Penguin GLYCOL CHILLER User manual

W W W . P E N G U I N C H I L L E R S . C O M
GLYCOL CHILLER
Owners Manual
P E N G U I N C H I L L E R S

R32
R32 refrigerant has a 68% lower GWP (Global Warming Potential) than
R410. While neither refrigerant deteriorates the Ozone layer like R22 did, there is a clear
winner when looking at potential to contribute to global warming via greenhouse gases.
R32 is a much more environmentally friendly alternative to R410 and we expect to see it
become the new environmentally friendly standard in the years to come.
THE LOW GWP
ALTERNATIVE TO R410A
R32 IS NONEXPLOSIVE
AND HARDLY FLAMMABLE.
R32 is technically classified as a "mildly flammable" gas by the EPA. However R32 is
extremely difficult to ignite, non-explosive, and the least toxic of all the Class A refrigerants.
The regulatory warning labels on Penguin Chillers are EPA mandated for all refrigerants
considered flammable which covers a wide range of refrigerants including mildly flammable
refrigerants like R32 as well as highly flammable gasses such as butane (R600) and
propane (R290). When it comes to label requirements there is no distinction made between
mildly flammable and highly flammable. These regulatory warnings can be a bit intimidating,
they are there to keep you informed, but they should not lead you to worry about the use of
our chillers in normal operation. Our Chillers are intended for indoor use.
This information is based on reports prepared by the Air-conditioning and Refrigeration Equipment
Manufacturers Association of Australia (AREMA) and the Consumer Electronics Supplier Association (CESA)
R32
When first receiving the chiller AND anytime the
chiller is moved without keeping the unit level, you
MUST let the chiller remain upright for at least 2
hours before plugging it in.
Urgent Notice
Failure to do so will
result in chiller damage.
THE LOW GWP
ALTERNATIVE TO R410A
www.PenguinChillers.com

Our standard glycol chillers (excluding our commercial line) have a GFI plug.
Depending on the model, it's suitable to plug into a 110v - 120v 15a outlet
(standard household outlet) OR a 208v - 240v 20a outlet (Nema 5-20R). Most of
our models plug into standard 15a outlets. It is recommended to plug directly into a
receptacle. Power strips should be avoided. If an extension cord is necessary we
recommend using a 12 awg cord with single end (not a multi tap). Once plugged in,
be sure the GFI is in the reset position and has a green light.
GLYCOL CHILLER SETUP
Chillers work on the principal of moving heat from one spot to another. In the case
of a glycol chiller, its job is to move heat from the glycol out into the air. This
means proper air flow is critical to the operation of a chiller. If the chiller is located
in an overly hot or unventilated area, it cannot dissipate the heat efficiently
therefore lowering the chiller's ability to cool. Unless properly modified, enclosed
spaces like small cabinets or closets will heat up quickly and won't provide enough
ventilation for the chiller to properly do its job. If the chiller's hot exhausted air is
being recirculated back into its intake grills, then the chillers BTU/hr capacity is
greatly reduced. It is recommended to have at least 6” of open space on the sides
and top of the chiller and at least 12” of open space behind the chiller to allow for
proper ventilation.
Power
Locating the Chiller
The most common misconception is that using glycol is better than using water.
This is actually not true because water is about 6 times more efficient at
transferring heat than glycol. The ONLY reason we add glycol to water is to lower
the water's freezing point. This allows the glycol chiller to operate at or below the
normal freezing temperatures of a Water Chiller.
We recommend a 35% - 40% water to glycol mix. Take your time when mixing.
Simply "eyeballing it" is not good enough in this situation because it's important to
accurately measure.
We recommend mixing the water and glycol in a clean bucket or separate container
and then add the mixture to the chiller. Do not attempt to mix the water & glycol
inside the chiller itself.
Mixing Glycol
1.www.PenguinChillers.com

We recommend you create your mixture by starting with whole (full) gallons of
glycol and then add the proper amount of water to achieve your mix ratio. After
filling the chiller any leftover mix can easily be saved. Having pre-made mixture on
hand makes it easy to top off the reservoir if you ever have a small spill.
Mixing Example:
1 Gallon Glycol + 1.75 Gallons Water = 36.3% Glycol Mix
(1.75 gallons also equals 7 Quarts, 14 Pints or 28 Cups of water.)
Mixing Glycol
If your chiller has a 3rd copper line coming into the reservoir and that 3rd line
is capped off (the pipe is sealed / temp probe is in that pipe), you will fill the
reservoir to the point of touching the bottom of the black fittings that the copper
lines pass through.
There are 2 variations to our glycol chillers and they have different ways to
determine the fill level.
Glycol Fill Level
2.
If your chiller has an exposed temperature probe/wire coming out of an open
copper tube in the reservoir, you will fill with enough mix to cover the main
body of the coils, but below the open copper tube by roughly 1”-2”.
The temperature probe chase tube will act as an overflow.
If your liquid level gets high enough to enter the open tube it will drain
out and onto the floor.
www.PenguinChillers.com

After you pump the glycol mixture out to fill the supply lines and the fermenter coils
or jacket, top the reservoir back off.
The copper refrigerant lines in and out of the reservoir will likely be above the liquid
level when the chiller is filled as intended. These lines will frost over, which is
perfectly normal.
(For brewing specific setups)
Our chillers can be utilized with either of the main installation styles that exist in the
brewing world. There is a bit of confusion on how the two systems differ, so we
want to clarify the systems before explaining how each would connect to a chiller.
In either type of setup the job of the chiller doesn't change, it's there to ensure you
have cold glycol mixture on hand for when cooling is called for. The only
difference is how the flow of the glycol mixture is being controlled.
One pump per fermenter: Typical in the home-brew space, it utilizes a pump for
every fermenter (as the name implies). The pumps are typically submersible and
go directly into the reservoir. Each pump plugs into its own pump controller. The
pump controller monitors the fermenter temperature. Temperature control is
achieved by the regulating the pump on/off.
Glycol loop: Typical in large commercial applications, it utilizes a single heavy
duty pump that runs 24/7 to provide constant flow through a loop of pipe that
travels through a facility and back to the chiller. Solenoid valves are installed on
the loop. A central control panel is typically responsible for managing multiple
fermenters. Temperature control is achieved by regulating a solenoid open/closed.
Type of Installation
Glycol Fill Level cont'd
One pump per fermenter:
STANDARD PUMPS: (1/3HP, 1/2HP, 1HP)
We supply 3/8” barbs to fit the lid, there are enough holes in the lid for 2 barbs
and 1 open hole for running a power cord through for each pump. Try to put return
lines as far from the pump as possible. Our standard glycol pumps go directly into
the reservoir. Up to 4 on the 1/3HP and 1/2HP, and up to 8 on the 1HP. Run a
short piece of 3/8” tubing from the pump to the under side of the lid, and then from
the top of the lid out to the fermenter and back. A short piece of tubing under the
lid on the return side is recommended. The tubing will prevent drain back when the
pump shuts off. Each pump is plugged into a pump controller. The temperature
probe of the pump controller goes into the fermenter. The chiller should be set to
28F-30F and the desired fermenter temperature is programmed into the pump
controller. When the fermenter is too warm, the pump is turned on and the cold
glycol mixture is sent to the fermenter until it is back at the desired set
temperature.
3.www.PenguinChillers.com

XL PUMPS: ( 2/3HP, 1-1/3HP, 2HP, 3-1/3HP)
Our XL glycol pumps go directly into the reservoir (up to 8). Pump orientation and
exact placement doesn't matter, the only requirement is that the inlet tube is under
liquid. Run tubing from the pump through one of the holes in the rear of the lid out
to the fermenter and back. Running the return tubing back to below liquid level is
recommended. This will prevent drain back when the pump shuts off. If necessary,
the return line can be secured to the coil using a zip tie. Each pump needs to be
plugged into its own pump controller. The temperature probe of the pump
controller goes into the fermenter. The chiller should be set to 28F - 30F and the
desired fermenter temp is programmed into the pump controller. When the
fermenter is too warm, the pump is turned on and the cold glycol mixture is sent to
the fermenter until it is back at the desired set temperature.
One pump per fermenter:
4.www.PenguinChillers.com
Glycol Loop (for all glycol chillers)
Glycol loops are typically going to be installed by service professionals, so there's
not much we really need to cover.
An external pump would draw the glycol mixture out of the chiller's reservoir simply
by placing the pump intake line through the chiller lid and down into the glycol
mixture. Most of the pumps used in this process will have some amount of draw
capacity to actually pull the glycol mixture up and out of the chiller as long as that
line isn't excessively long. If the pump being used isn't a self priming pump, you'll
have to fill the line with the glycol mixture manually. Once you've established prime
there shouldn't be a need to re-prime the pump on a regular basis.

Chiller Maintenance
If you do not need to use your chiller for a long period of time, it can simply be
unplugged and left with the glycol in it.
There is no hard rule on changing out the glycol mixture because it lasts for quite a
while. Glycol begins to break down when it is being heated. The chiller isn't heating
your glycol mixture so it should last for quite a long time when being used properly.
We tend to see our customers changing out their glycol mixture every 1 to 2 years.
The rear coil of the chiller can become dusty/dirty overtime. If it's dirty enough to
reduce airflow, the cooling capacity of the chiller will be reduced. Occasionally
using compressed air to blow the coils off will keep the chiller performing as
efficiently as possible. The frequency of these cleanings highly depends on your
operating environment. Yearly coil cleaning should be sufficient for most users,
however, if you know you are operating in a particularly dusty/dirty environment
then you'll want adjust your cleanings accordingly.
Common Issues
My fermenter's cold crash has stalled:
If a batch seems to get stuck around 40F - 45F, resist the natural urge to turn your
chiller even colder. A stall during cold crashing is actually often caused by the
glycol mixture being too cold. When the glycol mixture gets too cold, beer begins
freezing to the coil forming a layer of ice. This ice layer is actually insulating the
coil which keeps the beer from coming in contact with the cold glycol mixture. If
you decide to turn the chiller temperature down even colder, this will cause the ice
layer to continue getting thicker. This makes the problem worse by keeping the
beer from coming in contact with the cold glycol mixture.
Do not run a test batch of water only in place of beer or cider. Doing so can cause
a coil to freeze. The chiller should be set to 28F - 30F for most applications. A
temperature of 28F may actually be too cold if working with a lighter alcohol
content beer or ciders.
5.www.PenguinChillers.com

Low fill level could potentially cause the built in controller's probe to be exposed to
the air. This could cause a higher reading than the glycol mixture's actual
temperature.
Poor circulation in the reservoir can cause uneven reservoir temperatures. The
temperature may be getting read from a warmer pocket and your pump may be
drawing from a colder pocket. This difference alone may be enough to cause a
problem. You want to have your return lines on the opposite sides/ends of the
reservoir away from the pump. Pointing a return line towards the temperature probe
can also help.
Re-check the temperature of your glycol mixture with a thermometer (not an IR gun).
Does the chiller LCD have power? (check GFI plug if not)
Is there a green snowflake symbol that is lit up on the controller? (prior controllers
have a red dot by “work” or “cool”) If there is no light indicating the controller is
calling for cooling – check controller settings.
Does the Fan and Compressor come on?
Is the air coming out of the back of the chiller warm/hot compared to the ambient
air temp?
Check the glycol mixture's temperature with an external thermometer
If you identify that your glycol mixture is too cold for any reason, correct it and then turn
the chiller up to 35F - 40F for a few hours to ensure you melt any ice that has formed.
Then you can lower the glycol mixture's temperature back to 28F - 30F to proceed with
the cold crash.
My glycol is freezing / slushing:
A mix of 35% glycol does not freeze until it's nearly zero degrees Fahrenheit. If you
have any freezing or slushing then your glycol mixture is either too light of a mix OR
the glycol mixture is colder than you believe it is.
Condensation rolling down lines and into the reservoir has the potential to change your
mix ratio to the point of freezing at normal operating temps. The glycol mixture is mixed
with the coil temp in mind, not liquid temp. The coils get 15F - 20F colder than the
liquid temp.
My Chiller isn't cooling:
If warm air is coming out the back, the chiller is cooling, at least partially. The question
becomes why is it not working to your expectations / it's full potential.
(not an IR gun). It is possible that the glycol mixture is cold and the controller is
providing an incorrect reading. Is the controller readout steady or does it jump around?
Common Issues cont'd
6.www.PenguinChillers.com

Penguin Chillers offers a variety
of accessories for both our
Glycol and Water Chillers.
Scan this
accessory page
QR code or visit
our website.
Common Issues cont'd:
What is the heat load? In the case of brewing – what size and how many tanks do
you have? How many are you trying to cold crash at the same time?
Double check fill level, and temperature probe location to make sure the probe is
below liquid and not touching part of the coil.
What was the percentage of your original glycol mixture? When was the last time
you made ANY changes to your glycol mixture? Have you added glycol, water, or
a glycol/water mixture to your chiller and if so which one did you add? When was
the last time you replaced the entire contents of your glycol mixture in the chiller?
Ambient air temperature.
Chiller set point or chiller reading.
Fermenter set point or fermenter reading.
External thermometer to measure the glycol mixture's temperature.
When referring to a Temperature, please clearly identify what the specific
sources are.
There are many sources of temperature, clearly identifying which temperature you
are referring to is critical to an accurate and speedy assessment of the issue.
Send any questions to: [email protected]
Do you need accessories
for your Chiller?
Pumps - Tubing - Controller
Glycol - Quick Disconnects
7.www.PenguinChillers.com

All chillers come with a 1 year warranty. Certain chillers are offered with an optional extended
warranty for an additional charge. The length of warranty will be determine by your purchase,
minimum of 1 year.
Penguin Chillers warrants the Chiller to be free from defects in materials and workmanship. The
warranty term begins on the date of purchase. This limited warranty does not cover any damage,
deterioration or malfunction resulting from any alteration, modification, improper or unreasonable
use or maintenance, misuse, abuse, accident, neglect, exposure to excess moisture, fire, improper
packing and shipping (such claims must be presented to the carrier), lightning, power surges, or
other acts of nature. Penguin Chillers’ warranty liability extends only to the replacement cost of the
product. Penguin Chillers will not be liable for any consequential, indirect, or incidental damages of
any kind, including lost revenues, lost profits, or other losses in connection with the product. Some
states do not allow limitation on how long an implied warranty lasts or the exclusion of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. Penguin
Chillers will, at our discretion, repair or replace the Chiller covered under this warranty. To request
warranty service, please contact our technical support via email: [email protected].
If this product is returned to Penguin Chillers for repair the customer is responsible for shipping
charges to get the chiller to Penguin Chillers. The chiller needs to be properly packaged for safe
transport. This product must be insured during shipment. Customer assumes all risks of loss or
damage during shipment. After receiving the package Penguin Chillers will repair or replace the
chiller at our discretion. Penguin Chillers will repackage and ship the chiller back to you at no
additional cost within the continental 48 states, surcharges may apply outside of the continental 48
states. Penguin Chillers will not be responsible for any costs related to the removal or re-
installation of this product from or into any installation. Penguin Chillers will not be responsible for
any costs related to any setting up this product, any adjustment of user controls or any installation
cost of this product.
TO THE MAXIMUM EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY AND THE REMEDIES
SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF OTHER WARRANTIES, REMEDIES AND
CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE MAXIMUM EXTENT
PERMITTED BY LAW, PENGUIN CHILLERS SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. IF PENGUIN CHILLERS CANNOT LAWFULLY DISCLAIM OR
EXCLUDE IMPLIED WARRANTIES UNDER APPLICABLE LAW, THEN ALL IMPLIED WARRANTIES
COVERING THIS PRODUCT, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL APPLY TO PRODUCT AS PROVIDED UNDER APPlICABLE LAW.
This limited warranty is void if (i) the label bearing the serial number of this product has been removed or
defaced, (ii) the product is not distributed by Penguin Chillers or (iii) this product is not purchased from an
authorized Penguin Chillers reseller. If you are unsure whether a reseller is an authorized or not, contact us.
8.
8.www.PenguinChillers.com

www.PenguinChillers.com
(865) 214 - 6509
[email protected]
www.PenguinChillers.com
A Controller Guide was included with your chiller. Please
see the FAQ Page on our website to view a copy of the
controller guide and other helpful information.
