Peavey PR 15 User manual

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff
ssppaaccee))::
49 Hz to 1 kHz
SSeennssiittiivviittyy ((11 WWaatttt//11 mmeetteerr))::
97 dB
PPoowweerr rraattiinngg ((pprrooggrraamm))::
400 Watts
PPoowweerr ccaappaacciittyy ((ppeeaakk))::
800 Watts
TTrraannssdduucceerr ccoommpplleemmeenntt::
Heavy duty 15" woofer with
3/8" voice coil and 50 oz.
magnet, 14XT™1.4" titanium
diaphragm dynamic
compression driver
DDrriivveerr pprrootteeccttiioonn::
Positive temperature coefficient
resistor
NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::
90˚ x 40˚
NNoommiinnaall iimmppeeddaannccee::
8 Ohms
IInnppuutt ccoonnnneeccttiioonnss::
Two 1/4" phone jacks in parallel
EEnncclloossuurree mmaatteerriiaallss aanndd ffiinniisshh::
Injection-molded 1/4" thick
polypropylene with textured
finish; dark gray color
DDiimmeennssiioonnss ((HH xx WW xx DD))::
8.56 " x 1.31 " x 17"
7 .55 cm x 54.13 cm x 43.18 cm
Width in rear: 11.5" { 9. 1 cm}
WWeeiigghhtt::
4 lbs. (19.1 kg)
MMoouunnttiinngg oorr ssuussppeennssiioonn::
Molded-in stand-mounting cup,
top and bottom flying point
inserts
BBuulllleettss::
• Two-way sound reinforcement
enclosure
• 15" heavy-duty woofer with
3/8" voice coil and 50 oz.
magnet
• 14XT™titanium diaphragm
compression driver with 1.4"
titanium diaphragm
• 400 Watts program/800 Watts
peak power handling
• Crossover network for driver
protection and EQ
• High frequency driver
protection
• 90˚ x 40˚ coverage constant-
directivity horn for better off-
axis tonality
• Lightweight trapezoidal
enclosure
SPECIFICATIONS PR™15

SPECIFICATIONS PR™15
• Durable plastic injection-molded
enclosure
• Heavy duty steel grille
• Molded-in pole mount
• Top and bottom flying point inserts
DDeessccrriippttiioonn
The PR 15 is a two-way sound
reinforcement system consisting of
a heavy duty 15" woofer and a
14XT™titanium diaphragm, dynamic
compression driver mounted on a
90˚ x 40˚ coverage constant-
directivity horn.
The lightweight-yet-rugged
injection-molded plastic enclosure
with molded-in stand-mount cup
facilitates portable use for live
music or speech sound. A black
powder-coated steel grille provides
driver protection and a professional
appearance.
The PR 15 speaker system is rated at
400 Watts program power handling,
and the full crossover network
includes high voltage film capacitors
and high frequency driver protection
for clear, punchy sound and
excellent long-term reliability. Two
1/4" phone jack input connectors
make daisy-chaining to other
speakers simple.
CCaauuttiioonn::Before attempting to
suspend the PR 15 consult a
certified structural engineer. The
speaker may fall due to improper
suspension, resulting in serious
injury and property damage.
Additional speaker enclosures
must not be suspended below a PR
15, nor should additional weight be
suspended from one of these units.
Use only the correct mating
hardware. All associated rigging is
the responsibility of others.
Always use all four inserts of a
given group as a set. NEVER use
just one insert to fly a cabinet! The
four insert groupings include a top
group and a bottom group, but
some models have an additional
group of four on the rear plane of
the cabinet. Maximum enclosure
angle from vertical hang: 30˚
When mounting or flying, you must
use a suitable safety chain or wire
rope to secure the speaker loop
this through the top handle and
firmly attach to a suitable
structural member as indicated by
a certified structural engineer.
The recommended range of torque
for the mounting bolt is 3 to 3-3/4
lb./feet of torque. DO NOT
OVERTIGHTEN! If an insert spins, it
has been damaged and the cabinet
cannot be flown!
Never transport the cabinet while
mounted on an array bracket, or
other mounting bracket, this may
unduly stress the mounting
inserts.
WWAARRNNIINNGG!! ((nnoottee ttoo ssttrruuccttuurraall
eennggiinneeeerr))
The end of the mounting bolt
should not penetrate the cabinet
more than 1/ " beyond its surface.
If this penetration depth is
exceeded, then the insert may be
damaged or unseated from the
cabinet, severely compromising its
the mounting integrity!
The correct mounting bolt diameter
and threads per inch are: 1/4" x
0. We recommend the use of a
grade 5 bolt. For custom brackets,
we recommend a 5/16" hole for
the bolts to allow for tolerances
and adjustment.
33 ++ YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY
NNOOTTEE:: For details, refer to the
warranty statement. Copies of
this statement may be obtained
by contacting Peavey Electronics
Corporation, P.O. Box 898,
Meridian, Mississippi 39301- 898.

SPECIFICATIONS PR™15
PR 15 Input Plate

SPECIFICATIONS PR™15
80304975
Features and specifications subject to change without notice.
Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 • [phone] • FAX [phone] • www.peavey.com
© 003 Printed in the U.S.A. 11/03
