Pentair NRG-DM User manual

NRG-DM
EN-NRGDM-IM-EU0381 Rev2
THERMAL BUILDING SOLUTIONS
Software version 1.60
pentairthermal.com/manuals/
CZ – DA – DE – EN – ES – ET – FI – FR – HU – IT – LT – LV – NL – NO – PL – RU – SV

2
40
20
82
82
74
74
Figure 1
Figure 2

3
1Content 3
2Description 5
3Navigation principle 6
4Getting started 7
5Navigation structure 8
6
Working modes 9
6.1 Event Mode
(weekly schedule mode) 9
6.2 Constant Mode
(single temperature mode) 9
6.3 Boost Mode
(temporary override mode) 10
7
Changing/Consulting settings 11
7.1 Event settings
(programming a weekly schedule) 11
7.2 User settings 12
7.2.1 Time and date 12
7.2.2 Child lock 13
7.2.3 Display settings 13
7.2.4 Energy monitoring 14
7.3 Engineer settings 14
7.3.1 Temperature calibration 14
7.3.2 Adaptive function 15
7.3.3 Sensor setting 15
7.3.4 Temperature scale 16
7.3.5 Backlight 16
7.3.6 Sensor 16
7.3.7 Language 17
7.3.8 Factory reset 17
7.3.9 Information 17
1 CONTENT

4
8Trouble shooting 17
9Technical specification 18
10 Approvals and declarations 19
Attention:
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.

5
2 DESCRIPTION
The NRG-DM thermostat is a smart electronic thermostat
designed for electrical under floor heating. It is
designed to control your under floor heating in order
to give you the best possible comfort at the lowest
possible energy consumption. The NRG-DM is equipped
with an ambient sensor and a floor sensor and is thus
capable of monitoring and controlling your floor heating
cables in 4 different modes (Room sensing mode /
Floor sensing mode / Room sensing mode with floor
limiter / No sensor mode) depending on your needs.
The NRG-DM will switch on and off your floor heating in
order to obtain the set-temperature. When the NRG-DM is
switching on the electrical floor heating, the symbol ( ) is
visible on the display.
The NRG-DM is controlling your electrical floor heating in
3 working modes (see Table 1).
Working mode Description Symbol
Constant Mode
In the Constant Mode, the NRG-DM
is aiming for 1 temperature only.
You can easily adapt this set
temperature by using the +/- button
Event Mode In the Event Mode, the thermostat
is working according to a weekly
schedule. The Event Mode is
created in order to maximize
the comfort while minimizing
the energy consumption of your
electrical floor heating system
Boost Mode The Boost Mode is a temporary
override of the Constant Mode or
the Event Mode. When activating
the Boost Mode, you can choose a
temporary Set temperature and a
duration for the Boost Mode. After
this duration, the NRG-DM will
automatically switch back to the
last used Mode (Constant or Event)
Table 1
or

6
3 NAVIGATION PRINCIPLE
The NRG-DM is a thermostat with a big and clear
display of 1.8’’.
1. On/OFF switch
2. Day and time
3. Working Mode
4. Heating Symbol
5. Display temperature
6. 3 Commands
7. 3 Buttons
Use the button (7) in order to execute the command (6).
In the example on figure 3:
• The Left and Right buttons show “-“ & “+”, this means
that you can change the set temperature with 0.5°C by
using these buttons
• The Middle button shows “Menu”, this means that you
can enter the Menu by using this button
12
3
45
6
7
Figure 3

7
4 GETTING STARTED
When you power up the NRG-DM for the first time, you will
be asked to follow a set-up wizard with 4 simple questions.
1. Select Language 2. Confirm Time
3. Confirm Date 4. Select Sensor
Remark: This wizard will only be requested when installing
the thermostat for the first time or when you choose to
reset to the factory settings (see 7.3.8 Factory reset)
In select Sensor (see figure 7) you have the choice between:
• Factory = Sensor delivered in the box of the NRG-DM
• NRG-Temp = in case of retrofitting of an NRG-Temp
• Other = in case of retrofitting of a thermostat with a
different type of sensor. Compatible types are 2kΩ,
10kΩ, 12kΩ, 15kΩ and 33kΩ sensor. If you have the
sensor reference value table, please use this to set the
correct reference values at 15°C, 20°C, 25°C and 30°C.
Otherwise use the standard table settings by confirming
the values with the OK button.
Figure 4
Figure 6
Figure 5
Figure 7

8
5 NAVIGATION STRUCTURE
In the NRG-DM, it is very easy to navigate in the Menu
structure to activate working modes or to change settings.
When entering the MENU, you can directly activate the
working modes (Boost Mode, Event Mode or Constant
Mode) or enter the Settings.
The settings are divided in 3 categories:
• Event settings = program the weekly schedule
(see 7.1 Event settings)
• User settings = for users to make small changes
(see 7.2 User settings)
• Engineer settings = for installers or experienced users
(see 7.3 Engineer settings)
Standby
Home Boost Mode
Event Mode Constant
Mode
Boost Mode Settings
User
settings
Engineer
settings
Event
settings
List of
user
settings
List of
advanced
settings
Programming
the events
CHANGING/CONSULTING SETTINGS
MENU
WORKING MODES
Direct access to
BOOST is only active
in Event Mode using
the + and - button
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineer settings
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 10
Figure 9
Figure 8

9
6 WORKING MODES
6.1 EVENT MODE
(weekly schedule mode)
The Event Mode is the Energy efficient mode. In this mode
a weekly schedule has been set-up and can easily be
adapted to your needs.
The weekly schedule in the Event Mode is based on a
7 days schedule where each day can be defined as 1 to 6
events. Events are a combination of a duration (From – To)
and a temperature.
The Event Mode is pre-programmed as follows:
Table 2
To program the weekly schedule (see 7.1 Event settings).
Remark: You can temporarily step away from the weekly
schedule by activating the Boost Mode (see 6.3 Boost
Mode)
6.2 CONSTANT MODE
(single temperature mode)
The Constant Mode is a simple working mode where the
NRG-DM is aiming for 1 temperature only. In this mode,
you can choose the temperature by using the + & - buttons.
Remark: You can temporarily step away from the Constant
Mode by activating the Boost Mode (see 6.3 Boost Mode).
Schedule Period 1 Period 2 Period 3 Period 4 Period 5 Period 6
Mon-Fri
00:00-06:30 06:30-08:30 08:30-18:00 18:00-21:00 21:00-24:00 N/A
16°C 23°C 16°C 23°C 16°C N/A
Sat-Sun
00:00-08:00 08:00-24:00 N/A N/A N/A N/A
16°C 23°C N/A N/A N/A N/A
00
06
12 18
24
02 04 16
14
10 08
20 22
00 06 12 18 24
02 04 16
14
10 08 20 22
23°C
16°C
23°C
16°C
00 06 12 18 24
02 04 16
14
10 08 20 22
00 06 12 18 24
02 04 16
14
10 08 20 22
23°C
16°C
23°C
16°C

10
6.3 BOOST MODE
(temporary override mode)
The Boost Mode is a temporary override of the working
mode (Event Mode or Constant Mode). At the end of the
Boost Mode, the NRG-DM thermostat will continue working
in the mode that was active just before the activation of the
Boost Mode.
When activating the Boost Mode, the NRG-DM will ask you
to confirm the requested temperature and duration of the
temporary override.
The Boost Mode is identified on the screen by the Boost
Icon:
• When coming from the Constant Mode:
• When coming from the Event Mode:
In order to stop the Boost Mode, simply press on the Stop
button.
In order to activate the Boost Mode, press on the Menu
button, navigate to the Boost Mode and then press on
select.
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineer settings
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 11
Figure 12
23.0°C
Menu
MONDAY 11:42
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
23.0°C
Menu
MONDAY 11:42
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
23.0°C
Menu
MONDAY 11:42 ...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT

11
Note: If you are running in Event Mode, you can activate the
Boost Mode by pressing on the + or – button directly.
7 CHANGING/CONSULTING SETTINGS
7.1 EVENT SETTINGS
(programming a weekly schedule)
The Event settings are used in order to program or adapt a
weekly schedule used in the Event Mode.
Programming the weekly schedule is done in 3 steps:
Step 1: Select a day or a sequence of days to program
Step 2: Program up to 6 periods for this day:
Period 1:
• Duration = From 00:00 to xx:xx
Figure 13
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 14
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 15

12
• Temperature = xx.x °C
Period 2:
• Duration = From 07:00 to xx:xx
• Temperature = xx.x °C
Period 3 -6 (or when 24:00 is reached)
Step 3: Decide if you want to copy this programming for
the next day
You can repeat steps 1 to 3 for other days if needed.
7.2 USER SETTINGS
7.2.1 TIME AND DATE
With the Time and date setting, you can adjust the clock
and calendar.
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 17
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 18
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 16

13
7.2.2 CHILD LOCK
By activating the child lock, the NRG-DM will go to the
home screen and a lock sign will appear on the screen.
The child lock will prevent the thermostat settings to be
changed by accident.
To unlock the NRG-DM, press and hold the 3 buttons for
5 seconds.
7.2.3 DISPLAY SETTINGS
In the display settings, you can decide to customize what
appears on the display.
You can make changes to:
• Time and Day:
Show/hide the time and day on the home screen
• Temperature:
Show the desired temperature (called set
temperature) or the measured temperature
(called actual temperarture)
• Screen saver:
You can activate or deactivate the screen saver. The
screen saver shows the temperature, time and day
after 60 seconds of inactivity of the thermostat
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 19
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 21
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 20
ON OFF

14
• Screen mode:
The screen can be displayed in standard mode or in
inverted mode.
7.2.4 ENERGY MONITORING
You can display some statistics of the use of the NRG-DM.
In order to be able to do this, the currency, the load and the
cost of energy need to be filled in. In the energy monitoring
menu, you will find:
• Currency (what currency do you use)
• Load (how much electrical heating cable is installed in
this room in kW)
• Cost/unit (cost of 1 kWh)
In the energy monitoring menu, you will see the values
calculated for the last 2 days, for the last month & for the
last year.
7.3 ENGINEER SETTINGS
7.3.1 TEMPERATURE CALIBRATION
When running in Floor sensor mode (see 7.3.3 Sensor
setting)
You can calibrate the floor sensor to the actual floor
temperature by using the calibration menu. The floor
temperature can differ from temperature measured by the
floor sensor depending on the floor construction.
When running in Room sensor mode (see 7.3.3 Sensor
setting)
You can calibrate the ambient sensor to the actual room
temperature by using the calibration menu.
The NRG-DM is performing an auto calibration of the Room
Sensor after each factory reset (or after first installation).
The manual calibration of the Room sensor should only be
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
...
Engineering Mode
User settings
Event settings
...
SELECT
...
Event Mode
Boost Mode
Exit
...
SELECT
21.0°C
Stop
MONDAY 11:40
23.0°C
Menu
MONDAY 11:42
...
Mon-Fri
Sat-Sun
...
SELECT
SELECT DAY(S)
From To
07:00 09:00
OK
Mon-Fri, Period 2
From To
00:00 07:00
OK
Mon-Fri, Period 1
OK
Mon-Fri, Period 1
16.0°C
OK
Mon-Fri, Period 2
23.0°C
23.0°C
Menu
MONDAY 14:22
23.0°C
MONDAY 14:00
23.0°C
Menu
23.0°C
MONDAY 14:30
23.0°C
Menu
MONDAY 14:22
...
Constant Mode
Event Mode
Boost Mode
...
SELECT
23.0°C
Menu
MONDAY 14:32
Figure 22
Standard Inverted

15
performed after this automatic calibration and only in the
few cases where the automatic calibration seems not to be
100% accurate.
7.3.2 ADAPTIVE FUNCTION
Thanks to the adaptive function, the NRG-DM will know
when to switch your heating on, in order to obtain the
desired temperature at the desired time. The Adaptive
function is only active in the Event Mode and is activated
from factory. You can de-activate the Adaptive function in
the Adaptive function menu.
The Adaptive function will optimize the energy consumption
to the desired comfort of the user.
7.3.3 SENSOR SETTING
The NRG-DM can operate in different sensor settings.
Some of the settings are activated in the thermostat when a
physical floor sensor is installed; others are activated when
there is no external sensor installed.
• When there is a floor sensor installed and connected
• Floor
The NRG-DM is regulating the temperature based on
the input given by the floor sensor (embedded in the
floor)
• Room/limit
The NRG-DM is regulating the temperature based
on the input of the room sensor (integrated in the
thermostat) but is making sure the floor is not
exceeding a desired temperature measured by the
floor sensor
• When there is no external sensor installed or connected
• Room
The NRG-DM is regulating the temperature based
on the input of the room sensor (integrated in the
thermostat)
• No sensor
The thermostat works like a regulator. It will work in
duty cycles and it will activate the electrical heating
cables during a percentage of this duty cycle.

16
7.3.4 TEMPERATURE SCALE
The Temperature scale settings provide the possibility to
limit the minimum and maximum settable temperature in
the working modes (Event Mode, Constant Mode or Boost
Mode).
7.3.5 BACKLIGHT
You can define how the backlight (blue light) of the
NRG-DM is reacting.
There are 3 possible settings:
• Auto
The backlight is deactivated after 30 seconds of inactivity
• On heat
The backlight lights up every time the thermostat is
heating
• Constant On
The back light does not go off
7.3.6 SENSOR
In the Sensor setting, you select the type of sensor that is
installed. The possible sensors are:
• Factory = sensor delivered with the NRG-DM = 12kΩ
sensor
• NRG-Temp = sensor of the NRG-Temp or Green Leaf
thermostat = 10kΩ sensor
• 2 kΩ sensor
• 10 kΩ sensor
• 12 kΩ sensor
• 15 kΩ sensor
• 33 kΩ sensor
With the exception of the Factory sensor and the NRG-
Temp sensor, you will be asked to give reference points of
your sensor at 15, 20, 25 & 30°C. If you do not have these
reference points of the sensor, the NRG-DM is proposing
you a standard calibration of the sensor. This might not be
100% accurate but will be close to the real values.

17
7.3.7 LANGUAGE
The NRG-DM is translated in to 11 languages. In this menu
you can choose to use the following languages for the
firmware: Czech, Dutch, English, Finnish, French, German,
Lithuanian, Norwegian, Polish, Russian or Swedish.
7.3.8 FACTORY RESET
If you need to reset all the settings to the factory settings,
you can use the factory reset.
7.3.9 INFORMATION
In the information section of the thermostat, you will
find information on how to contact us, on the measured
temperatures and calibration and on the software version
in the thermostat.
8 TROUBLE SHOOTING
In the event of damage or malfunction of one of the
temperature sensors, the heating output cuts off (fail safe)
and an error code is displayed.
Table 3
* The floor sensor may be replaced by a new one (product
reference = 1244-002952). In case of replacement of the
floor sensor by a new sensor (1244-002952), the sensor
selection needs to be performed and you need to choose
the NRG-Temp sensor in the list of sensors (see 7.3.6
Sensor).
Number Error type
E0
Room failure. NRG-DM is defective. Please
replace the thermostat.
E1 Room sensor defective or short circuited.
Please replace the thermostat.
E2
Floor sensor defective or short circuited.
Please check or replace the external sensor *
E5 Internal overheating. Please inspect the
installation

18
9 TECHNICAL SPECIFICATION
Supply voltage 230VAC +/- 10%, 50Hz
Power consumption in
Sleep mode
400 mW
Power consumption in
Max. load
1000 mW
Main power switch 2-pole
Relay output 230V, max. 13A
Setpoint range 0°C to 40°C
Ambient temperature
– transport
-20°C to +70°C
Protection class IP21
Terminals 2,5 mm2Screw cage clamp
Floor sensor with 3 m
cable
12k @ 25°C +/- 0.75°C (no:38165)
Maximum length of
floor sensor cable
100m, 2 x 1,5mm² (230VAC cable)
Dimension with frame 84 X 84 X 40mm
Color rounded front RAL 9010
Color square front RAL 9003
Color switch gear frame RAL 9010
Display 1.8’’ Dot Matrix LCD display
(100 x 64 pixels) with blue
backlight
Control modes Floor Sensor (active when floor
sensor installed and connected)
Room Sensor with floor limiter
(active when floor sensor
installed and connected)
Room Sensor (active when no
floor sensor is connected)
No Sensor % regulator with
cycles of 20 minutes (active when
no floor sensor is connected)
Working modes Constant Mode, Event Mode,
Boost Mode

19
Table 4
10 APPROVALS AND DECLARATIONS
Temperature regulation
method
PWM (pulse with modulation
method) with PI control loop
Accuracy – floor/room
sensor
0.2°C in the range 0°C to +40°C
Back-up for set values In non-volatile memory
Back-up for time
and date
5 years storage or 10 years with
50% power on
Type of action 1.B. (39)*
Control pollution degree 2 (49)*
Rated impulse voltage 4kV (75)*
Temperature for the
ball pressure test
125°C (77)*
SELV limits realized 22 VDC (86)*
* According to the EN 60730-1 table 1

BELGIË / BELGIQUE
Tel. [phone]
Fax [phone]
[e-mail]
ČESKÁ REPUBLIKA
Tel. [phone]
Fax [phone]
[e-mail]
DANMARK
Tel. [phone]
Fax [phone]
[e-mail]
DEUTSCHLAND
Tel. [phone]
Fax [phone]
[e-mail]
ESPAÑA
Tel. [phone]
Fax [phone]
[e-mail]
FRANCE
Tél. [phone]
Fax [phone]
[e-mail]
ITALIA
Tel. [phone]
Fax [phone]
[e-mail]
NEDERLAND
Tel. [phone]
Fax [phone]
[e-mail]
NORGE
Tel. [phone]
Fax [phone]
[e-mail]
ÖSTERREICH
Tel. [phone]
Fax [phone]
[e-mail]
POLSKA
Tel. [phone]
Fax [phone]
[e-mail]
РОССИЯ
Тел. [phone]
Факс [phone]
[e-mail]
SCHWEIZ / SUISSE
Tel. [phone]
Fax [phone]
[e-mail]
SUOMI
Puh. 0800 11 67 99
Telekopio 0800 11 86 74
[e-mail]
SVERIGE
Tel. [phone]
Fax [phone]
[e-mail]
TÜRKIYE
Tel. [phone]
Fax [phone]
[e-mail]
UNITED KINGDOM
Tel. [phone]
Fax [phone]
[e-mail]
WWW.PENTAIRTHERMAL.COM
All Pentair trademarks and logos are owned by Pentair or its global affiliates.
Pentair reserves the right to change specifications without prior notice.
© 2015 Pentair.
EN-NRGDM-IM-EU0381 Rev2
THERMAL BUILDING SOLUTIONS
