RBN™110
Powered Speaker System
Operating
Manual


FCC/ICESCompliancyStatement
ThisdevicecomplieswithPart15oftheFCCrulesandIndustryCanadalicense‐exemptRSSStandard(s).Operationis
subjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust
acceptanyinterferencereceived,thatmaycauseundesiredoperation.
LeprésentappareilestconformeauxCNRd’lndustrieCanadaapplicablesauxappareilsradioexemptsde
licence.L’exploitationestautoriséeauxdeuxconditionssuivantes:(1)I’appareilnedoitpasproduirede
brouillage,et(2)I’utilisateurdeI’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesile
brouillageestsusceptibled’encompromettrelefonctionnement.

Warning:ChangesormodificationstotheequipmentnotapprovedbyPeaveyElectronicsCorp.canvoidthe
user’sauthoritytousetheequipment.

Note–ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,uses,andcanradiateradio
frequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurina
particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryandcorrectthe
interferencebyoneormoreofthefollowingmeasures.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.



Introduction
ank you for purchasing the Peavey® RBN™110 powered speaker system, designed specically for the profes-
sional. e RBN™110 features a bi-amped power section that provides 550 watts of peak power for the woof-
er and 500 watts of peak power for the ribbon driver tweeter, both with DDT™ compression. Featuring a 10”
high-performance woofer and the RD™2.6 true ribbon driver, the RBN™110 provides two independent mixed
input channels, each with Gain control and a mic/line gain switch, and each channel features a combo jack with
1/4” TRS & female XLR and a balanced input with volume control. A DSP based crossover and processor pro-
vides extreme exibility for the user faced with common location acoustics conditions.
Features
* Bi-amplied powered speaker system
* 550 watts peak available woofer power, 500 watts peak available tweeter power
* Both power amps have DDT compression
* 10” High Performance woofer
* Peavey RD™ 2.6 ribbon driver tweeter on a low-coloration waveguide
* Peak SPL up to 125 dB with music!
* DSP based crossover, limiting and EQ
* EQ presets available via rotary encoder pushbutton select
* 9-band EQ and other system settings accessed via rotary encoder pushbutton select
* Dynamic bass boost function
* Up to 150 mS of architectural delay
* Fan cooled for maximum reliability
* Two independent mixed input channels, with Gain control and mic/line gain switch
* Each channel features a combo jack with 1/4” TRS & female XLR balanced input
* Input 2 has a 3.5 mm (1/8”) stereo media input jack
* Output connectors are male XLR
* One full handle on the right side, full handle on top rear
* Full length perforated steel grille with cloth backing
* Rugged polypropylene molded enclosure
* Pole mount built-in
* Low weight – Only 37 pounds!
* Flying point insert groups on top and side mate with VM™ 70 mounting bracket
Description
e Peavey® RBN™110 is a powered, bi-amplied, two-way speaker system engineered to provide very high
levels of performance in a compact powered loudspeaker. is two-way powered system is comprised of a 550
W peak switching power amplier driving a 10” High Performance woofer. e RD™2.6 true ribbon tweeter is
driven by a 500 W peak switching power amplier, and is coupled to a low coloration waveguide with a cover-
age pattern of 110° horizontal by 30° vertical.
e RBN™110 is capable of up to 125 dB peak SPL. e enclosure utilizes tough high-performance plastic in an
injection-molded modied-trapezoidal form, with a full-length coated perforated steel grille to oer an attrac-
tive yet durable powered speaker system. e cabinet and grille are black.
ENGLISH

Two independent mixed input channels each oer a balanced input to the preamp/EQ electronics, and a level
control. Each channel has one combo female XLR and 1/4” TRS phone jack. It is switchable between mic-level
and line-level sensitivity. Channel 2 has a 3.5 mm media jack added. A line out section has male XLR connectors.
e ru outputs allow linking of additional speaker systems, or feed of the signal to a powered subwoofer, etc.
e power ampliers providing the bi-amplication are low-distortion switching units providing 550 W peak
available power into the nominal 8 ohm load of the woofer, and a 500 W peak available power into the nominal 8
ohm load of the tweeter. e power supply for both amps is a switch mode type for low weight and high ecien-
cy. Both ampliers feature our DDT™ compression, which virtually eliminates audible power amplier clipping.
Cooling is via forced air circulation. A full handle on the right side and top rear provides ease of transport, while
mounting points for the Peavey VM™ 70 mounting bracket allow maximum utility.
e combination of the high output woofer with the ribbon tweeter and DSP crossover and EQ provide a clarity
and impact far beyond conventional powered enclosures. e switching power amps and switch-mode power
supply, along with the neodymium magnet systems on the tweeter, provide this high level of technological so-
phistication at a very light weight while at a very reasonable cost.
Applications
e Peavey® RBN™110 has a variety of applications such as sound reinforcement, public address, side ll system,
karaoke, DJ or musical playback.
A typical signal source for the line-level inputs of the Peavey RBN™110 would be a sound reinforcement mixing
console (mixer) or the output from a CD player, MP3 player or tape deck. A dynamic microphone can be con-
nected directly and used as well.

DIRECT THRU
1
1
GAINGAIN
MIC
LINE
2
2
INPUTS
XLR: PIN 2 +
1/4”: TIP +
PIN 3
RING
OUTPUTS
Gnd
LIFT
IN
MEDIA
3.5mm
MIXDIR
Input1 1+ 2
Push to
Select
SUB WOOFER
3.5mm: L/R SUMMED
DIRECT THRU
DIR
MIX
1
1
2
min max
min
PROCESSED
max
Designed and Engineered in U.S.A.
Made in China
CAUTION
AVIS:RISQUE DE CHOC
ELECTRIQUE-NE PAS OUVRIR
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, THIS APPARATUS WARNING:
SHOULD NOT BE EXPOSED TO RAIN OR MOISTURE AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS. TO PREVENT THE
AVIS:
ELECTRIQUE, CET APPAREIL NE DOIT PAS ETRE EXPOSE A LA PLUIE OU A L’HUMIDITE ET
AUCUN OBJET REMPLI DE LIQUIDE, TEL QU’UN VASE, NE DOIT ETRE POSE SUR CELUI-CI.
DANS LE BUT DE REDUIRE LES RISQUES D’INCENDIE OU DE DECHARGE
RISK OF FIRE HAZARD, REPLACE WITH SAME TYPE 250 VOLT FUSE.
REMPLACER PAR UN FUSIBLE DE MEME TYPE ET DE 250 VOLTS.
ON
POWER
CAN-ICES-3(B)/NMB-3(B)
- - Apparatet må tilkoples jordet stikkontakt.
(For Norway only)
- - Apparaten skall anslutas till jordat uttag.
(For Sweden only)
-- Laite on liitettävä suojamaadoituskoskettimilla
varustettun pistorasiaan. (For Finland only)
FOR 120V OPERATION, FUSE
MUST BE CHANGED TO T10AH/250V
FOR 220-240V OPERATION, FUSE
MUST BE CHANGED TO T5AH/250V
220-240V
T5AH/250V
120V
T10AH/250V
FUSE
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
120V
220-240V
50/60Hz
200 WATTS
Consumo de energia
200Wh
AC Cable
A.D.S.P.
Advanced Digital Signal Processing
POWERED SPEAKER
RBN 112
TM
FUSE
FUSE
LOWER REAR PANEL
ONOFF SWITCH 1
is rocker switch supplies AC power to the RBN™110 when switched to the ON position. e ON position is
with the top side of the switch pushed “in” or nearly ush with the rear panel.
FUSE (2)
e unit is AC power line fuse protected from overloads and fault conditions with a slow-blow 5 x 20mm
250V fuse. is fuse is located within the cap of the fuse holder. If the fuse fails, THE FUSE MUST BE RE-
PLACED WITH THE SAME TYPE AND VALUE IN ORDER TO AVOID DAMAGE TO THE EQUIPMENT
AND TO PREVENT VOIDING THE WARRANTY!
e fuse in the RBN™110 can be replaced with a time-delay type 5 x 20 mm size 250V rated fuse.
For 120VAC operation, a fuse rated at 10 amps should be used. In the USA, types GDC, GMC, 215, 218, and 477
cartridge-style 5 x 20 mm size fuses with a 10 amp 250V rating can be used.
For 220-240VAC operation, a fuse rated at 5 amps and 250V should be
used, which conforms to the international fuse classication “T5AH”.
If the unit continues to blow replacement fuses, do not keep replacing them, it should be taken to a qualied
service center for repair. To replace the fuse, be sure to remove the IEC power cord from the IEC socket.
IEC POWER CORD CONNECTION (3)
is receptacle is for the IEC line cord (supplied) that provides AC power to the unit. It is very important
that you ensure the RBN™110 has the proper AC line voltage supplied.
You can set the proper voltage for your RBN™110 using the Voltage Selector switch (4) on the rear panel of the
unit.
Please read this guide carefully to ensure your personal safety as well as the safety of your equipment. Nev-
er break o the ground pin on any equipment. It is provided for your safety. If the outlet used does not have a
2
3
4
1

ground pin, a suitable grounding adapter should be used and the third wire should be grounded properly. To
prevent the risk of shock or re hazard, always be sure that the mixer and all other associated equipment are
properly grounded.
VOLTAGE SELECTOR SWITCH (4)
e RBN™110 has a voltage selector switch to allow switching between an input power voltage of 120VAC to a
range from 220VAC to 240VAC, all at either 50 or 60 cycles per second (Hz). It should be set to the proper volt-
age for your country out of the box. However, world conditions are such that some areas have power line voltages
diering from the voltage used by the majority of any given locale.
Be sure to check the position of the voltage selector switch to see that it matches the power line voltage used
locally. If it does not match, then to change the voltage to the correct one, follow the steps outlined below.
Changing the Voltage Range of the RBN™110
First, make sure the RBN™110 is disconnected from the power line, and that the power switch (1) is in the OFF
position.
Second, unscrew the screws holding the clear switch protector on the voltage selector switch (4) just a little, just
enough to allow rotation of the clear switch protector. e screws DO NOT need to be unscrewed very far.
ird, rotate the clear plastic protector about 90 degrees to uncover the voltage selector switch. One side of the
cover has a slot, the other just a hole, the side with the hole is the side that pivots.
Fourth, using a small at blade screwdriver, push the red selector switch slide plate to the other side from where
it was. e voltage that is now visible on the red slide plate is the one you have selected.
Fih, rotate the clear plastic protector back underneath the loosened screws, and tighten one down while hold-
ing the clear plastic protector in place. Tighten the other screw down, and make sure both screws are tight.
If the screws are over-tightened, this could damage the voltage selector switch clear plastic cover, so do not apply
excessive force to the screws!
Sixth, the fuse should be changed to the correct amperage rating. For an input power voltage of 120VAC, use a 10
amp rated, 250V 5 x 20 mm cartridge type time-delay fuse, which conforms to the international fuse classica-
tion “T10AH”.
For an input power voltage range of from 220VAC to 240VAC, use a 5 amp rated, 250V 5 x 20 mm cartridge type
time-delay fuse, which conforms to the international fuse
classication “T5AH”.
e IEC power cord that is correct for your locale can now be plugged into the IEC receptacle (3), and the Power
switch (1) activated to turn on the powered RBN™110 speaker system.

UPPER REAR PANEL
INPUTS (5)
Two input channels are provided. e line-level input is of the medium impedance balanced type. e jack is a
combo female XLR and 1/4” TRS connector. Sensitivity of this input is 0.42 volts for full output, when the MIC/
LINE switch (7) is in the LINE position. Channel 2 has a 3.5 mm jack for mobile device signal sources.
GAIN (6) Present on both input Ch 1 and input Ch 2
Controls the gain or output level of the same numbered input channel. It is used to directly set the system output
level for a given input signal.
MIC/LINE switch (7) Present on both input Ch 1 and input Ch 2
Switches between LINE level gain (out position) and MIC level gain (in position). MIC position increases gain
26 dB to allow use of most dynamic microphones.
NOTE: Phantom power is not supplied on the INPUT (5) jacks
Gnd LIFT switch (8)
Allows the shield to be disconnected from the chassis ground to alleviate hum from ground loops
DIRECT THRU output jack (9)
is jack is intended for the use of linking multiple RBN™110’s in a line, or to provide a feed to a powered sub-
woofer, or other electronics that needs to receive a full range version of the input signal.
DIR/MIX switch (10)
Switches between Direct ru from channel 1 input, or a mix of channel 1 and channel 2 at the Direct ru out-
put (9)
SUB WOOFER PROCESSED output jack (11)
Provides a ltered signal for use with powered Sub woofer speaker systems other than the RBN™215 or 118.
Follow the instructions in the Setup Wizard in the RBN™110 menu on the LCD screen using the Push-To-Select
5911
8
7
6
12
13
10

button for proper subwoofer set-up and connection.
LCD Display (12)
Provides a menu read-out manipulated and activated by the Push-To-Select button (13)
Push-To-Select button (13)
Rotary knob that allow the user to select and choose menu options on the LCD display screen (12). Pushing the
button in till it detents makes a menu choice, selecting the action or option highlighted in the LCD screen.
UPPER REAR PANEL
WARNINGS
Cautions
e unit must be disconnected from the AC power source before any work is done on it. Refer all servicing to
qualied service personnel.
e back plate can become hot to the touch. Do not block or cover the fan or the exhaust louvers from ventila-
tion. ere must be a minimum of 4” of space behind the fan. Do not allow the airow to be become blocked by
objects such as curtains or drapes, thermal building insulation, etc. It is recommended that the rear of the
RBN™110 not be placed in a closed space or a space that has no fresh, cool airow.
Be sure to keep the microphone away from the front of the speaker aer connecting it to the input, and while
setting the microphone level, or very loud feedback will occur! Damage to the system is likely if this occurs!
DO NOT connect the inputs of the RBN™110 to the output of a power amplier. e inputs are meant to be
driven from a line-level strength signal.
DO NOT remove the protective metal grille.
WARNING! e RBN™110 is very ecient and powerful! is sound system can permanently damage hearing!
Use extreme care setting the overall maximum loudness!
e apparent sound level of the RBN™110 can be deceiving due to its clear, clean sound output. e lack of dis-
tortion or obvious distress can make the sound level seem much lower than it actually is. is system is capable
of SPL in excess of 125 dB at 1 M from the speaker!
Flying/Rigging Information
Caution: Before attempting to suspend this speaker, consult a certied structural engineer. Speaker can fall
from improper suspension, resulting in serious injury and property damage. Do not suspend or mount any other
product or device from this enclosure! Maximum enclosure angle 30°. Use only the correct mating hardware.
All associated rigging is the responsibility of others.
Whenever possible, in addition to the nominal primary mounting method, use a suitable safety chain or wire
rope, looped through the side handle or attached to one of the other groups of inserts, and rmly attached
to a suitable structural member as indicated by a certied structural engineer. We recommend the use of
read-locker at the insert point bolts, so the bolts cannot vibrate loose.

Never transport the cabinet using the array bracket or other mounting brackets as a structural member, while
the cabinet is mounted on an array bracket or other mounting bracket and unsupported otherwise, as this may
unduly stress the mounting inserts.
WARNING! (note to structural engineer)
NOTE: e screws in the RBN™110 y point plate inserts are merely used to plug the mounting point holes,
those screws are not intended to be used for attachment or ying purposes. Use the correct type and grade of
bolt into the mounting point inserts. e correct mounting bolt diameter and thread spacing are: M6, 1.0 mm
per thread. Use of a metric grade 8.8 bolt or better is recommended.
e middle two screws of a smaller size in the middle of each mounting plate group of inserts are mounting plate
retention screws, and should not be removed from the insert mounting plate, or that location used as a ying
point. ere is no M6 insert at these locations.
e RBN™110 mounting inserts are designed to be used in groups of four with the Peavey® VM70 mounting
bracket (03011050), as well as the Peavey Impulse® 10” array bracket (00448690 black, 00440400 white). e
RBN™110 can also be used with the Peavey® Wall-Mount Speaker Stand (00922940 black), which will t into the
built-in stand mount cup on the bottom of the cabinet.
Note that the standard hardware supplied with the VM70 is NOT metric, additional metric bolts with the proper
ratings will have to be obtained.
Hardware for Flying/Rigging the RBN™110
Eyebolts or bracket bolts should be M6 metric thread, 1.0 mm per thread.
Eyebolts and bracket bolts must conform to certain minimum strength criteria for safety reasons.
Unspecied eyebolts found at local hardware stores are not strong enough to maintain safety for overhead ying
or rigging. Use only forged steel shoulder machinery eyebolts designed for rigging use, which adhere to the stat-
ed standards as outlined below.
is Peavey loudspeaker should be suspended overhead only in accordance with the procedures and limitations
specied in the User’s Manual and possible manual update notices.
is system should be suspended with certied rigging hardware by an authorized rigging professional and in
compliance with local, state and federal suspension ordinances.
Hardware Specications
Forged shoulder machinery eyebolts should be an M6 size, 1.0 mm per thread, and must conform to DIN 580
or ASTM A489, for Germany, BGV-C1 is the relevant standard. Minimum shank length should be 20 mm. e
eyebolts should be rated for a minimum of 450 lbs straight pull working load.
Bolts used on custom mounting brackets must be certied to be a metric grade 8.8 or better.
If there are any questions regarding the proper hardware or practices for safe ying or rigging of the Peavey
RBN™110, contact a certied structural engineer, or consult with those local rigging companies who have
trained and certied personnel.

Connecting AC Power To e RBN™110
e RBN™110 comes with an 6-foot IEC connection AC power cord. If you are using an extension cord or power
strip with this powered speaker, make sure it is of good quality and of a sucient current capacity to maintain
safety and maximize the power output capability of the RBN™110. For maximum undistorted output, do not
connect any other device to the same extension cord that the RBN™110 is connected to. Do not exceed the rated
current capacity of the extension cord with the sum total of all units connected to it.
When rst plugging in the AC cord, make sure the power switch is in the O position, and then turn it On only
once the power cord has been connected. Built-in muting will engage when the proper sequence of steps is tak-
en.
Use of the RBN™110 with a Speaker Stand
e RBN™110 has a stand mount cup molded-in so that the system can be stand mounted on a standard 1 3/8”
(36mm) diameter stand pole.
When using stands or poles, be sure to follow these precautions:
A. Check the stand or pole specs to make sure that it can support the weight of the RBN™110 (37 lbs./16.8
kg), and observe all safety precautions stated by the stand manufacturer, including the maximum
height the stand is rated for.
B. Always place the stand on a at, level and stable surface, and be sure to fully extend the stand legs as per
the stand manufacturer’s instructions.
C. Try to make sure that the stand legs are oriented for the least danger of tripping to those in the vicinity of
the stand. Never block a doorway or hallway with the legs of a stand.
D. Try to route cables so that people will not trip over them, or tip the speaker over. Use of duct tape, cable
channels or guards, or other appropriate tie-down/cover –up devices should be carefully considered and
implemented.
E. When installing or de-installing the speaker on the stand, it is a good practice to have a helper if possi
ble, it can be hard to “thread the needle” and mate the stand cup to the stand pole while holding the
RBN™110 speaker system at arm’s length. It is also helpful if someone holds the speaker stand and pole
down while the RBN™110 is removed from the stand pole, this prevents the RBN™110 from
pulling the pole up with it.
F. When using stands outdoors, never attach banners or ags to the stands or the RBN™110 speaker system,
strong winds may cause the speaker to blow over. If there is a possibility of windy conditions, then
it may be prudent to consider weighting or locking down the stand legs to prevent the RBN™110 speaker
system from being blown over.
Use of the RBN™110 with an RBN™215 Sub or RBN™118 Sub
e RBN™215 Sub or RBN™118 Sub can be used with a RBN™110 using the threaded 1 3/8” diameter pole supplied
with the Sub. All the precautions stated for use of the RBN™110 with a speaker stand should be applied as appro-
priate to use of the RBN™110 with a RBN™215 Sub or RBN™118 Sub. at would be primarily items B, D, E and F.
Connecting a Signal to the RBN™110
e inputs (5) provides either a balanced mic- or line-level input, allowing the use of a 1/4” TRS (ring-tip-sleeve)
type phone plug or a male XLR plug.
ere is also a 3.5 mm MEDIA IN jack on the Channel 2 input.
e 3.5mm TRS input jack has its own preamp designed for connection to the headphone jack on mobile audio
devices. e Channel 2 Gain control adjusts the signal level from all of the channel 2 input connectors. It is pos-
OPERATING INSTRUCTIONS
