Pentair Hypro 9205 Series User guide

Pentair
375 5th Ave., New Brighton, MN 55112
Phone: [phone] -OR- 800-424-9776 Fax: [phone]
www.hypropumps.com
EU Authorized Representative: QNET BV Hommerterweg 286
6436 AM Amstenrade, The Netherlands
KvK Zuid-Limburg 14091511
EC REP
Hypro Series 9205
Form L-1557
Rev. B
Original Instruction Manual
9205C & 9205C-SP
Cast Iron Series Centrifugal Pumps
KEEP FOR FUTURE REFERENCE

Contents
EU Language .........................................................................................................................................................................3
Introduction.................................................................................................................................................................4
Description.....................................................................................................................................................4
Intended Uses............................................................................................................................................................4
Purpose of Manual....................................................................................................................................................4
Misuses...........................................................................................................................................................4
 Pump Identication....................................................................................................................................................5
 PumpTechnicalData.................................................................................................................................................5
Fluid Pumping Applications.........................................................................................................................................6
Tools................................................................................................................................................................7
Lifting, Transport, and Intermediate Storage...............................................................................................................7
Assembly and Installation........................................................................................................................................................8
Assembly.........................................................................................................................................8
Installation......................................................................................................................................8
Plumbing Diagram.....................................................................................................................................................9
Commissioning, Start-Up, Operation, Shutdown...................................................................................................................10
Information.....................................................................................................................................10
Start-Up, Operation, Shutdown................................................................................................................................11
Maintenance and Servicing..................................................................................................................................................12
Information............................................................................................................................12
Disposal.................................................................................................................12
Cleaning............................................................................................................................12
Maintenance, Routine Servicing, and Inspection.....................................................................................................12
Troubleshooting.................................................................................................................................13
Replacement Parts...................................................................................................................................................14
Declaration of Incorporation.................................................................................................................................................15
Warranty....................................................................................................................................................................Last page
- 2 -

- 3 -
EU Languages
DO NOT attempt to install or operate your pump before reading the manual. Original copies of the manual for Hypro
pumpsareprovidedinEnglish.Tondacopyinyournativelanguage,gotowww.hypropumps.com.
Vor dem Ablesen des Handbuches versuchen Sie NICHT, Ihre Pumpe zu installieren. Originale des Handbuches fur
Hypro-PumpenwerdenaufenglischzurVerfugunggestellt.ZueineKopieinIhrerMuttersprachenden,zu
www.hypropumps.com zu gehen (German)
N’essayez pas d’installer votre pompe avant de lire le manuel. Des exemplaires originaux du manuel pour des pompes
de Hypro sont fournis en anglais. Pour trouver une copie dans votre langue maternelle pour aller a
www.hypropumps.com (French)
NON tentare di installare la vostra pompa prima di leggere il manuale. Esemplare originale del manuale per Hypro
pompe sono in inglese. Per trovare una copia nella vostra lingua andare a www.hypropumps.com (Italian)
Непытайтесьустановитьвашнасосдочтенияруководства.Оригинальныекопииэтогоруководствадлянасосы
Hyproнаанглийскомязыке.Найтикопиюнавашроднойязыкперейтикwww.hypropumps.com(Russian)
NO intente instalar su bomba antes de leer el manual. Copias originales del manual para Hypro se provee de bombas
en ingles. Para encontrar una copia en tu idioma nativo ir a www.hypropumps.com (Spanish)
NIEprobowaćinstalowaćpompyprzedjejodczytanieminstrukcji.OryginalnekopieinstrukcjiobsługipompHyprosą
dostarczanewjęzykuangielskim.Abyuzyskaćkopięwtwoimojczystymjęzykuprzejdźdowww.hypropumps.com
(Polish)
Takmayacalışmayınokumadanoncepompanınmanuel.OrijinalkopyalarınıHypropompalarıicinIngilizceolarak
sunulmuştur.Birkopyasınıbulmakicinyereldilgitwww.hypropumps.com(Turkish)
Nao tente instalar a bomba antes de ler o manual. As copias originais dos manuais para Hypro bombas sao
fornecidos em Ingles. Para encontrar uma copia em sua lingua nativa ir para www.hypropumps.com (Portuguese)
VERGEETNIETuwpompvoorhetlezenvanhethandboek.ExemplarenvandehandleidingvoorHypropompenzijn
beschikbaarinhetEngels.Opzoeknaareenexemplaarinuweigentaalganaarwww.hypropumps.com(Dutch)

Introduction
Description
Hyprocentrifugalpumpsaredesignedforcreatingandboostingpressureinuidcircuits.Thepumpoperatesbytaking
inuidfromtheinletportafterwhichitisslungbytheimpellerandexpelledthroughtheoutletport.Constructionfeatures
include housings, impellers and seals which come in a variety of materials in order to be resistant to a range of chemicals.
Standardmodelsofcentrifugalpumpsrotateclockwise,whenlookingatthefrontofthepump.
Intended Uses
Hyprocentrifugalpumpsareintendedforcreatingorboostingdynamicpressureinapproveduids.Hyprocentrifugal
pumps should never be used to pump liquids above 140°F (60°C), or below 34°F (1°C). Any uses outside of those
speciedinthismanualareconsideredmisusesandareprohibited.ContactHyprotechnicalservicewithanyquestions
regardingspecicacceptableuses.
Purpose of Manual
This manual provides instructions and requirements that must be met when installing, using and maintaining the
product(s)identiedonthecover.
If the product is sold, the seller must pass this manual onto the new owner.
The following special attention notices are used to notify and advise the user of this product of procedures that may be
dangerous to the user or result in damage to the product.
ATTENTION
Attention is used to notify of installation, operation, or maintenance information that is important but not safety related.
Thissymbolisusedtodenotethepresenceofanelectricalhazardthatwillresultinpersonalinjury,deathorproperty
damage.
Thissymbolisusedtodenotethepresenceofahazardthatwillresultinpersonalinjury,deathorpropertydamage.
California Proposition 65 Warning --Thisproductandrelatedaccessoriescontainchemicalsknowntothe
State of California to cause cancer, birth defects or other reproductive harm.
Misuses
Hyprocentrifugalpumpsaredesignedtooperateeffectivelywithinthespeciedspeed,pressureandenvironmental
ranges.Goingoutsideoftheserangeswillvoidthewarrantyandcouldcausedamagetopropertyorseriousinjuryor
death.
• DO NOT runthepumpfasterthanthemaximumspeciedspeed.
• DO NOTrunthepumphigherthanthemaximumspeciedpressure.
• DO NOT run pumps when the liquid has exceeded the maximum or minimum temperature limit (see Intended Uses).
• DO NOT pump non-approved liquids.
• DO NOT pump water or other liquids for human consumption.
• DO NOToperateanypumpundertheinuenceofdrugsoralcohol.
• DO NOT run the pump dry.
- 4 -

- 5 -
Pump Identication
Hypro uses serialized labeling to enable users to precisely identify the pump’s manufacturing date.
Serial Number:
First and second digits: year (14 = 2014)
Third through fth digits: consecutive day of the year the pump was manufactured.
Sixth through tenth digits: unique pump serial number.
Pump Technical Data
(Allspecicationsandperformancedataarebasedonwaterasacarrieruid.)
9205C & 9205C-SP
Pump Dimensions
Dim. Inch mm
A 12.12 307.8
B12.00 304.5
C 6.00 152.1
D5.50 139.7
E4.51 114.6
F 9.84 249.9
G5.19 131.8
H1.50 38.1
I 3.00 76.2
Pump Dimensions
Dim. Inch mm
A15.38 390.5
B12.00 304.8
C 6.00 152.4
D12.25 311.2
E1.75 4.5
F11.56 293.7
G 6.91 175.4
H1.50 38.1
I 3.00 76.2
Pump
PTO or Shaft
Output
Max Flow
Rate (GPM)
[LPM]
Max
Pressure
(PSI)
[BAR] Max RPM Ports Dry Weight
Mounting
Bolts
9205C 7/8" Solid
Shaft 180 [681.4] 196[13.5] 4200
2" NPT inlet
1-1/2" NPT
outlet
47lbs
(21.4kg) 3/8" OR M10

- 6 -
Pump
PTO or Shaft
Output
Max Flow
Rate (GPM)
[LPM]
Max
Pressure
(PSI)
[BAR] Max RPM Ports Dry Weight
Mounting
Bolts
9205C-SP 7/8" Solid
Shaft 160[605.7] 145[10] 3800
2" NPT inlet
2" NPT outlet 48lbs
(21.8kg) 3/8" OR M10
9205C-BSP 2 "  B S T  i n l e t 
2"BSToutlet
Fluid Pumping Applications
Application
Pump Materials Compatibility
Impeller Pump Housing Seal
Polypropylene Stainless Cast Iron Ceramic Silicon
Carbide
Weed Control Chemicals X X X X
Insect Control X X X X
BrushControl X X X X
Pest Control Chemicals and Fumigants X X X X
Liquid Fertilizers X X X
Powdered Fertilizers X X X X
Fluid Transfer X X X X
Acids X X
Table 1
Flammable liquids, sewage, and potable water should never be pumped through a Hypro pump.

- 7 -
Tools
The Hypro centrifugal pumps and mounting assemblies are designed with Imperial (inch) bolts, however, there are many
metric(mm)sizeswhichwillworkwiththesemounts.Inmostcases,anadjustablespannerwrenchcanalsobeused.
Lifting, Transport, and Intermediate Storage
Packaging Descriptions and Unpacking Instructions
• Hypro centrifugal pumps are shipped in cardboard boxes for safe transporting.
• When pumps are shipped in large quantities, they may be put on a pallet to allow for easy storage, lifting and
handling.
• Beforeliftinganypumporpallet,determinetheweightoftheitembylookingattheattachedpackingslipstoestablish
what lifting equipment should be used.
• Beforeinstallingthepump,determineifallthecomponentsarepresentandundamaged.Ifthepumpismissing
components, contact customer service immediately.
• Oncethepumpisunpacked,disposeofthepackaginginamannercompliantwithlocalandnationalregulations.
Lifting Instructions
• BeforeattemptingtoliftaHypropump,ensurethatthesurroundingworkingareaisfreeofhazardswhichcouldcause
injuryordamagetoproperty.
• Duringliftingoperations,anypersonnelnotinvolvedintheliftshouldnotentertheworkingarea.
• Ifliftinghooks,ropeorchainsarebeingusedforalift,theymustbefreeofdamageandberatedtocarry150%ofthe
weight of the load to be lifted.
• Always wear steel-toed shoes and cut-resistant gloves when attempting to lift.
• Whenliftingandcarrying,alwayskeepthepumpclosetoyourbody.(SeeFigure1)
• Whenstartingthelift,bendyourkneesandkeepyourbackstraight.(SeeFigure1)Tighteningthestomachmuscles
willhelpkeepyourbackstraight.
• Duringthelift,useyourlegstodothework.Neveruseyourback,andmakesureyourlegsareatleastshoulder-width
apart. (See Figure 1)
Figure 1
Transport
• All Hypro pumps are capable of being transported by air, sea, rail or motor vehicle. When the pump is shipped, ensure
that the pump is moved in accordance with local and national laws and is properly secured to prevent unwanted
movementwhichcouldcausedamagetopersonorproperty.Priortoshipping,alluidsshouldberemovedfromthe
pump.
Storage
• New pumps in their boxes can be stored several years as long as the port plugs are not removed. Once the plugs
have been removed, if the pump is not to be used for an extended period of time (i.e. more than 30 days), the pump
must be winterized as described in the Cleaning section of this manual.

- 8 -
Assembly and Installation
Assembly
• This pump comes completely assembled.
Installation
BeforeattemptingtoinstallyourHyprocentrifugalpump,itisimperativetoreadandunderstandthefollowing:
• InstallationofaHypropumpshouldonlybeperformedbyatechnicianhavingtheknowledgeandskillsnecessary
toinstallthepumpwithouttheriskofpropertydamageorinjury.
• When handling Hypro pumps, one should wear steel-toed shoes and protective gloves in order to protect the feet
in the event the pump is dropped and protect the hands from any sharp surfaces on the pump or chemicals.
• Pumping systems must be installed in accordance with Hypro installation instructions. Failure to do so will void
yourwarrantyandcouldcausedamagetoproperty,seriouspersonalinjury,ordeath
• Electricalpowercablesandpumphosesmustberoutedwherethereisnoriskofpersonneltripping,walkinginto,
or falling because they have been routed in areas where personnel are expected to move. Electrical power cables and
pump hoses should be routed according to local and national standards.
• Itistheinstaller’sresponsibilitytoensurethatACelectric-drivemotors,Hypropumps,andmetalworkofsupport
structures are bonded to earth (ground), per local and national standards.
• It is the installer’s responsibility to conduct earth continuity tests between AC electric-drive motors, Hypro pumps,
andmetalworkofsupportstructuresandearthaccordingtoEN60204-1:2006/A1:2009,oritssupersedingstandard,to
conrmthatallcomponentsthatneedtobeconnectedtoeartharesatisfactorilybonded.
• Itistheinstaller’sresponsibilitytoconductelectricaltestsinaccordancewithEN60204-1:2006/A1:2009,orits
supersedingstandard,onnishedpumpassemblies.
• All connections to electrical components must be number, symbol, or color-coded generally as recommended by
EN60204-1:2006/A1:2009,oritssupersedingstandard.
• For pumps with gas engines, the exhaust must be directed away from operators and anyone standing nearby to
ensure that exhaust fumes do not enter their breathing zone.
• If a rigid plumbing system is to be used on a Hypro centrifugal pump, the system must be properly aligned with the
inlet and outlet ports.
• Wheninstalling,adjustingorremovingaHyprocentrifugalpump,ensurethattherearenoobjectswhichcanfall
ontheinstallerandmakecertainthatallmachinerytowhichthepumpistobeattachedisturnedoff.
• Pumps must be installed in a location where they are accessible for any necessary maintenance.
• When a main electrical supply is needed to power electric-drive motors, installers are responsible for ensuring that a
supply disconnect device capable of isolating the machine from its electricity supply be provided.
Standard Mounting
• Inordertopreventinjuryordamagetoproperty,allHypropumpsshouldbeproperlymountedtoasolidbasewhere
thereisnodangerofthepumpfallingorbreakingloose.AllHypropumpscomewithmountingholeswhichallow
bolts to be put into the pump so it can be secured to a sturdy base. When mounting your Hypro centrifugal pump, be
sure to use bolts and nuts which are compatible with any chemicals that may come into contact with them as well as
choosing the correct grade of bolt based on the pump weight and any expected loads. Pumps should be mounted
as close to the liquid source as possible. Non self-priming pumps must be mounted below the liquid level to function
properly.
Pump Plumbing
• To achieve maximum pump performance the outlet port on the pump should be pointing straight up, and pump
inlet and outlet lines should be at least the same size as their respective port. Pump plumbing must be capable of
withstanding the maximum suction, and pressure, generated by the pump and should have as few restrictions as
possible.
• For best priming results, the upper most vent plug can be removed and a vent line can be installed. This line prevents
airlockandallowsthepumptoprimeitselfbybleedingofftrappedair.

- 9 -
Ref.
No. Description
1TankLid
2 Vent Line
3Jet Agitator
4Shut-offBallValves
5Centrifugal Pump
6 Spray Control Console
7 Centrifugal Pump Control
8ManifoldBoomValve
9 Flowmeter
10 JetTurretNozzleBody
Belt and Pulley Drive Installation
for Pedestal-Mounted Centrifugal Pumps
▫Pulley Driven-Mountpulleysasclosetopumpandmotorengineshaftbearingsaspossible.Checkalignment
with a straight edge as shown in Fig. 2.
▫ Makesurethatbelthaspropertension.(Toomuchtensionwillcausebearingwear;toolittlewillcauseslippage.)
See Fig. 3.
Push the belt midway between the pulleys, check the deection (D) and adjust: d = 0.016 x L
d
L
▫ Checkwithbeltandpulleysourcesforspecicrecommendation.Togureproperdiameterofpumppulley,multiply
motor/enginerpmbydiameterofthemotor/enginepulleyanddividethatgurebydesiredpumpspeed.Beltand
pulley drive systems are typically used to reduce pump speed. For determining proper pulley sizes, use the formula
belowasaguidelineanduse“A”or“B”sectionbelts.
Motor RPM =Flow (@ Rated Speed) =Pump Pulley Dia.
Pump RPM Flow (Desired) Motor Pulley Dia.
Figure 2
Figure 3

- 10 -
Example:
• Usea1725RPMelectricmotortodriveapumpat950RPM.
• Typically, a pulley diameter on the motor is 3.4 inches. The pump pulley diameter can be determined from the formula
above:
1725 RPM =Pump Pulley Dia.
950 RPM 3.4”
• SolvingthisequationforthePumpPulleydiameteryields:
1725 RPM = 3.4” = 6.2”
950 RPM
• Refertopumpperformancechartstodeterminedesiredspeedandtoobtaindesiredmaximumow.
ATTENTION: Note that shaft rotation is clockwise as viewed from the front of the pump. Be sure to drive pump in
proper direction.
• Flexible Coupling - To install couplings, slide coupling ends onto motor or engine and pump shafts as far as possi-
ble. Mount engine/motor and pump on base. Shim up pump or power to align shafts. Leave enough room between
shaft ends to install center disc. When aligned, slide ends over disc. Select couplings rated twice required horsepower
whenusingelectricmotor;threetimeswhenusinggasengine.
Control Systems
• All pump systems with electric or hydraulic power sources are required to have a control system which meets all local
and national standards.
• For more detail on a typical system installation, see preceding subsections of the “Assembly and Installation” section
of this manual.
Commissioning, Start-Up, Operation, Shutdown
Beforeattemptingtostartyourpump,thefollowingmustbeunderstoodandfollowedtoensuresafeoperation.
Information
• When running Hypro centrifugal pumps, it is essential that operators use hearing protection as the sound levels
can reach levels of 80 decibels.
• When handling Hypro pumps, one should wear steel-toed shoes and protective gloves in order to protect the feet
in the event the pump is dropped and protect the hands from any sharp surfaces on the pump or chemicals.
• OnlyauthorizedoperatorshavingtheknowledgeandskillnecessarytosafelyuseaHypropump,orany
equipment the pump is connected to, may run the pump.
• Whensprayingmanually,itisrecommendedthatchemical-resistantfacemasksandclothingbeworntoprevent
anychemicalsfromcomingintocontactwiththeskinorbeinginhaled.
• When spraying manually, always spray upwind of yourself as long as the sprayed chemical will not drift into the
vicinity of other people.
• Wheninstalling,adjustingorremovingaHyprocentrifugalpump,ensurethattherearenoobjectswhichcanfall
ontheinstallerandmakecertainthatallmachinerytowhichthepumpistobeattachedisturnedoff.
• Hypro centrifugal pumps should only be used on tractors or tow-behind spray platforms which have electrically
conductivetiresinordertoreducetheriskofelectrocution.
• NeveroperateaHyprocentrifugalpumpoutsidewhilethereisachanceofgettingstruckbylightning.
• Never leave electrical wires or plumbing components where they can be a tripping hazard or become entangled
inamovingcomponent.Ideally,electricalcables,hoses,pipesandttingsshouldberoutedoverhead.Intheevent
electrical wiring must be routed over the ground, operators are required to use rubber ramps if they cross a gangway.
•  IfusersofaHyprocentrifugalpumpareusingaPTOshaft,exiblecouplingorbeltdrivetheyarerequiredtouse
CE approved PTO shafts and guards
• Hypro centrifugal pumps should not be used if the ambient light is below 200lux.
• For centrifugal pumps which use gas engines the user should always ensure the exhaust is properly attached to
theengineandisnotleaking.
Only use approved chemicals in your pump. For a complete list of approved chemicals, see the “Fluid
Pumping Applications” section. Failure to follow this warning will void your warranty and could lead to property
damage, serious injury or death.

- 11 -
Start-up, Operation, Shutdown
Before Starting the Pump
• Ensure all unnecessary personnel are clear of the area.
• Forinitialsetupandtestofyoursystem,itisrecommendedtostartwithcleanwaterinsteadofchemicals,andconrm
thesystemandplumbingconnectionsareleakfree.
• Ensurethatthereisuidinthesourcetankorsupplyline.Donotrundry.
• Checklinestrainerfordebrisorclogs.Removeanyfound.
• Checkallplumbingconnectionstomakesuretheyaretight.
• Checkpowersourceandconnections.
• Checkthatallvalvesandregulatorsaresettothedesiredsettingandarefunctioningproperly.
• Ensure all hoses are properly positioned and are not damaged in any way.
Starting, Operation and Shutdown of the Pump
Toadjustthesprayer,followthesesteps:
1. Prime the pump with all valves open.
2. Closecontrolvalveandagitationlinevalve;thenopentheboomshut-offvalve.
3. With the pump running, open the control valve until the pressure gauge indicates desired spraying pressure.
4. Opentheagitationlinevalveuntilsufcientagitationisobserved.Then,ifsprayingpressuredrops,readjustthe
control valve to restore desired pressure.
5. Makesureowisuniformfromallnozzles.Aftersprayingadjustmentsaremade,itisonlynecessarytoclosethe
boom shut-off valve to discontinue spraying.
6. To shut down the pump, turn off the pump’s power supply.
When stopping, do not allow the pump to come to a sudden stop as this may damage the drive components of the
pump.

- 12 -
Maintenance and Servicing
Information
• All maintenance should be done when machinery is stationary and has been isolated from its energy sources. It
is dangerous to perform maintenance while machinery is still connected to its power source. Machinery should be
isolated from its electrical, hydraulic or gas engine power source.
• BesuretoreleaseallpressurefromthesystembeforeperforminganysortofmaintenanceonaHypropump.
• DO NOT perform service or maintenance to the pump, or attached components, until the pump unit is below
109°F(43°C).
• The lubrication of this pump unit has been done at the factory prior to shipping.
• When handling Hypro pumps, one should wear steel-toed shoes and protective gloves in order to protect the feet
in the event the pump is dropped and protect the hands from any sharp surfaces on the pump or chemicals. If the
pump is being repaired while the pump is in service, eye protection should also be worn.
Any hazardous liquids should be disposed of in a manner which complies with local and national regulations. Never dump
uidsontotheground.
Disposal
WhendisposingofaHypropump,besuretoremovealluidsfromthepumpbeforescrapping.Theseuidsshouldbe
disposedofinamannerwhichcomplieswithlocalandnationalregulations.Neverdumpuidsontotheground.Oncethe
pumpisfreeofalluids,itmaybescrappedinaccordancewithlocalandnationallaws.
Cleaning
Yourpumpwilllastlongerandgivebestperformancewhenproperlytakencareof.Properpumpcaredependsonthe
liquidbeingpumpedandwhenthepumpwillbeusedagain.Aftereachuse,ushpumpwithaneutralizingsolutionforthe
liquidjustpumped.Followwithacleanwaterrinse.Thisisespeciallyimportantforcorrosivechemicals.Itisgoodpractice
to clean the pump after each use to prevent deposits from forming and damaging the pump. For infrequent use and before
long periods of storage, drain pump thoroughly. Open any drain plugs, remove suction hose from liquid, and blow pump
drywithair.Anantifreeze/rustinhibitorshouldbeinjectedintothepumpbeforebothportsarepluggedandthepumpis
stored.Plugallportstokeepoutairuntilpumpisusedagain.
Maintenance, Routine Servicing, and Inspection
PREVENTATIVE MAINTENANCE CHECKLIST
Check Daily Weekly
WaterLeaks X
Plumbing X
• Eachsystem’smaintenancecyclewillbeexclusive.Ifsystemperformancedecreases,checkimmediately.
• Dutycycle,temperature,quality,typeofuidbeingpumped,andinletfeedconditionsallaffectthelifeofsprayboom
assemblies and service cycle.assemblies and service cycle.

- 13 -
Troubleshooting
Beforeattemptingtoserviceyourpump,besurethatitisdisconnectedfromallenergysources
Symptom Probable Cause(s) Corrective Action
Pump does not prime Leakinsuctionline Checkhoseandttingsforleaksandcorrect
Obstruction in suction line Inspect hose for obstructions and remove
Suctionhosestucktotank Cut a notch or “V” in end of suction hose
Clogged strainer Checkstrainerandcleanregularly
Low discharge Blockedsuctionhose Inspect suction hose and repair as necessary
Pump worn Repair pump
Undersized suction line See Installation
Pump will not turn Impeller plugged Inspect and clear obstruction

Replacement Parts
The following drawings show the pumps and their replacement parts. Only genuine replacement parts should be used.
Failure to follow this warning can result in damage to property, serious injury or death. If the pump malfunctions or
isdefective,itshouldbesentbacktoHyproforservice.
Ref.
No.
Qty.
Req’d.
Part No. Description
1 4 2406-0007 Drain Plug
1A 4 2406-0002 Drain Plug
1B 1 2406-0034 Priming Port Plug
2 1 0152-9200C Pump Casing
2A 1 0150-9075C Pump Casing (Standard)
2A 1 0150-9075C1 PumpCasing(BSPmodels)
3 1 2253-0002 Impeller Nut
4 1 2270-0071 Washer
51 0403-9200P Impeller (Nylon)
6 1 1700-0101 Gasket
Ref.
No.
Qty.
Req’d.
Part No. Description
7 1 3430-0537 Mechanical Seal (Standard)
7 1 3430-0646 Mechanical Seal (Life Guard)
8 1 1720-0180 O-Ring
9 1 1410-0083 Slinger Ring
10 1 0751-9200C Mounting Flange
11 6 2210-0086 Bolt
12 1 2300-0035 Protective Cover
13 2 2008-0001 Bearing
14 1 1610-0012 Key
15 1 3430-0846 Pump Shaft
16 1 1820-0025 BearingRetainer
Seal & O-Ring Kit No. 3430-0537
consistsof:
(1)Ref.6Gasket
(1) Ref. 7 Mechanical Seal
(1) Ref. 8 O-Ring
Silicon Carbide Seal Kit No. 3430-0646
consistsof:
(1) Ref. 7 Mechanical Seal
(1) Ref. 8 O-Ring
NOTE:Whenorderingparts,give
QUANTITY,PARTNUMBER,
DESCRIPTION, and COMPLETE
MODELNUMBER.Referencenumber
are used ONLY to identify part in the
drawing and are NOT to be used as
order numbers.
9205C, 9205C-SP, & 9205C-BSP
- 14 -

- 15 -
EC Declaration of Incorporation
Manufacturer’s Name: Pentair Flow Technologies, LLC
Manufacturer’s Address: 375 Fifth Avenue NW,
New Brighton, MN 55112, USA
Declare that the partially complete machinery described below conforms to applicable health and safety requirements of
Parts 1 of Annex I of Machinery Directive 2006/42/EC. This partly completed machinery must not be put into service until
the equipment into which it is to be incorporated has been declared in conformity with the provisions of this directive.
Condential technical documentation has been compiled as described in Annex VII Part B of Machinery Directive 2006/42/
EC and is available to European national authorities on written request. If a request is received, documentation will be
transmitted either electronically or by post. Clauses 1.1.4, 1.1.7, 1.1.8 Section 1.2, Clauses 1.3.5, 1.3.6, 1.3.7, 1.3.8.1, 1.3.8.2,
1.3.9, 1.4.1, 1.4.2.1, 1.4.2.2, 1.4.2.3, 1.4.3, 1.5.2, 1.5.7, 1.5.12, 1.5.14, 1.5.16, 1.6.2, 1.7.1.1, 1.7.1.2, 1.7.2, and 1.7.4.2 are clauses of
Machinery Directive 2006/42/EC that have not been met, but could be applicable and must be addressed during installation by
a third party.
Description: PENTAIR Pump
Type: Roller Pumps
Series Numbers: 1502, 1700, 4001, 4101, 6500, 7560, 7700
Type: Centrifugal Pumps
Series Numbers: 1442P, 9000, 9202, 9203, 9205, 9206, 9208, 9262, 9263, 9253, 9302, 9303,
9305, 9306, 9307, 9308
The following standards have either been referred to or been complied with in part or in full as relevant:
ENISO 12100 Machinery Safety General principles for design - Risk assessment and risk reduction
EN809-1998 + A1 2009 Machinery Safety Pumps and pump units for liquids - Common safety requirements
EN ISO 13732-1 Machinery Safety Ergonomics of the thermal environment
EN ISO 3744:2010 Acoustics Determination of sound power levels and sound energy levels of noise sources using
sound pressure
EN ISO 11202/A1 1997 Machinery Safety Noise emitted by machinery and equipment
EN 12162:2001+A1:2009 Machinery Safety Liquid pumps - Safety requirements - Procedure for hydrostatic testing
EN ISO 4254-6:2009 Machinery Safety Sprayers and liquid fertilizer distributors
97-68-EC + 2010/26/EU Gas Emission Non-road gas emissions
Name .……………...…………………………………………… Position …..……………………….…………
Signature …………………………………………..……………. Date …..……..……………………….………
Place of Signing……………………………………………………………………………………………………….........
QNET BV
Hommerterweg 286
6436 AM Amstenrade
The Netherlands
EC REP

Limited Warranty on Hypro/Shurflo Agricultural Pumps & Accessories
Hypro/Shurflo (hereafter, “Hypro”) agricultural products are warranted to be free of defects in material and workmanship under
normal use for the time periods listed below, with proof of purchase.
 -Pumps:one(1)yearfromthedateofmanufacture,orone(1)yearofuse.Thislimitedwarrantywillnot
exceed two (2) years, in any event.
 -Accessories:ninety(90)daysofuse.
This limited warranty will not apply to products that were improperly installed, misapplied, damaged, altered, or incompatible with
fluids or components not manufactured by Hypro. All warranty considerations are governed by Hypro’s written return policy.
Hypro’s obligation under this limited warranty policy is limited to the repair or replacement of the product. All returns will be tested
perHypro’sfactorycriteria.Productsfoundnotdefective(underthetermsofthislimitedwarranty)aresubjecttochargespaidbythereturn-
eeforthetestingandpackagingof“testedgood”non-warrantyreturns.
No credit or labor allowances will be given for products returned as defective. Warranty replacement will be shipped on a freight allowed
basis. Hypro reserves the right to choose the method of transportation.
This limited warranty is in lieu of all other warranties, expressed or implied, and no other person is authorized to give any other
warranty or assume obligation or liability on Hypro’s behalf. Hypro shall not be liable for any labor, damage or other expense, nor
shall Hypro be liable for any indirect, incidental or consequential damages of any kind incurred by the reason of the use or sale of
anydefectiveproduct.ThislimitedwarrantycoversagriculturalproductsdistributedwithintheUnitedStatesofAmerica.Otherworldmarket
areas should consult with the actual distributor for any deviation from this document.
Return Procedures
All products must be flushed of any chemical (ref. OSHA section 1910.1200 (d) (e) (f) (g) (h)) and hazardous chemicals must be labeled/
tagged before being shipped* to Hypro for service or warranty consideration. Hypro reserves the right to request a Material Safety Data
Sheet from the returnee for any pump/product it deems necessary. Hypro reserves the right to “disposition as scrap” products returned
whichcontainunknownfluids.Hyproreservestherighttochargethereturneeforanyandallcostsincurredforchemicaltesting,andproper
disposalofcomponentscontainingunknownfluids.Hyprorequeststhisinordertoprotecttheenvironmentandpersonnelfromthehazards
ofhandlingunknownfluids.
BepreparedtogiveHyprofulldetailsoftheproblem,includingthemodelnumber,dateofpurchase,andfromwhomyoupurchasedyour
product.Hypromayrequestadditionalinformation,andmayrequireasketchtoillustratetheproblem.
Contact Hypro Service Department at 800-468-3428 to receive a Return Merchandise Authorization number (RMA#).
ReturnsaretobeshippedwiththeRMAnumberclearlymarkedontheoutsideofthepackage.Hyproshallnotbeliableforfreightdamage
incurredduring shipping.Please packageall returnscarefully. Allproducts returnedfor warrantyworkshouldbesent shipping charges
prepaidto:
HYPRO / PENTAIR
 Attention:ServiceDepartment
 375FifthAvenueNW
 NewBrighton,MN55112
For technical or application assistance, call the Hypro Technical/Application number: 800-445-8360,or send anemail to:technical@
hypropumps.com. To obtain service or warranty assistance, call the Hypro Service and Warranty number:800-468-3428;orsendafax
to the Hypro Service and Warranty FAX:651-766-6618.
*Carriers, including U.S.P.S., airlines, UPS, ground freight, etc., require specific identification of any hazardous material being shipped. Failure to do so may
resultinasubstantialfineand/orprisonterm.Checkwithyourshippingcompanyforspecificinstructions.
375 Fifth Avenue NW •New Brighton, MN 55112 USA
Phone: [phone] •800-424-9776 •
Fax: [phone]
www.hypropumps.com
Hypro (06/14)
Printed in USA
Visit www.hypropumps.com/register today to register
your product and stay up-to-date on new products and
promotional offers.
Thefollowinginformationisrequired:  
Model # _______________ Serial # _______________
