one USB adapter for
communication via CAN, RS-232, and USB
User Manual
V2.1.1

PCAN-USB Hub – User Manual
2
Products taken into account
Product Name Model Part Number
PCAN-USB Hub IPEH-002004
CANopen® and CiA® are registered community trade marks of CAN in Automation
e.V.
All other product names mentioned in this document may be the trademarks or
registered trademarks of their respective companies. They are not explicitly marked
by “™” and “®”.
© 2012 PEAK-System Technik GmbH
PEAK-System Technik GmbH
Otto-Roehm-Strasse 69
64293 Darmstadt
Germany
Phone: [phone]
Fax: [phone]
www.peak-system.com
[e-mail]
Document version 2.1.1 (2012-04-04)

PCAN-USB Hub – User Manual
3
Contents
1Introduction 5
1.1 Properties at a Glance 5
1.2 System Requirements 6
1.3 Scope of Supply 7
2Installing the Software and the Adapter 8
3Connectors on the Adapter 11
3.1 Upstream Port (USB Cable) 11
3.2 Power (Voltage Supply) 11
3.3 CAN 12
3.3.1 Supplying External Devices via the CAN
Connector 13
3.4 RS-232 15
3.5 USB Ports (Downstream) 15
3.6 Cabling 16
3.6.1 Termination 16
3.6.2 Example of a Connection 16
3.6.3 Maximum Bus Length 17
4Operation 18
4.1 Status LEDs 18
4.2 Unplugging the Hub 19
4.3 Distinguishing Several PCAN-USB Hub 19
5Using the Software 20
5.1 CAN Monitor PCAN-View for Windows 20
5.1.1 Receive/Transmit Tab 22
5.1.2 Trace Tab 24
5.1.3 PCAN-USB Tab 25

PCAN-USB Hub – User Manual
4
5.1.4 Status Bar 25
5.2 Linking Own Programs with PCAN-Basic 26
5.2.1 Features of PCAN-Basic 27
5.2.2 Principle Description of the API 28
5.2.3 Notes about the License 29
6Technical Specifications 30
Appendix A CE Certificate 32
Appendix B Dimension Drawing 33
Appendix C Quick Reference 34

PCAN-USB Hub – User Manual
5
1Introduction
The PCAN-USB Hub provides several hardware interfaces via a USB
connection. The device has connection facilities for one CAN bus,
two serial RS-232 connections, and two additional USB devices.
Device drivers and programming interfaces exist for different
operating systems, so programs can easily access a connected CAN
bus.
Tip: At the end of this manual (Appendix C) you can find a
Quick Reference with brief information about the installation
and operation of the PCAN-USB Hub.
1.1 Properties at a Glance
High-speed USB 2.0 hub with
•USB to CAN interface, connection through 9-pin D-Sub
(in accordance with CiA® 102)
•Two USB to RS-232 converters using two
D-Sub connectors (9-pin)
•Two High-speed USB 2.0 downstream ports
Passive (bus-powered) hub operation through the USB port of a
PC enables power consumption of up to 100 mA per USB
channel
Active (self-powered) hub operation through the optional
external hub power supply (9 - 36 V) enables power
consumption of up to 500 mA per USB channel
Guaranteed high transfer rates on all channels if a Full-speed
device is connected, thanks to a hub controller with 4
transaction translators

PCAN-USB Hub – User Manual
6
Bit rates up to 1 Mbit/s
Time stamp resolution approx. 42 μs
Compliant with CAN specifications 2.0A and 2.0B
NXP PCA82C251 CAN transceiver
5-Volt and external power supply at the CAN connector
connectible by solder bridges, e.g. for external bus converter
Extended operating temperature range from -40 to 85 °C
(-40 to 185 °F)
Note: This manual describes the use of the PCAN-USB Hub
with Windows. You can find CAN drivers for Linux and the
corresponding application information on the provided CD in
the directory branch Develop and on our website under
www.peak-system.com/linux.
1.2 System Requirements
A vacant USB port at the computer (USB 2.0 recommended)
Operating system Windows 7/Vista/XP (32/64-bit)
or Windows CE 6.x (x86 and ARMv4 processor support)
or Linux (32/64-bit)
Note: Do not use a USB extension cable to connect the PCAN-
USB Hub to the computer. The use of an extension cable does
not comply with the USB specification and can lead to
malfunction of the adapter.

PCAN-USB Hub – User Manual
7
1.3 Scope of Supply
PCAN-USB Hub in aluminum casing
Mating connector for voltage supply
Device drivers for Windows 7/Vista/XP (32/64-bit)
and Linux (32/64-bit)
Device driver for Windows CE 6.x
(x86 and ARMv4 processor support)
PCAN-View CAN monitor for Windows
PCAN-Basic programming interface consisting of an interface
DLL, examples, and header files for all common programming
languages
Manual in PDF format

PCAN-USB Hub – User Manual
8
2Installing the Software and
the Adapter
This chapter covers the software setup for the PCAN-USB Hub
under Windows and the connection of the hub to the computer.
Drivers for the CAN interface as well as the RS-232 interfaces are
installed.
Setup the driver for the CAN interface before connecting the PCAN-
USB Hub to the computer for the first time.
Do the following to install the driver for the CAN interface:
1. Windows XP only: Make sure that you are logged in as user
with administrator privileges (not needed for normal use of
the PCAN-USB Hub later on).
2. Insert the supplied CD into the appropriate drive of the
computer. Usually a navigation program appears a few
moments later. If not, start the file Intro.exe from the root
directory of the CD.
3. On the page English > Drivers activate the entry PCAN-USB.
4. Click on Install now. The setup program for the driver is
executed.
5. Follow the instructions of the setup program.
Tip: If you don't want to install the CAN monitor PCAN-View for
Windows onto hard disk together with the driver, you have the
option to start the program later directly from CD without prior
installation.

PCAN-USB Hub – User Manual
9
Do the following to connect the PCAN-USB Hub and carry out
the initialization of the CAN driver and the installation of the
drivers for the RS-232 interfaces:
Note: Do not use a USB extension cable to connect the PCAN-
USB Hub to the computer. The use of an extension cable does
not comply with the USB specification and can lead to
malfunction of the adapter.
1. Connect the PCAN-USB Hub to a USB port at the computer.
The computer can remain powered on.
Windows notifies that new hardware has been detected.
2. Windows XP only: A Wizard dialog box appears. Follow its
instructions. Deny the search for driver software at
Windows Update and select the automatic software
installation during this procedure.
3. Dialog boxes appear for the installation of the drivers for the
RS-232 interfaces (devices “USB <-> Serial Cable” and “USB
Serial Port”). Follow their instructions. Select the search for
driver software on CD during this procedure.
All Windows operating systems: The drivers are found and
installed by Windows.
4. Afterwards you can work as user with restricted rights
again.
After the initialization process for the driver for the CAN interface is
finished successfully the red LED at the CAN connector of the
PCAN-USB Hub is illuminated.

PCAN-USB Hub – User Manual
10
The Device Manager of Windows contains the following new
entries:
Ports (COM & LPT) > USB Serial Port (COMn1) and USB Serial
Port (COMn1)
CAN-USB-Hardware > PCAN-USB Device
Universal Serial Bus controllers > Generic USB Hub
Universal Serial Bus controllers > USB Serial Converter A
Universal Serial Bus controllers > USB Serial Converter A
Universal Serial Bus controllers > USB Composite Device
1The port numbers for the COM ports may vary. If a COM port is occupied, the next
vacant port number is used. Changing the port number in the Device Manager:
Ports (COM & LPT) > USB Serial Port (COMn) > Properties > Port Settings >
Advanced
