PECO®Wave Wireless® System
Operating Manual
RW205 Wireless
Receiver
TW205
Non-programmable
Wireless Thermostat
TW206 Programmable
Wireless Thermostat

2
Thank you for choosing the PECO®Wave Wireless®System.
The PECO Wave Wireless Systemis comprised of a wireless thermostat transmitter and a
receiver. PECO offers two wireless thermostats: the non-programmable TW205 Thermostat,
and the programmable TW206 Thermostat. Both operate with the same wireless RW205
Receiver. This operating manual contains important information on operating the TW205 and
TW206 Thermostats and on the RW205 Receiver.
The TW205/TW206 are designed for use primarily in 2- or 4-Pipe Fan Coil Units, PTAC,
PTHP, and heat pump applications. The TW205/TW206 support 1-HEAT/1-COOL, 1-HEAT/
2-COOL, 2-HEAT/1-COOL, and three fan speeds. The TW205/TW206 may be powered by
batteries, 24 VAC, or both (recommended). The TW206 can be configured for 7-day individual,
5/2-day, 5/1/1-day, or 7-day identical programmable operation, with four time periods per day.
The TW205/TW206 feature an attractive blue digital display and support auto changeover,
remote temperature probes, outdoor air damper/reversing valves, wireless occupancy sensors
(SW205), and door switches (SW206).
The RW205 Receiver is wired to the HVAC equipment and controls all outputs.
T
HE PE
CO
WAVE WIRELE
SS
S
Y
S
TEM

3
Product Specifications
Temperature Range: 50° to 90° F (10° to 32° C)
Differential: 1° F (0.5°C)
Input Power: TW205-TW206 Thermostat: Two AA alkaline batteries or 24 VAC,
50/60 Hz; RW205 Receiver: 24 VAC, 50/60 Hz or 100-277 VAC, 50/60 Hz
Output Rating: RW205 output rating 24VA (Pilot Duty)
Wireless Type: 902 to 928 MHz Band, Frequency Hopping Spread Spectrum (FHSS)
Wireless Range: 100 feet (30.48 meters) typical reliable range in open air
Operation Temperature: 0° to 120° F (-17° to 48°C)
Shipping Temperature: -20° to 130°F (-28°to 54°C)
Operating Humidity: 5% to 95% RH, non-condensing
Physical Dimensions: TW205-TW206: 4.5”H x 5.75” W x 1.1”D
RW205: 4.8”H x 3.8”W x 1.3”D
Read and save this operating manual.

4
TABLE OF CONTENTS
The PECO Wave Wireless System......................................................................................................2
Front panel display reference: TW205 Thermostat..............................................................................6
Front panel display reference: TW206 Thermostat..............................................................................7
Button operation ..................................................................................................................................8
The TW205 & TW206 displays ..........................................................................................................12
Set the time and day (TW206 only) ...................................................................................................16
Select the Fahrenheit or Celsius temperature ...................................................................................17
Programming the TW206...................................................................................................................18
Custom program (TW206 only) .........................................................................................................19
Custom program: Copy feature (TW206 only)...................................................................................22
Overriding the program (TW206 only) ...............................................................................................23
FCC COMPLIANCE...................................................................................................................................24

5
!CAUTION!
•READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO OPERATE THIS THERMOSTAT AND
RECEIVER.
• Contact a qualified service person if at any time your system does not operate properly.
• Use care to avoid static discharge to the thermostat and receiver.
• Failure to observe safety information and comply with instructions could result in PERSONAL INJURY,
DEATH AND/OR PROPERTY DAMAGE.
• To avoid electrical shock or damage to equipment, disconnect power before installing or servicing and use
only wiring with insulation rated for full thermostat operating voltage.
• To avoid potential fire and/or explosion, do not use in potentially flammable or explosive atmospheres.
• This product, when installed, will be part of an engineered system whose specifications and performance
characteristics are not designed or controlled by PECO. You must review your application and national
and local codes to assure that your installation will be functional and safe.
• Retain these instructions for future reference.
IMPORTANT NOTE: This thermostat was shipped with factory default settings. Your thermostat’s installer
may have configured the thermostat differently from the factory default settings, and may have modified
or disabled certain features. Contact the installer or a service technician if you have questions about the
thermostat’s configuration.

6
The illustration below depicts the non-programmable TW205 Thermostat display and
buttons.
FRONT PANEL DISPLAY REFERENCE: TW205 THERMOSTAT
SYSTEM button
1
Display
2
FAN button
4
°F /°C button
5
UP ▲and
DOWN ▼
buttons
AUTOMATION AND CONTROLS

7
The illustration below depicts the programmable TW206 Thermostat display and buttons.
FRONT PANEL DISPLAY REFERENCE: TW206 THERMOSTAT
SYSTEM button
1
Display
2
FAN button
5
UP ▲and
DOWN ▼
buttons
3
PROGRAM
button
AUTOMATION AND CONTROLS

8
System Button
The SYS (system) button is used to control the operating mode of the TW205/TW206.
Press the SYS button once to show the menu options, as described below. Continue
pressing SYS button to scroll through menu options. As you scroll, the menu option
being accessed (operating mode) will flash. To select that option, allow the display to
automatically time out. The TW205/TW206 saves the “flashing” option and switches the
thermostat to the selected operating mode. The SYS modes are:
HEAT – Indicates the system is in heating mode.
COOL – Indicates the system is in cooling mode.
AUTO – Indicates the system will automatically changeover between heating
and cooling modes as the room temperature varies.
OFF – Disables thermostat outputs.
SETBACK –Indicates the heating or cooling system is operating in manual setback
mode. (To appear, SETBACK must be selected in “Advanced Configuration.” See the
“PECO Wave Wireless System TW205/TW206 &RW205 Installation Guide”).
NOTE: SETBACK must be selected in the Service Menu in order to appear in
the SYS mode (see “Advanced Configuration” in the “Wave Wireless System
TW205-TW206 & RW205 Thermostat and Receiver Installation Instructions”). The
SYS button is also used to scroll through the Service Menu in advanced configuration.
BUTTON OPERATION
1
i

9
Fan Button
The FAN button is used to control the fan mode. Pressing FAN will show fan mode options.
Press FAN continuously to scroll through the options. The “flashing” option is automatically
saved and the thermostat times out. The modes are:
FAN – “FAN” will always be lit in conjunction with “ON” or “AUTO.”
ON – Turns on continuous fan, even if no demand exists for heating or cooling.
AUTO – Sets fan cycles with demand for heating and cooling.
*ON Hi – High speed fan is on continuously, even if no demand exists for heating or
cooling.
*ON M – Medium speed fan is on continuously, even if no demand exists for heating or
cooling.
*ON Lo – Low speed fan is on continuously, even if no demand exists for heating or
cooling.
*AUTO Hi – High speed fan cycles with active demand for heating and cooling.
*AUTO M – Medium speed fan cycles with active demand for heating and cooling.
*AUTO Lo – Low speed fan cycles with active demand for heating and cooling.
*NOTE: Options must be selected in the Service Menu in order to appear (see
“Advanced Configuration” in the “Wave Wireless System TW205-TW206 & RW205
Thermostat and Receiver Installation Instructions”).
2
BUTTON OPERATION
i

10
Program Button (TW206 only)
The PROG (program) button is used to program the TW206. Press PROG button once
to show the five program mode options, described below. Press ▲or ▼buttons to scroll
through the options. As you scroll, the option being accessed will flash. To select the
flashing option (e.g.,”CLOCK”), press PROG again, and an associated submenu appears.
Press ▲or ▼to scroll through the submenu options. Press the PROG button to select an
option. The thermostat times out and automatically saves the “flashing” option. The five
program mode options are:
CLOCK – Sets the current time and day (see “Setting the time and day”).
°F / °C – Sets temperature display to Fahrenheit or Celsius. Default setting is
Fahrenheit (see “Selecting the Fahrenheit or Celsius temperature”).
SET – Initiates the time and temperature schedule for a particular day or group of days.
Allows you to reset the thermostat to the factory program default settings
(see “Programming the TW206”).
COPY – Copies one day’s schedule to another day or to another group of days (see
“Programming the TW206”).
HOLD – Puts the thermostat in Temporary or Permanent Hold mode. Overrides your
programmed settings but does not lose them (see “Overriding the program”).
NOTE: Press the SYS button to exit the program menu at any time.
BUTTON OPERATION
3
i

11
°F /°C Button (TW205 only)
The °F /°C button allows you to toggle between Fahrenheit or Celsius temperature
displays. Press ▲or ▼to select either option. Flashing option is automatically saved.
°F / °C –Sets temperature display to Fahrenheit or Celsius. Default setting is
Fahrenheit.
Up ▲and ▼Down Button Operation
The up ▲and ▼down buttons are used to display the current setpoint, to create a
temporary override and increase or decrease the current setpoint, or to access the
Service Menu. On the TW206, they are also used with the PROG button to select various
programming options.
BUTTON OPERATION
4
5

12
The TW205 and TW206 displays are illustrated below (see Fig. 1 & 2). While both models share
certain common features, the TW206 has additional capabilities (shown by asterisks “*”). The
Display menus are:
System Mode Display Programming Commands* Program Override Commands*
Temperature Display Time Period Indicators* Service Indicator
Time & Day Display* Fan Operation Indicators Keypad Lockout
Battery Indicator
THE TW205 & TW206 DISPLAYS
Figure 1. TW205 display.
Figure 2. TW206 display.
1
2
3
4
5
6
7
8
9
10
8
21
6
910
*Note: Features only present in TW206.
8
2
3
1
6
57
4
910
i

13
System Mode Display
HEAT – Indicates the system is in heating mode.
COOL – Indicates the system is in cooling mode.
AUTO – Indicates the system will automatically changeover between heating and cooling
modes as the room temperature varies.
OFF – Disables all thermostat outputs. While thermostat is disabled, it will only show
current temperature (TW205/TW206) and time (TW206).
SETBACK – Indicates the heating or cooling system is operating in manual setback mode.
Temperature Display
Default display: Digits display the current room temperature. During programming, you can
set the desired temperatures format to Fahrenheit or Celsius (°F / °C).
Time & Day Display *(TW206 only)
Default display: Digits indicate the current time. Day abbreviations indicate the current day.
During programming: Digits and days are used to program time periods.
CLOCK – Appears in programming when the clock is being set.
24Hr – Appears in programming to indicate time will be displayed in 24-hour clock format.
AM / PM – Appears in programming and indicates 12-hour clock format.
THE TW205 & TW206 DISPLAYS (CONT.)
1
2
3

14
Programming Commands*(TW206 only)
SET – Enters thermostat into custom program mode which allows you to specify unique
times and temperatures for a particular day or for group of days.
COPY – Allows you to copy all of an individual day’s settings to another day/group of days.
DFLT – Restores the thermostat to the factory program.
SYS – Allows you to exit the PROG menu; current menu option is not saved.
Time Period Indicators *(TW206 only)
WAKE, DAY, EVE, and SLEEP are the names given to the four time periods per day. Each
time period has its own unique setpoint times and temperatures.
Fan Operation Indicators
FAN – “FAN” will be always be lit in conjunction with “ON” or “AUTO.”
ON – Indicates constant, continuous fan operation.
Auto – Indicates fan is only on with heating or cooling demand.
Hi – Indicates high speed fan; always lit in conjunction with “ON” or “AUTO.”
M – Indicates medium speed fan; always lit in conjunction with “ON” or “AUTO.”
Lo – Indicates low speed fan; always lit in conjunction with “ON” or “AUTO.”
Program Override Commands *(TW206 only)
While in HOLD mode, you may select temperature settings without affecting scheduled
time periods.
THE TW205 & TW206 DISPLAYS (CONT.)
4
5
6
7

15
HOLD – Indicates thermostat is in a Temporary or Permanent Hold.
HOLD HRS – During programming, appears in conjunction with clock digits; allows
program to be put on Temporary Hold for up to 24 hours.
HOLD DAYS – During programming, appears in conjunction with the clock digits; allows
program to be put on Temporary Hold for up to 99 days.
HOLD ON – Turns on the Permanent Hold. The current setpoint is maintained indefinitely
or until the Permanent Hold is turned off.
HOLD OFF – Turns off the Permanent Hold and resumes programmed settings.
Service Indicator
The wrench symbol will flash during wireless pairing. The wrench symbol is also displayed
when there is a temperature sensor error. The wrench symbol indicates there is an open or
a short connection to the remote sensor. When this occurs, the TW205/TW206 Thermostat
will disable all outputs and illuminate the wrench symbol. Contact a service technician to
determine the cause of the error.
Keypad Lockout
Allows you to set keypad access. If keypad prohibits input, see “Advanced Configuration”
in “PECO Wave Wireless System TW205/TW206 &RW205 Installation Guide.”
Battery Indicator
Lit only when battery is low; flashes when at a critically low level—replace immediately.
THE TW205 & TW206 DISPLAYS (CONT.)
8
9
10

16
Note: You must press PROG to advance
to the next menu option. The flashing
option is saved automatically in each of
the program modes.
Make your selections in consecutive order.
Set the time
1. Press PROG to show program options.
2. Press
▲or ▼to scroll until “CLOCK” is
flashing. To select, press PROG once.
3. Press ▲or ▼to scroll through “24Hr”,
“AM”, “PM” options. “24Hr” sets your
thermostat to a 24-hour clock. “AM” and
“PM” sets your thermostat to a 12-hour
clock. To select, press PROG once.
4. Press ▲or ▼to scroll to the current
hour. To select, press PROG once.
5. Press ▲or ▼to scroll to the current
minute. To select, press PROG once.
Set the day
6. Press ▲or ▼to scroll to the current day.
To select, press PROG once.
SET THE TIME AND DAY (TW206 ONLY)
Press ▲or ▼buttons in PROG menu until
“CLOCK” is flashing.
i

17
Note: After you select the preferred
temperature format, the thermostat
automatically saves the flashing option
and times out.
TW205 Thermostat (Fig. 3)
1. Press °F/°C button once.
2. Press
▲or ▼to scroll until either
“°F” or “°C” is flashing.
3. Press °F/°C
button to select desired
Temperature Display format.
TW206 Thermostat (Fig. 4)
1. Press PROG once.
2. Press ▲or ▼to scroll until BOTH “°F/°C”
are flashing.
3. Press PROG once to enter the
temperature menu for “°F/°C.” Note:
Either “°F” or “°C” will flash as an option.
4. Press
▲or ▼to indicate the flashing
option as desired.
5. Press PROG to select desired
temperature display format.
SELECT THE FAHRENHEIT OR CELSIUS TEMPERATURE
i
Figure 3. TW205 Display with °F/°C.
Figure 4. TW206 Display with °F/°C.

18
Each day has four scheduled periods (WAKE, DAY, EVE, and SLEEP ). Each period has a start
time and heat and cool setpoints. Heat Setpoint controls system heating during cold weather.
Cool Setpoint controls the cooling system during hot weather. Program one event after the next,
in consecutive order. Press PROG to retain your current selection, and the system will advance
to the next menu item. Press the SYS button to exit the PROG menu at any time.
Factory Program: The TW206 is preprogrammed with seven days of the week as follows:
Time Period Start Time Heat Setpoint
Temperature
Cool Setpoint
Temperature
Wake 6:00 am 70° F (21.0° C) 78° F (25.0° C)
Day 8:00 am 62° F (17.0° C) 85° F (28.5° C)
Evening 6:00 pm 70° F (21.0° C) 78° F (25.0° C)
Sleep 10:00 pm 62° F (17.0° C) 82° F (27.0° C)
Note: If you want to change the preprogrammed times and/or temperatures, follow the
instructions under “Custom program.”
PROGRAMMING THE TW206
i

19
The TW206 can be programmed with settings
for each day individually, for Monday through
Friday, for Saturday and Sunday, or for all
seven days as identical. Follow this step-by-
step procedure.
1. Press PROG once.
2. Press
▲or ▼to scroll until “SET” is
flashing.
3. Press PROG once to select a menu
option.
4. Press ▲or ▼to scroll to the day or group
of days you want to program.
CUSTOM PROGRAM (TW206 ONLY)
In the PROG menu, press ▲or ▼until
“SET” is flashing.

20
Day/Group of Days
NOTE: Default (DFLT) Programming:
Select “DFLT” to restore seven days of
the week to the original factory program
default settings.
5. Select one of the following options, and
press PROG.
7- Day Individual Programming: Each day
flashes individually. Select: “M,” Monday; “TU,”
Tuesday; “W,” Wednesday; “TH,” Thursday;
“F,” Friday,“SA,” Saturday, and “SU,” Sunday.
You must program four periods for each day.
7- Day Identical Programming:
“MTUWTHFSASU” flashes as a block. Select
“MTUWTHFSASU” to program every day of
the week identically.
5- Day Identical Programming: “MTUWTHF”
flashes as a block. Select “MTUWTHF” to
program Monday through Friday identically
SASU Programming: “SASU” flashes as a
block. Select “SASU” to program identically.
CUSTOM PROGRAM (TW206 ONLY CONT.)
5-Day Identical Programming is example
shown here.
i
