Pentair STA-RITE C Series User manual

OWNER’S MANUAL
Centrifugal Pumps
© 2013 Pentair, Ltd. All Rights Reserved. S150 (Rev. 02/04/13
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.STA-RITE.COM
PH: 888-782-7483
STARITE®
2791 0397
“C” and “CC” Series
Installation/Operation/Parts
For further operating, installation,
or maintenance assistance:
Call 1-888-782-7483

Safety 2
READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol. When you see this symbol on
your pump or in this manual, look for one of the following signal words
and be alert to the potential for
personal injury:
warns about hazards that will cause serious personal injury,
death or major property damage if ignored.
warns about hazards that can cause serious personal injury,
death or major property damage if ignored.
warns about hazards that will or can cause minor personal
injury or property damage if ignored.
The label NOTICE indicates special instructions which are important but
not related to hazards.
Carefully read and follow all safety instructions in this manual and
on pump.
Keep safety labels in good condition.
Replace missing or damaged safety labels.
Motor normally operates at high temperature and will be
too hot to touch. It is protected from heat damage during operation by
an automatic internal cutoff switch. Before handling pump or motor, stop
motor, and allow it to cool for 20 minutes.
California Proposition 65 Warning
This product and related accessories contain chemicals
known to the State of California to cause cancer, birth defects or other
reproductive harm.

Table of Contents 3
Page
General Safety....................................................................................................2
Warranty .............................................................................................................3
Installation........................................................................................................4-5
Maintenance ....................................................................................................5-7
Troubleshooting .................................................................................................8
Repair Parts ..................................................................................................9-11
Limited Warranty
STA-RITE warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be
free from defects in material and workmanship for the Warranty Period shown below.
Product Warranty Period
Water Systems Products — jet pumps, small centrifugal pumps,
submersible pumps and related accessories
whichever occurs first:
12 months from date of original installation,
or 18 months from date of manufacture
Pro-Source®Composite Tanks 5 years from date of original installation
Pro-Source®Steel Pressure Tanks 5 years from date of original installation
Pro-Source®Epoxy-Lined Tanks 3 years from date of original installation
Sump/Sewage/Effluent Products 12 months from date of original installation, or
18 months from date of manufacture
Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication,
improper installation, or improper maintenance. Without limiting the foregoing, operating a three phase motor with single
phase power through a phase converter will void the warranty. Note also that three phase motors must be protected by three-
leg, ambient compensated, extra-quick trip overload relays of the recommended size or the warranty is void.
Your only remedy, and STA-RITE’s only duty, is that STA-RITE repair or replace defective products (at STA-RITE’s choice).
You must pay all labor and shipping charges associated with this warranty and must request warranty service through the
installing dealer as soon as a problem is discovered. No request for service will be accepted if received after the Warranty
Period has expired. This warranty is not transferable.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES
WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. THE FOREGOING WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION
EXPRESSLY PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of
an implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights
and You may also have other rights which vary from state to state.
This Limited Warranty is effective June 1, 2011 and replaces all undated warranties and warranties dated before June 1, 2011.
STA-RITE INDUSTRIES
293 Wright Street • Delavan, WI U.S.A. 53115
Phone: [phone] • Fax: [phone] • Web Site: sta-rite.com

Installation 4
SERIES C/CC CENTRIFUgAL PUmPS
The “C” and “CC” Series pumps are close coupled pumps with optional
traps. “CC” Series have cast iron volutes and adapters. “C” Series have
bronze volutes and adapters. Impellers on both series are bronze.
INSTALLATION
Location of Unit
Install pump as close to liquid source as possible, using short, simple
suction piping.
Piping should be as direct as possible; elbows and other fittings greatly
increase friction losses.
Allow service and maintenance access.
Mount on solid, rigid, vibration-free foundation.
Protect pump against flooding and excess moisture.
Piping
Pump is not self-priming. Unless liquid source level is above pump
suction at all times, install a foot valve on suction pipe.
Support both suction and discharge piping independently near the pump
to avoid placing strains on pump. Start all piping at pump to avoid strains
left by a gap at last connection.
If possible, increase size of both suction and discharge piping if more
than short runs are required.
NOTICE: Never use a suction pipe smaller than the suction connection of
the pump.
NOTICE: If a reducer is necessary in the suction piping, always use an
eccentric reducer with the straight side on top.
NOTICE: BE SURE suction does not leak. Suction pipe must slope
gradually upward to the pump. Avoid any fittings which might cause an air
trap.
Install gate valve and union in suction and discharge lines. If complete
pump removal is required for service, close gate valves and disconnect at
unions.
Grounding the Motor
Hazardous
voltage
Can shock, burn or cause death.
Ground motor before working
on pump or motor.
Install, ground, wire and maintain this pump in accordance with the
National Electrical Code, Article 250, or applicable local Codes and
Ordinances.
Ground the pump permanently using a wire of size and type specified
by National or Local Electrical Code.
Connect ground wire first. Connect to ground first, then to motor
terminal provide. Do not connect motor to electrical power supply until
unit is permanently grounded. Any other sequence may cause serious
shock hazard. Do not ground to a gas supply line.
The motor grounding wire need not be larger than the wires supplying the
motor, provided the supply wires conform to the wiring date included in
this manual (see Table I, Page 5).

Installation / Maintenance 5
Wiring
NOTICE: For 575 volt installations, see motor nameplate. Consult a
licensed electrician for wiring information. Installation must meet code.
For 200, 230, and 460 volt installations, check fusing/wiring data chart
(Table I, below) before connecting pump to power source.
Check that voltage/frequency on motor nameplate are identical with
voltage/frequency of incoming power supply.
NOTICE: Wire dual voltage motors correctly according to wiring diagram
on motor.
Check rotation of motor. Look through opening in adapter. Rotation
should be clockwise when viewed from the motor end. If not:
• TurnpumpOFFanddisconnectfrompowersource.
• Forthree-phasemotors,reverseanytwoleadstomotorstarter.
• Forsinglephasemotors,re-connectaccordingtowiringdiagramon
motor.
Priming the Pump
NOTICE: NEVER run pump dry. To run pump dry may damage seals.
To Prime:
1. If pump is installed below liquid source level, open gate valve in
suction line and flood suction.
2. If pump is not installed below liquid source level, fill pump through a
tee installed in pump discharge and fitted with a priming plug in the
upright position.
Tighten priming plug securely after priming!
IMPORTANT: BE SURE lead wire opening on end of
motor is fully sealed when conduit or a pressure switch
is not used. Failure to seal it properly will allow dirt, rain,
bugs, etc. to enter back compartment of motor through
conduit opening and cause switch malfunction.
TABLE I - RECOmmENDED FUSINg AND WIRINg DATA - 60 CYCLE mOTORS
* Time delay fuse or circuit breakers are recommended in any motor circuit.
DIAMETER IN FEET FROM MOTOR TO METER (METERS)
BRANCH 0’(0) 101’(31) 201’(62) 301’(92) 401’(123)
MAX. FUSE* TO TO TO TO TO
MOTOR LOAD RATING 100’(30) 200’(61) 300’(91) 400’(122) 500’(152)
HP PHASE VOLTS AMPS AMPS WIRE SIZE
3 1 230 17.0 25 10 (5.5) 10 (5.5) 10 (5.5) 8 (8.4) 8 (8.4)
3 3 200 11.0 15 14 (2) 14 (2) 12 (3) 10 (5.5) 10 (5.5)
3 3 230 9.6 15 14 (2) 14 (2) 12 (3) 12 (3) 10 (5.5)
3 3 460 4.8 15 14 (2) 14 (2) 14 (2) 14 (2) 14 (2)
5 1 230 28.0 40 8 (8.4) 8 (8.4) 8 (8.4) 6 (14) 6 (14)
5 3 200 17.5 25 10 (5.5) 10 (5.5) 10 (5.5) 8 (8.4) 8 (8.4)
5 3 230 15.2 20 12 (3) 12 (3) 10 (5.5) 10 (5.5) 8 (8.4)
5 3 460 7.6 15 14 (2) 14 (2) 14 (2) 14 (2) 14 (2)

Stationary
Seat
Rotating
Seal
Spring
1419 1294
Figure 1
Figure 2
Maintenance 6
mAINTENANCE
Little or no maintenance to pump is required other than possible
replacement of shaft seal after a reasonable period of operation (see
below).
Lubricate motor according to motor manufacturer’s instructions. Periodic
greasing is required for most motors.
PUmP STORAgE
Drain pump to prevent freezing.
Keep motor dry and loosely covered. Do not wrap with plastic sheeting;
trapped moisture could cause corrosion or insulation deterioration.
NOTICE: A good rust inhibitor in the liquid end of cast iron pumps is
recommended to prevent excessive corrosion.
PUmP START-UP AFTER STORAgE
Replace all drain plugs and close all drain valves in system.
Be sure all connections are tightly sealed.
After inital check is made, fill pump according to “Priming the Pump”
above.
SHAFT SEAL REPLACEmENT
NOTICE: The highly polished and lapped faces of the seal are easily
damaged. Follow instructions and handle the seal with care.
Hazardous
voltage
Be sure unit is grounded and power
disconnected before attempting any
work on pump or motor.
REmOVAL OF OLD SEAL
Refer to Figure 1 for Mechanical Seal parts identification.
1. Remove motor hold down bolts and bolts holding adapter/seal plate to
volute. Slide motor, adapter/seal plate and impeller backward to clear
volute.
2. Remove impeller screw and washer from end of shaft and slide
impeller off of shaft.
3. Unbolt adapter/seal plate from motor.
4. Use two screwdrivers (Figure 2) or bearing puller to carefully separate
motor from adapter/seal plate, bringing rotating half of seal off with
adapter/seal plate. Shaft sleeve may come off with seal.
5. Use hammer, if necessary, to drive shaft sleeve out of seal. Clean up
shaft sleeve with emery paper if necessary.
6. Place adapter/seal plate face down on bench and drive old stationary
half of seal out of adapter/seal plate by carefully tapping with
screwdriver and hammer (Figure 3).
7. Use a wire brush to thoroughly clean adapter/seal plate cavity. Be sure
all dust and grime are out of seal cavity before installing new seal.
If Gear Puller is used,
place jackscrew here.
Rotating Seat will come off
with adapter/sealplate.
1420 1294
If Gear Puller is used,
place jackscrew here.
Rotating Seat
will come off with
adapter/sealplate

Maintenance 7
INSTALLINg NEW SEAL
1. NOTICE: Seal faces are highly polished and lapped. Handle with
care. Any mar, nick or scratch on seal face will cause it to leak.
BE SURE to install with polished faces toward each other.
2. Clean polished surface of ceramic seat with clean cloth.
3. Wet O-Ring around ceramic seat with liquid soap.
4. Press stationary (ceramic) half of seal cavity into cavity firmly and
squarely with thumb pressure. If it does not seat properly, remove
and place seal face up on bench. Re-clean adapter/seal plate cavity.
Seal should now seat correctly.
5. If seal does not seat after re-cleaning adapter/seal plate cavity, place
a cardboard washer over polished face of seal and carefully press
into place using a piece of 1” standard pipe as a press (Figure 4).
NOTICE: BE SURE you do not scratch seal face.
6. Dispose of cardboard washer and recheck seal face to be sure it is
free of dirt, foreign particles, scratches and grease.
7. Inspect shaft and shaft sleeve to be sure they are clean.
8. Re-install O-Ring, shaft sleeve and slinger on shaft.
NOTICE: A small amount of grease or Never-Seez under shaft sleeve
will help prevent shaft and sleeve from freezing together when pump
is in service.
9. Remount adapter/seal plate to motor, being careful not to scratch seal
face.
10. Apply liquid soap to inside diameter and outside face of rubber drive
ring on rotating half of seal.
11. Slide seal assembly onto shaft sleeve (sealing face first) far enough
so that seal spring is located on shaft sleeve.
NOTICE: Be careful not to nick carbon seal face when passing it
over end of shaft sleeve.
12. Slide impeller and gaskets onto shaft with key in position. Be sure to
maintain proper order as shown in Exploded View, Page 9.
13. Install washer and impeller screw on end of shaft and tighten screw
until it is snug. This should locate seal in place and bring seal faces
together.
14. Reinstall motor, adapter and impeller assembly on volute, using new
gasket.
15. Reinstall motor hold-down bolts.
16. Check all bolts for tightness.
1421 1294
1" Standard Pipe
Stationary Seat
Cardboard
Washer
(Supplied with seal)
1422 1294
Figure 3
Figure 4

Troubleshooting 8
SYmPTOm KEY NUmBERS FOR CAUSES
Pump does not deliver liquid 1, 2, 3, 4, 6, 10, 12, 14, 15, 20, 21
Pump delivers too little flow 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 15, 18, 20, 21, 27, 28
Delivery pressure too low 5, 12, 13, 14, 15, 18, 20, 27, 28
Pump loses prime after starting 2, 3, 5, 6, 7, 10
Pump needs too much power 13, 14, 15, 16, 17, 18, 21, 22, 24, 25, 27
Seal leaks 22, 24, 29, 30
Pump vibrates or is noisy 2, 3, 4, 8, 9, 10, 11, 19, 21, 22, 23, 24, 25, 26, 28, 29, 30,
31, 32, 33, 34
Motor bearings have short life 22, 24, 25, 26, 29, 30, 31, 32, 33, 34
Pump overheats and/or seizes 1, 4, 19, 20, 22, 25, 26, 29, 30
CAUSES
1. Pump not primed. 18. Viscosity of liquid different than design.
2. Pump or suction pipe not completely full of liquid. 19. Pump operating at very low capacity.
3. Suction lift too high. 20. Parallel operation of pumps unsuited for such operation.
4. Pump cavitating; increase suction pressure. 21. Foreign matter in impeller.
5. Excessive amount of air or gas in liquid. 22. Misalignment of pump or piping.
6. Air pockets in suction pipe. 23. Foundations not rigid.
7. Air leakage in suction pipe. 24. Shaft bent.
8. Foot valve too small. 25. Rotating part rubbing on stationary part.
9. Foot valve partially clogged. 26. Bearings worn.
10. Suction pipe inlet not sufficiently submerged. 27. Wear ring worn.
11. Impeller, suction or trap partially or completely 28. Impeller damaged.
plugged. 29. Shaft running off center due to worn bearings or
12. Speed too low. misalignment.
13. Voltage wrong or too low. 30. Impeller out of balance resulting in vibration.
14. Wrong direction of rotation. 31. Excessive grease in bearing causing high bearing
temperature.
15. System head too high for pump design. 32. lack of lubrication.
16. System head too low for pump design. 33. Dirt in bearings.
17. Specific gravity of liquid different than design. 34. Rust in bearings due to water getting into motor.
Read symptom describing problem below at left. Causes
for problems (bottom) are keyed to numbers at right.
Check pump for causes listed at right and correct those
that apply.
Hazardous voltage. Can shock, burn
or kill. Take all normal precautions for the voltage
involved.

Repair Parts 9
1839 0695
5
4
3
2
1
6
7
1128 0695
7
3
4
5
2
1
6
8
9
Key Part
No. Description Cast Iron Bronze
1* Lock Handle C154-18D C154-18D
2 Cover - 6” C30-30 C3-78DZZ
2 Cover - 8” C3-105 C3-105D
2 Cover - 11” C3-76 –
3 O-Ring - 6” U9-46 U9-46
3 O-Ring - 8” U9-171 U9-171
3 O-Ring - 11” U9-105 –
4 Strainer Basket - 6” C108-11P C108-11P
4 Strainer Basket - 8” C108-34SS C108-34SS
4 Strainer Basket - 11” C108-25SS –
5 Suction Trap Body - 6” C53-5B C53-5D
5 Suction Trap Body - 8” C53-21 C53-21D
5 Suction Trap Body - 11” C53-8 –
6** Pipe Plug 1/4” U78-57DT U78-57DT
7 Gasket, Flange C20-19 C20-19
8 Capscrew, 3/8-16x1-3/4” – U30-77C
9 Nut, Hex 3/8-16 – U36-38C
 • Capscrew,5/16-18x7/8” U30-61C(4) U30-61C(4)
Suction Trap Complete - 6” Pkg. #51 Pkg. #56
Suction Trap Complete - 8” Pkg. #98 Pkg. #99
Suction Trap Complete - 11” Pkg. #74 –
Quantity1unlessotherwisenoted().
•Notillustrated.
* 6” has 2 each; 8” & 11” have 4 each.
** 6” & 8” have 1 each; 11” has 2 each.
6” Suction Trap 8” and 11” Suction Trap
NOTICE:
Traps are not
included with pumps.

Repair Parts 10
1
2
5
3
4
6
7
8
9
10 12
11
17
18
13
14
16
21
22
23
6
15
1904 0795 CC P/S
19
20
Model numbers with a “3” in them indicate a 3-Phase motor.
Model numbers with a “2” in them indicate a 200V motor.
NOTE: CSerieswithdifferenthydraulicnumbers(CCMH-93)areoldermodelsthatusedifferentparts.
Consult factory for older models.
CCmH-136 CCHH-137S
CCm2H-136 CmH-136 CCHH3-137S
CCm2H-136S CmH3-136 CCHH36-137
CCmH3-136S CCmH36-136 CCH2H-137S CHH-137
CCm2H3-136 Cm2H-136 CCH2H3-137 CHH3-137
Key CCm2H3--136S Cm2H3-136 CCH2H3-137S CH2H3-137
No. Description Qty. 3 HP 3 HP 3 HP 3 HP
1 Motor 230V/60H/1 Ph. 1 C218-177 C218-177 C218-177 C218-177
1 Motor 230/460V/60H/3 Ph. 1 C218-179 C218-179 C218-179 C218-179
1 Motor 575V/60H/3 Ph. 1 – C218-290C C218-290C –
1 Motor 200V/60H/1 Ph. 1 C218-191 C218-191 C218-191 C218-191
1 Motor 200V/60H/3 Ph. 1 C218-178 C218-178 C218-178 C218-178
2 Water Slinger-1 Ph. 1 C69-15 C69-15 C69-15 C69-15
 2 WaterSlinger-3Ph.(†) 1 C69-16 C69-16 C69-16 C69-16
3 Key, Impeller 1 U65-42A U65-42A U65-42A U65-42A
4 O-Ring 1 U9-265 U9-265 U9-265 U9-265
5 Adapter 1 C2-81 C2-81D C2-81 C2-81D
6 Lockwasher, 3/8” 8 U43-12ZP U43-12ZP U43-12ZP U43-12ZP
7 Capscrew, 3/8-16x7/8” 4 U30-73ZP U30-73ZP U30-73ZP U30-73ZP
8 Gasket 1 C20-77 C20-77 C20-77 C20-77
9 Shaft Seal 1 U109-433SS U109-433SS U109-433SS U109-433SS
10 Shaft Sleeve 1 C23-58 C23-58 C23-58 C23-58
11 Gasket, Sleeve 1 C20-101 C20-101 C20-101 C20-101
12 Impeller 1 C105-224DD C105-224DD – –
 12 Impeller(SiliconBrass) 1 C105-224DG C105-224DG C105-224DF C105-224DF
13 Gasket, Impeller 1 C20-100 C20-100 C20-100 C20-100
14 Washer, Impeller 1 C43-45SS C43-45SS C43-45SS C43-45SS
15 Washer, Stat-O-Seal 1 C43-46 C43-46 C43-46 C43-46
16 Screw, Impeller 3/8-16x3/4” 1 U30-72SS U30-72SS U30-72SS U30-72SS
17 Wear Ring Only 1 C23-40 C23-40 C23-40 C23-40
 18 VoluteAssembly(includes18A&20) 1 C201-174 C201-174D C201-174 C201-174D
 18A VoluteAssemby(Incl.17Only) 1 C101-167 C101-167D C101-167 C101-167D
19 Capscrew 5/16-18x3/4” 4 U30-62ZP U30-62ZP U30-62ZP U30-62ZP
20 Pipe Plug, 1/4” NPT, Hex Head 1 U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV
21 Stud, 3/8-16x1-1/4” 4 U30-22SS U30-22SS U30-22SS U30-22SS
22 Nut, Hex 3/8x16 4 U36-38ZP U36-38SSW U36-38ZP U36-38SSW
23 Pipe Plug, 1/4” NPT 1 U78-57SSS U78-57SSS U78-57SSS U78-57SST

1
2
5
3
4
6
7
8
9
10 12
11
17
18
13
14
16
21
22
23
6
15
1904 0795 CC P/S
19
20
Repair Parts 11
Model numbers with a “3” in them indicate a 3-Phase motor.
Model numbers with a “2” in them indicate a 200V motor.
(†)ModelnumberCCH2J3-138ShasnoWaterSlinger.
NOTE: CSerieswithdifferenthydraulicnumbers(CCMH-93)areoldermodelsthatusedifferentparts.
Consult factory for older models.
CCHJ-138
CCHJ-138S
CCHJ3-138S CHJ-138
CCHJ36-138 CHJ3-138
Key CCH2J3-138S CH2J3-138
No. Description Qty. 5 HP 5 HP
1 Motor 230V/60H/1 Ph. 1 C218-180 C218-180
1 Motor 230/460V/60H/3 Ph. 1 C218-182 C218-182
1 Motor 575V/60H/3 Ph. 1 C218-292C –
1 Motor 200V/60H/3 Ph. 1 C218-181 C218-181
 2 WaterSlinger-3Ph.(†) 1 C69-16 –
3 Key, Impeller 1 U65-42A U65-42A
4 O-Ring 1 U9-265 U9-265
5 Adapter 1 C2-81 C2-81D
6 Lockwasher, 3/8” 8 U43-12ZP U43-12ZP
7 Capscrew, 3/8-16x7/8” 4 U30-73ZP U30-73ZP
8 Gasket 1 C20-77 C20-77
9 Shaft Seal 1 U109-433SS U109-433SS
10 Shaft Sleeve 1 C23-58 C23-58
11 Gasket, Sleeve 1 C20-101 C20-101
 12 Impeller(SiliconBrass) 1 C105-224DE C105-224DE
13 Gasket, Impeller 1 C20-100 C20-100
14 Washer, Impeller 1 C43-45SS C43-45SS
15 Washer, Stat-O-Seal 1 C43-46 C43-46
16 Screw, Impeller 3/8-16x3/4” 1 U30-72SS U30-72SS
17 Wear Ring Only 1 C23-40 C23-40
 18 VoluteAssembly(includes18A&20) 1 C201-174 C201-174D
 18A VoluteAssemby(Incl.17Only) 1 C101-167 C101-167D
19 Capscrew 5/16-18x3/4” 4 U30-62ZP U30-62ZP
20 Pipe Plug, 1/4” NPT, Hex Head 1 U78-941ZPV U78-941ZPV
21 Stud, 3/8-16x1-1/4” 4 U30-22SS U30-22SS
22 Nut, Hex 3/8x16 4 U36-38ZP U36-38SSW
23 Pipe Plug, 1/4” NPT 1 U78-57SSS U78-57SSS
