pedestal Lean User manual

Assembly
Guide
Lean

Tools
1: Wrench (Provided in the hardware bag)
2: Hex keys (Provided in the hardware bag)
3: Table
4: So cloth or blanket
5: Tape measure or ruler
6: Assiing friend
Congratulations on your new Pedeal produ.
We welcome you on our journey towards creating flexible
interior design solutions for tv-screens.
Back in the day, televisions were design objes –
beautifully made, and put on dilay. But somewhere
along the line, we began to care less about how they look.
Mo of us have a big screen at home. Personally,
we love them. We watch, zap, and binge with a single click.
But making them look good? Now, that’s a challenge.
Mounts, pods, links, ands, call them what you want.
Those things that hold your screen can really ruin your
feng shui. Seing up your screen at home can feel like
choosing between a living room — or a screening room.
So, we founded Pedeal.
We’re a small team of people who design furniture that
hold screens, inired by 20th century indurial aehetics.
They should look good and work ju right. That’s it.
You will need the tools listed below:
2
3
4
5
1
Lean
Use the QR code or type in the URL to access our video guides.
www.pdl.com/pages/manualer

1.0 Floor Protection
Parts
Task
2 x Silicone gliders
Slide the silicone gliders onto the tube.
2.0 Mount brackets
Parts
Task
8 x M8 x 30 mm bolts
8 x M8 Nuts
Mount the brackets horizontally onto both sides as shown.
Tighten all conneions.

2.1 Mount brackets detail
Task
Detailed view of ep 2.0.
3.0 Mount foot
Parts
Task
2 x M4 x 3 mm set screws
Mount the boom tube into the main frame using the set screws
and the smalle hex key. Tighten all conneions.

5.0 Mount wall hook
Parts
Task
1 x Wall mounting screw
1 x Wall plug
Mark the placement of the hole on the wall hook using a pencil.
The hole mu be placed 120 cm from the floor.
Drill a Ø8 mm hole and insert the included wall plug.
Faen the wall hook to the wall, using the included screw.
120 cm
!
4.0 Wall protection
Parts
Task
8xRubber dots
Place the adhesive rubber dots onto the head of each bolt as shown.
WARNING!
Incorre assembly and inallation of the and can cause damage to the aached equipment and its surroundings. To prevent the and
from tipping over, the and mu be used with the wall aachment device provided. The included universal plugs and screws may, in rare
inances, not be suitable for your wall. Use screws and plugs suitable for your walls. If you are uncertain, seek professional advice.

6.0 Mount stand on wall hook
Task
Place the assembled and in the wall hook, leaning again the wall.
7.0 Mount TV brackets
Parts
Task
Place your screen facing backside up on a tabletop with
a so cloth or blanket between the two in order to prote both.
Mount the TV brackets vertically using the fiing holes.
For corre fit, see ep 7.1
4 x suitably sized bolts
4 x M6/M8 washers
At lea 4 x suitably sized acers

7.1 TV brackets ing
Do not panic!
You will not need all of the remaining hardware.
The large seleion of remaining hardware is to
accommodate as many dierent screens as possible.
For a corre fit you will have to identify the right combination
of provided acers, washers and bolts.
Place the acers between the screen and the brackets
to ensure that the brackets do not touch the screen.
If for inance your screen has a curved backside, you might
have to use more than one layer of acers.
Now screw the appropriately dimensioned bolts with washers
through the brackets and acers into the threaded holes on
the backside of the screen. Tighten the bolts until you have a
snug fit. Be sure not to overtighten. The bolts mu not reach
the boom of the threaded holes. Overtightening might cause
damage to your screen.
Correct t
Incorrect t
1 2
8.0 Mount TV on stand
Task
Place your screen on the and.

9.0 Mount safety hooks All done
Parts
Task
2 x M5 x 8 mm
Secure the TV bracket with the safety
hooks as shown. Tighten all conneions.

www.pdl.com
Popcorn ready
Screen steady
