Pentair RAINBOW HC 3315 User manual

RAINBOW™ CHLORINE / BROMINE HIGH
CAPACITY COMMERCIAL FEEDER
MODELS: HC 3315, 3330 AND 3340
FEATURES:
• Extra large capacity models.
• For use with Trichlor or Bromine tablets.
• No special venting required.
• Completely enclosed - no escaping gases.
• Positive external no-clog control valve.
• No equipment damage. Feeds sanitizer directly to pool.
• NSF 50 Certified when paired with flow rate indicator (such as P/N R172082)
installed on inlet line.
INSTALLATION
This feeder is designed for hard plumbing installation using
1” PVC pipe and includes standard threaded inlet and
outlet fittings. It operates by pressure differential which
circulates through the feeder. The inlet line (control valve
side of feeder), connects to the plumbing between the
pump and filter. The outlet side of the feeder connects
to pool return line after the filter and/or heater, pool
cleaner, diverter valves or any other piece of equipment
(if installed). A corrosion resistant check valve such as
Rainbow’s R172288 should be installed between the
feeder inlet and outlet and the equipment to help prevent
equipment damage. DAMAGE TO THE HEATER OR
OTHER EQUIPMENT COULD RESULT FROM A HIGH
CONCENTRATION OF SANITIZER BACK FLOWING INTO
IT WHEN PUMP IS SHUT OFF. It is recommended that
feeder be bolted down.
OPERATING INSTRUCTIONS
Exercise extreme caution when operating or servicing feeder. NEVER
OPEN FEEDER WHEN PUMP IS RUNNING. DO NOT INHALE
FUMES, especially in hot weather which can create more gases.
Wear protective gear. Follow chemical manufacturer’s instructions for
handling the chemical. Before start up of feeder your pool should be
properly conditioned and the chlorine residual should be 1.0 to 1.5 ppm
(Bromine 2.0 to 4.0 ppm). Consult your local dealer for water conditioning
information in your area. Because the sanitizer demand in your pool is
dependent on many factors (sunlight, high temperatures, bather load,
etc.) your valve setting may have to be changed from time to time to
adjust to these conditions. When possible, increase the feed rate a day
or two in advance. The recommended start up setting is #1. Use a test kit
to determine the sanitizer residual. It is recommended that the sanitizer
residual be checked daily for the first 5 days to find the ideal setting.
NOTE: Higher numbers dispense more chemical. Small gradual changes
are imperative for control.
READ CAREFULLY.
This feeder is designed to use only CLEAN Trichlor-s-trizinetrione OR CLEAN Bromine tablets - slow dissolving type.
Never use dirty tablets. UNDER NO CIRCUMSTANCES MIX Trichlor or Bromine with Calcium Hypochlorite, with other
forms of concentrated chlorine or with other chemicals. Keep inside of feeder clean of dirt and debris at all times. FIRE
AND/OR TANK SEPARATION MAY RESULT.
NEVER use oils or grease to lubricate o-ring. Oil in contact with Trichlor OR Bromine may result in FIRE. Lubricate o-ring with Lifegard
Silicone o-ring Lubricant ONLY, available at your dealers. If shock treatments or Algaecides containing chemicals other than sanitizers
tablets in feeder must be used, turn off Feeder OR remove tablets until the shock or Algae treatment is complete and all granules have
dissolved. Failure to do so may result in granules mixing in feeder causing FIRE AND/OR TANK SEPARATION. The shock or algae
treatment dissolved in water is safe with tablets. If you are not the original owner of this feeder, not sure which chemicals was used, or if dirt
and/or debris inside feeder, be SAFE and flush thoroughly with fresh water. CAUTION SHOULD BE USED WHEN REMOVING CAP. DO
NOT INHALE FUMES.
CALCIUM HYPOCHLORITE IS NOT TO BE USED IN ANY FORM. Use of chemicals other than those recommended by manufacturer
may be hazardous.
READ CAREFULLY.
It is important to read all information BEFORE proceeding with the
installation. The information will guide you in installing your feeder properly and avoiding problems
due to improper isntallation. IF INSTRUCTIONS ARE NOT FOLLOWED FIRE OR TANK
SEPARATION MAY RESULT, CAUSING PROPERTY DAMAGE AND/OR PERSONAL INJURY.
IF YOUR POOL HAS COPPER PLUMBING...STOP! Never Install feeder into copper plumbing
as pipe dmage may occur.
NOTE: If a heater is used, a FIREMAN’S SWITCH or equivalent must be installed to prevent
possible damage and improper operation of CHECK VALVE and other equipment subject to heat
damage.

*R2401*
CHARGING INSTRUCTIONS
Exercise extreme caution when operating or servicing feeder. DO NOT INHALE FUMES, especially in hot weather which can create
more gases. Wear protective gear. Follow chemical manufacturer’s instructions for handling the chemical.
1. Shuf off pump and close control valve. Wait one minute. If feeder is below water level, before opening drain valve, be sure to close
any inline valve(s) to prevent back flow. Open vent valve on top of lid. Open drain valve on bottom of feeder. (Always drain water into
plastic container and then pour contents back into pool.)
2. Close drain valve. Then depress lock spring and unscrew lock ring
counter-clockwise. Remove the lid and fill with proper size chlorine or
bromine slow-dissolve tablets.
3. Before replacing lid, clean and lubricate o-ring with Lifegard Silicone
Lubricant only. Push lid firmly into position. Close vent valve. Thread
on lock ring clockwise until lock spring snaps into place. Do not force
lock ring past lock spring.
4. Open any inline valve(s) and turn on pump and timer switches.
5. Adjust control valve to desired setting.
During no flow through feeder, potential for
elevated chemical concentrations and hazardous
gas introduction exists.
NOTE: If isolation valves are used anywhere in the system, you must
remember to open them before start-up. To prevent gas buildup in the
feeder, be sure to keep return line valve(s) open, except when operating
or servicing unit. Close control valve when adding other chemicals to your
pool, vacuuming, backwashing or adding D.E. to filter.
WINTERIZING
If feeder is subject to freezing, drain all water from chamber. Carefully
remove any undissolved tablets. Rinse out feeder with water, replace lid
with vent valve slightly open and keep unit covered all winter.
PARTS LIST
Item Qty. Part No. Description
1 1 R172214 Lock Ring
2 1 R172385D Lid Assembly
3 1 R172224X Vent Valve
4 1 R172221 O-Ring, Valve
5 1 R172240 O-Ring, Lid to Housing
6 1 R172375 Lock Screw
7 1 R172374 Lock Spring
8 1 R175251 Screen
9 1 R172435 Check Ball
10 1 R172436 Housing w/stand, HC 3315
10 1 R172437 Housing w/stand, HC 3330
10 1 R172438 Housing w/stand, HC 3340
11 2 R270484 1” Close Nipple
12 1 R270531 1” Threaded Union
13 1 R172439 Control Valve
14 1 R172036 Silicone Lubricant
15 Optional R172288 1-1/2” - 2” Check Valve
16 1 R175009 1/2” Drain Valve
17 1 R172134 1/2” Threaded Plug
- Optional R172082 Flow Rate Indicator
1620 HAWKINS AVE., SANFORD, NC 27330 • [phone]
10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • [phone]
WWW.PENTAIR.COM
All indicated Pentair trademarks and logos are property of Pentair Inc. or its global aliates in the U.S.A. and/or other countries. Third
party registered and unregistered trademarks and logos are the property of their respective owners.
© 2020 Pentair. All rights reserved. This document is subject to change without notice.
P/N R24001 REV. D 6/2020
4
3
1
5
2
8
96
7
14
15
13
16
17
12 11
11
10
MODEL Capacity
(Lbs.)
Tested Flow
Rate@100%
Setting (GPM)
Output Rate (lbs/hr) @ 100% Setting* Maximum Pool Size
(10PPM) @ 34 GPM
Cl Tested Flow
Rate @ 50%
Setting (GPM)
Output Rate (lbs/hr)
@ 50% Setting*
Br Tested Flow
Rate @ 50%
Setting (GPM)
Output Rate (lbs/hr)
@ 50% Setting*
Cl-Pool Cl-Spa Br-Pool Br-Spa Trichlor Bromine Cl-Pool Cl-Spa Br-Pool* BR-Spa*
HC-3315 15 34 2.8 4.8 0.5 1.0 224,000 38,690 17.8 2.1 1.8 25 0.4 0.6
HC-3330 30 34 4.6 7.9 1.1 2.2 369,000 65,556 17.8 3.4 3.0 25 0.8 1.2
HC-3340 40 11.5 3.0 5.7 0.6 1.4 658,533 105,176 9.2 2.6 5.4 9 0.5 1.2
PERFORMANCE DATA SPECIFICATION*
Maximum Working Pressure - 50 PSI
Output rating for Bromine is not NSF certified.
* Results based on use of 1” BioGuard®bromine tablets and 1” Trichlor-S-Triazinetrione chlorine tablets.
