Peloton BIKE User manual

USER MANUAL
BENUTZERHANDBUCH

TABLE OF CONTENTS / INHALTSVERZEICHNIS
3
In Studio with Tunde Oyeneyin
CAUTION Read all precautions and instructions in this manual before using this equipment. Improper use or
maintenance can void the warranty. Keep this manual for future reference. The information in this manual may
not reect recent updates as we continue to improve our product. Please see onepeloton.co.uk/manuals for the latest
version of the manual.
Connecting to Ethernet
Logging In
Adding a Rider
Peloton 101
Joining a Ride
THE CLASS SCREEN
MAINTENANCE AND CARE
After Each Ride
Every 3 to 5 rides
Every 15 to 20 Rides
Annually
BIKE ASSEMBLY
Bike Parts
Spare Parts
Assembly
WARRANTY
SUPPORT
DEUTSCH / GERMAN
15
15
15
15
15
16
17
17
18
18
19
20
20
23
24
27
35
36
ENGLISH / ENGLISCH
SAFETY INFORMATION
NOTICES
SPECIFICATIONS
Bike Specifications
Touchscreen Specifications
SETTING UP YOUR BIKE
Location Requirements
Moving The Bike
Seat Height
Seat Depth
Handlebar Height
Proper Body Position
Clipping In and Out
Adjusting Resistance
GETTING STARTED
Plugging In
Powering On and Off
Connecting to WiFi
02
04
05
06
07
07
09
09
09
10
10
11
11
12
12
13
13
13
14
32

NOTICESSAFETY INFORMATION
DISTRIBUTED BY:
US/CANADA
Peloton Interactive, Inc.
441 9th Ave, 9th Floor
New York, NY 10001
United States
UK
Peloton Interactive UK Limited
110 Long Acre
Covent Garden
London WC2E 9LH
United Kingdom
GERMANY
Peloton Interactive Deutschland GmbH
c/o WeWork Neue Schönhauser Str. 3-5
Neue Schönhauser Straße 3-5
10178 Berlin
Germany
AUSTRALIA
Peloton Interactive Australia Pty Ltd
20 Martin Place
Sydney NSW 2000
Australia
Read all safety information before
operating the bike. It is the owner’s
responsibility to ensure that users are
aware of all warnings and precautions.
Consult a doctor before beginning a
new tness plan. Incorrect or excessive
training can result in serious injury.
If you experience faintness, chest pain,
or shortness of breath, stop exercising
immediately and consult a doctor.
Metrics on the screen, including
heart rate monitoring, may be
inaccurate. Values should be used
for reference only.
This bike has a direct driven ywheel.
If the ywheel is moving, the pedals
are moving. Stop by reducing pedaling
frequency in a controlled manner or
by using the emergency brake. Do not
remove your feet from the pedals until
the ywheel stops moving.
The resistance knob can be used as an
emergency brake. To stop immediately,
push down on the resistance knob.
Use caution when mounting
and dismounting.
To prevent injury, always adjust the
seat and handlebars to your
personal requirements.
Children under the age of 14 and
persons with reduced physical, sensory,
or mental capabilities that impair the
safe use of the bike must not use the
bike. Keep children and pets away from
the bike at all times.
Children over the age of 14 and
persons with a lack of experience and
knowledge must be given supervision or
instruction before using the bike.
Do not allow children to perform
maintenance or to play with the bike.
Always fully engage the brake when the
bike is not in use.
Keep hands, loose clothing, shoelaces,
and accessories away from moving
parts. Do not insert objects into
openings on the equipment.
The bike is equipped with
Delta-compatible pedals. Always
cycle using footwear equipped with
appropriate cleats.
Perform regular maintenance for
optimal performance and longevity. To
ensure safety, the bike must be checked
for wear and damage on a regular basis.
Replace any damaged or worn parts
immediately. Do not use the bike until
the repair is performed.
Use only original parts from the
manufacturer. Changes or
modications to this unit not expressly
approved by Peloton could void
the warranty.
Always unplug the bike immediately
after use and before cleaning or
performing maintenance. Service
other than the procedures described
here must be performed by an
authorised technician.
The bike should not be used by persons
exceeding 135 kg/297 lb in weight.
This bike is for indoor home use only. Do
not store the bike outdoors, near water,
or at high humidity levels.
This bike is for home use only. Do not
use in a commercial setting. Use the
bike only for its intended purpose.
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
local authority or retailer for
recycling advice.
This product is ANT+™ certied and
is compatible with ANT+ sensors
that support heart rate monitoring.
The Peloton Bike is according to EN
ISO 20957-1 and EN ISO 20957-10
a Class H product and is built to
the highest standards for indoor
home tness use. It was designed
especially for lower body workout
and cardiovascular training.
EU DECLARATION OF
CONFORMITY
Hereby, Peloton Interactive, Inc.
declares that the radio equipment
type PLTN-RB1VQ is in compliance
with Directive 2014/53/EU. The
full text of the EU declaration of
conformity is available at
onepeloton.co.uk/compliance.
54
ENGLISH

VOLUME CONTROLS
ETHERNET PORT
METRICS PORT
SPECIFICATIONS
WEIGHT
HOLDERS
SADDLE
SEAT HEIGHT
L-HANDLE
HANDLEBARS
HANDLEBAR HEIGHT
L-HANDLE
FLYWHEEL
TRANSPORT
WHEELS
PEDAL
BELT GUARD
RESISTANCE KNOB/
EMERGENCY BRAKE
LEVELLING FEET
TOUCHSCREEN
SEAT DEPTH
L-HANDLE
POWER BUTTON
POWER INPUT
USB PORT
AUDIO JACK
FOOTPRINT : 120 x 60 cm
WEIGHT : 9 stone, 12 lbs/62.7 kg/138 lbs
HEIGHT : 147 cm
USER HEIGHT RANGE : 150-196 cm
MAX USER WEIGHT : 21 stone, 3 lbs/135 kg/297 lbs
WEIGHT HOLDER CAPACITY : 3 lbs/1.36 kg
BIKE TOUCHSCREEN
21.5” 1080p HD touchscreen
WiFi 802.11 a/b/g/n/ac / 100 Mbps Ethernet
16 GB internal ash storage
ANT+™ wireless / Bluetooth® 4.0
2×10 watt stereo speakers
76
ENGLISH

WARNINGS SETTING UP YOUR BIKE
LOCATION REQUIREMENTS
MOVING THE BIKE
60 cm
60 cm 60 cm
60 cm
yPlace the bike on a solid, level and horizontal surface
yUse a mat to avoid damage to the bike and oor
yAllow a clearance of 60 cm on each side of the bike
yTilt the bike forward onto the wheels. Lift the rear stabiliser
while a second person holds the handlebars
yCarefully roll the bike to the new location. Avoid
uneven surfaces
yIf the bike rocks after being set down, unscrew each levelling
foot until it rests rmly on the oor
Familiarise yourself with all warnings on the bike before use. If any label is damaged or lost, contact member
support for a replacement immediately.
WARNING / WARNUNG
Misuse of this bike may result in serious injury. Read user manual prior to use
and follow all warnings and instructions. Keep children and pets away from
the bike at all times. Set up and operate on a solid, level surface. Use
equipment in a supervised environment. Maximum user weight 21 stone, 3
lbs/135 kg/297 lb Take care when mounting and dismounting. Before
mounting or dismounting, move the pedal on the mounting or dismounting
side to its lowest position and bring the pedals to a complete stop. This bike
does not free-wheel. Reduce pedal speed in a controlled manner. Keep body,
clothing, and accessories clear of all moving parts. Contact with moving
parts may result in serious injury. Keep away from the flywheel at all times.
Always keep top surface of pedals clean and dry. Inspect bike before use. Do
not use the bike if it appears worn, damaged, or inoperable. Replace this
label if damaged, illegible, or removed.
Der unsachgemäße Gebrauch dieses Bikes kann zu schweren Verletzungen
führen. Vor Gebrauch die Bedienungsanleitung lesen und alle Warnhinweise
und Anweisungen befolgen. Kinder und Haustiere stets vom Bike
fernhalten. Auf einem stabilen, ebenen Untergrund aufstellen und
verwenden. Verwende das Gerät in einer kontrollierten Umgebung.
.Maximales Benutzergewicht: 135 kg (297 lb). Vorsicht beim Auf- und
Absteigen. Vor dem Auf- und Absteigen das Pedal auf der Auf- bzw.
.Absteigeseite in die unterste Position bringen und die Pedale vollständig
zum Stillstand bringen. Dieses Bike hat keinen Freilauf. Reduziere die
Pedalgeschwindigkeit in kontrollierter Weise. Halte Körperteile, Kleidung
und Zubehör von den beweglichen Teilen fern. Der Kontakt mit beweglichen
Teilen kann zu schweren Verletzungen führen. Halte dich stets vom
Schwungrad fern. Halte die Oberfläche der Pedale immer sauber und trocken.
Überprüfe das Bike vor dem Gebrauch. Benutze das Bike nicht, wenn es
abgenutzt, beschädigt oder funktionsuntüchtig erscheint. Sollte dieses
Etike beschädigt worden, unleserlich geworden oder verloren gegangen
sein, ersetze es bie. 1031029-01
98
ENGLISH

SEAT HEIGHT
SEAT DEPTH
Set the seat depth so that the distance between seat and
handlebars is equal to the distance between your elbow
and ngertips.
yTurn L-handle anticlockwise to loosen
yRaise or lower seat
yTurn L-handle clockwise to tighten
yTurn L-handle anticlockwise to loosen
yMove seat forward or back
yTurn L-handle clockwise to tighten
Set the seat height to line up with the top of your hip bone.
SETTING UP YOUR BIKE CONTINUED
BODY POSITION
Arms slightly bent
Hands rest on handlebars without reaching
Leg slightly bent at the bottom of the stroke
These adjustments should get you started. If you’re
uncomfortable, or want to ne-tune your bike’s settings, go
to support.onepeloton.co.uk
HANDLEBAR HEIGHT
Set the handlebars to seat height, then adjust until you
feel comfortable.
yTurn L-handle anticlockwise to loosen
yRaise or lower the handlebars
yTurn L-handle clockwise to tighten
CAUTION To prevent injury, always adjust seat and handlebars to your personal requirements. Tighten all adjustment
handles before using the Peloton Bike. Projecting adjustment handles could interfere with your movements. Do not exceed
maximum adjustment marks on seat and handlebar posts and sliders.If any adjustment handle sticks out sideways, pull the
handle out, rotate it to point down, and then release it.
CAUTION The Peloton Bike has a direct driven ywheel; the pedals will continue to move until the ywheel stops. Reduce
speed slowly. To stop the ywheel immediately, push down the resistance knob.
1110
ENGLISH

SETTING UP YOUR BIKE CONTINUED
CLIPPING IN AND OUT
TO CLIP IN: Point your toes down to t the cleat
into the pedal, then push down through your heel.
TO CLIP OUT: Kick your heel away from the bike.
ADJUSTING RESISTANCE
yTurn knob right to increase resistance
yTurn knob left to decrease resistances
yPress knob down for emergency brake
GETTING STARTED
POWERING ON AND OFF
yHold the power button for two seconds to power on the bike
yThe bike will sleep after about 20 minutes of inactivity. To
wake the bike, press the power button
yTo power down, hold the power button for two seconds.
Select Shut Down when prompted
PLUGGING IN
tooltip
t
p
tooltip
t
yPlug the power supply into the wall
yPlug the power cord into the power jack at the back of
the bike
1312
ENGLISH

CONNECTING TO THE INTERNET
To connect to a WiFi network, tap the network name
yIf the network is not secured, the bike will connect to
the network
yIf the network is secured, you will be prompted
to enter a password. Type in the password and
tap Connect
To connect to a wired network, connect an Ethernet cable to the
Ethernet port on the back of the touchscreen and to a wall jack
or router used by your local area network. The bike will connect
to the network automatically.
GETTING STARTED CONTINUED
ADDING A PROFILE
To let another person use your bike, tap the icon
next to your username at the lower left of the screen and
select Add/Remove Proles. The new user can
log in with an existing Peloton account or tap
Create an Account to set up a new one.
LOGGING IN
When logging in for the rst time, please have
available your Subscription Activation Key or the
login information you set up when you purchased
the Peloton Bike.
Once a subscription is activated and associated
with this bike, any user can log in and access
subscription content.
JOINING A RIDE
yFind live classes on the schedule or choose
from on-demand classes.
yFilter by instructor, class length, class type, and more.
yYour instructor will guide you through your workout.
If the workout does not include a warmup and cooldown,
warmup and cooldown classes are available separately.
ySelect More for a Scenic Ride or Just Ride experience.
PELOTON 101
Select Peloton 101 from the menu for more on adjusting
your bike to t your body and maintaining proper body
position when you ride.
1514
ENGLISH

CLASS SCREEN
RESISTANCE
Pedaling diculty, measured
as a percentage
CADENCE
How fast you're pedaling,
in revolutions per minute
OUTPUT
The power you're exerting,
measured in watts
TIME REMAINING
HEART RATE*
LEADERBOARD
DISTANCE
TRAVELED
TOTAL OUTPUT
CALORIES BURNED
*Appears only when a heart rate monitor is connected.
MAINTENANCE AND CARE
CLEANING: Wipe down the bike using a damp cloth.
LEVELLING FEET: If the bike rocks back and forth, turn
each levelling foot clockwise (when viewed from above) until it
rests rmly on the ground.
EVERY 3 TO 5 RIDES
CLEANING: Clean the bike thoroughly using a damp cloth and
a mild household cleaner diluted in water. Clean the touchscreen
using an electronics wipe.
PEDALS: Tighten any loose pedal with the included 15 mm
spanner. Pedals should be tightened to 34 N.m/25 lb-ft
of torque. Turn clockwise to tighten the right pedal and
anticlockwise to tighten the left pedal.
CAUTION To ensure safe operation and optimal
performance, check for wear and damage and perform
maintenance on a regular basis. Replace any damaged
or defective parts immediately. Do not use the bike until
the repair is performed. Only use original parts from the
manufacturer. Changes or modications to this unit not
expressly approved by Peloton could void the warranty.
AFTER EVERY RIDE
1716
ENGLISH

EMERGENCY BRAKE: Press down on the resistance knob
while pedaling slowly. The flywheel should come to a complete
stop immediately. If it does not, stop using the bike immediately and
contact Peloton Support.
FRAME: Check the entire frame and all belt guards for signs
of wear and damage, and tighten any loose bolts. If there is any
damage to the belt guards, immediately stop using the bike and
contact member support.
EVERY 3 TO 5 RIDES CONTINUED
CLEATS: Use a 4 mm Allen key to tighten any loose screws
attaching your cleats to your cycling shoes.
SADDLE: Make sure the saddle is parallel to the ground. Then
use the included 13mm spanner to tighten the seat-xing nuts
on both sides.
CAUTION Service other than the procedures described here
must be performed by an authorised technician.
EVERY 15 TO 20 RIDES
MAINTENANCE AND CARE CONTINUED
ANNUALLY
PEDALS: Replace pedals. Tighten new pedals to
34 N.m/25 lb-ft of torque. For further instructions,
see support.onepeloton.co.uk.
1918
ENGLISH

1 Bike frame
2 Front stabiliser
3 Rear stabiliser
4 M8×20 socket cap screw × 8
5 Right and left pedals
6 Handlebar post
7 M8×12 round head screw × 2
8 M8×10 round head screw × 2
9 Flat washer × 4
10 M5×15 Phillips head screw
11 Handlebars
12 Water bottle holder cups × 2
13 M5×8 stainless steel screws × 4
14 Touchscreen arm
15 Touchscreen
16 M4×10mm ange head screws × 4
17 Right and left weight holders
18 M5 washer × 4
19 M5 spring washer × 4
20 M5×8 round head screw × 4
21 Power supply and cord
BIKE PARTS
BIKE ASSEMBLY
y3mm Allen key
y4mm Allen key
y5mm Allen key
y6mm Allen key
yPhillips head screwdriver
yTorque wrench with 15mm
crowfoot attachment
TOOLS
WARNING These assembly instructions are intended to assist trained professional installers in assembling the Peloton
Bike. Damage or equipment failure resulting from the improper or negligent assembly of the bike will not be covered
under Peloton’s warranties.
WARNING Perform a complete visual inspection of the Peloton Bike and test all features and functions prior to use.
15
11
7
9
6
16
14
8
9
7
10
13
24
4
3
1
19
5
21
20
18
12
12 17
13
2120
ENGLISH

A Saddle SP-03-1
B Small L-handle SP-06/RP-06
C Large L-handle SP-07/RP-07
D Outer Belt Guard SP-11-12
E Belt SP-15
F Right Crank Arm SP-11-17
G Left Crank Arm SP-11-19
H Front Belt Guard SP-11-26
I Sensor Assembly SP-27-2/RP-27
J Foot SP-31
K Wheels SP-32
L Stabiliser Screw Set SP-35
M Wire Bracket SP-41/RP-41
SPARE PARTS
BIKE ASSEMBLY CONTINUED
C
F
I
A
D
G
B J
L
K
ME
H
yMonitor Cable SP-39
yInner Wiring SP-38/RP-38
yLabel package PL-11-KIT
yPedals PL-PS7-02-L/R
yWeight Holders SP-09/RP-09
yFront Stabiliser SP-33/RP-33
yRear Stabiliser SP-34/RP-34
yHandlebars SP-43/RP-43
2322
ENGLISH

ASSEMBLY
1 Fit the handlebar post onto the
handlebars. Make sure the letters on
the post will be upright when the
handlebar is right-side-up.
2 Add two at washers and two M8×12
round head screws to the front of the
handlebar base. Screw them in with a
5mm Allen key.
3 Add two at washers and two M8×10
round head screws to the sides of the
handlebar base. Screw them in with the
5mm Allen key.
4 Loosen the L-handle at the front of the
bike frame and slide the handlebar post
into the head tube.
5 Add an M5×15 Phillips head screw to
the hole at the end of the handlebar
post. Screw it in using a Phillips
head screwdriver.
6 Raise the handlebars to seat height and
tighten the L-handle.
7 Take four M5x12 round head screws
and add one at washer and one spring
washer to each.
8 Secure each weight holder to the seat
slider using two screw-and-washer sets
and a 4mm Allen key.
BIKE ASSEMBLY CONTINUED
ASSEMBLY CONTINUED
9 Rest the bike frame on the weight
holders and back foot.
10 Add the front stabiliser and four M8x20
socket cap screws. Screw them in with
a 6mm Allen key.
11 Rest the bike frame on the handlebars
and front stabiliser.
12 Add the rear stabiliser and four M8x20
socket cap screws. Screw them in with
the 6mm Allen key.
13 Remove the square panel from the back
of the touchscreen. Using a Phillips
head screwdriver and four M4x10
ange head screws, secure the
touchscreen to the monitor arm.
14 Return the back panel to
the touchscreen.
15 Push the monitor arm all the way into
the handlebars.
1-3
5
4
6
87
10
1211
13 15
9
2524
ENGLISH

ASSEMBLY CONTINUED
BIKE ASSEMBLY CONTINUED
16 Tighten the bolt at the right side using
the 6mm Allen key.
17 Plug the monitor cable into the back of
the touchscreen. Use the velcro strap to
secure it to the monitor arm.
18 Add a water bottle cup to each side
of the front shroud using two M5x8
screws and a 3mm Allen key.
19 Screw the pedals into the crank arms.
The left pedal is reverse-threaded.
20 Using a torque wrench and a 15mm
crowfoot, tighten each pedal to
34 N.m/25 lb-ft. Be careful not to
over-tighten the pedals.
21 Plug the power cord into the power
supply and the back of the bike. Plug
the power supply into an outlet.
22 Check that the bike is stable. If it rocks
or wobbles, adjust the outer feet on
each stabiliser until all feet rest rmly
on the ground.
LIMITED HOME USE WARRANTY
Peloton Interactive, Inc. and its aliate
companies (“Peloton”) extends the
following Limited Warranty, which applies
only to non-commercial, in-home, indoor
use of the Peloton Bike. Any other use of
the Peloton Bike shall void this Limited
Warranty. During the applicable Limited
Warranty periods described below, the
covered components of the Peloton Bike
will be free of defects or malfunctions
during normal use. Certain exclusions
apply, as further described in this
Limited Warranty.
The Limited Warranty applies for the
following components of the Peloton
Bike only, for the time period indicated.
The Limited Warranty applies only
against defects discovered within the
applicable Limited Warranty period
and only so long as the Peloton Bike
remains in the possession of the original
purchaser, or for gifted bikes, the owner
of the original Subscription attached to
that Peloton Bike.
HD TOUCHSCREEN – 12 MONTHS.
Peloton warrants the touchscreen
against defects in workmanship and
materials for a period of 12 months from
the date of original delivery.
FRAME – FIVE YEARS.
Peloton warrants the frame (excluding
any moving parts attached to the
structural frame) against defects in
workmanship and materials for a period
of ve years from the date of
original delivery.
BIKE COMPONENTS –
12 MONTHS.
Peloton warrants the components and
all original parts of the Peloton Bike
other than pedals, including its belt,
brake resistance, crankshaft, seat post,
handlebars and water bottle holder,
against defects in workmanship and
materials for a period of 12 months from
the date of original delivery.
BIKE PEDALS – 12 MONTHS.
Peloton warrants the components and
all original parts of the original pedals
that come with the Peloton Bike against
defects in workmanship and materials
for a period of 12 months from the date
of original delivery. Bike pedals are not
warranted against normal wear and tear
and it is important that you maintain the
pedals by inspecting the pedals regularly
for any damage, loose parts or other
signs of wear and tear that could cause
breakdowns or part failures. Any pedal
that shows signs of worn or damaged
parts should be removed from service
immediately. Please refer to Peloton’s
guide on maintaining your pedals,
available on Peloton’s website.
LABOUR – 12 MONTHS.
For Peloton Bikes originally assembled
by an authorised Peloton technician,
Peloton will cover the labour cost for
the repair or replacement made under
this Limited Warranty for a period of 12
months from the date of original delivery.
Except where applicable law requires
otherwise, repair labour is not covered
for locations where Peloton did not
originally assemble the Peloton Bike or if
the Peloton Bike is moved to a location
that is outside of Peloton’s service area.
EXCLUSIONS AND LIMITATIONS
WHO IS COVERED?
The original owner of the Peloton Bike.
The Peloton Bike must remain in the
possession of the original purchaser, or
for gifted Peloton Bikes, the owner of
the original Subscription attached to
that Peloton Bike. This Limited Warranty
is not transferable. Service location
is limited to any area which Peloton
delivers to in the UK.
UNITED KINGDOM
17
1918
21 22
16
ENGLISH
2726

LIMITED HOME USE WARRANTY CONTINUED
WHAT IS COVERED?
yIf a defect arises in the Peloton Bike
or a warranted component within the
applicable Limited Warranty period,
the purchaser’s sole and exclusive
remedy is for Peloton to, at Peloton’s
discretion to the extent permitted
by law, either replace or repair the
defective or malfunctioning Peloton
Bike or component with the same or
a comparable model.
yAny replacement or repaired
component shall be warranted for
the remainder of the original Limited
Warranty period or 30 days,
whichever is longer, or for any
additional period that is required
by applicable law.
WHAT IS NOT COVERED?
yAny other Peloton products or
services, non-Peloton products or
labour, units that are, or that Peloton
reasonably believes to be, stolen,
counterfeit, or purchased from an
unauthorized distributor or reseller,
units purchased or used outside any
area which Peloton delivers to in
the UK to, and units missing
serial numbers.
ySoftware, even if sold with or
embedded in the Peloton Bike, or
Internet connectivity. Peloton does
not warrant that the operation of the
Peloton Bike will be uninterrupted
or error-free.
yDamage or equipment failure due
to normal wear and tear, improper
or negligent assembly, maintenance,
installation, relocation, or repair
(other than that caused by a Peloton
authorised service technician), use of
the Peloton Bike with parts or
accessories from third parties, or
with parts or accessories not
originally intended for or compatible
with the Peloton Bike, or any use
contrary to the instructions in the
Peloton Bike User Manual.
yDamage or equipment failure due to
accident, abuse, improper or
abnormal use, neglect, corrosion,
discoloration of paint or plastic
(or any other change in cosmetic
appearance that does not affect
performance), theft, vandalism, re,
ood, wind, lightning, freezing or
other natural disasters or acts of God
of any kind, electrical wiring, power
reduction, power uctuation or power
failure from whatever cause, unusual
atmospheric conditions, collision,
introduction of foreign objects, or
modications that are unauthorised
or not recommended by Peloton.
yIncidental or consequential damages.
Peloton is not responsible or liable
for indirect, special, incidental or
consequential damages, economic
loss, loss of property or prots,
loss of enjoyment or use, or other
consequential damages of any nature
whatsoever in connection with the
purchase, use, repair or maintenance
of equipment or parts. Peloton
does not provide monetary or other
compensation for any such repairs
or replacement parts costs, including
but not limited to gym membership
fees, work time lost, cost of
substitute equipment, diagnostic
visits, maintenance visits
or transportation.
yEquipment used for commercial
purposes or for any use other than a
single-family or household.
ADDITIONAL INFORMATION
yAny attempt to move or repair tness
equipment creates a risk of injury
and property damage. Peloton is not
responsible or liable for any damage
or injury incurred during, or as a result
of, any move, repair or attempted
repair of equipment by anyone other
than a Peloton authorized service
technician. All moves or repairs
attempted by you or your agents
are undertaken AT YOUR OWN RISK
and Peloton will have no liability for
any injury to persons or property
arising from such attempted moves
or repairs. In addition, labour may
no longer be covered if you move
outside of Peloton’s service area.
yReplacement units, parts and
electronic components
reconditioned by Peloton or its
vendors may sometimes be
supplied as warranty replacement
and constitute fullment of
warranty terms.
THIS LIMITED WARRANTY IS THE
EXCLUSIVE WARRANTY GIVEN BY
PELOTON AND SUPERSEDES ANY
PRIOR, CONTRARY OR ADDITIONAL
REPRESENTATIONS. ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING ANY STATUTORY
WARRANTY OR CONDITION OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, ARE
DISCLAIMED EXCEPT TO THE EXTENT
PROHIBITED BY LAW. IN SUCH EVENT,
SUCH WARRANTY IS LIMITED TO THE
DURATION OF THE WARRANTY PERIODS
SET FORTH ABOVE. THIS EXCLUSION
APPLIES EVEN IF THIS WARRANTY
FAILS OF ITS ESSENTIAL PURPOSES
AND REGARDLESS OF WHETHER
DAMAGES ARE SOUGHT FOR BREACH
OF WARRANTY, BREACH OF CONTRACT,
NEGLIGENCE, OR STRICT LIABILITY IN
TORT OR UNDER ANY OTHER LEGAL
THEORY. SOME JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION
MAY NOT APPLY TO YOU. THIS LIMITED
WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE
OTHER LEGAL RIGHTS, WHICH VARY
FROM STATE TO STATE.
ADDITIONAL COVERAGE
For information on available service
plans, visit support.onepeloton.co.uk.
HOW DO I OBTAIN
WARRANTY SERVICE?
Contact member support if you believe
you need service.
[phone]
support.onepeloton.co.uk
Peloton Interactive UK Limited
110 Long Acre
Covent Garden
London WC2E 9LH
United Kingdom
Attn: Limited Warranty Claims
To be eligible for service under this
Limited Warranty you must provide
Peloton with the serial number of your
Peloton Bike and the dated receipt, or
other proof of purchase indicating the
date purchased, upon discovering any
nonconformity or defect.
Claims must be made within the
specied warranty period.
Any disputes between you and
Peloton related to this Limited
Warranty or the Peloton Bike will be
governed by the then-current dispute
resolution procedures in Peloton’s
Terms of Service, available at
onepeloton.co.uk/terms-of-service.
UNITED KINGDOM
ENGLISH
2928

LIMITED HOME USE WARRANTY
AUSTRALIA
YOUR RIGHTS UNDER THE
AUSTRALIAN CONSUMER LAW
Our goods and services come with
guarantees that cannot be excluded
under the Australian Consumer Law.
For major failures with the service,
you are entitled:
yto cancel your service contract with
us; and
yto a refund for the unused portion,
or to compensation for its
reduced value.
You are also entitled to choose a refund
or replacement for major failures with
goods. If a failure with the goods or a
service does not amount to a major
failure, you are entitled to have the
failure rectied in a reasonable time.
If this is not done you are entitled to a
refund for the goods and to cancel the
contract for the service and obtain a
refund of any unused portion. You are
also entitled to be compensated for any
other reasonably foreseeable loss or
damage from a failure in the goods
or service.
The rights described in this Peloton
Bike Limited Warranty are in addition to
the rights to which you may be entitled
or other signs of wear and tear that
could cause breakdowns or part failures.
Any pedal that shows signs of worn
or damaged parts should be removed
from service immediately. Please refer
to Peloton’s guide on maintaining your
pedals, available on Peloton’s website.
LABOR  12 MONTHS 
For a Peloton Bike originally assembled
by an authorized Peloton technician,
Peloton will cover the labour cost for
the repair or replacement made under
this Limited Warranty for a period of
12 months from the date of original
delivery. Without excluding, restricting
or modifying any rights or remedies
to which you may be entitled under
the Australian Consumer Law or other
applicable law, repair labour is not
covered for locations where Peloton
did not originally assemble the Peloton
Bike or if the Peloton Bike is moved to
a location that is outside of Peloton’s
service area.
WHO IS COVERED BY THIS
LIMITED WARRANTY?
This Limited Warranty covers the
original purchaser of the Peloton Bike
or, for a gifted Peloton Bike, the owner
of the original Subscription attached
under the Australian Consumer Law and
other Australian consumer protection
laws and regulations.
WHAT IS COVERED BY THIS
LIMITED WARRANTY?
Peloton Interactive Australia Pty Ltd.
(“Peloton”) extends the following
Limited Warranty, which applies only
to non-commercial, in-home, indoor
use of the Peloton Bike. Any other
use of the Peloton Bike shall void this
Limited Warranty. During the applicable
Limited Warranty periods described
below, the covered components
of the Peloton Bike will be free of
defects or malfunctions during normal
use. Certain exclusions apply,
as further described in this
Limited Warranty.
The Limited Warranty applies for the
following components of the Peloton
Bike only, for the time period indicated.
The Limited Warranty applies only
against defects discovered within the
applicable Limited Warranty period.
HD TOUCHSCREEN  12 MONTHS
Peloton warrants the touchscreen
against defects in workmanship and
materials for a period of 12 months
to that Peloton Bike. Without excluding,
restricting or modifying any rights or
remedies to which you may be entitled
under the Australian Consumer Law or
other applicable law, any other person
in possession of the Peloton Bike is not
covered by this Limited Warranty.
WHAT IS NOT COVERED BY THIS
LIMITED WARRANTY?
This Limited Warranty does not apply to:
yAny other Peloton products or
services not expressly referred to
under the heading “What is covered
by this Limited Warranty?” above,
non-Peloton products or labour, units
that are, or that Peloton reasonably
believes to be, stolen, counterfeit,
or purchased from an unauthorized
distributor or reseller, units purchased
or used outside Australia, and units
missing serial numbers.
ySoftware, even if sold with or
embedded in the Peloton Bike, or
Internet connectivity. Peloton does
not warrant that the operation of the
Peloton Bike will be uninterrupted or
error-free.
yDamage or equipment failure due
from the date of original delivery.
FRAME  FIVE YEARS.
Peloton warrants the frame (excluding
any moving parts attached to the
structural frame) against defects in
workmanship and materials for a period
of ve years from the date of
original delivery.
BIKE COMPONENTS 
12 MONTHS
Peloton warrants the components and
all original parts of the Peloton Bike
other than pedals, including its belt,
brake resistance, crankshaft, seat post,
handlebars and water bottle holder,
against defects in workmanship and
materials for a period of 12 months
from the date of original delivery.
BIKE PEDALS  12 MONTHS
Peloton warrants the components and
all original parts of the original pedals
that come with the Peloton Bike against
defects in workmanship and materials
for a period of 12 months from the date
of original delivery. Bike pedals are not
warranted against normal wear and tear
and it is important that you maintain
the pedals by inspecting the pedals
regularly for any damage, loose parts
to normal wear and tear, improper
or negligent assembly, maintenance,
installation, relocation, or repair
(other than that caused by a Peloton
authorized service technician), use of
the Peloton Bike with parts or
accessories from third parties, or
with parts or accessories not
originally intended for or compatible
with the Peloton Bike, or any use
contrary to the instructions in the
Peloton Bike User Manual.
yDamage or equipment failure due to
accident, abuse, improper or
abnormal use, neglect, corrosion,
discoloration of paint or plastic
(or any other change in cosmetic
appearance that does not affect
performance), theft, vandalism, re,
ood, wind, lightning, freezing or
other natural disasters or acts of God
of any kind, electrical wiring, power
reduction, power uctuation or power
failure from whatever cause, unusual
atmospheric conditions, collision,
introduction of foreign objects, or
modications that are unauthorized
or not recommended by Peloton.
yIncidental or consequential damages.
Except to the extent required by the
ENGLISH
3130

yUse of the Peloton Bike for
commercial purposes or for any
use other than normal use in a
single-family or household.
yAny attempt to move or repair tness
equipment creates a risk of injury and
property damage. Peloton is not
responsible or liable for any damage
or injury incurred during, or as a result
of, any move, repair or attempted
repair of equipment by anyone other
than a Peloton authorized service
technician. All moves or repairs
attempted by you or your agents
are undertaken AT YOUR OWN RISK
and Peloton will have no liability for
any injury to persons or property
arising from such attempted moves
or repairs. In addition, labour may
no longer be covered if you move
outside of Peloton’s service area.
TO THE EXTENT ALLOWED BY LAW AND
WITHOUT EXCLUDING, RESTRICTING
OR MODIFYING THE APPLICATION OR
EXERCISE OF ANY RIGHT OR REMEDY
TO WHICH YOU MAY BE ENTITLED
UNDER AUSTRALIAN CONSUMER LAW
OR ANY LIABILITY OF PELOTON IN
RELATION TO A FAILURE TO
COMPLY WITH A GUARANTEE THAT
APPLIES UNDER AUSTRALIAN
CONSUMER LAW TO A SUPPLY OF
GOODS OR SERVICES:
yTHIS LIMITED WARRANTY IS THE
EXCLUSIVE WARRANTY GIVEN BY
PELOTON AND SUPERSEDES ANY
PRIOR, CONTRARY OR
ADDITIONAL REPRESENTATIONS.
yALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING ANY
STATUTORY WARRANTY OR
CONDITION OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR
PURPOSE, ARE DISCLAIMED TO THE
EXTENT PERMITTED BY LAW.
yIN SO FAR AS A WARRANTY
CANNOT BY LAW BE DISCLAIMED,
SUCH WARRANTY IS LIMITED TO
THE DURATION OF THE WARRANTY
PERIODS SET FORTH ABOVE.
TO THE EXTENT THAT THIS EXCLUSION
APPLIES, IT APPLIES EVEN IF THIS
WARRANTY FAILS OF ITS ESSENTIAL
PURPOSES AND REGARDLESS OF
WHETHER DAMAGES ARE SOUGHT FOR
BREACH OF WARRANTY, BREACH OF
CONTRACT, NEGLIGENCE, OR STRICT
LIABILITY IN TORT OR UNDER ANY
OTHER LEGAL THEORY. 
SOME JURISDICTIONS DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
WHAT YOU MUST DO TO OBTAIN
WARRANTY SERVICE
To be eligible for service under this
Limited Warranty you must provide
Peloton with the serial number of your
LIMITED HOME USE WARRANTY CONTINUED
AUSTRALIA
Peloton Bike and the dated receipt, or
other proof of purchase indicating the
date purchased, upon discovering any
nonconformity or defect. Claims must
be made within the specied
warranty period.
To make a claim under this Limited
Warranty, contact member support.
[phone]
support.onepeloton.com.au
Peloton Interactive Australia Pty Ltd
20 Martin Place
Sydney NSW 2000
Attention: Limited Warranty Claims
WHAT WILL PELOTON DO IF
THE LIMITED WARRANTY
IS BREACHED?
If, within the applicable Limited
Warranty period, a defect arises in the
Peloton Bike or a warranted component
that is covered by this Limited Warranty
and you submit a claim to Peloton under
this Limited Warranty, then without
excluding, restricting or modifying
any other rights to which you may be
entitled under the Australian Consumer
Law or any other Australian consumer
protection laws and regulations,
Peloton will, at its option and as its sole
obligation, either replace or repair the
defective or malfunctioning Peloton
Bike or component with the same or a
comparable model.
Any replacement or repaired component
shall be warranted for the remainder
of the original Limited Warranty period
or 30 days, whichever is longer, or for
any additional period that is required by
applicable law.
Where permitted by law, replacement
units, parts and electronic components
reconditioned to as-new condition by
Peloton or its vendors may sometimes
be supplied as warranty replacement
and constitute fullment of warranty
terms. Goods presented for repair may
be replaced by refurbished goods of the
same type rather than being repaired.
Refurbished parts may be used to repair
the goods. Where Peloton considers a
component of the Peloton Bike to have
breached a consumer guarantee, any
shipping costs to return the relevant
component to Peloton or the cost of
Peloton collecting the relevant part(s)
will be at Peloton’s cost.
To the extent that the Peloton Bike or
component is capable of retaining
user-generated data, you should be
aware that repairs may result in the
loss of that data.
WHAT IF I HAVE QUESTIONS
OR CONCERNS?
This Limited Warranty is given by
Peloton Interactive Australia Pty Ltd
You may direct any questions or
concerns to member support.
[phone]
Without excluding, restricting or
modifying any rights or remedies to
which you may be entitled under the
Australian Consumer Law or other
applicable law, any disputes between
you and Peloton related to this
Limited Warranty or the Peloton Bike
will be governed by the then-current
dispute resolution procedures in
Peloton’s Terms of Service, available
atonepeloton.com.au/terms-of-service
WHAT IF I WANT
MORE COVERAGE?
Extended warranty coverage is available
for purchase. See:
support.onepeloton.com.au
for more details.
ENGLISH
Australian Consumer Law or other
applicable law that cannot be
excluded, Peloton is not responsible
or liable for indirect, special,
incidental or consequential damages,
economic loss, loss of property or
prots, loss of enjoyment or use, or
other consequential damages of
any nature whatsoever in
connection with the purchase, use,
repair or maintenance of equipment
or parts, and Peloton will not provide
monetary or other compensation
for any such repairs or replacement
parts costs, including but not limited
to gym membership fees, work time
lost, cost of substitute equipment,
diagnostic visits, maintenance
visits or transportation.
3332

SUPPORT
In Studio with Kendall Toole
UK +44.808.169.6469
DE [phone]
AU [phone]
support.onepeloton.co.uk
support.onepeloton.de
support.onepeloton.com.au
QUESTIONS OR CONCERNS
Peloton’s #1 concern is member
satisfaction. If you require assistance
or are experiencing issues with your
Peloton Bike, please contact the
member support team for
additional help.
ENGLISH
3534

INHALTSVERZEICHNIS
37
Im Studio mit Tunde Oyeneyin
VORSICHT Lies alle Warnhinweise und Anweisungen in diesem Handbuch, bevor du dieses Gerät benutzt.
Unsachgemäße Handhabung oder Wartung kann zum Erlöschen der Garantie führen. Bewahre dieses Handbuch für
eventuelle Rückfragen auf. Da wir unser Produkt ständig verbessern, sind die Informationen in diesem Handbuch
möglicherweise nicht auf dem neuesten Stand. Die neueste Version des Handbuchs ist verfügbar
unter onepeloton.de/manuals.
Ethernet Verbindung Erstellen
Einloggen
Rider Hinzufügen
Peloton-Einführung
An einem Kurs teilnehmen
DER KURSBILDSCHIRM
WARTUNG UND PFLEGE
Nach jedem Ride
Alle 3 bis 5 Rides
Alle 15 bis 20 Rides
Jährlich
BIKEMONTAGE
Bike-Teile
Ersatzteile
Montage
GARANTIE
KUNDENSERVICE
48
49
49
49
49
50
51
52
52
53
53
54
55
57
58
61
65
SICHERHEITSHINWEISE
HINWEISE
TECHNISCHE DATEN
Fitnessbike-Spezifikationen
Bildschirm-Spezifikationen
AUFBAU DES FITNESSBIKES
Standortanforderungen
Fitnessbike Bewegen
Sitzhöhe
Sitztiefe
Lenkerhöhe
Richtige Körperhaltung
Ein- und Ausklicken
Anpassung Des Widerstandes
LOSLEGEN
Inbetriebnahme
Ein- und Ausschalten
Wi-Fi-Verbindung herstellen
38
39
40
41
41
43
43
43
44
44
45
45
46
46
47
47
47
48
3736
DEUTSCH

HINWEISESICHERHEITSHINWEISE
VERTRIEB DURCH:
USA/KANADA
Peloton Interactive, Inc.
441 9th Ave, 9th Floor
New York, NY 10001
USA
VEREINIGTES KÖNIGREICH
Peloton Interactive UK Limited
110 Long Acre
Covent Garden
London WC2E 9LH
Vereinigtes Königreich
DEUTSCHLAND
Peloton Interactive Deutschland GmbH
c/o WeWork Neue Schönhauser Str. 3-5
Neue Schönhauser Straße 3-5
10178 Berlin
Deutschland
AUSTRALIEN
Peloton Interactive Australia Pty Ltd
20 Martin Place
Sydney NSW 2000
Australien
Lies alle Sicherheitshinweise, bevor
du das Fitnessbike nutzt. Es liegt in
der Verantwortung des Eigentümers,
sicherzustellen, dass die Benutzer
über alle Warnungen und
Vorsichtsmaßnahmen informiert sind.
Konsultiere einen Arzt, bevor du einen
neuen Fitnessplan erstellst. Falsches
oder übermäßiges Training kann zu
schweren Verletzungen führen.
Wenn du unter Schwäche,
Brustschmerzen oder Kurzatmigkeit
leidest, dann bitte sofort mit dem
Training aufhören und einen Arzt zu
Rate ziehen.
Kennzahlen auf dem Touchscreen,
einschließlich der Pulsmessung,
können ungenau sein. Die Werte dienen
nur als Referenz.
Dieses Bike ist mit einem direkt anget-
riebenen Schwungrad
ausgestattet. Wenn sich das
Schwungrad bewegt, bewegen sich
auch die Pedale. Halte an, indem du die
Trittfrequenz gezielt reduzierst oder
die Notbremse betätigst. Nimm deine
Füße erst von den Pedalen, wenn das
Schwungrad stillsteht.
Der Widerstands-Drehknopf kann
als Notbremse verwendet werden.
Um sofort anzuhalten, drücke den
Widerstands-Drehknopf.
Beim Auf- und Absteigen ist
Vorsicht geboten.
Stell den Sattel und den Lenker immer
auf deine persönlichen Bedürfnisse ein,
um Verletzungen zu vermeiden.
Kinder unter 14 Jahren und Personen
mit eingeschränkten körperlichen,
sensorischen oder geistigen
Fähigkeiten, die eine sichere Nutzung
des Fitnessbikes beeinträchtigen,
dürfen das Fitnessbike nicht benutzen.
Kinder und Haustiere stets vom
Bike fernhalten.
Kinder über 14 Jahre und Personen
mit mangelnder Erfahrung und Kennt-
nissen müssen vor der Benutzung des
Bikes beaufsichtigt oder unterwiesen
werden.Kindern ist es nicht gestattet,
Wartungsarbeiten durchzuführen oder
mit dem Bike zu spielen. Ziehe die
Bremse immer vollständig an, wenn das
Fitnessbike nicht benutzt wird.
Halte Hände, lose Kleidung,
Schnürsenkel und Zubehör von
beweglichen Teilen fern. Stecke keine
Gegenstände in Öffnungen am Gerät.
Das Fitnessbike ist mit Pedalen
ausgestattet, die mit Delta kompatibel
sind. Fahre stets mit Schuhen, die mit
passenden Cleats ausgestattet sind.
Führe regelmäßige Wartungsarbeit-
en durch, um optimale Leistung und
Lebensdauer zu gewährleisten. Führe
regelmäßige Wartungen durch, um eine
optimale Leistung und Langlebigkeit
des Produktes zu gewährleisten.
Ersetze beschädigte oder verschlissene
Teile umgehend. Verwende das Bike
erst nach Abschluss von Reparaturen.
Es dürfen nur Originalteile des
Herstellers verwendet werden.
Änderungen oder Modikationen an
diesem Gerät, die nicht ausdrücklich
von Peloton genehmigt wurden, können
zum Erlöschen der Garantie führen.
Ziehe den Netzstecker immer sofort
nach Gebrauch und vor dem
Reinigen oder Warten aus der
Steckdose. Wartungsarbeiten, die hier
Elektroaltgeräte dürfen nicht über
den Hausmüll entsorgt werden.
Bitte recycle dort, wo Anlagen
vorhanden sind. Erkundige dich
bei deiner örtlichen Behörde
oder deinem Händler nach
Empfehlungen zum Recycling.
Dieses Produkt ist ANT+™-
zertiziert und mit ANT+-
Sensoren kompatibel, welche
die Herzfrequenzüberwachung
unterstützen.
Das Peloton Bike ist nach EN ISO
20957-1 und EN ISO 20957-10 ein
Produkt der Klasse H und entspricht
den höchsten Standards für den
Fitnesseinsatz in Innenräumen.
Es wurde speziell für das
Beinmuskeltraining und das
Herz-Kreislauf-Training entwickelt.
EU
KONFORMITÄTSERKLÄRUNG
Hiermit erklärt Peloton Interactive
Inc., dass der Funkanlagentyp
PLTN-RB1VQ den Anforderungen
der Richtlinie 2014/53/EU
entspricht. Der vollständige
Text der Konformitätserklärung ist
unter folgender
nicht beschrieben sind, müssen von
einem autorisierten Techniker
durchgeführt werden.
Das Fitnessbike sollte nicht von
Personen benutzt werden, die mehr
als 135 kg (297 lbs.) wiegen.
Dieses Fitnessbike ist nur für den
Gebrauch im Innenbereich bestimmt.
Lagere das Fitnessbike nicht im
Freien, in der Nähe von Wasser oder
bei hoher Luftfeuchtigkeit.
Dieses Bike ist nur für den
Heimgebrauch bestimmt. Nicht in
gewerblichen Umgebungen
verwenden. Verwende das Bike nur
für den vorgesehenen Zweck.
Internetadresse verfügbar:
onepeloton.de/compliance
3938
DEUTSCH
