Peavey TLS 1X User manual

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff ssppaaccee))::
60 Hz to 20 Hz
FFrreeqquueennccyy rreessppoonnssee ((++//-- 33 ddBB,, hhaallff
ssppaaccee))::
97 Hz to 20 Hz
SSeennssiittiivviittyy ((11ww//11mm))::
97 dB
PPoowweerr rraattiinngg ((pprrooggrraamm))::
160 Watts
PPoowweerr ccaappaacciittyy ((ppeeaa))::
320 Watts
MMaaxxiimmuumm SSPPLL::
121 dB
TTrraannssdduucceerr ccoommpplleemmeenntt::
Blue Marvel®10" woofer, premium
dual bi-morph compression drivers
with 1.5" diaphragms on a dual
exponential horn
DDrriivveerr pprrootteeccttiioonn::
Dual bi-morph compression driver
series resistor protection networ
NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::
60˚ x 30˚
EElleeccttrroo--aaccoouussttiicc ccrroossssoovveerr ffrreeqquueennccyy::
3.4 Hz
NNoommiinnaall iimmppeeddaannccee::
8 Ohms
IInnppuutt ccoonnnneeccttiioonnss::
Two 3/4" phone jac s in parallel
EEnncclloossuurree mmaatteerriiaallss aanndd ffiinniisshh::
Trapezoidal, blac carpet-covered
enclosure with dado joined 1/2"
MDF (Medium Density Fiberboard),
and a full-length blac powder -
coated steel grille
DDiimmeennssiioonnss ((HH xx WW xx DD))::
FFrroonntt::
20.5" x 15.125" x 12.25"
52.07 cm x 38.418 cm x 31.115 cm
RReeaarr::
20.5" x 11.25" x 12.25"
52.07 cm x 28.575 cm x 31.115 cm
WWeeiigghhtt::
24 lbs. (10.91 g)
OOppttiioonnaall ssyysstteemm uuppggrraaddeess::
TLS™115X add-on subwoofer
BBuulllleettss::
• Two-way sound reinforcement
enclosure
• Peavey exclusive Blue Marvel®
10" woofer
• Premium dual bi-morph
compression drivers, with 1.5"
diaphragms
• Series resistor tweeter
protection networ
• 160 Watts program/320 Watts
pea power handling
• Extremely lightweight
trapezoidal enclosure
• Dual exponential horn
• High quality, heavy duty
carpet covering
• Steel handles
• Steel corners
• Pole stand adapter
SPECIFICATIONS TLS™1X

SPECIFICATIONS TLS™1X
• Rugged dado and rabbet
construction for light weight-yet-
strong joints
• T-Nut spea er mounting
• Heavy duty full-length steel grille
DDeessccrriippttiioonn
The TLS 1X is a two-way spea er system
based on a 10" Blue Marvel®woofer and
premium, dual, bi-morph compression
drivers mounted on a dual exponential
horn. The extremely lightweight-yet-
rugged, carpet-covered trapezoidal
enclosure with steel handles facilitates
portable use for live music or speech
sound reinforcement, as well as music
playbac . A full-length, blac powder-
coated steel grille provides driver
protection and a professional
appearance.
The TLS 1X spea er system is rated at
160 Watts program power handling and
includes a series resistor protection
networ for the premium dual bi-morph
compression drivers, which results in
excellent long-term reliability. Its light
weight and smooth response ma es this
system ideal for smaller venues where
space is in demand, and its two 1/4"
phone jac input connectors ma e hoo -
up a breeze.
Broaden your sound reinforcement
experience by utilizing the TLS 115X
subwoofer with the TLS 1X spea er
system.
33 ++ 22 YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY
NNOOTTEE:: For details, refer to the
warranty statement. Copies of
this statement may be obtained
by contacting Peavey Electronics
Corporation, P.O. Box 2898, Meridian,
Mississippi 39301-2898.
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
60
70
80
90
100
110
dB SPL (re 20 Pa)
Amplitude Response (1W 1m On-Axis)
Figure 1
Features and specifications subject to change without notice.
Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 [phone] • FAX [phone] • www.peavey.com
©2003 Printed in the U.S.A. 2/03
80305047
