peplink PEPWAVE FlexModule Mini User manual

FlexModule Mini User Guide
For Balance 20X / 380X / 580X
Sep 2021
Important Notes
1. Please handle the connectors with care as to not damage them.
2. LTE-A (CAT-6) and LTE-A Pro (CAT-12) FlexModule Minis have 2x cellular antenna
connectors while LTE-A Pro (CAT-18) and 5G have 4x cellular antenna connectors. So if
you are upgrading from LTE-A (CAT-6) or LTE-A Pro (CAT-12) to either LTE-A Pro
(CAT-18) or 5G, you will require additional antennas.
3. FlexModule Minis are fully interchangeable with other FlexModule Minis, e.g. Ethernet,
and cellular.

Procedure for changing the FlexModule Mini on
the B380X/B580X
Step 1: Power off the router. The router MUST be disconnected from power before starting the
upgrade.
Step 2: Disconnect all antennas.
Step 3: Loosen the screws on the cover or the installed FlexModule Mini.
Step 4: Remove the cover or module by pulling them out directly.
https://www.peplink.com 2 Copyright @ 2021

Step 5: Loosen the screws of the new FlexModule Mini in order to remove the module cover
which is for the Balance 20X.
Step 6: Install the 380X/580X module cover and tighten the screws.
Step 7: Install the new module. Make sure it is correctly aligned before pressing the module
firmly into place. The FlexModule Mini should sit flush with the router chassis.
https://www.peplink.com 3 Copyright @ 2021

Step 8: Tighten the screws until the FlexModule Mini sits flush and tight with the collar.
Step 9: Reconnect the antennas.
Step 10: Reconnect the power.
https://www.peplink.com 4 Copyright @ 2021

Procedure for changing the FlexModule Mini on
the B20X
Step 1: Power off the router. The router MUST be disconnected from power before starting the
upgrade.
Step 2: Disconnect all antennas.
Step 3: Loosen the screws on the cover or the installed FlexModule Mini.
https://www.peplink.com 5 Copyright @ 2021

Step 4: Remove the cover or module by pulling it out directly.
Step 5: Install the new module. Make sure it is correctly aligned before pressing the module
firmly into place. The FlexModule Mini should sit flush with the router chassis.
Step 6: Tighten the screws until the FlexModule Mini sits flush and tight with the collar.
https://www.peplink.com 6 Copyright @ 2021

Step 7: Reconnect the antennas.
Step 8: Reconnect the power.
https://www.peplink.com 7 Copyright @ 2021

FCC Requirements for Operation in the United States
Federal Communications Commission (FCC) Compliance Notice:
For FlexModule Mini
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy, and if it
is not installed and used in accordance with the instruction manual, it may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case the user will be required to correct the interference
at his own expense.
Any changes or modifications not expressly approved by the party responsible for compliance
could void your authority to operate the equipment.
https://www.peplink.com 8 Copyright @ 2021

CE Statement for Pepwave Product ( FlexModule Mini for MV31-W )
https://www.peplink.com 9 Copyright @ 2021

https://www.peplink.com 10 Copyright @ 2021

WWAN : Refer 3GPP TS 36.521 -1 ( UE Power class )
This equipment complies with CE radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
20cm between the radiator & your body.
contact as: https://www.peplink.com/
https://www.peplink.com 11 Copyright @ 2021

CE Statement for Pepwave Product ( FlexModule Mini for MC7455 )
https://www.peplink.com 12 Copyright @ 2021

https://www.peplink.com 13 Copyright @ 2021

WWAN : Refer 3GPP TS 36.521 -1 ( UE Power class )
This equipment complies with CE radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
20cm between the radiator & your body.
contact as: https://www.peplink.com/
