PS2R1-P Chip Replacement Instructions
The PS2R1-1P is a rate programmable scale. It is not necessary
for you to buy a chip. Let’s take a look at how to change the chip
if you decide to purchase a new chip.
All manuals and user guides at all-guides.com
all-guides.com

First turn the scale on. The scale must remain on while
changing the rate chip to retain the memory.
Turn the scale upside down
All manuals and user guides at all-guides.com

Remove the battery rate chip compartment cover
from the bottom of the scale.
Note the direction of the old chip.
You will see the notch on the top surface of the chip.
All manuals and user guides at all-guides.com

Using a flat head screwdriver gently pry one side up
and the other side to remove the chip.
Lift the chip straight up and out of the socket.
All manuals and user guides at all-guides.com

Be careful that the notch is on the correct side of the socket.
Check that each pin will slip into the socket.
Now place the new rate chip in the socket.
All manuals and user guides at all-guides.com

Gently press down to seat the chip into the socket.
Replace the battery rate chip compartment cover.
All manuals and user guides at all-guides.com
all-guides.com

Turn the scale over, press the count key…
The scale will show ACCP , AD10 or PC.
All manuals and user guides at all-guides.com

Turn the scale off.
Turn the scale back on.
All manuals and user guides at all-guides.com

If the new rate chip has been installed correctly the scale will
automatically go through its self check operation
showing a four digit version code number …
and then 0.0.
Your scale is now ready for use.
