peplink balance ONE User manual

User Manual
For Models:
ONE/20/30/30 LTE/50/210/310/305/380/580/710/1350/2500
MediaFast 200/500
Peplink Balance Firmware 6.2.2
December 2015
Copyright & trademark specifications are subject to change without prior notice. Copyright © 2015 Peplink International Ltd. All Rights
Reserved. Peplink and the Peplink logo are trademarks of Peplink International Ltd. Other brands or products mentioned may be
trademarks or registered trademarks of their respective owners.
Peplink Balance Multi-WAN Bonding Routers

USER MANUAL
Peplink Balance Series
http://www.peplink.com -2 / 261- Copyright © 2015 Peplink
TABLE OF CONTENTS
1INTRODUCTION AND SCOPE·················································································· 7
2GLOSSARY ················································································································ 8
3PRODUCT COMPARISON CHART ·········································································· 9
Capacity ······················································································································· 9
Core Functionality ······································································································ 10
VPN Functionality······································································································· 11
WLAN Control ············································································································ 12
Advanced QoS ··········································································································· 13
Networking Functionality ···························································································· 14
Device ························································································································ 16
Hardware···················································································································· 18
4PRODUCT FEATURES···························································································· 19
4.1 Supported Network Features············································································· 19
4.2 WAN·················································································································· 19
4.3 LAN ··················································································································· 19
4.4 VPN··················································································································· 19
4.5 Inbound Traffic Management············································································· 20
4.6 Outbound Policy ································································································ 20
4.7 AP Controller ····································································································· 20
4.8 QoS ··················································································································· 20
4.9 Firewall·············································································································· 20
4.10 Captive Portal································································································· 21
4.11 Other Supported Features·············································································· 21
5PACKAGE CONTENTS ··························································································· 22
5.1 Peplink Balance One························································································· 22
5.2 Peplink Balance 20/30/30 LTE/50 ····································································· 22
5.3 Peplink Balance 210/310··················································································· 22
5.4 Peplink Balance 305/380/580/710/1350/2500··················································· 22
5.5 Peplink MediaFast 200······················································································ 22
5.6 Peplink MediaFast 500······················································································ 22
6PEPLINK BALANCE OVERVIEW··········································································· 23
6.1 Peplink Balance One························································································· 23
6.2 Peplink Balance 20···························································································· 25
6.3 Peplink Balance 30···························································································· 27
6.4 Peplink Balance 30 LTE ···················································································· 29
6.5 Peplink Balance 50···························································································· 31

USER MANUAL
Peplink Balance Series
http://www.peplink.com -3 / 261- Copyright © 2015 Peplink
6.6 Peplink Balance 210·························································································· 33
6.7 Peplink Balance 310·························································································· 35
6.8 Peplink Balance 305·························································································· 37
6.9 Peplink Balance 380·························································································· 40
6.10 Peplink Balance 580······················································································· 43
6.11 Peplink Balance 710······················································································· 46
6.12 Peplink Balance 1350····················································································· 49
6.13 Peplink Balance 2500····················································································· 52
6.14 Peplink MediaFast 500··················································································· 56
7INSTALLATION········································································································ 59
7.1 Preparation········································································································ 59
7.2 Constructing the Network ·················································································· 59
7.3 Configuring the Network Environment······························································· 61
8BASIC CONFIGURATION ······················································································· 62
8.1 Connecting to the Web Admin Interface···························································· 62
8.2 Configuration with the Setup Wizard ································································· 63
8.3 Advanced Setup ································································································ 67
8.4 Cellular WAN····································································································· 68
9MEDIAFAST CONFIGURATION ············································································· 74
9.1 Setting Up MediaFast Content Caching ···························································· 74
9.2 Scheduling Content Prefetching ········································································ 75
9.3 MDM Settings···································································································· 77
9.4 Viewing MediaFast Statistics············································································· 78
10 CONFIGURING THE LAN INTERFACE(S) ···························································· 79
10.1 LAN Configuration with VLAN ········································································ 86
11 DROP-IN MODE ······································································································· 91
12 CONFIGURING THE WAN INTERFACE(S) ··························································· 94
12.1 Physical Interface Settings ············································································· 96
12.2 Connection Method(s) ···················································································· 97
WAN Health Check ·································································································· 105
12.3 Bandwidth Allowance Monitor ······································································ 108
12.4 Additional Public IP Settings········································································· 109
12.5 Dynamic DNS Settings················································································· 110
13 PEPVPN WITH SPEEDFUSIONTM BANDWIDTH BONDING ······························ 112
13.1 SpeedFusionTM Settings ··············································································· 112
13.2 The Peplink Balance Behind a NAT Router ················································· 118
13.3 SpeedFusionTM Status·················································································· 119

USER MANUAL
Peplink Balance Series
http://www.peplink.com -4 / 261- Copyright © 2015 Peplink
14 IPSEC VPN ············································································································· 120
14.1 IPsec VPN Settings ······················································································ 120
14.2 IPsec Status ································································································· 123
15 OUTBOUND POLICY MANAGEMENT································································· 124
15.1 Outbound Policy ··························································································· 125
15.2 Custom Rules for Outbound Policy ······························································ 126
16 INBOUND ACCESS ······························································································· 134
16.1 Definition of Servers on LAN ········································································ 134
16.2 Definition of Port Forwarding ········································································ 135
16.3 Inbound Access Services ············································································· 137
16.4 Reverse Lookup Zones ················································································ 153
16.5 DNS Record Import Wizard ·········································································· 157
17 NAT MAPPINGS····································································································· 161
18 CAPTIVE PORTAL································································································· 163
19 QOS························································································································· 166
19.1 User Groups ································································································· 166
19.2 Bandwidth Control ························································································ 167
19.3 Application···································································································· 168
20 FIREWALL·············································································································· 170
20.1 Outbound and Inbound Firewall Rules ························································· 170
21 OSPF & RIPV2 ······································································································· 177
22 REMOTE USER ACCESS ····················································································· 180
MISCELLANEOUS SETTINGS······················································································ 182
22.1 High Availability ···························································································· 182
22.2 Certificate Manager ······················································································ 185
22.3 Service Forwarding ······················································································ 185
22.4 Service Passthrough ···················································································· 187
23 AP···························································································································· 189
23.1 AP Controller ································································································ 189
23.2 Wireless SSID ······························································································ 190
23.3 Profiles ········································································································· 195
23.4 Info ··············································································································· 199
23.5 Usage··········································································································· 200
23.6 AP Status ····································································································· 202
23.7 Rogue AP ····································································································· 204
23.8 Toolbox ········································································································ 204

USER MANUAL
Peplink Balance Series
http://www.peplink.com -5 / 261- Copyright © 2015 Peplink
24 SYSTEM SETTINGS ······························································································ 205
24.1 Admin Security ····························································································· 205
24.2 Firmware ······································································································ 209
24.3 Time ············································································································· 210
24.4 Email Notification·························································································· 211
24.5 Event Log ····································································································· 213
24.6 SNMP··········································································································· 214
24.7 InControl······································································································· 216
24.8 Configuration ································································································ 217
24.9 Feature Add-ons··························································································· 218
24.10 Reboot······································································································· 218
25 TOOLS ···················································································································· 219
25.1 Ping ·············································································································· 219
25.2 Traceroute Test ···························································································· 220
25.3 CLI (Command Line Interface) Support························································ 220
26 STATUS ·················································································································· 222
26.1 Device ·········································································································· 222
26.2 Active Sessions ···························································································· 224
26.3 Client List······································································································ 226
26.4 WINS Client·································································································· 226
26.5 OSPF & RIPv2 ····························································································· 226
26.6 SpeedFusionTM Status ·················································································· 227
26.7 Event Log ····································································································· 229
26.8 Bandwidth····································································································· 231
APPENDIX A. RESTORATION OF FACTORY DEFAULTS········································ 236
APPENDIX B. ROUTING UNDER DHCP, STATIC IP, AND PPPOE ·························· 237
B.1 Routing Via Network Address Translation (NAT) ········································· 237
B.2 Routing Via IP Forwarding············································································ 238
APPENDIX C. CASE STUDIES ····················································································· 239
C.1 Performance Optimization ············································································ 239
C.2 Maintaining the Same IP Address Throughout a Session ···························· 243
C.3 Bypassing the Firewall to Access Hosts on LAN ·········································· 244
C.4 Inbound Access Restriction·········································································· 245
C.5 Outbound Access Restriction ······································································· 246
APPENDIX D. TROUBLESHOOTING··········································································· 247
APPENDIX E. PRODUCT SPECIFICATIONS ······························································ 249
E.1 Peplink Balance 20, 30, 30 LTE, and 50 ······················································ 249

USER MANUAL
Peplink Balance Series
http://www.peplink.com -6 / 261- Copyright © 2015 Peplink
E.2 Peplink Balance 210 and 310······································································· 250
E.3 Peplink Balance 380····················································································· 251
E.4 Peplink Balance 305····················································································· 252
E.5 Peplink Balance 380····················································································· 253
E.6 Peplink Balance 580····················································································· 254
E.7 Peplink Balance 710····················································································· 255
E.8 Peplink Balance 1350··················································································· 256
E.9 Peplink Balance 2500··················································································· 257
E.10 Peplink MediaFast 200/500 ·········································································· 258
APPENDIX F. DECLARATION ······················································································ 259

USER MANUAL
Peplink Balance Series
http://www.peplink.com -7 / 261- Copyright © 2015 Peplink
1Introduction and Scope
The Peplink Balance series provides link aggregation and load balancing across up to
thirteen WAN connections.
The Peplink Balance series offers cost-effective solutions suitable for SOHO/power
users and small businesses. The Balance lineup also features a range of advanced
enterprise solutions. Peplink enterprise routers are ideal single-box solutions for
medium to large business environments, and they allow service providers to enable
highly available multi-network services.
The Peplink MediaFast series downloads and buffers video, audio, iTunes/iTunes U,
HTTP, and other content for uninterrupted learning and fun anytime.
This manual applies to the following Peplink Balance products:
Peplink Balance 20/30 (firmware version v6.2.1)
Peplink Balance 30 LTE (firmware version v6.2.1)
Peplink Balance 50 (firmware version v6.2.1)
Peplink Balance 210/310 (firmware version v6.2.1)
Peplink Balance 380 (firmware version v6.2.1)
Peplink Balance 580 (firmware version v6.2.1)
Peplink Balance 710 (firmware version v6.2.1)
Peplink Balance 1350 (firmware version v6.2.1)
Peplink Balance 2500 (firmware version v6.2.1)
Peplink MediaFast 200/500 (firmware version v6.2.1)
The manual covers setting up your Peplink Balance or MediaFast and provides a
collection of case studies detailing the advanced features of the Peplink Balance.
Important Note to Users Upgrading from Firmware 4.7 or below
If your current firmware version is 4.7 or below, please upgrade to Firmware 4.8.2 before upgrading to Firmware
6.2.1
Important Note to Users of the Peplink Balance 30 (Classic Edition)
Firmware 5.0 or above is NOT applicable to the Peplink Balance 30 (Classic Edition). For more information on
identifying the generation of your Peplink Balance 30, please visit our knowledge base at
<http://www.peplink.com/index.php?view=faq&id=231&path=16>.

USER MANUAL
Peplink Balance Series
http://www.peplink.com -8 / 261- Copyright © 2015 Peplink
2Glossary
The following terms, acronyms, and abbreviations are frequently used in this manual:
Term
Definition
3G
3rd generation standards for wireless communications (e.g.,
HSDPA)
4G
4th generation standards for wireless communications (e.g.,
WiMAX, LTE)
DHCP
Dynamic Host Configuration Protocol
DNS
Domain Name System
EVDO
Evolution-Data Optimized
FQDN
Fully Qualified Domain Name
HSDPA
High-Speed Downlink Packet Access
HTTP
Hyper-Text Transfer Protocol
ICMP
Internet Control Message Protocol
IP
Internet Protocol
LAN
Local Area Network
MAC Address
Media Access Control Address
MTU
Maximum Transmission Unit
MSS
Maximum Segment Size
NAT
Network Address Translation
PPPoE
Point to Point Protocol over Ethernet
QoS
Quality of Service
SNMP
Simple Network Management Protocol
TCP
Transmission Control Protocol
UDP
User Datagram Protocol
VPN
Virtual Private Network
VRRP
Virtual Router Redundancy Protocol
WAN
Wide Area Network
WINS
Windows Internet Name Service
WLAN
Wireless Local Area Network
210+
Refers to Peplink Balance 210/310/380/580/710/1350/2500
380+
Refers to Peplink Balance 380/580/710/1350/2500

USER MANUAL
Peplink Balance Series
http://www.peplink.com -9 / 261 - Copyright © 2015 Peplink
3Product Comparison Chart
20/30/50
30
LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A
500-B
Capacity
WAN Ports
(GbE)/Internet
Links
2/3/5
2
2
2
3
3
5
7
13
12
21
51
USB WAN
Modem Port
1
1
1
1
1
1
1
1
1
1
1
1
Embedded
LTE Modem
X
1
X
X
X
X
X
X
X
X
X
X
Recommended
Users
1-25
1-25
1-50
1-50
1-50
50-
500
300-
1000
500-
2000+
1000-
5000+
5000-
20000+
1-50
300-1000
Router
Throughput
100M
100M
1Gbps
200M
200M
400M
800M
1Gbps
2Gbps
8Gbps
80<M
250M
1MediaFast 200 has WAN 1 activated. To activate WAN 2, a Load Balancing or SpeedFusion license is required. MediaFast 500-B
WAN ports 1-5 are active by default. Load balancing or SpeedFusion license is required to activate MediaFast 500-A WAN ports 2-5.

USER MANUAL
Peplink Balance Series
http://www.peplink.com -10 / 261 - Copyright © 2015 Peplink
20/30/50
30
LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A 500-B
Core Functionality
Load Balancing &
Failover
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Load Balancing
Algorithms
7
7
7
7
7
7
7
7
7
7
7
7
Weighted
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Enforced
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Persistence
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Priority
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Overflow
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Least Used
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Lowest Latency
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Drop-In Mode
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Inbound Load
Balancing
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
4G/3G Modem Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Scheduled Content
Caching
X
X
X
X
X
X
X
X
X
X
Yes
Yes

USER MANUAL
Peplink Balance Series
http://www.peplink.com -11 / 261 - Copyright © 2015 Peplink
20/30/50
30
LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A
500-B
VPN Functionality
SpeedFusionTM
Hot Failover
X
X
X2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SpeedFusionTM
WAN Smoothing
X
X
X2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SpeedFusionTM
Bandwidth
Bonding
X
X
X2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SpeedFusionTM
Peers
X
X
X2
2
2
30
50
300
800
4000
2
2/50
Bonded VPN
Throughput
X
X
X
30M
30M
60M
80M
150M
350M
2Gbps
X
X
L2TP with IPsec
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PPTP VPN
Server
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Recommended
PPTP VPN
Users
15
15
15
15
15
50
100
200
500
1000
15
100
2SpeedFusion is available on the Balance One as an optional feature, supporting 2 peers.

USER MANUAL
Peplink Balance Series
http://www.peplink.com -12 / 261 - Copyright © 2015 Peplink
RADIUS / LDAP
Support for
PPTP
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IPsec VPN
(Network-to-
Network)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Number of IPsec
Tunnels
2
2
2
2
2
20
50
150
400
800
2
50
Certificate
Manager
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
20/30/50
30 LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A 500-B
WLAN Control
Pepwave AP
One
Management
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Access Point
Configuration
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AP Profiles
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
AP Firmware
Update
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Number of
APs
Supported
10
10
10
10
10
50
100
250
500
1500
50
100

USER MANUAL
Peplink Balance Series
http://www.peplink.com -13 / 261 - Copyright © 2015 Peplink
20/30/50
30 LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A 500-B
Advanced QoS
Bandwidth
Usage
Monitor
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
QoS for VoIP
and
Ecommerce
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DSL/Cable
Optimization
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Application
Prioritization
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Application
Prioritization
by User
Group
X
X
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
User Group
Bandwidth
Reservation
X
X
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Individual
Bandwidth
Limit
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes

USER MANUAL
Peplink Balance Series
http://www.peplink.com -14 / 261 - Copyright © 2015 Peplink
20/30/50
30
LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A 500-B
Networking
Functionality
NAT and IP
Forwarding
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Static Routes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Port Forwarding
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Forwarding Server
Definition
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Many-to-One, One-
to-One NAT
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
NAT Pool
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SIP ALG, H.323 ALG
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
UPnP, NAT-PMP
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
WINS Server
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Dynamic DNS
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Web Blocking
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DNS Proxy
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DNS Record
Delegation
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DNS Record Import
Wizard
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Reverse Lookup
Zones
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes

USER MANUAL
Peplink Balance Series
http://www.peplink.com -15 / 261 - Copyright © 2015 Peplink
Inter-VLAN Routing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DHCP Relay
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
BOOTP Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Inbound Access
Services
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Outbound Policy
Management
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
LACP (802.3ad)
support
X
X
X
X
X
Yes
Yes
Yes
Yes
Yes
X
Yes
OSPF and RIPv2
Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Service/SMTP/Web
Proxy/DNS
Forwarding
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Service Passthrough
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Ping/Traceroute Test
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
PepVPN
Test/Analyzer
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
CLI Support
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes

USER MANUAL
Peplink Balance Series
http://www.peplink.com -16 / 261 - Copyright © 2015 Peplink
20/30/50
30 LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A 500-B
Device
Web
Administrative
Interface
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Admin/User
Access Levels
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Active Client
List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Active Session
List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
WINS Client
List
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Bandwidth
Allowance
Monitor
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Web Reporting
Services
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Email
Notification
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Syslog
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SNMP v1, v2c
and v3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
InControl
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
WAN Health
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes

USER MANUAL
Peplink Balance Series
http://www.peplink.com -17 / 261 - Copyright © 2015 Peplink
Check
Captive Portal
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Firewall
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Intrusion
Detection and
DoS
Prevention
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
High
Availability
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X
X

USER MANUAL
Peplink Balance Series
http://www.peplink.com -18 / 261 - Copyright © 2015 Peplink
20/30/5
0
30 LTE
One
210
310
380
580
710
1350
2500
MediaFast
200
MediaFast
500-A
500-B
Hardware
LAN Ports
(GbE)
4
4
4
7
7
3
3
3
3
8/
2(10GbE
SFP+)
8
3
Power Input
9V-16V
DC
9V-16V
DC
9V-
16V
DC
12V-
24V
AC DC
12V-
24V
AC DC
100V
to
240V
AC
100V
to
240V
AC
100V
to
240V
AC
100V
to
240V
AC
100V to
240V AC
12V-48V
DC
100V to
240V AC
Power
Consumption
15W
15W
15W
15W
15W
50W
50W
70W
70W
230W
38W
50W
1U
Rackmount
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X
Yes
High
Availability
X
X
X
Yes
Yes
Yes
Yes
Yes
Yes
Yes
X
Yes
LAN Bypass
X
X
X
X
X
X
Yes
Yes
Yes
Yes
X
Yes
Dimensions
(H x W x D)
3.5 x
26 x
13.3cm
4.4 x
29.3 x
15.9cm
3 x
27.1 x
16cm
1U x
27.3cm
1U x
27.8cm
1U x
37.9cm
1U x
39.8cm
1U x
55cm
29.2
x
17.7
x
5cm
1U x
27.8cm
29.2 x
17.7 x 4.4
cm
24.1 x
30.5 x 4.4
cm
Weight
1.0kg
1.0kg
1.0kg
1.2kg
1.2kg
3.5kg
5.5kg
5.5kg
6.5kg
12kg
1.9kg
5.5kg

USER MANUAL
Peplink Balance Series
http://www.peplink.com -19 / 261 - Copyright © 2015 Peplink
4Product Features
Peplink Balance Series products enable all LAN users to share broadband Internet
connections and provide advanced features to enhance Internet access. The following
is a list of supported features:
4.1 Supported Network Features
4.2 WAN
Multiple public IP support (DHCP, PPPoE, static IP address)
Static IP support for PPPoE
10/100/1000Mbps Ethernet connection in full/half duplex
Built-in HSPA and EVDO cellular modems
USB mobile connection (only one USB modem can be connected at a time)
Drop-in mode on selectable WAN port with MAC address passthrough network
address translation (NAT) / port address translation (PAT)
Inbound and outbound NAT mapping
Multiple static IP addresses per WAN connection
MAC address clone
Customizable MTU and MSS values
WAN connection health check
Dynamic DNS (supported service providers: changeip.com, dyndns.org, no-
ip.org,tzo.com, and DNS-O-Matic)
Ping, DNS lookup, and HTTP-based health check
4.3 LAN
DHCP server on LAN
Extended DHCP option support
Static routing rules
Local DNS proxy server
VLAN on LAN support
4.4 VPN
Secure SpeedFusionTM
SpeedFusion performance analyzer
X.509 certificate support (feature activation required on some Balance
models)
Bandwidth bonding and failover among selected WAN connections
Ability to route traffic to a remote VPN peer
Optional pre-shared key setting

USER MANUAL
Peplink Balance Series
http://www.peplink.com -20 / 261 - Copyright © 2015 Peplink
Layer 2 bridging
Layer 2 Peer Isolation
SpeedFusionTM throughput, ping, and traceroute tests
Built-in L2TP / PPTP VPN server
Authenticate L2TP / PPTP clients using RADIUS and LDAP servers
Multi-Site PepVPN Profile
IPsec VPN for network-to-network connections (works with Cisco and Juniper
only)
L2TP / PPTP and IPsec passthrough
4.5 Inbound Traffic Management
TCP/UDP traffic redirection to dedicated LAN server(s)
Inbound link load balancing by means of DNS
4.6 Outbound Policy
Link load distribution per TCP/UDP service
Persistent routing for specified source and/or destination IP addresses per
TCP/UDP service
Prioritize and route traffic to VPN tunnels with Priority and Enforced algorithms
4.7 AP Controller
Configure and manage Pepwave AP devices
Review the status of connected AP
4.8 QoS
Quality of service for different applications and custom protocols
User group classification for different service levels
Bandwidth usage control and monitoring on group- and user-level
Application prioritization for custom protocols and DSL optimization
4.9 Firewall
Outbound (LAN to WAN) firewall rules
Inbound (WAN to LAN) firewall rules per WAN connection
Intrusion detection and prevention
Specification of NAT mappings
Web blocking
