Slash pool heating costs to pennies per day
ThermalFlo
™
Heat Pump
By Pentair Water Pool and Spa®
With ThermalFlo™heat pump, heat from the atmosphere is transferred to your
pool or spa, providing the most energy efficient heating available. ThermalFlo is
the latest and most technologically advanced heat pump from Pentair Water Pool
and Spa®, the company that brings you energy-efficient heaters and heat pumps
for every application.
●ThermalFlo can cost up to 80% less to operate, saving hundreds of dollars
in energy costs each year.
●Easy-to-use digital controls for precise temperature control of your pool
and spa.
●Clean and safe to operate—ETL listed. The only pool heat pump using
EPA-recognized R-410A environmentally safe, clean, and non-ozone
depleting refrigerant.
●Perfect companion for IntelliTouch®automation controls.
The result? Heating your pool is easier and more economical than ever before.
Compare the Cost
Fuel Type Cost/Per BTU/$.01
Electric $.075/KWh 455
LP Gas $.99/Gal 653
Oil $.99/Gal 979
Natural Gas $.65/ Therm 1077
ThermalFlo $.075/KWh 2093
This chart illustrates how aThermalFlo Heat Pump
generates 2 to 4.6 times more heat for the same
cost. Costs are based on national average fuel costs
and efficiencies. Please consult your local provider
for current pricing.
PE35980_sppp.indd 1PE35980_sppp.indd 1 10/31/07 11:13:53 AM10/31/07 11:13:53 AM

More standard features
than any other heat pump
ThermalFlo
™Heat Pump
Model Breaker Wire
Number Description BTUs/COP†Size Size
460912 ThermalFlo HP 500 99,000/4.0 50 amp 8
460913 ThermalFlo HP 700 107,000/4.1 50 amp 8
460914 ThermalFlo HP 900 117,000/4.4 60 amp 6
460915 ThermalFlo HP 1200 125,000/4.2 60 amp 6
460922 ThermalFlo HP 125,000 Heat/4.1 60 amp 6
1200R H/C 71, 000 Cool
Please consult your pool professional for theThermalFlo model
to meet your pool/spa requirements.
†BTU = British Thermal Unit, COP = Coefficient of Performance
©2007 Pentair Water Pool and Spa, Inc. All rights reserved.
10/07 Part # P1-379
Digital controls with dual thermostats
offer precise temperature control for
pool/spa combinations to avoid
overheating or wasted energy
Self-diagnostic control panel monitors
and troubleshoots heat pump operations
to ensure safe, dependable operation
Long-life corrosion-resistant composite
cabinet stands up to severe climates and
pool chemicals
Coated evaporator coil prevents
corrosion for longer service life
2-inch plumbing connections for easy
installation
Available from:
Pentair Pool Products®Sta-Rite®
800.831.7133 800.831.7133
www.pentairpool.com www.staritepool.com
Automatic Heating/Cooling Feature!
Only ThermalFlo offers a model that automatically heats
or cools your pool water based on temperatures you set.
Select the AUTO mode and the intelligent thermostat
will automatically heat or cool the water to your selected
temperature. Available only on the 1200R H/C model.
pumps /filters /heaters /heat pumps /automation /lighting /cleaners /sanitizers /maintenance products
The newest version of ThermalFlo™heat pump provides more
standard features than any other heat pump on the market, including
●High-efficiency Trane®Climatuff®* compressor is the most
dependable, durable and quietest available.
●100% pure titanium heat exchanger assures corrosion-free
performance for extra long life.
●New LCD control board displays an intuitive menu-driven
readout with easy to follow full word messages—no more codes.
●New self-diagnostic software continuously monitors system for
peak performance.
●Thermostatic Expansion Valve (TXV) controls refrigerant flow for
optimum efficiency and BTU output over a wider operating range.
●AutoSet (time clock override) feature monitors water
temperature and turns the water circulation pump on and
off as needed to maintain desired pool temperatures.
●Automatic defrost feature senses refrigerant temperature and
preventsThermalFlo from freezing, allowing the heat pump to
operate at even lower temperatures.
●ETL listed to ensure safe, dependable operation.
●Ten-year limited warranty. See warranty for details.
*Trane and Climatuff are registered trademarks of American Standard International, Inc.
