Pepperl+Fuchs IC-HH20-V1 User manual

IC-HH20-V1
Handheld
FACTORY AUTOMATION
MANUAL

With regard to the supply ofproducts, the current issue of the following documentis applicable: The
General Terms of Delivery for Products and Services of the Electrical Industry, published by the
Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie
(ZVEI) e.V.) in its mostrecent version as well as the supplementary clause: "Expanded reservation
of proprietorship"
IC-HH20-V1

IC-HH20-V1
Contents
259778 2013-02
3
1 Introduction......................................................................... 6
2 Declaration of conformity.................................................. 7
2.1 CE conformity ...............................................................................................7
2.2 Declaration of Conformity..............................................................................7
3 Safety................................................................................... 8
3.1 Symbols relevant to safety ............................................................................8
3.2 Intended use .................................................................................................8
3.3 General safety instructions ............................................................................9
4 Product Description ......................................................... 10
4.1 Use and Application....................................................................................10
4.2 Displays and Controls .................................................................................11
4.2.1 Status LED..............................................................................................12
4.2.2 Display ...................................................................................................12
4.2.3 Button overview......................................................................................14
4.3 Connections................................................................................................16
4.4 Scope of Delivery........................................................................................16
5 Installation......................................................................... 17
5.1 Preparation .................................................................................................17
5.2 Handle attachment......................................................................................19
6 Commissioning................................................................. 22
6.1 Switching on/off ..........................................................................................22
6.2 Basic operation........................................................................................... 22
6.2.1 Navigating through menus......................................................................22
6.2.2 Data input ...............................................................................................23
6.3 Connecting a Read/Write Head ..................................................................23
6.4 Operating modes ........................................................................................24
6.4.1 Wireless operation (batch mode)............................................................24
6.4.2 Cable operation: RS 232 ........................................................................ 24
6.4.3 Cable operation: PS/2 ............................................................................25
6.4.4 Cable operation: USB.............................................................................27
6.4.5 Operating with Bluetooth ........................................................................ 28
7 Operation........................................................................... 29
7.1 Teaching In .................................................................................................29
7.2 Read Data...................................................................................................29
7.3 Write Data ...................................................................................................30
7.4 Editing or Entering Data Manually ...............................................................32

259778 2013-02
4
IC-HH20-V1
Contents
8 Troubleshooting ............................................................... 34
8.1 Error Message "Unknown System"............................................................. 34
8.2 "No transponder" fault message................................................................. 34
8.3 "No connection!" fault message ................................................................. 34
8.4 "No saved data" fault message ................................................................... 35
8.5 "No data to copy" fault message................................................................. 35
9 Software description PF_Ident ....................................... 36
9.1 Menu Read/Write ....................................................................................... 36
9.1.1 Read/Write > Read data ........................................................................ 37
9.1.2 Read/Write > Write data......................................................................... 41
9.1.3 Read/Write > Copy data......................................................................... 45
9.1.4 Read/Write > Read fixcode.................................................................... 48
9.1.5 Read/Write > Format data car. ............................................................... 52
9.1.6 IP* Read/Write Heads............................................................................ 55
9.1.7 IS* Read/Write Heads............................................................................ 68
9.2 Menu Memory............................................................................................ 80
9.2.1 Memory > Options ................................................................................. 81
9.3 Menu Settings ........................................................................................... 84
9.3.1 Settings > Tag Type ............................................................................... 85
9.3.2 Settings > Data format ........................................................................... 87
9.3.3 Settings > Trigger buttons...................................................................... 88
9.3.4 Settings > Time stamp ........................................................................... 88
9.3.5 Settings > Check sum............................................................................ 89
9.3.6 Settings > Prefix/suffix ........................................................................... 90
9.3.7 Settings > Interface................................................................................ 90
9.3.8 Settings > Send/Save ............................................................................ 93
9.3.9 Settings > Language.............................................................................. 94
9.3.10 Settings > Date/time .............................................................................. 95
9.3.11 Settings > System.................................................................................. 95
9.3.12 Settings > Vibration................................................................................ 96
9.3.13 Settings > Buzzer................................................................................... 97
9.3.14 Settings > Default settings ..................................................................... 97
9.3.15 IP* Read/Write Heads............................................................................ 55
9.4 Menu Applications.................................................................................... 100
9.5 Menu Info ................................................................................................. 101

IC-HH20-V1
Contents
259778 2013-02
5
10 Commands...................................................................... 102
10.1 General Information about Command References.....................................102
10.2 IP* Read/Write Heads................................................................................. 55
10.2.1 Command Reference ........................................................................... 102
10.3 IS* Read/Write Heads.................................................................................68
10.3.1 Command Reference ........................................................................... 105
10.4 IQ* Read/Write Heads............................................................................... 108
10.4.1 Command reference.............................................................................108
10.5 Special Command Modes for IPC03 Read/Write Tags..............................110
11 ASCII table....................................................................... 115

259778 2013-02
6
IC-HH20-V1
Introduction
1Introduction
Congratulations
You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs
develops, produces and distributes electronic sensors and interface modules for
the market of automation technology on a worldw ide scale.
Before you install this device and put it into operation, please read the operating
instructions thoroughly. The instructions and notes contained in this operating
manual will guide you step-by-step thro ugh the installation and commissioning
procedures to ensure trouble-free use of this product. By doing so, you:
■guarantee safe operation of the device
■can utilize the entire range of device functions
■avoid faulty operation and the associated errors
■reduce costs from downtimes and incidental repairs
■increase the effectiveness and operating efficiency of your plant.
Store this operating manual somewhere safe in order to have it available for future
work on the device.
After opening the packaging, please ensure that the device is intact and that the
package is co mplete.
Symbols used
The following symbols are used in this manual:
Handling instructions
You will find handling instructions beside this symbol
Contact
If you have any questions about the device, its functions, or accessories, please
contact us at:
Pepperl+Fuchs GmbH
Lilienthalstraße 200
68307 Mannheim
Telephone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Note!
This symbol draws your attention to important information.

IC-HH20-V1
Declaration of conformity
259778 2013-02
7
2 Declaration of conformity
2.1 CE conformity
This product was developed and manufactured under observance of the
applicable European standards and guidelines.
2.2 Declaration of Conformity
The device has been tested for compliance with FCC regulations Tests confirmed
that all valid FCC rules and regulations h ave been complied with.
Note!
A declaration of conformity can be requested from the manufacturer.
Note!
The device may not be used in the vicinity or in combination with another antenna
or a transmitter in order to meet the requirements stipulated in FCC RF exposure
guidelines.

259778 2013-02
8
IC-HH20-V1
Safety
3Safety
3.1 Symbols relevant to safety
3.2 Intended use
Always operate the device as described in these instructions to ensure that the
device and connected systems function correctly. The protection of operating
personnel and plant is only guaranteed if the device is operated in accordance
with its intended use.
The handheld device was designed to identify RFID code and data carriers within
a defined frequency range and should be used for this purpose only. The devices
are used, for instance, to manually control quality or verify maintenance.
Danger!
This symbol indicates a warning about an immediate possible danger.
In case of ignoring the consequences may range from personal injury to death.
Warning!
This symbol indicates a warning about a possible fault or danger.
In case of ignoring the consequences may cause personal injury or heaviest
property damage.
Caution!
This symbol indicates a warning about a possible fault.
In case of ignoring the devices and any connected facilities or systems may be
interrupted or fail completely.
Caution!
Modified or independent JavaScript programs
The processes involved in the reading and writing of data are susceptible to
external influences and interference.
■Do not modify JavaScript programs from the manufacturer.
■If you write your own JavaScript programs, check that the identification
function is not affected.

IC-HH20-V1
Safety
259778 2013-02
9
3.3 General safety instructions
Installation and commissioning of all devices must be performed by a trained
professional only.
When packing the device for storage or transport, use materials that will protect
the device from bumps and impacts and protect against moisture. The original
packaging provides the best protection. Also take into account the permitted
ambient conditions.
Do not open, burn or short-circuit the battery. The battery may ignite, explode,
leak or heat up and become irreparably damaged.
Always charge the battery using approved cables.
Only use reco mmended original accessories.
The operating company bears responsibility for observing locally applicable
safety regulations.
User modification and or repair are dangerous and will void the warranty and
exclude the manufacturer from any liability. If serious faults occur, stop using the
device. Secure the device against inadvertent operation. In the event of repairs,
return the device to your local Pepperl+Fuchs representative or sales office.
Do not dispose of storage batteries with the household refuse.
Consumers are obliged by law to dispose of used storage batteries in accordance
with regulations. You can hand in your used batteries at public collection points in
your area or sales points where batteries of that particular kind are sold. You can
also send your used batteries directly to us for disposal. Please remember that
this service is only available within the scope of normal use. If you wish to send
back your used batteries, please affix sufficient postage stamps and send to our
address. There are no extra charges for disposal.

259778 2013-02
10
IC-HH20-V1
Product Description
4 Product Description
4.1 Use and Application
Handheld
The IDENTControl system from Pepperl+Fuchs is an established, proven solution
for stationary RFID applications. A mobile device for process control (read/write
functio ns, initia lizing read/write tags) is provided with this handheld as an ideal
enhancement to this system.
The cell-phone-style design with keyboard and display screen offers an intuitive
operating concept. The device features two unassigned keys that can be
programmed with frequently repeated actions. These actions can be executed at
the touch of a button. To further enhance user functionality, a familiar, cross-
platform programming language is provided in JavaScript.
A lithium-ion battery, large nonvolatile memory and the option to communicate
wirelessly within the 2.45 GHz frequency band, based on the Bluetooth standard,
mean that the device is fully portable.
The M12 socket gives you the option of connecting IDENTControl read/write
heads of all frequency ranges to the handheld, thus making the system more
flexible.
Read only / read/write tag 125 kHz (inductive)
A wide range of read only and read/write tag designs are available for this
frequency range, from a 3 mm thin glass tube to a transponder 50 mm in diameter.
Read/write tags are available for temperatures up to 300 °C (max. 5 min) in
chemical-resistant housings for installation in metal and in degree of protection
IP68/IP69K. IPC02-... read only tags offer 40-bit read only codes. IPC03-...
read/write tags have a 928-bit freely programmable memory bank and an
unmodifiable 32-bit read only code. You can define 40-bit read only codes with
IPC11-... read only tags. You can use these as permanent read only codes or
continually redefine them.

IC-HH20-V1
Product Description
259778 2013-02
11
Read/write tag 250 kHz (inductive)
Data carriers from this frequency range achieve a higher reading speed than 125
kHz data carriers. ICC ... code carriers with a 28 bit fix code and IDC ... data
carriers with a memory capacity of 1 kBit are available in various designs.
Read/write tag 13.56 MHz (inductive)
Read/write tags in this frequency range save larger quantities of data and offer a
considerably higher reading speed than read/write tags of the 125 kHz system.
IQH-* and IQH1-* read/write heads from Pepperl+Fuchs are compatible with most
existing read/write tags that comply with standard ISO 15693. With the IQH2-*
read/write heads you can use read/write tags that comply with standard ISO
14443A.
The 13.56 MHz technology even allows smart labels (read/write tags in the form
of adhesive labels with printed barcode). Currently available read/write tags have
a memory capacity of 64 bits of read only code and a maximum 2 KB of
programmable memory.
4.2 Displays and Controls
The device is equipped with the following displays and controls:
1
2
3
4
5
6
7
8
9

259778 2013-02
12
IC-HH20-V1
Product Description
4.2.1 Status LED
The status LED indicates the following states:
Meaning of status LED
4.2.2 Display
The display on the device consists of different areas:
1Status LED
2LC display
3Softkeys
4Navigation keys
5Trigger keys
6Keypad
7Interface
8Battery compartment
9M12 connection for read/write head
Sta t u s Description
Green ■The handheld device is switched on.
■The interface has been changed.
■Data has been read or written.
Ye l l o w f l a s h i n g The handheld device has executed a read or write command
successfully.
Red flashing The handheld device has executed a read or write command
unsuccessfully and indicates an error.
Off Read/write head is inactive
1Toolbar
2Display
3Softkey bar
1
2
3

IC-HH20-V1
Product Description
259778 2013-02
13
The following table lists all the symbols in the status bar and explains what they
mean:
Symbols in the status bar
Symbol Description
Charge state
The battery capacity is between 50 % and 100 %.
The battery capacity is between 20 % and 50 %.
The battery capacity is between 0 % and 20 %. Charge the battery.
Battery is charging.
Connection status
The handheld device is connected to an interface.
RS 232 is the preset interface.
PS/2 is the preset interface.
USB is the preset interface.
Bluetooth is the preset interface.
Data transfer
Data transfer in one direction: Data is sent from the handheld device to
the computer. A response from the computer is not required.
Data transfer in two directions: Data is sent from the handheld device to
the computer. The handheld device then waits for a response from the
computer.
Keyboard mode: The handheld device is connected to the computer
via a USB or PS/2 interface.
Virtual COM port mode: The handheld device emulates an RS 232
interface via the USB interface to allow communication from the
computer to the handheld device as well. A response from the
computer is not required.
Secure mode
Memory status
0 % to 25 % of the internal memory is occupied.
25 % to 50 % of the internal memory is occupied.
50 % to 75 % of the internal memory is occupied.
75 % to 100 % of the internal memory is occupied.

259778 2013-02
14
IC-HH20-V1
Product Description
4.2.3 Button overview
The following table lists all the buttons on the device and their names:
Selection buttons
Navigation keys
The internal memory is full. There internal memory has no more space
to store data.
Batch mode inactive. Data is not cached in the internal memory.
Input mode
Numerical input mode - data entered using the input keys appears in
the numerical form.
Alphabetical input mode - data entered using the input keys appears in
alphabetical form.
Alphabetical input mode - data entered using the input keys appears in
the form of lowercase letters.
Symbol input mode - data entered using the input keys appears in the
form of symbols.
Symbol Description
Button Description
Left selection button
Right selection button
Keys Designation
Up navigation key
Down navigation key
Left navigation key
Right navigation key
Enter navigation key

IC-HH20-V1
Product Description
259778 2013-02
15
Function buttons
Input keys
Button Description
Left function button
(= left trigger button)
Right function button
(= right trigger button)
Keys "Numerical" mode
"Alphanumerical
upper case" mode
"Alphanumerical
lower case"
mode
"Symbols"
mode
Switches between "Numerical", "Alphanumerical upper case",
"Alphanumerical lower case" and "Symbols" mode.
1Space, 1 Space, 1 Space
) < _
2A, B, C, 2 a, b, c, 2 ! * = `
3D, E, F, 3 d, e, f, 3 " + > {
4G, H, I, 4 g, h, i, 4 # , ? |
5J, K, L, 5 j, k, l, 5 $ - @ }
6M, N, O, 6 m, n , o, 6 % . [ ~
7P, Q, R , S, 7 p, q, r, s, 7 & / \
Space
8T, U, V, 8 t, u, v, 8 ' : ]
Space
9W, X, Y, Z w, x, y, z ( ; ^
Space
000Scrolls
through the
different
symbol pages
For data input fields: delete the last character. Otherwise: ESC function (exits
the menu without adopting the current settings.)

259778 2013-02
16
IC-HH20-V1
Product Description
4.3 Connections
The handheld features the following connections:
4.4 Scope of Delivery
The following elements are included in the scope of delivery:
■Handheld device without battery or battery compartment cover
■CD with documentation (manual)
18-pin connecting socket
14-pin M12 socket
1
1
Note!
To complete the device, some other components are required in addition to the
handheld included in the scope of delivery. The basic equipment includes:
handheld, battery, double-ended cordset for handheld/read/write head, and
charger. All components can be obtained from Pepperl+Fuchs.

IC-HH20-V1
Installation
259778 2013-02
17
5Installation
5.1 Preparation
Unpacking the unit
1. Check that all package contents are present and undamaged.
If anything is damaged, inform the shipper and contact the supplier.
2. Check that all items are present and correct based on your order and the
shipping documents.
If you have any questions, please contact Pepperl+Fuchs.
3. Keep the original packing material in case you need to store or ship the unit at
a later time.
Fitting the battery
Fit the battery as follows:
1. Turn the battery so that you can remove it as shown in the illustration.
2. Slide the plastic tab on the battery into the corresponding recess on the
Handheld.
3. Push the locking device upwards and push in the battery.

259778 2013-02
18
IC-HH20-V1
Installation
4. Push the battery in the Handheld, hold in position and release the locking
device so that the battery engages.
Charging the battery
Charge the battery as follows:
1. Connect the handheld device with battery to an interface cable.
2. Make sure the computer is switched on and then connect the interface cable
to computer.
When the handheld device is switched on, the symbols displayed in the
status bar on the handheld device indicate the charge state. See table
"Symbols in the status bar" on page 13
Note!
If you are operating the handheld via an RS 232 interface, connect the RS 232
interface power supply unit to the socket to charge the battery.
Note!
Completely discharged storage batteries
If the storage battery is completely discharged, you will have to wait at least 10
minutes before the Handheld is ready for operation again.

IC-HH20-V1
Installation
259778 2013-02
19
5.2 Handle attachment
Attaching the standard handle
Proceed as follows to attach the grip to the handheld device:
1. Insert the handheld device with battery into the bracket on the handle.
2. Slide back the handheld device until the connector on the handle engages in
the cable connector socket on the handheld device.
3. Push the handheld device firmly onto the connector until it is flush with the
handle.
The handheld device is attached to the handle.
Fitting a handle with cable connection
Fit the handle to the Handheld as follows:
1. Remove the battery from the battery compartment of the Handheld if neces-
sary.
2. Carefully pull the rear, flexible part of the handle attached to the plug
downwards.
3. Attach the cable connection socket on the Handheld to the plug on the
handle.
4. Slide the plastic tab on the battery into the corresponding recess on the
Handheld.

259778 2013-02
20
IC-HH20-V1
Installation
The H andheld is now fitted to the handle.
5. Push down the Handheld carefully until the locking device on the Handheld
engages in the handle.
6. Connect the interface cable to the cable connection socket underneath the
handle.
The Handheld is now ready for operation.
Fitting a handle with integrated storage battery
A handle with integrated battery is also available for this Handheld as an optional
accessory. Fit the handle to the Handheld as follows:
1. Remove the battery from the battery compartment of the Handheld if neces-
sary.
2. Slide the plastic tab on the battery into the corresponding recess on the
Handheld.
3. Push down the Handheld carefully until the locking device on the Handheld
engages in the handle.
The H andheld is now fitted to the handle.
Securing the interface cable to prevent inadvertent removal
You have the option of attaching a cord grip to prevent the interface cable from
being pulled out inadvertently. Proceed as follows:
1. Secure the interface cable to the cable connection socket on the handle.
2. Guide the cable through the slot on the cord grip and slide the cord grip
towards the cable connection socket.
3. Make sure that you slide the cord grip over the interface cable and into the
correct position.
4. Screw the cord grip to the handle using the screws provided.
