INSTALLATION AND
OPERATION MANUAL
SUBMERSIBLE SOLIDS HANDLING PUMP
C4H(X*)P, H4Q(X*)P, S4K(X*)P, S4L(X*)P, S4LV(X*)P, S4B(X*)
P, S6L(X*)P, S6A(X*)P, S8F(X*)P
(* USED IN HAZARDOUS LOCATIONS CLASS I, DIVISION I, GROUPS C & D): FM
E-03-558 (08-01-21) | Part # 056255581

TABLE OF CONTENTS
Safety Information ................................................................................................................................................................................... 3
General Information.................................................................................................................................................................................. 4
Pump Installation...................................................................................................................................................................................... 5
Pump Operation & Maintenance ............................................................................................................................................................... 6
Troubleshooting ....................................................................................................................................................................................... 7
Parts List.................................................................................................................................................................................................. 8
Wiring Diagrams ......................................................................................................................................................................................15
Warranty..................................................................................................................................................................................................16

3
E-03-558 (08-01-21)
READ AND FOLLOW SAFETY INSTRUCTIONS!
This is the safety alert symbol. When you see this symbol
on your pump or in this manual, look for one of the following
signal words and be alert to the potential for personal injury:
warns about hazards that will cause serious
personal injury, death or major property damage if ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if ignored.
warns about hazards that will or can cause minor
personal injury or property damage if ignored.
NOTE: indicates special instructions which are important but
not related to hazards.
CALIFORNIA PROPOSITION 65 WARNING
This product and related accessories contain
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
GENERAL SAFETY
Do not touch an operating motor. Modern
motors can operate at high temperatures. To avoid burns when
servicing pump, allow it to cool for 20 minutes after shutdown
before handling.
 Do not allow pump or any system component to freeze. To
do so will void the warranty. See “Warranty” .
 Pump only water with this pump.
 Periodically inspect pump and system components.
 Wear safety glasses at all times when working on pumps.
 Keep work area clean, uncluttered and properly lighted.
Store all unused tools and equipment.
 Keep visitors at a safe distance from the work areas.
 Carefully read and follow all safety instructions in this
manual and on pump.
 Keep safety labels in good condition.
 Replace missing or damaged safety labels.
 Make workshops childproof; use padlocks and master
switches; remove keys.
Read carefully the product installation &
operation instructions. Failure to follow the instructions and
warnings in the manual may result in serious or fatal injury
and/or property damage, and will void the product warranty.
This product must be installed by a qualified professional.
Follow all applicable local and state codes and regulations. In
the absence of such codes, follow the current editions of the
National Plumbing Code and National Electrical Code (NEC), as
applicable.
This product is used in conjunction with a
system containing a tank under pressure, which may over time
corrode, weaken and burst or explode, causing serious or fatal
personal injury, leaking or flooding and/or property damage.
To minimize risk, a licensed professional must install and
periodically inspect and service the product and system. A drip
pan connected to an adequate drain must be installed if leaking
or flooding may cause property damage. Do not locate system
in an area where leaking may cause property damage.
This control is capable of running pumps
to pressures that may exceed the limitations of system
components. Never set the operating pressure higher than that
of the safe system capacity.
This control can be adjusted to a narrow
pressure differential. An improperly sized tank can cause the
pump to cycle and lead to pump damage. This may require a
larger pressure tank than is normally used.
ELECTRICAL SAFETY
ELECTROCUTION HAZARD: Must be installed by
a qualified professional. First disconnect all electrical power
before attempting service. For your safety, the installation and
operation instructions must be followed to minimize the risk of
electric shock, property damage or personal injury.
Pump body may explode if used as a booster
pump unless a relief valve capable of passing full pump flow at
75 psi is installed.
A water test must be taken before installation
of any water treatment equipment. The water quality can
significantly influence the life of your system. You should
test for corrosive elements, acidity, total solids and other
relevant contaminants, including chlorine and treat your water
appropriately to ensure satisfactory performance and prevent
premature failure.
Use only lead-free solder and flux for all
sweat-solder connections, as required by state and federal
codes.
EXPLOSION OR RUPTURE HAZARD: A relief
valve must be installed to prevent pressure in excess of local
code requirement or maximum working pressure designated in
the product manual, whichever is less. Do not expose system
to freezing temperatures or temperatures in excess of 120°F
(49°C). Failure to properly size the system or follow instructions
in the manual may result in excessive strain on the system and
may lead to product failure, leakage, flooding and/or property
damage.
SAFETY INFORMATION

4E-03-558 (08-01-21)
This manual contains important information for the safe use of
this product. Read completely and do not throw away.
Reasonable care and safe methods should be practiced. Check
local codes and requirements before installation.
UNPACKING PUMP
When unpacking unit, check for damage. Claims for damage must
be made at the receiving end through the delivery carrier. Damage
cannot be processed from the factory.
Before handling these pumps and controls,
always disconnect the power first. Do not smoke or use sparkable
electrical devices or flames in a septic (gaseous) or possible
septic sump.
PUMPS IN STORAGE OR NOT OPERATING
Pumps with silicon/carbide seals must have impellers manually
rotated (6 revolutions) after setting non-operational for 3 months
or longer and prior to electrical start-up.
Pumps with tungsten carbide seals must have impellers
manually rotated (6 revolutions) after setting non-operational
for 3 weeks or longer and prior to electrical start-up.
SEAL FAILURE PROBES
All hazardous location submersible pumps have two factory
installed moisture detectors (seal failure probes). They are in a
normally open series circuit in the seal chamber. Under normal
operating conditions, the circuit remains open. If the lower seal
leaks and moisture enters this chamber, the moisture would
settle to the bottom of the chamber and will complete the circuit
between the moisture detectors.
This circuit must be connected to a sensing unit and signaling
device. This is supplied in a Hydromatic®built control panel.
Failure to install such a device negates all warranties by
Hydromatic.
HEAT SENSORS
All motors in this family have heat sensors on or embedded in the
motor winding to detect excessive heat. This prevents damage to
the motor. If sensor trips due to excessive winding temperature,
the starter in the panel breaks power to the pump.
Once the sensor resets, the starter is automatically reset for FM
for continued operation of the pump. This circuitry is supplied in a
Hydromatic control panel.The sensors are set to trip at 130°C.
Failure to install such circuitry would negate FM approvals and
all warranties by Hydromatic.
POWER CORDS
The power cord and heat sensor seal failure cord are potted into
the cord cap. The cords must not be spliced.
Each cable has a green lead. This is the ground wire and must be
grounded properly per NEC and/or local codes. Cords should be
inspected for abnormal wear and replaced accordingly.
OVERLOAD HEATERS
If the Hydromatic electrical panel is not used, starters with 3 leg
overload relay must be supplied on 3 phase pumps. Each leg is to
have an identical heater sized in accordance with the nameplate
amps on the motor housing. The amp draw on these submersible
motors is slightly higher than a corresponding horsepower surface
motor, so heaters must be sized by the nameplate rating.
Capacitor start single phase pumps have a run and start winding
that draws different currents. To adequately protect these
windings with the appropriate heaters, consult the factory.
The red lead is always the start winding of a pump using single
phase.
INSTALLING SUMP LEVEL CONTROLS FLOAT CONTROLS
In either simplex, duplex or triplex systems, the lower or turn-
off control is to be set to maintain a minimum level in the sump.
This level shall be no more than 3-1/4" from the top of the motor
housing down to the surface of the sewage.
The second or turn-on control is set above the lower turn-off
control. The exact distance between the two floats must be a
compromise between a frequent pumping cycle (15 starts per hour
max.) to control septicity, solids and a slower cycle for energy
economy. This distance should be determined by the engineer or
consulting engineer, depending on the conditions of
the application.
GENERAL INFORMATION

5
E-03-558 (08-01-21)
INSTALLING PUMP IN SUMP
Before installing the pump in the sump, lay it on its side and rotate
impeller. Impeller may be slightly stuck due to factory test water.
The impeller should turn freely. DO NOT connect the power until
after this test.
Clean all debris from sump and connect pump to piping. A check
valve must be installed on each pump and a gate or plug valve
in each pump discharge is highly recommended. This valve
should be installed on the discharge side of the check valve so
if it becomes necessary to service the check valve, the line
pressure can be cut off. Single pump systems are sometimes
installed without a check valve where it is desirable to self-drain
the discharge line to prevent freezing. This can be done only with
short discharge lines; otherwise water will return to the sump and
cause short cycling of the pump.
MAKING ELECTRICAL CONNECTIONS
All electrical wiring must be in accordance with local codes,
and only competent electricians should make the installations.
Complete wiring diagrams are glued to the inside cover of the
panel. It is VERY IMPORTANT to check all wires for grounds with
an ohmmeter or Megger(r) after the connections are made as
one grounded wire can cause considerable trouble.
NOTE: If equipment is not properly wired and protected as
recommended, the warranty is void.
The 230 volt 3 phase pump has a dual marked
nameplate. For ordinary location pumps, voltage may be rewired
by qualified personnel. For hazardous location pumps, voltage
may be rewired by the manufacturer or a Class I, Div I equipment
qualified electrician. Once the voltage is changed, the factory
cord tag indicating 230 volt 3 phase must be removed.
For record keeping purposes, we suggest the pump be marked
externally with the new voltage and qualified personnel that
performed the change. Pumps shipped from the factory as 460
volt 3 phase cannot be rewired to any other voltage.
TO RE-WIRE THE PUMP FROM 230V TO 460V 3 PHASE
Only a 230V pump from the factory is considered dual voltage, a
cord label clearly states the factory wound voltage.
1. Remove all six (#7) cap screws then raise the cord cap
assembly enough to slip a prying instrument on opposite
sides between the cord cap casting and the motor housing.
Take care to not damage the o-ring or the machined
surfaces of the castings. Doing so could void FM agency
certifications.
2. While prying evenly on both sides; separate the cord cap
casting from the motor housing, the assembly is airtight
and will have a vacuum effect when disassembling.
3. Once separated, the cord cap can be inverted and rotated
to the outside of the pump assembly, and a bolt can be
re-used to secure the upside down cord cap to the motor
housing for ease of rewiring.
Refer to the wiring diagram within this manual for wiring
details. Once all electrical connections are finished and secure
(a crimped electrical connector is best to prevent issues due
to vibration if required), the cord cap should be re-attached
reversing the steps above. Ensure the o-ring is in place and
perform a hi-pot test for safety once everything is complete.
HEAT SENSORS AND SEAL FAILURE CONNECTIONS
Be sure heat sensor wires are connected in series with the starter
coil. Connections are provided on the terminal strip.
INSTALLATION & OPERATIONS
SYSTEM TYPE NUMBER OF
CONTROL WIRE
NUMBER OF
POWER LINE
NUMBER OF
GROUND WIRES #8
HEAT SENSOR & SEAL FAILURE
NUMBER OF SENSOR WIRES NUMBER OF GROUND WIRES
Simplex 4 3 1 3 1
Simplex with Alarm 6 3 1 3 1
Duplex 6 6 2 6 2
Duplex with Alarm 8 6 2 6 2
NUMBER OF CONDUCTORS REQUIRED BETWEEN CONTROL PANEL AND NEMA 4 JUNCTION BOX
Power lines and control wires can be carried in conduit or can be underground buried cable
DUAL VOLTAGE
3 PHASE MOTOR WIRING
230V 3ø 460V 3ø
GREEN GREEN
R
(L3)
W
(L2)
BL
(L1)
R
(L3)
W
(L2)
BL
(L1)
12 3
78 9
45 6
12 3
78 9
45 6

6E-03-558 (08-01-21)
PUMP OPERATIONS STARTING SYSTEM
1. Double check all wire connections.
2. Turn pumps to Off position on H-O-A switches.
3. Turn on breakers.
4. When using single phase pumps, make sure red pump lead
is connected to capacitor circuit. Connect amprobe to pump
power cord and turn pump on. The pump will show high amp
draw momentarily, then as pump comes off start wirings, amps
will drop to normal nameplate amps.
5. When using three phase pumps (230/460/575), turn the
H-O-A switch to Hand position on one pump and notice
operation. If pump is noisy and vibrates, rotation is wrong.
To change rotation, interchange any two line leads to pump.
Do not interchange main incoming lines. Check rotation of
all pumps in this same manner.
6. Now set both H-O-A switches to Auto position and allow
water to rise in sump until one pump starts. Allow pump to
operate until the level drops to turn-off point.
7. Allow sump level to rise to start other pump(s). Notice run
lights in panel. Pumps should alternate on each successive
cycle of operation.
8. Turn both H-O-A switches to Off position and allow sump to
fill to the override control level(s).
9. Turn switches to Auto position, and pumps should start and
operate together until level drops to turn-off point.
10. Repeat this operation and cycle several times before
leaving the job.
11. Check voltage when pumps are operating and check the
amp draw of each pump. Check amps on each wire as
sometimes a high leg will exist. For excessive voltage on
one leg, the electric utility company should be consulted.
PUMP MAINTENANCE
As the motors are oil filled, no lubrication or other maintenance
is required. If the heat sensor and seal failure are hooked up
properly, no attention is necessary as long as the seal failure
indicator light does not come on. To ensure continuity of the
seal sensor leads, a test light is provided on intrinsically safe
Hydromatic panels as standard equipment. Pump should be
checked every quarter for corrosion and wear.
Before handling these pumps and controls,always
disconnect the power first. Do not smoke, use flames or devices
that can produce electrical discharge or sparks in a septic
(gaseous) or possible septic sump.
FIELD SERVICE ON HYDROMATIC ORDINARY LOCATION PUMPS
Ordinary location submersible motors that are out of warranty
can be serviced in the field by any reliable motor service shop.
Any pump that is in warranty must be returned to the factory for
service or repaired at an authorized Pentair Hydromatic service
center. Charges will not be allowed if (in warranty) pump is not
taken to an authorized Pentair Hydromatic service center. When
field service is performed on a pump, these instructions should be
carefully followed.
FIELD SERVICE ON HYDROMATIC HAZARDOUS LOCATION PUMPS
Hydromatic hazardous location pumps must be returned to the
factory for electrical and motor service. Any repair not at an
authorized service center will void the Factory Mutual (FM) listing.
This will ensure the integrity of the hazardous location rating of
the pump and comply with our warranty requirements.
The upper and lower seal, volute and impeller components may be
repaired or replaced by an authorized Hydromatic service facility
without compromising the hazardous location rating to the pump.
Any time a seal is disturbed, it must be replaced. Check the pump
for proper rotation before returning to service.
ADJUST CUTTER CLEARANCE ON CHOPPER PUMP
Disconnect power before adjusting chopper
clearance; always keep fingers and hands away from chopper
parts.
1. First install the chopper plate (Item D) into the volute. It may
be helpful to install ½-20 studs into the chopper plate to line
up the holes with the corresponding volute holes. You may
have to tap the plate all the way down with a rubber hammer.
2. Remove the studs and replace with four ½-20 x 1 (Item A) in
long socket head screws from beneath the volute, do not
tighten.
3. Install motor with impeller mounted, tighten motor housing
bolts to the volute
4. Install the chopper retainer ring (Item B) and tighten the four
3/8 -16 x 1" long (Item C) socket head cap screws to force the
chopper plate up against the impeller and chopper blade
5. Next back off these 3/8-16 (Item C) bolts one quarter of a
turn. This should give you .015 clearances.
6. Tighten the outer four ½ -20 screws (Item A) to 75-85 Ft-lbs.
7. Measure the clearance with a feeler gage it should be
between .010 and .015.
8. Spin impeller with a hex wrench on the Impeller hub screw or
use a wooden pry bar to spin impeller to make sure there is no
rub.
9. If you hear or feel a rub readjust the clearance by loosening
the inner 3/8-16" screws evenly and tightening the ½- 20
screws.
INSTALLATION & OPERATIONS

7
E-03-558 (08-01-21)
PUMP TROUBLESHOOTING
Below is a list of common problems and the probable causes:
PUMP WILL NOT START.
1. No power to the motor. Check for blown fuse or open circuit
breaker.
2. Selector switch may be in the Off position.
3. Control circuit transformer fuse may be blown.
4. Overload heater on starter may be tripped. Push to reset.
PUMP WILL NOT START AND OVERLOAD HEATERS TRIP.
1. Turn off power and check motor leads with Megger or
ohmmeter for possible ground.
2. Check resistance of motor windings. All 3 phases should
show the same reading.
3. If no grounds exist and the motor windings check OK,
remove pump from sump and check for clogged or blocked
impeller.
PUMP OPERATES WITH SELECTOR SWITCH IN HAND POSITION
BUT WILL NOT OPERATE IN AUTO POSITION.
1. This indicates trouble in the float level control or the
alternator relay.
2. Check control panel for trouble.
PUMP RUNS BUT WILL NOT SHUT OFF.
1. Pump may be air locked. Turn pump off and let set for
several minutes, then restart.
2. Lower float control may be hung-up in the closed position.
Check in sump to be sure control is free.
3. Selector switch may be in the Hand position.
PUMP DOES NOT DELIVER PROPER CAPACITY.
1. Discharge gate valve may be partially closed or partially
clogged.
2. Check valve may be partially clogged. Raise level up and
down to clear.
3. Pump may be running in wrong direction. Low speed pumps
can operate in reverse direction without much noise or
vibration.
4. Discharge head may be too high. Check total head with
gauge when pump is operating. Total head is discharge
gauge pressure converted to feet plus vertical height from
water level in sump to center line of pressure gauge in
discharge line. Gauge should be installed on pump side of
all valves. Multiply gauge pressure in pounds by 2.31 to get
head in feet.
5. If pump has been in service for some time and capacity falls
off, remove pump and check for wear or clogged impeller.
MOTOR STOPS AND THEN RESTARTS AFTER SHORT PERIOD
BUT OVERLOAD HEATERS IN STARTER DO NOT TRIP.
1. This indicates heat sensors in the motor are tripping due
to excessive heat. Impeller may be partially clogged giving
a sustained overload but not high enough to trip overload
heater switch.
2. Motor may be operating out of liquid due to a failed level
control.
3. Pump may be operating on a short cycle due to sump being
too small or from water returning to sump due to a leaking
check valve.
TROUBLESHOOTING
A
B
C
D
CUTTER INSERT
IMPELLER
CHOPPER PLATE
3/8-16 BOLTS
PLATE RETAINING RING
1/2-20 BOLTS
RECOMMENDED
MAX CUTTER GAP
.015
.010

8E-03-558 (08-01-21)
C4H(X)P, H4Q(X)P, S4K(X)P, S4L(X)P, S4LV(X)P, S4B(X)P, S6L(X)P, S6A(X)P AND S8F(X)P
For use with product built with Premium Efficient motor.
Ref. Part No. Part Description Qty.
128011D000 MOTOR HOUSING 1
227808D010 BEARING HOUSING 1
327882A009 TERMINAL BLOCK* 1
406106A069 SCREW – CAP SKT HD. 2
5110650043 SCREEN 1
619331A009 WASHER SPRING 1
719101A017 SCREW - CAP 6
8026030003 STATOR RING 1
906106A028 SCREW – SEAL PLATE 4
10 001500191 O-RING (CORD CAP) 1
11 05876A112 O-RING (SEAL PLATE) 1
12 05876A178 O-RING (MOTOR HOUSING) 1
13 19103A048 SCREW - CAP 8
14 08565A026 BALL BEARING 1
15 071670171 ANG. CONTACT DBL ROW BALL BEARING 1
16 009240101 PLUG – PIPE 1/2" SKT HD. BRASS 3
17 05818A012 STATOR KEY 1
18 109010021 PROBE – SEAL FAILURE 2
19 109000045 SEAL – SENSOR ASSEMBLY 1
20 12558A036 RETAINING RING – EXTERNAL 2
21 009740041 RETAINING RING – INTERNAL 1
22 27994A000 SIL CAR/CARBON – NITRILE UPPER 1
23 080732251 SIL CAR/CARBON – NITRILE LOWER 1
24 152880315 CORD CAP ASSEMBLY – 10-4 SOOW 1
152880325 CORD CAP ASSEMBLY – 8-4 W 1
152880335 CORD CAP ASSEMBLY – 6-4 W 1
152880345 CORD CAP ASSEMBLY – 4-4 W 1
25 107550312 SEAL PLATE 1
132531001 OIL, DIELECTRIC VARIES
PARTS INDEX
1
2
3, 4
5
7
8
12
11
15
16
18
19
10
A1
A2
A4
24
6
16
16
17
13
14
20
21
A3
22
23
9
20
25
250 FRAME PUMPS
Ref. Part No. Part Description Qty.
128012D000 MOTOR HOUSING 1
227966D010 BEARING HOUSING 1
327882A009 TERMINAL BLOCK* 1
406106A069 SCREW – CAP SKT HD. 2
5110650043 SCREEN 1
619331A009 WASHER SPRING 1
719101A017 SCREW - CAP 6
8026032801 STATOR RING 1
906106A028 SCREW – SEAL PLATE 4
10 001500191 O-RING (CORD CAP) 1
11 05876A112 O-RING (SEAL PLATE) 1
12 001500441 O-RING (MOTOR HOUSING) 1
13 19103A062 SCREW - CAP 8
14 08565A026 BALL BEARING 1
15 071670171 ANG. CONTACT DBL ROW BALL BEARING 1
16 009240101 PLUG – PIPE 1/2" SKT HD. BRASS 3
17 05818A012 STATOR KEY 1
05818A005 STATOR KEY – All 1750RPM & 30hp 1150RPM 1
18 109010021 PROBE – SEAL FAILURE 2
19 109000045 SEAL – SENSOR ASSEMBLY 1
20 12558A036 RETAINING RING – EXTERNAL 2
21 009740041 RETAINING RING – INTERNAL 1
22 27994A000 SIL CAR/CARBON – NITRILE UPPER 1
23 080732251 SIL CAR/CARBON – NITRILE LOWER 1
24 152880315 CORD CAP ASSEMBLY – 10-4 SOOW 1
152880325 CORD CAP ASSEMBLY – 8-4 W 1
152880335 CORD CAP ASSEMBLY – 6-4 W 1
152880345 CORD CAP ASSEMBLY – 4-4 W 1
25 107550312 SEAL PLATE 1
132531001 OIL, DIELECTRIC VARIES
280 FRAME PUMPS - DISCONTINUED, FOR REFERENCE ONLY

9
E-03-558 (08-01-21)
Item
No. Description S4L(X)P S4B(X)P S4K(X)P S4LV(X)P H4Q(X)P S6L(X)P S6A(X)P S8F(X)P C4H(X)P
1IMPELLER 025940002 136920012 137200012 110430002 151510012 025940002 136940052 025940002 153590002
D1 O-RING 05876A178 05876A178 05876A178 05876A178 05876A178 05876A178 05876A178 05876A178 05876A178
D2 SCREW-CAP 005700601 (8) 005700601 (8) 005700601 (8) 005700601 (8) 005700601 (8) 005700601 (8) 005700601 (8) 005700601 (8) 005700601 (8)
D3 KEY 05818A010 05818A010 05818A010 05818A010 05818A010 05818A010 05818A010 05818A010 05818A010
D4 WASHER-IMPELLER 019450001 019450001 019450001 019450001 019450001 019450001 019450001 019450001 N/A
D5 VOLUTE 089190015 136910022 137190002 107830002 151520015 089180015 136930012 089260025 153580002
D6 IMP BOLT 005700181 005700181 005700181 005700181 005700181 005700181 005700181 005700181 005680191
D7 SCREW-MACHINE
(NOT SHOWN)
SEE VOLUTE
ASSY 008290061 (3) 008290061 (3) N/A SEE VOLUTE ASSY
SEE VOLUTE
ASSY 008290091 (4) SEE VOLUTE ASSY N/A
D8 WEAR RING SEE VOLUTE
ASSY 136900003 136900003 N/A SEE VOLUTE ASSY
SEE VOLUTE
ASSY 136900003 SEE VOLUTE ASSY N/A
D9 CUTTER PLATE N/A N/A N/A N/A N/A N/A N/A N/A 153600002
D10 CUTTER INSERT N/A N/A N/A N/A N/A N/A N/A N/A 153320014
D11 RETAINER PLATE N/A N/A N/A N/A N/A N/A N/A N/A 153330001
D13 SCREW-CAP
(RETAINER PLATE) N/A N/A N/A N/A N/A N/A N/A N/A 06106A028 (4)
D14 SCREW-CAP
(CUTTER PLATE) N/A N/A N/A N/A N/A N/A N/A N/A 005680021 (4)
D15 SCREW-FLAT HEAD
SCKT (INSERT) N/A N/A N/A N/A N/A N/A N/A N/A 07597A037 (4)
PARTS INDEX
S4L(X)P
S4B(X)P
S4K(X)P
S4LV(X)P
H4Q(X)P
C4H(X)P
S6L(X)P
S6A(X)P
S8F(X)P
D1 D3
D4 D6
D51
1 D5
D6 D9
D4
D3
D1
1 D5
D6D4
D3D1
1 D5
D6
D4
D3D1
1 D5
D6 D9D4
D3D1
1D5
D6D4
D3
D1
D1 D3
D4 D6
D5
1
D10
D14
D3, D6, D15 - Not shown in this view
D12
D11 D13
D5
D2D1
1
D1 D3
D4 D6
D5
1
D2
D2
D2
D2
D2 D2
D2
D2

10 E-03-558 (08-01-21)
MOTOR PARTS GROUP
ITEM 4-POLE 1750 RPM 40 HP 40 HP 30 HP 30 HP 30 HP 20 – 25 HP 20 – 25 HP 20 – 25 HP
460/3/60 575/3/60 230/3/60 460/3/60 575/3/60 208-230/3/60 460/3/60 575/3/60
A1 STATOR 27904D003 27904D603 27903D003 27903D003 27903D603 27902D003 27902D003 27902D603
A2 ROTOR/SHAFT ASSEMBLY 27904D011 27904D011 27903D011 27903D011 27903D011 27902D011 27902D011 27902D011
A3 BOLT – STATOR (4) 06106A071 06106A071 06106A027 06106A027 06106A027 06106A027 06106A027 06106A027
A4 SPACER – – 076650011 076650011 076650011 076650041 076650041 076650041
CONNECTOR 12672A001 – – 12672A001 – – 12672A001 –
ITEM 6-POLE 1150 RPM 15 HP 15 HP 15 HP 7.5 – 10 HP 7.5 – 10 HP 7.5 – 10 HP
208-230/3/60 460/3/60 575/3/60 208-230/3/60 460/3/60 575/3/60
A1 STATOR 27901D003 27901D003 27901D603 27900D003 27900D003 27900D603
A2 ROTOR/SHAFT ASSEMBLY 27901D011 27901D011 27901D011 27900D011 27900D011 27900D011
A3 BOLT – STATOR (4) 06106A027 06106A027 06106A027 06106A027 06106A027 06106A027
A4 SPACER 076650041 076650041 076650041 076650121 076650121 076650121
CONNECTOR – 12672A001 – – 12672A001 –
ITEM 8-POLE 870 RPM 10 – 15 HP 10 – 15 HP 10 – 15 HP
208-230/3/60 460/3/60 575/3/60
A1 STATOR 27963D003 27963D003 27963D603
A2 ROTOR/SHAFT ASSEMBLY 27963D011 27963D011 27963D011
A3 BOLT – STATOR (4) 005560081 005560081 005560081
A4 SPACER 076651001 076651001 076651001
CONNECTOR – 12672A001 –
ITEM 6-POLE 1150 RPM 20 – 25 HP 20 – 25 HP 20 – 25 HP
208-230/3/60 460/3/60 575/3/60
A1 STATOR 27961D003 27961D003 27961D603
A2 ROTOR/SHAFT ASSEMBLY 27961D011 27961D011 27961D011
A3 BOLT – STATOR (4) 005560081 005560081 005560081
CONNECTOR – 12672A001 –
ITEM 8-POLE 870 RPM 5 – 7.5 HP 5 – 7.5 HP 5 – 7.5 HP
208-230/3/60 460/3/60 575/3/60
A1 STATOR 27898D003 27898D003 27898D603
A2 ROTOR/SHAFT ASSEMBLY 27898D011 27898D011 27898D011
A3 BOLT – STATOR (4) 06106A027 06106A027 06106A027
A4 SPACER 076650121 076650121 076650121
CONNECTOR – 12672A001 –
ITEM 4-POLE 1750 RPM 50 HP 50 HP
460/3/60 575/3/60
A1 STATOR 27959D003 27959D603
A2 ROTOR/SHAFT ASSEMBLY 27959D011 27959D011
A3 BOLT – STATOR (4) 06106A071 06106A071
CONNECTOR 12672A001 –
250 FRAME PUMPS MOTOR PARTS GROUP
280 FRAME PUMPS MOTOR PARTS GROUP - DISCONTINUED, FOR REFERENCE ONLY

11
E-03-558 (08-01-21)
IMPELLER PARTS LIST
S4B(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4B(X)P2000DC 20 208/3 6-4 9 136920132
S4B(X)P2000EC 20 230/3 6-4 9 136920132
S4B(X)P2000FC 20 460/3 8-4 9 136920132
S4B(X)P2000GC 20 575/3 8-4 9 136920132
S4B(X)P2500DC 25 208/3 4-4 9.5 136920112
S4B(X)P2500EC 25 230/3 6-4 9.5 136920112
S4B(X)P2500FC 25 460/3 8-4 9.5 136920112
S4B(X)P2500GC 25 575/3 8-4 9.5 136920112
S4B(X)P3000EC 30 230/3 4-4 10 136920092
S4B(X)P3000FC 30 460/3 8-4 10 136920092
S4B(X)P3000GC 30 575/3 8-4 10 136920092
S4B(X)P4000FC 40 460/3 6-4 11 136920052
S4B(X)P4000GC 40 575/3 8-4 11 136920052
1150 RPM
S4B(X)P750DB 7.5 208/3 8-4 10 136920092
S4B(X)P750EB 7.5 230/3 8-4 10 136920092
S4B(X)P750FB 7.5 460/3 10-4 10 136920092
S4B(X)P750GB 7.5 575/3 10-4 10 136920092
S4B(X)P1000DB 10 208/3 8-4 11 136920052
S4B(X)P1000EB 10 230/3 8-4 11 136920052
S4B(X)P1000FB 10 460/3 10-4 11 136920052
S4B(X)P1000GB 10 575/3 10-4 11 136920052
S4B(X)P1500DB 15 208/3 8-4 12 136920012
S4B(X)P1500EB 15 230/3 8-4 12 136920012
S4B(X)P1500FB 15 460/3 8-4 12 136920012
S4B(X)P1500GB 15 575/3 10-4 12 136920012
870 RPM
S4B(X)P500DA 5 208/3 8-4 11 136920052
S4B(X)P500EA 5 230/3 10-4 11 136920052
S4B(X)P500FA 5 460/3 10-4 11 136920052
S4B(X)P500GA 5 575/3 10-4 11 136920052
S4B(X)P750DA 7.5 208/3 8-4 12 136920012
S4B(X)P750EA 7.5 230/3 8-4 12 136920012
S4B(X)P750FA 7.5 460/3 10-4 12 136920012
S4B(X)P750GA 7.5 575/3 10-4 12 136920012
S4LV(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4LV(X)P2000DC 20 208/3 6-4 8.63 110430132
S4LV(X)P2000EC 20 230/3 6-4 8.63 110430132
S4LV(X)P2000FC 20 460/3 8-4 8.63 110430132
S4LV(X)P2000GC 20 575/3 8-4 8.63 110430132
S4LV(X)P2500DC 25 208/3 4-4 9.25 110430122
S4LV(X)P2500EC 25 230/3 6-4 9.25 110430122
S4LV(X)P2500FC 25 460/3 8-4 9.25 110430122
S4LV(X)P2500GC 25 575/3 8-4 9.25 110430122
S4LV(X)P3000EC 30 230/3 4-4 10.38 110430382
S4LV(X)P3000FC 30 460/3 8-4 10.38 110430382
S4LV(X)P3000GC 30 575/3 8-4 10.38 110430382
S4LV(X)P4000FC 40 460/3 6-4 11.5 110430012
S4LV(X)P4000GC 40 575/3 8-4 11.5 110430012
1150 RPM
S4LV(X)P750DB 7.5 208/3 8-4 10 110430042
S4LV(X)P750EB 7.5 230/3 8-4 10 110430042
S4LV(X)P750FB 7.5 460/3 10-4 10 110430042
S4LV(X)P750GB 7.5 575/3 10-4 10 110430042
S4LV(X)P1000DB 10 208/3 8-4 11.25 110430082
S4LV(X)P1000EB 10 230/3 8-4 11.25 110430082
S4LV(X)P1000FB 10 460/3 10-4 11.25 110430082
S4LV(X)P1000GB 10 575/3 10-4 11.25 110430082
S4LV(X)P1500DB 15 208/3 8-4 12 110430002
S4LV(X)P1500EB 15 230/3 8-4 12 110430002
S4LV(X)P1500FB 15 460/3 8-4 12 110430002
S4LV(X)P1500GB 15 575/3 10-4 12 110430002
870 RPM
S4LV(X)P500DA 5 208/3 8-4 11.5 110430012
S4LV(X)P500EA 5 230/3 10-4 11.5 110430012
S4LV(X)P500FA 5 460/3 10-4 11.5 110430012
S4LV(X)P500GA 5 575/3 10-4 11.5 110430012
S4LV(X)P750DA 7.5 208/3 8-4 12 110430002
S4LV(X)P750EA 7.5 230/3 8-4 12 110430002
S4LV(X)P750FA 7.5 460/3 10-4 12 110430002
S4LV(X)P750GA 7.5 575/3 10-4 12 110430002
250 FRAME PUMPS IMPELLER PARTS LIST
H4Q(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
H4Q(X)P2000DC 20 208/3 6-4 9 151510062
H4Q(X)P2000EC 20 230/3 6-4 9 151510062
H4Q(X)P2000FC 20 460/3 8-4 9 151510062
H4Q(X)P2000GC 20 575/3 8-4 9 151510062
H4Q(X)P2500DC 25 208/3 4-4 10 151510042
H4Q(X)P2500EC 25 230/3 6-4 10 151510042
H4Q(X)P2500FC 25 460/3 8-4 10 151510042
H4Q(X)P2500GC 25 575/3 8-4 10 151510042
H4Q(X)P3000EC 30 230/3 4-4 11 151510022
H4Q(X)P3000FC 30 460/3 8-4 11 151510022
H4Q(X)P3000GC 30 575/3 8-4 11 151510022
H4Q(X)P4000FC 40 460/3 6-4 12 151510012
H4Q(X)P4000GC 40 575/3 8-4 12 151510012
S4K(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4K(X)P2000DC 20 208/3 6-4 9.25 137200122
S4K(X)P2000EC 20 230/3 6-4 9.25 137200122
S4K(X)P2000FC 20 460/3 8-4 9.25 137200122
S4K(X)P2000GC 20 575/3 8-4 9.25 137200122
S4K(X)P2500DC 25 208/3 4-4 10.5 137200072
S4K(X)P2500EC 25 230/3 6-4 10.5 137200072
S4K(X)P2500FC 25 460/3 8-4 10.5 137200072
S4K(X)P2500GC 25 575/3 8-4 10.5 137200072
S4K(X)P3000EC 30 230/3 4-4 11 137200052
S4K(X)P3000FC 30 460/3 8-4 11 137200052
S4K(X)P3000GC 30 575/3 8-4 11 137200052
S4K(X)P4000FC 40 460/3 6-4 12 137200012
S4K(X)P4000GC 40 575/3 8-4 12 137200012

12 E-03-558 (08-01-21)
MOTOR PARTS GROUP
S4L(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4L(X)P2000DC 20 208/3 6-4 9.88 025940372
S4L(X)P2000EC 20 230/3 6-4 9.88 025940372
S4L(X)P2000FC 20 460/3 8-4 9.88 025940372
S4L(X)P2000GC 20 575/3 8-4 9.88 025940372
S4L(X)P2500DC 25 208/3 4-4 10 025940062
S4L(X)P2500EC 25 230/3 6-4 10 025940062
S4L(X)P2500FC 25 460/3 8-4 10 025940062
S4L(X)P2500GC 25 575/3 8-4 10 025940062
S4L(X)P3000EC 30 230/3 4-4 10.5 025940082
S4L(X)P3000FC 30 460/3 8-4 10.5 025940082
S4L(X)P3000GC 30 575/3 8-4 10.5 025940082
S4L(X)P4000FC 40 460/3 6-4 11.38 025940202
S4L(X)P4000GC 40 575/3 8-4 11.38 025940202
1150 RPM
S4L(X)P750DB 7.5 208/3 8-4 10.38 025940162
S4L(X)P750EB 7.5 230/3 8-4 10.38 025940162
S4L(X)P750FB 7.5 460/3 10-4 10.38 025940162
S4L(X)P750GB 7.5 575/3 10-4 10.38 025940162
S4L(X)P1000DB 10 208/3 8-4 11 025940102
S4L(X)P1000EB 10 230/3 8-4 11 025940102
S4L(X)P1000FB 10 460/3 10-4 11 025940102
S4L(X)P1000GB 10 575/3 10-4 11 025940102
S4L(X)P1500DB 15 208/3 8-4 11.88 025940002
S4L(X)P1500EB 15 230/3 8-4 11.88 025940002
S4L(X)P1500FB 15 460/3 8-4 11.88 025940002
S4L(X)P1500GB 15 575/3 10-4 11.88 025940002
870 RPM
S4L(X)P500DA 5 208/3 8-4 11.63 025940182
S4L(X)P500EA 5 230/3 10-4 11.63 025940182
S4L(X)P500FA 5 460/3 10-4 11.63 025940182
S4L(X)P500GA 5 575/3 10-4 11.63 025940182
S4L(X)P750DA 7.5 208/3 8-4 11.88 025940002
S4L(X)P750EA 7.5 230/3 8-4 11.88 025940002
S4L(X)P750FA 7.5 460/3 10-4 11.88 025940002
S4L(X)P750GA 7.5 575/3 10-4 11.88 025940002
S6L(X)P
Cat. No. HP Volt/Ph Cord Trim Impeller
1750 RPM
S6L(X)P2000DC 20 208/3 6-4 9.88 025940372
S6L(X)P2000EC 20 230/3 6-4 9.88 025940372
S6L(X)P2000FC 20 460/3 8-4 9.88 025940372
S6L(X)P2000GC 20 575/3 8-4 9.88 025940372
S6L(X)P2500DC 25 208/3 4-4 10.25 025940072
S6L(X)P2500EC 25 230/3 6-4 10.25 025940072
S6L(X)P2500FC 25 460/3 8-4 10.25 025940072
S6L(X)P2500GC 25 575/3 8-4 10.25 025940072
S6L(X)P3000EC 30 230/3 4-4 10.5 025940082
S6L(X)P3000FC 30 460/3 8-4 10.5 025940082
S6L(X)P3000GC 30 575/3 8-4 10.5 025940082
S6L(X)P4000FC 40 460/3 6-4 11.88 025940002
S6L(X)P4000GC 40 575/3 8-4 11.88 025940002
1150 RPM
S6L(X)P750DB 7.5 208/3 8-4 10.38 025940162
S6L(X)P750EB 7.5 230/3 8-4 10.38 025940162
S6L(X)P750FB 7.5 460/3 10-4 10.38 025940162
S6L(X)P750GB 7.5 575/3 10-4 10.38 025940162
S6L(X)P1000DB 10 208/3 8-4 11 025940102
S6L(X)P1000EB 10 230/3 8-4 11 025940102
S6L(X)P1000FB 10 460/3 10-4 11 025940102
S6L(X)P1000GB 10 575/3 10-4 11 025940102
S6L(X)P1500DB 15 208/3 8-4 11.88 025940002
S6L(X)P1500EB 15 230/3 8-4 11.88 025940002
S6L(X)P1500FB 15 460/3 8-4 11.88 025940002
S6L(X)P1500GB 15 575/3 10-4 11.88 025940002
870 RPM
S6L(X)P500DA 5 208/3 8-4 11.5 025940122
S6L(X)P500EA 5 230/3 10-4 11.5 025940122
S6L(X)P500FA 5 460/3 10-4 11.5 025940122
S6L(X)P500GA 5 575/3 10-4 11.5 025940122
S6L(X)P750DA 7.5 208/3 8-4 11.88 025940002
S6L(X)P750EA 7.5 230/3 8-4 11.88 025940002
S6L(X)P750FA 7.5 460/3 10-4 11.88 025940002
S6L(X)P750GA 7.5 575/3 10-4 11.88 025940002
250 FRAME PUMPS IMPELLER PARTS LIST

13
E-03-558 (08-01-21)
IMPELLER PARTS LIST
S6A(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S6A(X)P2500DC 25 208/3 4-4 9 136940132
S6A(X)P2500EC 25 230/3 6-4 9 136940132
S6A(X)P2500FC 25 460/3 8-4 9 136940132
S6A(X)P2500GC 25 575/3 8-4 9 136940132
S6A(X)P3000EC 30 230/3 4-4 9.5 136940112
S6A(X)P3000FC 30 460/3 8-4 9.5 136940112
S6A(X)P3000GC 30 575/3 8-4 9.5 136940112
S6A(X)P4000FC 40 460/3 6-4 10.5 136940072
S6A(X)P4000GC 40 575/3 8-4 10.5 136940072
1150 RPM
S6A(X)P750DB 7.5 208/3 8-4 9 136940132
S6A(X)P750EB 7.5 230/3 8-4 9 136940132
S6A(X)P750FB 7.5 460/3 10-4 9 136940132
S6A(X)P750GB 7.5 575/3 10-4 9 136940132
S6A(X)P1000DB 10 208/3 8-4 10 136940102
S6A(X)P1000EB 10 230/3 8-4 10 136940102
S6A(X)P1000FB 10 460/3 10-4 10 136940102
S6A(X)P1000GB 10 575/3 10-4 10 136940102
S6A(X)P1500DB 15 208/3 8-4 11 136940052
S6A(X)P1500EB 15 230/3 8-4 11 136940052
S6A(X)P1500FB 15 460/3 8-4 11 136940052
S6A(X)P1500GB 15 575/3 10-4 11 136940052
870 RPM
S6A(X)P500DA 5 208/3 8-4 9.5 136940112
S6A(X)P500EA 5 230/3 10-4 9.5 136940112
S6A(X)P500FA 5 460/3 10-4 9.5 136940112
S6A(X)P500GA 5 575/3 10-4 9.5 136940112
S6A(X)P750DA 7.5 208/3 8-4 10 136940102
S6A(X)P750EA 7.5 230/3 8-4 10 136940102
S6A(X)P750FA 7.5 460/3 10-4 10 136940102
S6A(X)P750GA 7.5 575/3 10-4 10 136940102
S8F(X)P
Cat. No. HP Volt/Ph Cord Trim Impeller
1750 RPM
S8F(X)P2000DC 20 208/3 6-4 9.63 025940302
S8F(X)P2000EC 20 230/3 6-4 9.63 025940302
S8F(X)P2000FC 20 460/3 8-4 9.63 025940302
S8F(X)P2000GC 20 575/3 8-4 9.63 025940302
S8F(X)P2500DC 25 208/3 4-4 10.13 025940172
S8F(X)P2500EC 25 230/3 6-4 10.13 025940172
S8F(X)P2500FC 25 460/3 8-4 10.13 025940172
S8F(X)P2500GC 25 575/3 8-4 10.13 025940172
S8F(X)P3000EC 30 230/3 4-4 10.5 025940082
S8F(X)P3000FC 30 460/3 8-4 10.5 025940082
S8F(X)P3000GC 30 575/3 8-4 10.5 025940082
S8F(X)P4000FC 40 460/3 6-4 11.38 025940202
S8F(X)P4000GC 40 575/3 8-4 11.38 025940202
1150 RPM
S8F(X)P750DB 7.5 208/3 8-4 10.38 025940162
S8F(X)P750EB 7.5 230/3 8-4 10.38 025940162
S8F(X)P750FB 7.5 460/3 10-4 10.38 025940162
S8F(X)P750GB 7.5 575/3 10-4 10.38 025940162
S8F(X)P1000DB 10 208/3 8-4 10.88 025940272
S8F(X)P1000EB 10 230/3 8-4 10.88 025940272
S8F(X)P1000FB 10 460/3 10-4 10.88 025940272
S8F(X)P1000GB 10 575/3 10-4 10.88 025940272
S8F(X)P1500DB 15 208/3 8-4 11.5 025940122
S8F(X)P1500EB 15 230/3 8-4 11.5 025940122
S8F(X)P1500FB 15 460/3 8-4 11.5 025940122
S8F(X)P1500GB 15 575/3 10-4 11.5 025940122
870 RPM
S8F(X)P500DA 5 208/3 8-4 11.25 025940112
S8F(X)P500EA 5 230/3 10-4 11.25 025940112
S8F(X)P500FA 5 460/3 10-4 11.25 025940112
S8F(X)P500GA 5 575/3 10-4 11.25 025940112
S8F(X)P750DA 7.5 208/3 8-4 11.88 025940002
S8F(X)P750EA 7.5 230/3 8-4 11.88 025940002
S8F(X)P750FA 7.5 460/3 10-4 11.88 025940002
S8F(X)P750GA 7.5 575/3 10-4 11.88 025940002
C4H(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
C4H(X)P2000DC 20 208/3 6-4 9 153590232
C4H(X)P2000EC 20 230/3 6-4 9 153590232
C4H(X)P2000FC 20 460/3 8-4 9 153590232
C4H(X)P2000GC 20 575/3 8-4 9 153590232
C4H(X)P2000DC 25 208/3 4-4 9.5 153590192
C4H(X)P2000EC 25 230/3 6-4 9.5 153590192
C4H(X)P2000FC 25 460/3 8-4 9.5 153590192
C4H(X)P2000GC 25 575/3 8-4 9.5 153590192
C4H(X)P2000EC 30 230/3 4-4 10.5 153590112
C4H(X)P2000FC 30 460/3 8-4 10.5 153590112
C4H(X)P2000GC 30 575/3 8-4 10.5 153590112
C4H(X)P2000FC 40 460/3 6-4 11.88 153590002
C4H(X)P2000GC 40 575/3 8-4 11.88 153590002
250 FRAME PUMPS IMPELLER PARTS LIST

14 E-03-558 (08-01-21)
S4L(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4L(X)P5000FC 50 460/3 4-4 11.63 025940002
S4L(X)P5000GC 50 575/3 6-4 11.63 025940002
1150 RPM
S4L(X)P2000DB 20 208/3 6-4 12 025940352
S4L(X)P2000EB 20 230/3 6-4 12 025940352
S4L(X)P2000FB 20 460/3 8-4 12 025940352
S4L(X)P2000GB 20 575/3 8-4 12 025940352
S6L(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S6L(X)P5000FC 50 460/3 4-4 11.88 025940002
S6L(X)P5000GC 50 575/3 6-4 11.88 025940002
1150 RPM
S6L(X)P2000DB 20 208/3 6-4 12 025940352
S6L(X)P2000EB 20 230/3 6-4 12 025940352
S6L(X)P2000FB 20 460/3 8-4 12 025940352
S6L(X)P2000GB 20 575/3 8-4 12 025940352
S8F(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S8F(X)P5000FC 50 460/3 4-4 11.88 025940002
S8F(X)P5000GC 50 575/3 6-4 11.88 025940002
S4B(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4B(X)P5000FC 50 460/3 4-4 12 136920012
S4B(X)P5000GC 50 575/3 6-4 12 136920012
1150 RPM
S4B(X)P2000DB 20 208/3 8-4 12 136920012
S4B(X)P2000EB 20 230/3 8-4 12 136920012
S4B(X)P2000FB 20 460/3 8-4 12 136920012
S4B(X)P2000GB 20 575/3 10-4 12 136920012
870 RPM
S4B(X)P1000DA 10 208/3 8-4 12 136920012
S4B(X)P1000EA 10 230/3 8-4 12 136920012
S4B(X)P1000FA 10 460/3 10-4 12 136920012
S4B(X)P1000GA 10 575/3 10-4 12 136920012
S4LV(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S4LV(X)P5000FC 50 460/3 4-4 12 110430002
S4LV(X)P5000GC 50 575/3 6-4 12 110430002
S6A(X)P
CAT. NO. HP VOLT/PH CORD TRIM IMPELLER
1750 RPM
S6A(X)P5000FC 50 460/3 4-4 11 136940052
S6A(X)P5000GC 50 575/3 6-4 11 136940052
1150 RPM
S6A(X)P2000DB 20 208/3 6-4 11 136940052
S6A(X)P2000EB 20 230/3 6-4 11 136940052
S6A(X)P2000FB 20 460/3 8-4 11 136940052
S6A(X)P2000GB 20 575/3 8-4 11 136940052
S6A(X)P2500DB 25 208/3 4-4 12 136940012
S6A(X)P2500EB 25 230/3 6-4 12 136940012
S6A(X)P2500FB 25 460/3 8-4 12 136940012
S6A(X)P2500GB 25 575/3 8-4 12 136940012
870 RPM
S6A(X)P1000DA 10 208/3 8-4 10 136940102
S6A(X)P1000EA 10 230/3 8-4 10 136940102
S6A(X)P1000FA 10 460/3 10-4 10 136940102
S6A(X)P1000GA 10 575/3 10-4 10 136940102
S6A(X)P1500DA 15 208/3 8-4 11 136940052
S6A(X)P1500EA 15 230/3 8-4 11 136940052
S6A(X)P1500FA 15 460/3 8-4 11 136940052
S6A(X)P1500GA 15 575/3 10-4 11 136940052
280 FRAME PUMPS IMPELLER PARTS LIST - DISCONTINUED, FOR REFERENCE ONLY
IMPELLER PARTS LIST

15
E-03-558 (08-01-21)
WIRING DIAGRAM

All indicated Pentair trademarks and logos are property of Pentair. Third party registered and unregistered trademarks and logos are the property of their respective owners. Because
we are continuously improving our products and services, Pentair reserves the right to change specications without prior notice. Pentair is an equal opportunity employer.
©2020 Pentair. All Rights Reserved. E-03-558 (08-01-21)
Pentair Hydromatic® warrants its products against defects in material and workmanship for a period of 12 months from installation
date or 18 months from manufacturing date, whichever occurs first – provided that such products are used in compliance with the
requirements of the Pentair Hydromatic catalog and technical manuals for use in pumping raw sewage, municipal wastewater or
similar, abrasive-free, noncorrosive liquids.
During the warranty period and subject to the conditions set forth, Pentair Hydromatic, at its discretion, will repair or replace to
the original user, the parts that prove defective in materials and workmanship. Pentair Hydromatic reserves the right to change or
improve its products or any portions thereof without being obligated to provide such a change or im-provement for prior sold and/or
shipped units.
Start-up reports and electrical schematics may be required to support warranty claims. Submit at the time of start up through the
Pentair Hydromatic website: http://forms.pentairliterature.com/startupform/startupform.asp? type=h. Warranty is effective only
if Pentair Hydromatic authorized control panels are used. All seal fail and heat sensing devices must be hooked up, functional and
monitored or this warranty will be void. Pentair Hydromatic will cover only the lower seal and labor thereof for all dual seal pumps.
Under no circumstance will Pentair Hydromatic be responsible for the cost of field labor, travel expenses, rented equipment, removal/
reinstallation costs or freight expenses to and from the factory or an authorized Pentair Hydromatic service facility.
This limited warranty will not apply: (a) to defects or malfunctions resulting from failure to properly install, operate or main-tain the
unit in accordance with the printed instructions provided; (b) to failures resulting from abuse, accident or negli-gence; (c) to normal
maintenance services and parts used in connection with such service; (d) to units that are not installed in accordance with applicable
local codes, ordinances and good trade practices; (e) if the unit is moved from its original installation location; (f) if unit is used for
purposes other than for what it is designed and manufactured; (g) to any unit that has been repaired or altered by anyone other than
Pentair Hydromatic or an authorized Pentair Hydromatic service provid-er; (h) to any unit that has been repaired using non factory
specified/OEM parts.
Warranty Exclusions: PENTAIR HYDROMATIC MAKES NO EXPRESS OR IMPLIED WARRANTIES THAT EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF. PENTAIR HYDROMATIC SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE.
Liability Limitation: IN NO EVENT SHALL PENTAIR HYDROMATIC BE LIABLE OR RESPONSIBLE FOR CONSEQUENTIAL, IN-CIDENTAL
OR SPECIAL DAMAGES RESULTING FROM OR RELATED IN ANY MANNER TO ANY PENTAIR HYDROMATIC PROD-UCT OR PARTS
THEREOF. PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY RESULT FROM IMPROPER INSTALLATION. PENTAIR HYDROMATIC
DISCLAIMS ALL
LIABILITY, INCLUDING LIABILITY UNDER THIS WARRANTY, FOR IMPROPER INSTALLATION. PENTAIR HYDROMATIC RECOM-MENDS
INSTALLATION BY PROFESSIONALS.
Some states do not permit some or all of the above warranty limitations or the exclusion or limitation of incidental or consequential
damages and therefore such limitations may not apply to you. No warranties or representations at any time made by any
representatives of Pentair Hydromatic shall vary or expand the provision hereof.
WARRANTY
AMERICAS
740 East 9th Street
Ashland, Ohio
44805
USA
Ph: 855.274.8947
CANADA
490 Pinebush Road,
Unit 4
Cambridge, Ontario,
Canada N1T 0A5
PH: 800-363-7867
pentair.com
