Pendo BH32 User manual

QUICKSTART GUIDE &
USER MANUAL
> Please read carefully before use
PENDO HEADSET
BLUETOOTH BH32
PEN_1303_BH32_user manual_02.indd 1 22/08/12 10:22 AM

1
CONTENTS
1. INTRODUCTION 2
Bluetooth wireless technology
2. GET STARTED 4
Overview
Chargers and batteries
Switch the headset on or off
Pair the headset with a compatible phone
Disconnect the headset from the phone
Reconnect the paired headset to your phone
Troubleshooting
3. BASIC USE 10
Call handing
Adjust the earphone volume
4. BATTERY INFORMATION 11
5. CARE AND MAINTENANCE 12
PEN_1303_BH32_user manual_02.indd 2-1 22/08/12 10:22 AM

32
1. INTRODUCTION
The Pendo headset BH32 gives you the
freedom to make and receive calls while on
the move or in the office. You can connect the
headset to a compatible phone that supports
Bluetooth wireless technology.
Please read the user manual to make the
best use of this BH32 headset and its many
features.
Bluetooth wireless technology
Bluetooth wireless technology makes it
possible to connect compatible communication
devices without using cables. A Bluetooth
connection does not require the phone and
the headset to be in line of sight, but both
devices should be within 10 meters (30 feet) of
each other. Connections can be subjected to
interference from obstructions, such as walls
or other electronic devices.
The headset is compliant with Bluetooth
Specification 2.1 supporting Headset profiles
1.1 and Hands-Free profiles 1.5. Check with
the manufactures of the other devices to
determine their compatibility with this device.
There may be restrictions on using Bluetooth
technology in some locations. Check with your
local authorities or service provider.
PEN_1303_BH32_user manual_02.indd 2-3 22/08/12 10:22 AM

54
2. GET STARTED
Overview
The headset contains the following parts as
shown in the figure:
Before using the headset for the first time,
make sure it is fully charged.
Note: Parts of the headset are magnetic. Metallic materials may
be attracted to the headset. Do not place credit cards or other
magnetic storage media near the headset, because information
stored on them may be erased.
Charger and batteries
The headset BH32 can be charged by USB port
of a computer.
Please use with the USB charging cable that is
included in the package.
This device has a built-in rechargeable battery.
1. Connect the headset to the USB port of
computer. The red indicator light is on
during charging. If charging does not start,
disconnect the charger, plug it in again, and
retry. Charging the battery fully may take up
to 2 hours.
2. When the battery is fully charged, the
blue indicator light will be on. Disconnect
the charger from the wall outlet and the
headset or disconnect the headset from USB
charging cable.
The fully charged battery has power for up to
4 hours of talking time or up to 100 hours of
standby time. However, the talking and standby
times may vary when used with different
1. Answer/end key
2. LED Indicator
(red/blue)
3. Volume + and
volume – buttons
4. Earphone
5. Charging socket
6. Microphone
3
4
56
2
7
1
PEN_1303_BH32_user manual_02.indd 4-5 22/08/12 10:22 AM

76
mobile phones, usage settings, usage styles,
and environments.
When the battery is running out of power,
the red indicator light starts to flash and will
prompt every 15 seconds.
Switch the headset on or off
To switch on, press and hold the answer/end
key for 4 seconds. The blue indicator light
starts to flash 3 times and there is a prompt
sound.
To switch off, press and hold the answer/end
key for 4 seconds until the red indicator light
flashes 3 times with prompt.
Pair the headset with a compatible phone
1. Make sure your headset is off
2. Press the answer/end key for 6 second until
the red and blue LED flash alternately.
3. Activate the Bluetooth feature on the phone,
and set the phone to search for Bluetooth
devices. See the user guide of your phone
for instructions.
4. Select the headset (BH32) from the list of
found devices.
5. Enter the pass code 0000 to pair and
connect the headset to your phone. For
some phones you may need to make the
connection separately after pairing. See
the user guide of your phone for details.
You only need to pair the headset with your
phone once.
6. If the pairing is successful, the headset’s
blue light will flash 3 times briefly for the
first time follow by a single flash every 5
seconds. The headset’s name appears in
the phone menu where you can view the
currently paired Bluetooth devices.
* Pair the second mobile phone
When the Bluetooth headset is connected with
a mobile phone, and hold its Volume– button
for 3 seconds until the red and blue LED flash
alternately. It indicates that the headset is now
in pairing mode and has disconnected from
the first mobile phone. And you can now pair
and connect a second mobile phone.
PEN_1303_BH32_user manual_02.indd 6-7 22/08/12 10:22 AM

98
* Active the Multipoint Function
To active the multipoint Function, press and
hold the volume+ and volume- buttons at the
same time. When you see the blue light turn
on for about 2 seconds, and then turn off, it
means the Multipoint Function is active.
Disconnect the headset from the phone
To disconnect the headset from your phone
(for example, to connect the phone to another
Bluetooth device), do one of the following:
•Switch off the headset.
•Disconnect the headset in the Bluetooth
menu of your phone.
•Move the headset more than 10 meters (30
feet) away from the phone.
You do not need to delete the pairing with the
headset to disconnect it.
Troubleshooting
If you cannot connect the headset to your
phone:
•Ensure that the headset is charged, switched
on, paired with and connected to your phone.
•Ensure that the Bluetooth feature is
activated on your phone.
•Check that the headset is within 10 meter
(30 feet) of your phone and that there are
no obstructions between the headset and
the phone, such as walls or other electronic
devices.
PEN_1303_BH32_user manual_02.indd 8-9 22/08/12 10:22 AM

1110
3. BASIC USE
Call handling
To make a call
Use your phone in the normal way when the
headset is connected to your phone.
To answer a call
Press the answer/end key, or use the phone
keys. If the automatic answer function is set on,
the phone automatically answers the incoming
call after one ring.
To end a call
Press the answer/end key, or use the phone keys.
To redial the last dialed number
If your phone supports redialing, you can long
press the Volume+ to redial the last dialed
number.
To reject the call
When there is incoming call, press answer/end
key for 3 seconds to reject the call. This function
depends on whether your mobile support or not.
Adjust the earphone volume
While in conversation, press the Volume+
button to increase the volume, and press the
Volume- button to decrease the volume.
4. BATTERY INFORMATION
Your device is powered by a rechargeable
battery. The full performance of a new battery
is achieved only after two or three complete
charge and discharge cycles. The battery can
be charged and discharged hundreds of times,
but it will eventually wear out. Recharge
your battery only with compatible chargers
designated for this device.
Unplug the charger from the electrical plug
and the device when not in use. Do not leave a
fully charged battery connected to a charger,
since overcharging may shorten its lifetime. If
left unused, a fully charged battery will lose its
charge over time. Never use any charger that
is damaged.
PEN_1303_BH32_user manual_02.indd 10-11 22/08/12 10:22 AM

1312
Leaving the device in hot or cold places, such
as in a closed car in summer or winter will
reduce the capacity and lifetime of the battery.
Always try to keep the battery between 15° and
25°. A device with a hot or cold battery may not
work temporarily, even when the battery is fully
charged. Battery performance is particularly
limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they
may explode. Batteries may also explode if
damaged. Dispose of batteries according to
local regulations. Please recycle when possible.
Do not dispose as household waste
5. CARE AND MAINTENANCE
Your device is a product of superior design and
craftsmanship and should be treated with care.
•Keep all accessories and enhancements out of
the reach of small children.
•Keep the device dry. Precipitation, humidity,
and all types of liquids or moisture can contain
minerals that will corrode electronic circuits.
If your device does get wet, allow it to dry
completely.
•Do not use or store the device in dusty,
dirty areas. Its moving parts and electronic
components can be damaged.
•Do not store the device in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
•Do not store the device in cold areas. When
the device returns to its normal temperature,
moisture can form inside the device and
damage electronic circuit boards.
•Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and
fine mechanics.
•Do not use harsh chemicals, cleaning solvents,
or strong detergents to clean the device.
•Do not paint the device. Paint can clog the
moving parts and prevent proper operation.
All of the above suggestions apply equally to your
device, battery, charger, or any enhancement.
PEN_1303_BH32_user manual_02.indd 12-13 22/08/12 10:22 AM
