INSTALLATION AND
OPERATION MANUAL
SUBMERSIBLE SOLIDS HANDLING PUMPS
MODELS 4VC(X*), 6VC(X*), 4VE(X*) AND 4RC(X*)
*Used in Hazardous Locations Class I, Division 1, Groups C & D
For use with product built with USEM motor
MYERS

TABLE OF CONTENTS
Safety Information ................................................................................................................................................................................... 3
Installation and Operation ........................................................................................................................................................................ 4
Wiring Diagrams ....................................................................................................................................................................................... 6
Repair Parts Index .................................................................................................................................................................................... 9
Troubleshooting ......................................................................................................................................................................................15
Warranty..................................................................................................................................................................................................16
NOTE! To the installer: Please make sure you provide this manual to the owner of the equipment or to the responsible party who maintains the system.

3
Part # 23833A627 (09-01-21)
READ AND FOLLOW SAFETY INSTRUCTIONS!
This is the safety alert symbol. When you see this symbol
on your pump or in this manual, look for one of the following
signal words and be alert to the potential for personal injury.
DANGER
warns about hazards that will cause serious
personal injury, death or major property damage if ignored.
warns about hazards that can cause serious
personal injury, death or major property damage if ignored.
warns about hazards that will or can cause minor
personal injury or property damage if ignored.
NOTE: indicates special instructions which are important but
not related to hazards.
CALIFORNIA PROPOSITION 65 WARNING
This product and related accessories contain
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
GENERAL SAFETY
 Most accidents can be avoided by using common sense.
 Read the operation and maintenance instruction manual
supplied with the pump.
 Do not wear loose clothing that can become entangled in
the impeller or other moving parts.
 This pump is designed to handle materials that could cause
illness or disease through direct exposure.
 Wear adequate protective clothing when working on the
pump or piping.
ELECTRICAL SAFETY
 To reduce the risk of electrical shock, pump must be
properly grounded in accordance with the National
Electric Code and all applicable state and local codes and
ordinances.
 To reduce risk of electrical shock, disconnect the pump
from the power source before handling or servicing.
 Any wiring to be done on pumps should be done by a
qualified electrician.
 Never operate a pump with a power cord that has frayed or
brittle insulation.
 Never let cords or plugs lie in water.
 Never handle connected power cords with wet hands.
PUMPS
 Pump builds up heat and pressure during operation; allow
time for pump to cool before handling or servicing.
 Only qualified personnel should install, operate or repair
pump.
 Keep clear of suction and discharge openings. Do not
insert fingers in pump with power connected.
 Do not pump hazardous material not recommended for
pump (flammable, caustic, etc.).
 Make sure lifting handles are securely fastened each time
before lifting.
 Do not lift pump by the power cord.
 Do not exceed manufacturer's recommendation for
maximum performance, as this could cause the motor to
overheat.
 Secure the pump in its operating position so it cannot tip
over, fall or slide.
 Keep hands and feet away from impeller when power is
connected.
 Submersible solids handling pumps are not approved for
use in swimming pools, recreational water installations,
decorative fountains or any installation where human
contact with the pumped fluid is common.
 Do not operate pump without safety devices in place.
IMPORTANT! Myers is not responsible for losses, injury or death
resulting from a failure to observe these safety precautions,
misuse or abuse of pumps or equipment.
SAFETY INFORMATION

4Part # 23833A627 (09-01-21)
PUMP MODELS
These instructions cover the installation and service of the
Myers pumps as listed on the front cover. The hazardous
location models are Factory Mutual approved and listed
hazardous location for hazardous sewage locations Class 1,
Division 1, Groups C & D.
MOTOR HP AND VOLTAGES
These pumps are offered in a three phase wiring configuration
only. Voltages will vary according to the application.
ELECTRICAL CONTROLS
All of these pump models must be used with a control panel.
Myers built control panels are designed to supply the correct
electrical controls, motor starting equipment and include the
circuitry for moisture and heat sensors. It is recommended that
a Myers built control panel be used so that all warranties apply.
GENERAL CONSTRUCTION
The motor construction is designed to meet Factory Mutual’s
requirements for Class 1, Division 1, Groups C & D sewage
applications. The hazardous location models are certified and
nameplated with this approval. The motor chamber and seal
chamber are filled with a high dielectric type oil for improved
lubrication and heat transfer of the bearings and motor. Since
the bearings have been designed for 50,000 hours of life, the
oil should never require replacement under normal operating
conditions. An air space above the oil level in both the seal
and motor chambers is provided to allow for the expansion of
the oil when at operating temperature. The power and control
lines are sealed and strain relieved by a grommet in the cord
cap, and internally through the use of a dielectric potting resin
surrounding the electrical wires. All of the pump fasteners and
shafts are made from corrosion resistant stainless steel, while
the pump castings are made of ASTM A-48 Class 30 cast iron.
The wear ring is brass and all impellers are two vane enclosed
solids handling design made from ductile iron.
GENERAL INSTALLATION
Various configurations and methods of plumbing this series
of solids handling pumps may be used; however, for ease
of installation and service a Myers 4" rail lift-out system is
recommended.
Note: If the hazardous location pumps are used in conjunction
with a rail lift-out system, it must be an F.M. approved
nonsparking, hazardous location system. The Myers approved
lift-out models are:
4" Liftout 6" Liftout
SRAX44HH SRAX66
If these guidelines are not followed, the Factory Mutual approval
is void.
HAZARDOUS LOCATION SERVICE
These pumps are to be used for handling sewage, wastewater
and storm water only. Do not use in other hazardous locations.
These motors must be repaired and serviced only at Myers
Authorized Service Centers or at the Myers factory. Any
unauthorized field repair voids the warranty, the hazardous
location rating, and Factory Mutual approval.
After the pump is installed and sewage has entered
the basin there are methane and hydrogen sulfide gases, which
are poisonous. Never enter a wet well unless the cover is open
for a sufficient period of time to allow fresh air into the basin.
Myers recommends using the rail lift-out system so that no
service is required inside the basin.
OIL FILLED MOTOR
The motor chamber and seal chamber are dielectric oil-filled
for good heat transfer and lubrication of bearings and seals.
The motor requires no other lubrication. Oil level in the motor
housing should be to the bottom of the oil fill plug with the pump
in a vertical position, ensuring the upper bearing is submerged
in oil. Do not overfill the motor housing since some space is
required for oil expansion. Oil level in the seal chamber should be
checked with the pump lying horizontally with the fill plug at the
top. The oil level should be approximately 3/4" from the outside
surface of the housing. Transformer oil should be used and may
be purchased from your Myers distributor.
Each motor is provided with heat sensor thermostats attached
directly to the motor windings. The thermostats open if the
motor windings see excessive heat and, in turn, open the motor
contactor in the control panel, breaking the power to the pump.
When the motor is stopped due to an overheated condition, it
will not start until the motor has cooled and the heat sensor
reset button is manually pushed on the front of the Myers control
panel. This circuitry is provided in the Myers control panel
designs.
The thermostats are set to open at a temperature of 302º F
(150ºC). The maximum contact rating is 18 amps at 115 VAC and
12 amps at 230 VAC. Motor winding insulation is good for Class F
(311ºF, 155ºC, or higher).
Note: Failure to use proper circuitry and to connect the motor
overheat protection in the control panel would negate all
warranties and Factory MutualApproval.
MOTOR SEAL FAILURE WARNING
The seal chamber is oil filled and provided with moisture sensing
probes to detect water leakage through the lower shaft seal.
The probes can also detect moisture present in the upper motor
housing.
INSTALLATION AND OPERATION

5
Part # 23833A627 (09-01-21)
The presence of water energizes a red seal leak warning light
at the control panel. This is a warning light only, and does not
stop the motor. It indicates a leak has occurred and the pump
must be repaired. Normally, this indicates the outboard seal
has leaked. Allowing the unit to operate after the warning could
cause upper seal leakage along with motor failure.
The resistance across the moisture seal (seal failure) probes
should be checked after a seal leak warning light has lit. This
can be done by disconnecting the red and orange control wires
from the control panel, and measuring the resistance with an
ohmmeter between the wires. If the measured values are below
specification, then the pump may have a lower seal failure and
require service.
On the Myers hazardous location control panels the seal leak
test switch tests the seal leak circuitry continuity. When pushed
the seal leak test bulb should light. If the test bulb does not light
it means either the wiring circuitry to the seal leak probes has
been broken or the bulb has burned out.
Note Myers built control panels supply the correct circuitry for
moisture and heat sensor connections. Failure to install the
correct circuitry with proper connection would negate warranty
and Factory Mutual Approval.
MOTOR POWER CORD, CONTROL CORD AND CORD CAP
ASSEMBLY
Each motor power cord has 4 conductors – white, black, red
and green. For a three phase motor the red, black and white
conductors connect to the three line leads, and the green is
connected to a good ground. Interchanging any two leads will
reverse the rotation of the motor.
Note: Rotation should be clockwise when observed from the top
of the pump. This can be checked by noting which direction the
pump torque is upon initial starting. A properly rotating pump
will torque counter- clockwise upon start.
The control cable has 5 conductors – black, white, red, orange
and green. White and black connect to the heat sensor
terminals in the control panels; red and orange connect to
the seal failure terminals in the control panel; and the green
connects to the ground in the control panel.
The cord cap is epoxy potted. The cord cap provides for a
sealed wire connection with terminals so that connections can
be made without breaking the motor seal. This allows the cord
cap, with cords, to be removed from the motor. An approved
hazardous location junction box is required for hazardous
locations.
Note: Each cable has a green ground wire and must be properly
grounded per the National Electric Code and local codes.
ELECTRICAL MOTOR CONTROLS
All electrical controls and motor equipment should be as
specified in these instructions. Consult factory for any
acceptable alternatives. For hazardous locations the controls
and control panel must be installed outside the hazardous area,
or approved hazardous location controls that are intrinsically
safe must be used.
JUNCTION BOX
If a junction box is used in a hazardous location, it must be a
hazardous location approved type with hazardous location cord
connectors. Wires from the junction box must pass through a
hazardous location seal connector.
LEVEL SENSING CONTROLS
Intrinsically safe type float controls are recommended for all
applications and required for hazardous location service. An
intrinsically safe control panel relay will limit the current and
voltage to the level controls. A Myers control panel can be
supplied with this type circuitry.
The float level controls maintain the basin sewage water level by
controlling pump turn-on and turn-offlevels.
1. The lower turn-off control should be set so that the pump
stops at approximately the top of the pump. Consult the
factory for any settings below thispoint.
2. The upper turn-on control should be set above the lower
turn-off control. The exact height between the controls is
determined by the number of pump starts desired and the
depth of the basin. A maximum of 10 starts per hour should
not beexceeded.
3. The override control is set at a specified height above the
upper turn-on control.
4. The alarm control is set about 6" to 12" above the override
control.
5. No control should be set above the inlet invert.
ELECTRICAL CONNECTIONS
All electrical wiring must be in accordance with local code and
only qualified electricians should make the installations. All
wires should be checked for shorts to ground with an ohmmeter
or megger after the connections are made. This is important, as
one grounded wire can cause failure of the pump, control panel
or personal injury.
INSTALLATION AND OPERATIONS

6Part # 23833A627 (09-01-21)
PUMP
The fluid end of the pump is field serviceable and can be
disassembled in case of wear, damage, plugging or outboard
seal failure. The following will describe the disassembly and
reassembly process.
DISASSEMBLY
1. With the pump located in a secure place, remove the bolts
fastening the seal housing to the volute. The motor and
impeller can now be removed as aunit.
2. Lay the unit down on its side. If the lower seal is to be
removed, it is recommended that the oil in the seal
chamber be drained. This can be done by removing the
lower seal chamber plug and draining the oil into a holding
container.
3. To remove the impeller, first remove the bolts from the
nose cone. The nose cone will pull off. Using a proper
wrench, the impeller retaining bolt and washer must
be removed. This may require a piece of wood placed
between the vanes to keep the impeller from rotating while
removing the bolt. Once the bolt has been removed, tap
lightly with a hammer around the outside diameter of the
impeller to loosen from tapered shaft and key.
The impeller is large and heavy and will need to
be supported.
4. If the lower seal needs to be removed, first remove the
compression spring that rides between the impeller and
the seal assembly. Next remove the compression ring
that surrounds the rubber bellows on the rotating portion
of the seal assembly. Again using screwdrivers, pry the
remaining portion of the rotating seal assembly off the
shaft. The ceramic stationary can be removed by placing
a screwdriver between the rubber and the ceramic face
and then prying, working around the entire diameter. Note,
these parts should be discarded and a new seal assembly
installed.
5. If the oil in the seal chamber was drained, examine the
contents to determine if the upper seal has been damaged.
Sign of grit or other abrasive material may indicate that the
upper seal has also been damaged. Pressurizing the motor
housing assembly between 7 and 10 psi and observing
any drop in pressure will indicate if the upper seal is
functioning properly.
Note: Upper seal repairs must be done at a Myers
Authorized Service Center or at the Myers factory. Any
unauthorized field repair voids warranty and the hazardous
location approval on the Factory Mutual listed pump.
6. The wear ring can be removed from the volute for repair or
replacement.
REASSEMBLY
1. Remove the ceramic portion of the new seal from the
package. Brush new dielectric oil around the rubber portion
of the stationary assembly and into the pocket in the seal
housing. Note, keep the oil off the seal face. Without
scratching the seal face, press the ceramic stationary
portion into the seal housing with a Myers® seal pusher.
With clean cloth, lightly wipe the face of the seal surface to
make sure it is dirt free. Remove the rotating portion of the
seal from the package and lubricate the inside diameter of
the rubber bellows and the outside diameter of the shaft.
Place the seal over the shaft (make sure the key is removed).
Evenly press on the body of the rotational assembly and slide
it down the shaft until the seal faces meet. Once the seal
assembly is in position, place the spring over the register on
the rotational portion of the seal.
2. Position the key into the seat of the shaft. Align the impeller
onto the shaft, making sure that the seal spring is registered
properly onto the back side of the impeller. Insert the bolt
and washer assembly into the shaft and tighten. Replace the
nose cone onto the impeller. The proper Loctite® should be
applied to the bolts. Install and tighten.
3. Fill the seal chamber with new dielectric oil. An air gap of
10–15% volume must be left for the expansion of the oil when
it is at operating temperature.
4. The wear ring can be aligned with the retaining holes and
tapped into place with a soft mallet. The proper Loctite®
should be applied to the bolts. Install and tighten.
5. The motor and impeller assembly can be installed into the
volute. Make sure that the impeller aligns properly with the
volute. Install the volute retaining bolts and tighten.
6. Air tends to trap in the pump case when water rises in the
sump or when the pump is lowered into the water after
service. To vent off this air, a small hole is drilled into the
volute casting. Be sure this vent hole is clean after any
service work on pump. Air venting is not a problem after
initialstart.
INSTALLATION AND OPERATIONS

7
Part # 23833A627 (09-01-21)
WIRING DIAGRAM
172839456
17
28
394
5
6
1 2 3
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STAT OR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STATOR
AB
00
230 VOLT – THREE PHASE
1
7
2
6
5
4
8
3
9
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STATOR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STATOR
AB
00
460 VOLT – THREE PHASE
1
2
3
7
4
8
4
9
5
BLACK
BLACK
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STATOR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STAT OR
AB
00
200 or 575 VOLT – THREE PHASE
1
2
3
BLACK
BLACK
WIRING DIAGRAMS
172839456
17
28
394
5
6
1 2 3
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STAT OR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STATOR
AB
00
230 VOLT – THREE PHASE
1
7
2
6
5
4
8
3
9
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STATOR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STATOR
AB
00
460 VOLT – THREE PHASE
1
2
3
7
4
8
4
9
5
BLACK
BLACK
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STATOR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STAT OR
AB
00
200 or 575 VOLT – THREE PHASE
1
2
3
BLACK
BLACK
WIRING DIAGRAMS
17283945617
28
394
5
6
1 2 3
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STAT OR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STATOR
AB
00
230 VOLT – THREE PHASE
1
7
2
6
5
4
8
3
9
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STATOR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STATOR
AB
00
460 VOLT – THREE PHASE
1
2
3
7
4
8
4
9
5
BLACK
BLACK
POTTING
RESIN
CONTROL
CORD
TERMINAL
POSTS
POWER
CORD
ELECTRODE
HEAT SENSOR
ON STATOR
GROUND
SCREW
RED
RED
WHITE
BLACK
BLACK
BLACK
RED
WHITE
GREEN
GREEN
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
STAT OR
AB
00
200 or 575 VOLT – THREE PHASE
1
2
3
BLACK
BLACK
WIRING DIAGRAMS

8Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
CAP SCREW TORQUE VALUE
3/8-16 20 ft.-lbs.
1/2-13 43 ft.-lbs.
5/8-11 93 ft.-lbs.
3/4-10 "28 ft.-lbs.
7/8-14 193 ft.-lbs.
19
7
8
21
14
3
4
A1
20
9
15
1
16 11 10 26 12825
24
22
5
23
A3
17
A2
13
27
28
30
1829
12 6
2

9
Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
ITEM PART NO. DESCRIPTION QT Y.
1080730001 SEAL; SHAFT 2-1/4 2
205022A015 PLUG – PIPE ST GALV 1/2 1
305022A092 PLUG – PIPE ST GALV 1/4 HEX HD. 2
405030A214 WASHER – SUPPORT 1
505434A025 SCREW – MACH ST Z&D #6-32 2
6055830011 SCREW – MACH (PAN HD) 10-24 4
705876A135 O-RING 1
805876A136 O-RING 1
905876A137 O-RING 1
10 05876A138 O-RING 1
11 06106A028 SCREW – CAP CKT HD SST 8
12 06107A015 WASHER – LOCK 4
13 07597A017 SCREW – MACH FT HD 2
14 08565A027 BEARING – BALL (UPPER) 1
15 000650381 BEARING – BALL (LOWER) 1
16 12558A020 RING – RETAINING EXTERNAL 1
17 12558A024 RING – RETAINING EXTERNAL 1
18 19099A003 SCREW – CAP HEX 1/4 SST 1
19 19103A047 SCREW – CAP HEX SST 8
20 19103A049 SCREW – CAP HEX SST 8
21 000640061 WASHER – SPRING WAVE 2
22 22912A000 RESISTOR 1
23 22578A001 ELECTRODE 5-15 HP 2
24 25343A100 PROBE – SEAL LEAK 2
25 23604D010 HOUSING-SEAL UPPER – ORDINARY LOCATION 1
23604D010X HOUSING-SEAL UPPER – HAZARDOUS LOCATION 1
26 23610D100 HOUSING-SEAL LOWER – ORDINARY LOCATION 1
23610D100X HOUSING-SEAL LOWER – HAZARDOUS LOCATION 1
27 11904A005 1/4-20 SST LOCK NUT – 3450 RPM
11904A037 1/4-20 SST LOCK NUT – 870, 1150, 1750 RPM
28 19103A045 SCREW – CAP HEX SST 3/4, 4RC(X), 4VC(X), 6VC(X) 8
19103A062 SCREW – CAP HEX SST 3/4, 4VE(X) 8
29
23549D031 35' CORD ASSEMBLY 10-4 1
23549D032 35' CORD ASSEMBLY 8-4 SOOW 1
23549D039 35' CORD ASSEMBLY 8-4 W 1
23549D036 35' CORD ASSEMBLY 6-4 1
23549D037 35' CORD ASSEMBLY 4-4 1
23549D038 35' CORD ASSEMBLY 2-4 1
23549D631 35' HAZARDOUS LOCATION CORD ASSEMBLY 10-4 1
23549D632 35' HAZARDOUS LOCATION CORD ASSEMBLY 8-4 SOOW 1
23549D639 35' HAZARDOUS LOCATION CORD ASSEMBLY 8-4 W 1
23549D636 35' HAZARDOUS LOCATION CORD ASSEMBLY 6-4 1
23549D637 35' HAZARDOUS LOCATION CORD ASSEMBLY 4-4 1
23549D638 35' HAZARDOUS LOCATION CORD ASSEMBLY 2-4 1
30 23555A000 TERMINAL 1

10 Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
ITEM DESCRIPTION 20 HP
230/3/3450
20 HP
460/3/3450
20 HP
575/3/3450
25 HP
230/3/3450
25 HP
460/3/3450
25 HP
575/3/3450
30 HP
230/3/3450
30 HP
460/3/3450
A1 ROTOR; W/SHAFT – ORDINARY
LOCATION
26576D312 26576D312 26576D312 26576D312 26576D312 26576D312 26576D312 26576D312
ROTOR; W/SHAFT – HAZARDOUS
LOCATION
26576D312X 26576D312X 26576D312X 26576D312X 26576D312X 26576D312X 26576D312X 26576D312X
A2 HOUSING, BRG; UPPER 23557D011 23557D011 23557D010 23557D011 23557D011 23557D010 23557D011 23557D011
A3 HOUSING; & STATOR – HAZARDOUS
LOCATION
23558E724 23558E724 23558E725 23558E724 23558E724 23558E725 23558E724 23558E724
HOUSING; & STATOR – ORDINARY
LOCATION
23558E324 23558E324 23558E325 23558E324 23558E324 23558E325 23558E324 23558E324
ITEM DESCRIPTION 30 HP
575/3/3450
40 HP
460/3/3450
40 HP
575/3/3450
50 HP
460/3/3450
50 HP
575/3/3450
60 HP
460/3/3450
60 HP
575/3/3450
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D312 26576D313 26576D313 26576D313 26576D313 26576D313 26576D313
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D312X 26576D313X 26576D313X 26576D313X 26576D313X 26576D313X 26576D313X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D010 23557D011 23557D010 23557D011 23557D010
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E725 23558E726 23558E727 23558E726 23558E727 23558E726 23558E727
HOUSING; & STATOR – ORDINARY LOCATION 23558E325 23558E326 23558E327 23558E326 23558E327 23558E326 23558E327
3450 RPM
ITEM DESCRIPTION 15 HP
200/3/1750
15 HP
230/3/1750
15 HP
460/3/1750
15 HP
575/3/1750
20 HP
200/3/1750
20 HP
230/3/1750
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D307 26576D307 26576D307 26576D307 26576D307 26576D307
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D307X 26576D307X 26576D307X 26576D307X 26576D307X 26576D307X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D011 23557D010 23557D010 23557D011
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E755 23558E758 23558E758 23558E759 23558E755 23558E758
HOUSING; & STATOR – ORDINARY LOCATION 23558E355 23558E358 23558E358 23558E359 23558E355 23558E358
ITEM DESCRIPTION 20 HP
460/3/1750
20 HP
575/3/1750
25 HP
200/3/1750
25 HP
230/3/1750
25 HP
460/3/1750
25 HP
575/3/1750
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D307 26576D307 26576D310 26576D310 26576D310 26576D310
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D307X 26576D307X 26576D310X 26576D310X 26576D310X 26576D310X
A2 HOUSING, BRG; UPPER 23557D011 23557D010 23557D010 23557D011 23557D011 23557D010
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E758 23558E759 23558E790 23558E762 23558E762 23558E763
HOUSING; & STATOR – ORDINARY LOCATION 23558E358 23558E359 23558E390 23558E362 23558E362 23558E363
1750 RPM

11
Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
1750 RPM
ITEM DESCRIPTION 30 HP
200/3/1750
30 HP
230/3/1750
30 HP
460/3/1750
30 HP
575/3/1750
40 HP
230/3/1750
40 HP
460/3/1750
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D310 26576D310 26576D310 26576D310 26576D310 26576D310
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D310X 26576D310X 26576D310X 26576D310X 26576D310X 26576D310X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D011 23557D010 23557D011 23557D011
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E790 23558E762 23558E762 23558E763 23558E764 23558E764
HOUSING; & STATOR – ORDINARY LOCATION 23558E390 23558E362 23558E362 23558E363 23558E364 23558E364
ITEM DESCRIPTION 40 HP
575/3/1750
50 HP
230/3/1750
50 HP
460/3/1750
50 HP
575/3/1750
60 HP
460/3/1750
60 HP
575/3/1750
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D310 26576D310 26576D310 26576D310 26576D310 26576D310
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D310X 26576D310X 26576D310X 26576D310X 26576D310X 26576D310X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D011 23557D010 23557D011 23557D010
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E765 23558E766 23558E766 23558E767 23558E766 23558E767
HOUSING; & STATOR – ORDINARY LOCATION 23558E365 23558E366 23558E366 23558E367 23558E366 23558E367
ITEM DESCRIPTION 5 HP
200/3/1150
5 HP
230/3/1150
5 HP
460/3/1150
5 HP
575/3/1150
7.5 HP
200/3/1150
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D303 26576D303 26576D303 26576D303 26576D302
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D303X 26576D303X 26576D303X 26576D303X 26576D302X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D011 23557D010 23557D010
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E774 23558E775 23558E775 23558E776 23558E749
HOUSING; & STATOR – ORDINARY LOCATION 23558E374 23558E375 23558E375 23558E376 23558E349
Item Description 7.5 HP
230/3/1150
7.5 HP
460/3/1150
7.5 HP
575/3/1150
10 HP
200/3/1150
10 HP
230/3/1150
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D302 26576D302 26576D302 26576D306 26576D306
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D302X 26576D302X 26576D302X 26576D306X 26576D306X
A2 HOUSING, BRG; UPPER 23557D011 23557D011 23557D010 23557D010 23557D011
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E750 23558E750 23558E751 23558E749 23558E750
HOUSING; & STATOR – ORDINARY LOCATION 23558E350 23558E350 23558E351 23558E349 23558E350
1150 RPM

12 Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
Item Description 10 HP
460/3/1150
10 HP
575/3/1150
15 HP
200/3/1150
15 HP
230/3/1150
15 HP
460/3/1150
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D306 26576D306 26576D306 26576D306 26576D306
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D306X 26576D306X 26576D306X 26576D306X 26576D306X
A2 HOUSING, BRG; UPPER 23557D011 23557D010 23557D010 23557D011 23557D011
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E750 23558E751 23558E752 23558E753 23558E753
HOUSING; & STATOR – ORDINARY LOCATION 23558E350 23558E351 23558E352 23558E353 23558E353
Item Description 15 HP
575/3/1150
20 HP
200/3/1150
20 HP
230/3/1150
20 HP
460/3/1150
20 HP
575/3/1150
A1
ROTOR; W/SHAFT – ORDINARY LOCATION 26576D306 26576D306 26576D306 26576D306 26576D306
ROTOR; W/SHAFT – HAZARDOUS LOCATION 26576D306X 26576D306X 26576D306X 26576D306X 26576D306X
A2 HOUSING, BRG; UPPER 23557D010 23557D010 23557D011 23557D011 23557D010
A3
HOUSING; & STATOR – HAZARDOUS LOCATION 23558E754 23558E752 23558E753 23558E753 23558E754
HOUSING; & STATOR – ORDINARY LOCATION 23558E354 23558E352 23558E353 23558E353 23558E354
1150 RPM
ITEM DESCRIPTION 2 HP
200/3/870
2 HP
230/3/870
2 HP
460/3/870
2 HP
575/3/870
3 HP
200/3/870
3 HP
230/3/870
3 HP
460/3/870
3 HP
575/3/870
A1
ROTOR; W/SHAFT – ORDINARY
LOCATION 26576D300 26576D300 26576D300 26576D300 26576D300 26576D300 26576D300 26576D300
ROTOR; W/SHAFT – HAZARDOUS
LOCATION 26576D300X 26576D300X 26576D300X 26576D300X 26576D300X 26576D300X 26576D300X 26576D300X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D011 23557D010 23557D010 23557D011 23557D011 23557D010
A3
HOUSING; & STATOR – HAZARDOUS
LOCATION 23558E743 23558E744 23558E744 23558E745 23558E743 23558E744 23558E744 23558E745
HOUSING; & STATOR – ORDINARY
LOCATION 23558E343 23558E344 23558E344 23558E345 23558E343 23558E344 23558E344 23558E345
ITEM DESCRIPTION 5 HP
200/3/870
5 HP
230/3/870
5 HP
460/3/870
5 HP
575/3/870
7.5 HP
200/3/870
7.5 HP
230/3/870
7.5 HP
460/3/870
7.5 HP
575/3/870
A1
ROTOR; W/SHAFT – ORDINARY
LOCATION 26576D300 26576D300 26576D300 26576D300 26576D302 26576D302 26576D302 26576D302
ROTOR; W/SHAFT – HAZARDOUS
LOCATION 26576D300X 26576D300X 26576D300X 26576D300X 26576D302X 26576D302X 26576D302X 26576D302X
A2 HOUSING, BRG; UPPER 23557D010 23557D011 23557D011 23557D010 23557D010 23557D011 23557D011 23557D010
A3
HOUSING; & STATOR – HAZARDOUS
LOCATION 23558E743 23558E744 23558E744 23558E745 23558E771 23558E772 23558E772 23558E773
HOUSING; & STATOR – ORDINARY
LOCATION 23558E343 23558E344 23558E344 23558E345 23558E371 23558E372 23558E372 23558E373
870 RPM

13
Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
B1 B5 B4 B1 B5 B4
B7 B2 B3 B7
B3B2
B6 B1 B5 B4 B6 B1 B5 B4
B2 B3 B8 B7 B2 B3 B7
B4 B1
B1 B5 B4
B3
B2 B3
B2
4VC / 4VCX 6VC / 6VCX
B1 B5 B4 B1 B5 B4
B7 B2 B3 B7
B3B2
B6 B1 B5 B4
B6 B1 B5 B4
B2 B3 B8 B7
B2 B3 B7
B4 B1
B1 B5 B4
B3
B2 B3
B2
4VE / 4VEX
B1 B5 B4 B1 B5 B4
B7 B2 B3 B7
B3B2
B6 B1 B5 B4 B6 B1 B5 B4
B2 B3 B8 B7 B2 B3 B7
B4 B1
B1 B5 B4
B3
B2 B3
B2
4RC / 4RCX 3450 RPM
B1 B5 B4 B1 B5 B4
B7 B2 B3 B7
B3B2
B6 B1 B5 B4 B6 B1 B5 B4
B2 B3 B8 B7 B2 B3 B7
B4 B1
B1 B5 B4
B3
B2 B3
B2
4RC / 4RCX 1750 RPM and 1150 RPM
ITEM DESCRIPTION 4RC / 4RCX
3450 RPM
4RC / 4RCX
1150 / 1750 RPM 4VC / 4VCX 4VE / 4VEX 6VC / 6VCX
B1 KEY-SQ. SST 05818A087 05818A071 05818A071 05818A071 05818A071
B2 WASHER-RETAINER 23609A004 23609A004 23609A004 23609A004 23609A004
B3 SCREW-CAP HEX SST 1/2 19106A017 19106A017 19106A017 19106A017 19106A017
B4 CASE-VOLUTE 26606E000 107835002 23606F010 26889F000 23606F000
B5 GASKET 05863A021 - 05863A021 05863A021 (2) 05863A021
B6 PLATE-ADAPTER/SPACER - - - 26888D000 -
B7 RING-WEAR - - 23607B000 26889F010B 23607B000
B8 ADAPTER-WEAR RING - - - 26889F011C -

14 Part # 23833A627 (09-01-21)
REPAIR PARTS INDEX
PUMP RPM HP TRIM IMPELLER
4VC / 4VCX 1750 15 8.5 23608D548
4VC / 4VCX 1750 20 923608D544
4VC / 4VCX 1750 25 9.5 23608D540
4VC / 4VCX 1750 30 10 23608D536
4VC / 4VCX 1750 40 11 23608D528
4VC / 4VCX 1750 50 11.5 23608D524
4VC / 4VCX 1750 60 12 23608D520
4VC / 4VCX 1150 5 9 23608D544
4VC / 4VCX 1150 7.5 10 23608D536
4VC / 4VCX 1150 10 10.75 23608D530
4VC / 4VCX 1150 15 11.75 23608D522
4VC / 4VCX 1150 20 12 23608D520
4VC / 4VCX 870 2 8 23608D552
4VC / 4VCX 870 3 9 23608D544
4VC / 4VCX 870 511 23608D528
4VC / 4VCX 870 7.5 12 23608D520
4VE / 4VEX 1750 15 926899D212
4VE / 4VEX 1750 20 10 26899D208
4VE / 4VEX 1750 25 11 26899D204
4VE / 4VEX 1750 30 12 26899D200
6VC / 6VCX 1750 15 8.5 23608D548
6VC / 6VCX 1750 20 923608D544
6VC / 6VCX 1750 25 9.5 23608D540
6VC / 6VCX 1750 30 10 23608D536
6VC / 6VCX 1750 40 11 23608D528
6VC / 6VCX 1750 50 11.5 23608D524
6VC / 6VCX 1750 60 12 23608D520
6VC / 6VCX 1150 58.5 23608D548
6VC / 6VCX 1150 7.5 9.5 23608D540
6VC / 6VCX 1150 10 10 23608D536
6VC / 6VCX 1150 15 11.5 23608D524
6VC / 6VCX 1150 20 12 23608D520
6VC / 6VCX 870 28.5 23608D548
6VC / 6VCX 870 39.5 23608D540
6VC / 6VCX 870 510.5 23608D532
6VC / 6VCX 870 7.5 12 23608D520
4RC / 4RCX 3450 20 5.5 26605C524
4RC / 4RCX 3450 25 5.75 26605C522
4RC / 4RCX 3450 30 626605C520
4RC / 4RCX 3450 40 6.5 26605C516
4RC / 4RCX 3450 50 726605C512
4RC / 4RCX 3450 60 7.5 26605C508
4RC / 4RCX 1750 10 7.88 069585112
4RC / 4RCX 1750 15 7.88 069585112
4RC / 4RCX 1750 20 8.63 069585122
4RC / 4RCX 1750 25 9.25 069585132
4RC / 4RCX 1750 30 10.31 069585142
4RC / 4RCX 1750 40 11.5 069585012
4RC / 4RCX 1150 37.38 069585252
4RC / 4RCX 1150 58.63 069585122
4RC / 4RCX 1150 7.5 10 069585042
4RC / 4RCX 1150 10 11.25 069585192
Note: Standard non-overloading impeller diameters shown.

15
Part # 23833A627 (09-01-21)
CHECKING FOR MOISTURE IN MOTOR
Use an ohm - meter or a megger and set on highest scale.
Readings on the large power cord between any of the
conductors red, black or white to the green conductor or to
the motor housing should be greater than 1,000,000 ohms (1
megohm). Service work should be done only at an authorized
service facility. Note, readings should be taken with line leads
disconnected from the control panel.
RESISTANCE OF WINDINGS
Every motor winding has a fixed resistance. The windings must
check close to specification values. Verification of the proper
wiring of a dual voltage motor can also be checked by measuring
the motor winding resistance.
TROUBLESHOOTING
CONDITION PROBABLE CAUSE
Red light comes on at control box.
This indicates some water has leaked past the lower seal and has entered the seal chamber and
made contact with the electrode probe. Pump must be removed for replacement of lower seal.
This preventive repair will save
an expensive motor.
Overload trips at control box and alarm buzzer
or ashing red light comes on due to high water
level in basin.
1. Push in on red reset button to reset overload. If overload trips again after short run, pump
has some damage and must be removed from basin for checking.
2. Trouble may be from clogged impeller causing motor to overload or could be from failed
motor.
3. Trouble may be from faulty component in control box. Always check control box before
removing pump.
Yellow run light stays on continuously.
1. Indicates H-O-A switch may be in the hand position.
2. Level control switch may have failed causing pump to continue to operate when water is
below lower control.
3. Impeller may be partially clogged causing pump to operate at very reduced capacity.
4. Gate valve or check valve may be clogged causing low pump flow.
5. Pump may be air locked.
Circuit breaker trips.
1. Reset breaker by pushing completely down on handle then back to ON position. If breaker
trips again in a few seconds it indicates excessive load probably caused by a short in the
motor or control box. Check out instructions given with control box before pulling pump.
2. If this condition happens after an electrical storm, motor or control box may be damaged by
lightning.
3. Resistance reading of the motor with lead wires disconnected from the control box can
determine if trouble is in motor or control box.
Pump is noisy and pump rate is low.
1. Impeller may be partially clogged with some foreign objects causing noise and overload on
the motor.
2. Impeller may be rubbing on wear ring due to bent shaft or misalignment.
3. Pump may be operating too close to shut-off. Check head.
Grease and solids have accumulated around
pump and will not pump out of basin.
1. Lower control switch may be set too high.
2. Run pump on hand operation for several minutes with small amount of water running into
basin to clean out solids and grease. This allows pump to break suction and surge which will
break up the solids. If level switch is set properly this condition generally will not occur.
3. Trash and grease may have accumulated around floats causing pump to operate erratically.

WARRANTY
1101 MYERS PARKWAY 490 PINEBUSH ROAD, UNIT #4
ASHLAND, OHIO, USA 44805 CAMBRIDGE, ONTARIO, CANADA N1T 0A5
419-289-1144 800-363-PUMP
WWW.FEMYERS.COM
Warranty Rev. 12/13
STANDARD LIMITED WARRANTY
Pentair Myers
®
warrants its products against defects in material and workmanship for a period of 12 months from the
date of shipment from Pentair Myers or 18 months from the manufacturing date, whichever occurs first – provided
that such products are used in compliance with the requirements of the Pentair Myers catalog and technical manuals
for use in pumping raw sewage, municipal wastewater or similar, abrasive-free, noncorrosive liquids.
During the warranty period and subject to the conditions set forth, Pentair Myers, at its discretion, will repair or
replace to the original user, the parts that prove defective in materials and workmanship. Pentair Myers reserves the
right to change or improve its products or any portions thereof without being obligated to provide such a change or
improvement for prior sold and/or shipped units.
Start-up reports and electrical schematics may be required to support warranty claims. Submit at the time of start-
up through the Pentair Myers website: http://forms.pentairliterature.com/startupform/startupform.asp?type=m.
Warranty is effective only if Pentair Myers authorized control panels are used. All seal fail and heat sensing devices
must be hooked up, functional and monitored or this warranty will be void. Pentair Myers will cover only the lower
seal and labor thereof for all dual seal pumps. Under no circumstance will Pentair Myers be responsible for the cost
of field labor, travel expenses, rented equipment, removal/reinstallation costs or freight expenses to and from the
factory or an authorized Pentair Myers service facility.
This limited warranty will not apply: (a) to defects or malfunctions resulting from failure to properly install, operate or
maintain the unit in accordance with the printed instructions provided; (b) to failures resulting from abuse, accident
or negligence; (c) to normal maintenance services and parts used in connection with such service; (d) to units that
are not installed in accordance with applicable local codes, ordinances and good trade practices; (e) if the unit is
moved from its original installation location; (f) if unit is used for purposes other than for what it is designed and
manufactured; (g) to any unit that has been repaired or altered by anyone other than Pentair Myers or an authorized
Pentair Myers service provider; (h) to any unit that has been repaired using non factory specified/OEM parts.
Warranty Exclusions: PENTAIR MYERS MAKES NO EXPRESS OR IMPLIED WARRANTIES THAT EXTEND BEYOND
THE DESCRIPTION ON THE FACE HEREOF. PENTAIR MYERS SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE.
Liability Limitation: IN NO EVENT SHALL PENTAIR MYERS BE LIABLE OR RESPONSIBLE FOR CONSEQUENTIAL,
INCIDENTAL OR SPECIAL DAMAGES RESULTING FROM OR RELATED IN ANY MANNER TO ANY PENTAIR MYERS
PRODUCT OR PARTS THEREOF. PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY RESULT FROM IMPROPER
INSTALLATION. PENTAIR MYERS DISCLAIMS ALL LIABILITY, INCLUDING LIABILITY UNDER THIS WARRANTY, FOR
IMPROPER INSTALLATION. PENTAIR MYERS RECOMMENDS INSTALLATION BY PROFESSIONALS.
Some states do not permit some or all of the above warranty limitations or the exclusion or limitation of incidental or
consequential damages and therefore such limitations may not apply to you. No warranties or representations at any
time made by any representatives of Pentair Myers shall vary or expand the provision hereof.
MYERS
1101 Myers Parkway 490 Pinebush Road, Unit 4 www.pentair.com/pentair-myers
Ashland, Ohio, USA 44805 Cambridge, Ontario, Canada N1T 0A5
Ph: 419-289-1144 Ph: 800-363-PUMP
Warranty Rev. 12/13
All indicated Pentair trademarks and logos are property of Pentair. Third party registered and unregistered trademarks and logos are the property of their respective owners. Because we are
continuously improving our products and services, Pentair reserves the right to change specications without prior notice. Pentair is an equal opportunity employer.
©2021 Pentair. All Rights Reserved. Part # 23833A627 (09/01/2021)
1101 Myers Parkway
Ashland, Ohio 44805
USA
Ph: 855-274-8947
490 Pinebush Road
Unit 4
Cambridge, Ontario
N1t 0A5
Canada
Ph: 800.363.7867
pentair.com
