Pepperl+Fuchs PROFINET IO Power Hub User manual

®
PROFINET IO Power Hub
With HD2-GTR-4PA.PN
Ga t e w a y
PROCESS AUTOMATION
MANUAL

With regard to the supply of products, the current issue of the following document is ap-
plicable: The General Terms of Delivery for Products and Services of the Electrical Indus-
try, published by the Central Association of the Electrical Industry (Zentralverband
Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the
supplementary clause: "Expanded reservation of proprietorship"
PROFINET IO Power Hub

PROFINET IO Power Hub
3
1 Introduction................................................................................. 6
1.1 Contents................................................................................................ 6
1.2 Target Group, Personnel...................................................................... 6
1.3 Symbols Used ...................................................................................... 6
2 Product Specifications............................................................... 8
2.1 Overview and Application ................................................................... 8
2.2 System Components ........................................................................... 8
2.3 Recommended System Combinations............................................. 11
2.4 Component Overview ........................................................................ 13
2.5 Technical Data .................................................................................... 14
2.6 Dimensions......................................................................................... 16
3 PROFINET System Integration ................................................ 17
3.1 PROFINET IO Communication Profile.............................................. 17
3.2 Gateway Device Model ....................................................................... 17
3.3 Gateway Management Function........................................................ 18
3.4 Supported PROFIBUS PA Device Features...................................... 18
3.5 Cyclic IO Data of the PROFIBUS PA Devices................................... 19
3.6 PROFIBUS PA Device Diagnostics ................................................... 19
4 Installation and Commissioning ............................................. 20
4.1 Mounting and Dismounting............................................................... 20
4.2 Shielding/Grounding ......................................................................... 22
4.2.1 Connection to Equipotential Bonding System .................................. 23
4.3 Hazardous Area Installation and Use............................................... 24
4.3.1 Installation in Zone 2, Category 3G .................................................. 24
4.4 Connections ....................................................................................... 25
4.5 Gateway Addressing .......................................................................... 26
4.6 PROFIBUS PA Device Addressing .................................................... 26
4.7 Gateway Configuration....................................................................... 26

4
PROFINET IO Power Hub
4.8 Gateway Device Parameters (DAP Submodules).............................26
4.9 PROFIBUS PA Master Parameters (FAP Submodules) ...................27
4.10 Start-Up Behavior ...............................................................................27
5 System Integration ................................................................... 28
5.1 System Integration in Practice ..........................................................28
5.2 PROFINET GSD File Generator..........................................................28
5.3 PROFINET Redundancy Concepts ...................................................30
6 PROFIBUS Commissioning ..................................................... 33
6.1 Device Type Manager (DTM): Installation and Commissioning .....33
6.2 PROFINET DTM Project......................................................................33
6.3 DTM Offline Project Tree ....................................................................34
6.4 PROFINET Gateway Addressing........................................................36
6.5 Topology Scan ....................................................................................37
6.6 PROFINET Identification and Maintenance (I&M) ..........................39
7 Diagnostic Information and Troubleshooting ........................ 40
7.1 PROFIBUS PA Device Diagnostics....................................................40
7.2 Gateway Diagnostics ..........................................................................40
7.3 Diagnostics Indicated via LEDs ........................................................42
8 Gateway Web Server................................................................. 45
9 Gateway Information and Diagnostics.................................... 46
9.1 Device Identification...........................................................................47
9.2 Device Diagnostics.............................................................................48
9.3 Device Network Information ..............................................................49
9.4 Segment Diagnostics.........................................................................50
9.5 Information on Field Devices of the Segment .................................50
9.6 Gateway Firmware Update (Web Server Only).................................52

PROFINET IO Power Hub
5
9.7 Gateway Documentation .................................................................... 53
10 References ................................................................................ 55

2016-06
6
PROFINET IO Power Hub
Introduction
1Introduction
1.1 Contents
This document contains information that you need in order to use your product throughout the
applicable stages of the product life cycle. These can include the following:
■Product identification
■Delivery, transport, and storage
■Mounting and installation
■Commissioning and operation
■Maintenance and repair
■Troubleshooting
■Dismounting
■Disposal
The documentation consists of the following parts:
■Present document
■Instruction manual
■Datasheet
Additionally, the following parts may belong to the documentation, if applicable:
■EU-type examination certificate
■EU declaration of conformity
■Attestation of conformity
■Certificates
■Control drawings
■Additional documents
1.2 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance, and
dismounting lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting, installation,
commissioning, operation, maintenance, and dismounting of the product. The personnel must
have read and understood the instruction manual and the further documentation.
Prior to using the product make yourself familiar with it. Read the document carefully.
1.3 Symbols Used
This document contains symbols for the identification of warning messages and of informative
messages.
Note!
This document does not substitute the instruction manual.
Note!
For full information on the product, refer to the instruction manual and further documentation on
the Internet at www.pepperl-fuchs.com.

PROFINET IO Power Hub
Introduction
2016-06
7
Warning Messages
You will find warning messages, whenever dangers may arise from your actions. It is mandatory
that you observe these warning messages for your personal safety and in order to avoid
property damage.
Depending on the risk level, the warning messages are displayed in descending order as
follows:
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note!
This symbol brings important information to your attention.

2016-06
8
PROFINET IO Power Hub
Product Specifications
2 Product Specifications
2.1 Overview and Application
The Pepperl+Fuchs FieldConnex®Power Hub for PROFINET IO is based on a modular
system. The system consists of various motherboards with slots, plug-in modules, e.g., power
supplies, diagnostic modules, and a gateway. The gateway couples up to 4 PROFIBUS PA
segments to PROFINET IO system interfaces. On the PROFIBUS PA trunk a high energy level
is fed to the field devices via device couplers, such as FieldBarriers or Segment Protectors. A
dedicated version of the Power Hub (DART) supports the intrinsically safe concept for fieldbus.
In its basic version, the diagnostic module is used ensure to the functional integrity of the Power
Hub. The advanced version additionally monitors the physical layer of the 4 PROFIBUS PA
segments online, this way enabling the detection of degradation and faults in real-time during
operation. Measurement data and alarms are transmitted to the control room. This makes the
fieldbus physical layer visible and accessible as an active component in plant asset
management systems. Operating personnel are enabled to decide on proactive measures to
avoid unwanted situations while the plant is running smoothly. For further information on the
diagnostic capabilities, refer to the specific product documentation.
The Power Hub offers various redundancy options such as gateway and power supply
redundancy.
A complete tool chain supports the engineering for system integration. A gateway device type
manager (DTM) and a web server enable the access to status and diagnostic of infrastructure
components and connected field devices. The gateway DTM allows using the DTMs of the
connected PROFIBUS PA devices for parameterization, access to diagnostic, and status
information.
R
FDT/DTM
PROFIBUS PA
Device Configuration
Web Browser
PROFINET Configuration
Cyclic data
- Configuration
- IO and status
Diagnostic data
Parameter ???
GSDML Generator
ENGINEERING STATION
PROFINET Configuration
Cyclic data
- Configuration
- IO and status
Diagnostic data
Parameter ???
PROFINET IO Controller
4 x PA Segments
PROFINET
Gateway
and Power Hub
PROFIBUS PA
R
ENGINEERING STATION
PROFINET IO Controller

PROFINET IO Power Hub
Product Specifications
2016-06
9
2.2 System Components
Motherboards
The following types of gateway motherboards are available:
■Compact motherboard MBHC-FB-4.GT: Slots for 1 gateway HD2-GTR-4PA.PN,
4 simplex power supply modules, and 1 diagnostic module. For further information, refer
to the documentation for MBHC-FB-4.GT.
■Gateway motherboard MB-FB-GTR1: 2 slots for up to 2 gateway modules HD2-GTR-
4PA.PN. The gateway motherboard is designed for the use with Power Hub motherboards
holding power supply modules for the supply of PROFIBUS PA segments. The
motherboard can be used with a single gateway for simplex coupling to PROFINET IO or
with 2 gateways for redundant coupling. At the point of issue of this manual, redundant
coupling is not supported yet. For more information, contact you Pepperl+Fuchs
representative.
MB-FB-GTR1 can be used with the following Power Hub motherboards:
• MBHC-FB-4.HSC* supports 4 simplex segments, redundant bulk power supply
• MBHC-FB-4R.HSC* supports 4 redundant segments, redundant bulk power supply
• MBHD-FB-D-4R.GEN supports 4 redundant DART intrinsically safe segments,
redundant bulk power supply
The motherboards are connected with a customized cable that is included in the delivery
of the gateway motherboard.
For further information refer to the respective product documentation at www.pepperl-
fuchs.com.
Ga t e w a y
The PROFINET/PROFIBUS PA gateway module HD2-GTR-4PA.PN connects 4 PROFIBUS PA
segments to PROFINET IO on the performance level “real-time RT”. It supports 2 Ethernet-
switched ports for PROFINET S2 system redundancy and media ring redundancy based on
the media redundancy protocol (MRP).
The gateway features LEDs to diagnose the status of the Ethernet ports, gateway hardware,
redundancy, and the PROFIBUS PA segments.
For system integration the software tool "PROFINET GSD generator" is provided. The
generator builds a PROFINET GSD including all gateway and PROFIBUS PA device-specific
information required for engineering the PROFINET IO system. As input, the GSD files of the
PROFIBUS PA devices used in a specific project are required. The PROFINET GSD is
generated out of the individual GSD files.
Both, a gateway device type manager (DTM) and a PROFINET communication DTM enable
the access and use of the device manufacturer DTMs in oder to parameterize and diagnose the
individual PROFIBUS PA devices.
A web server provides access to gateway-specific and optional physical layer status read-only
information of the 4 segments. Update functionality of gateway firmware is provided.
The gateway is compatible with the motherboards of the following Power Hubs:
■Universal Power Hubs MB–FB–GT, MB–FB–GTR, MBHC–FB-4.GT, MB-FB-GTR1
■Compact Power Hub KT–MB–GTB–2PS
■DART Power Hub KT–MB–GTB–D–2PS
Application documents for the integration of the PROFINET Power Hub into various control
systems are available. For more information, contact your Pepperl+Fuchs representative or visit
pepperl-fuchs.com.

2016-06
10
PROFINET IO Power Hub
Product Specifications
Fieldbus Power Supply Modules
The fieldbus power supplies supply the PROFIBUS PA segments with power. For different
application requirements, dedicated power supply modules are available:
■HCD2-FBPS-1.500. Output: 28 V... 30 V at 500 mA with an intrinsically safe limited
voltage for Zone 2 of Uo= 30 V
■HCD2-FBPS-1.23.500. Output: 21 V...23 V at 500 mA with an intrinsically safe limited
voltage for Zone 2 of Uo= 24 V
■HD2-FBPS-IBD-1.24.360. Output: 24 V at 360 mA for intrinsically safe (DART) segments
installed in Zone 1
The power supply modules provide full galvanic isolation between the bulk power supply and
the PA segments. The modules offer system reliability for applications where cabling and wiring
are routed through critical or harsh electrical environments, with full protection from
electromagnetic interference (EMI).
Power supply modules are plugged into the motherboard slots and can be exchanged during
system operation. In redundant configuration, load is shared between 2 power supply modules.
Diagnostic Modules
Basic Diagnostic Module
The basic diagnostic module provides basic system diagnostics. It monitors the input voltage
of the bulk power supply and each segment for overload and short circuit conditions. Each
power supply module is checked for proper function. Power supply modules operating in
redundant configuration are checked for compatibility. LEDs indicate both status and fault
information. This information can be transmitted via volt-free contact.
For further information refer to the manual "Basic Diagnostic Module " at www.pepperl-
fuchs.com.
Advanced Diagnostic Module
The advanced diagnostic module is a comprehensive measurement tool for the PROFIBUS PA
physical layer, and supports commissioning, online monitoring, and maintenance tasks. The
module provides the exact segment and individual device data needed for detection of
changes in the fieldbus physical layer. Segment measurements include fieldbus voltage and
load current. Device-specific measurements are signal level, noise, and jitter. All data is
transmitted to the control room via Ethernet. The basic edition of the diagnostic manager
displays all data in an easy-to-use user interface. The professional edition of the diagnostic
manager offers extended software functions: the commissioning wizard generates automated
reports; the software displays clear-text messages for troubleshooting of out-of-specification
behavior.
For further information refer to the manual "Advanced Diagnostic Module " at www.pepperl-
fuchs.com.

PROFINET IO Power Hub
Product Specifications
2016-06
11
2.3 Recommended System Combinations
Simplex Power Feed for 4 Segments with Single Gateway
Figure 2.1 MBHC-FB-4.GT motherboard for the simplex supply of 4 segments and 1 gateway
module HD2-GTR-4PA.PN for simplex gateway coupling.
The one-board simplex system with single gateway coupling consists of the following
components:
■Combined Power Hub gateway motherboard MBHC–FB–4.GT
■HD2-GTR-4PA.PN (x 1)
■Power supply modules (x 4)
Optional components:
■Diagnostic module HD2–DM*
■Surge protectors TPH-LBF-IA1.36.DE* (x 4)
■Earth bar for surge protectors ACC–LBF–EB.4
PROFINET IO
Power
4 x PA Fieldbus Trunk
Coupling Segment Supply
PROFIBUS
Power Hub

2016-06
12
PROFINET IO Power Hub
Product Specifications
Redundant Power Feed for 4 Segments with Single Gateway
Figure 2.2 MBHC-FB-4R.HSC motherboard for the redundant supply of 4 segments combined
with the MB-FB-GTR1 motherboard and 1 HD2-GTR-4PA.PN gateway module for
gateway coupling.
The redundant system with gateway coupling for ring redundancy or S2 redundancy consists of
the following components:
■Combined Power Hub gateway motherboard MBHC–FB–4R.HSC*
■Gateway motherboard MB–FB–GTR1 (x 1)
■HD2-GTR-4PA.PN (x 1)
■Power supply modules (x 8)
■Sub-D cable 9 pins for connecting gateway motherboard and Power Hub motherboard
ACC-MB-HGC
Optional components:
■Diagnostic module HD2–DM*
■Surge protectors TPH-LBF-IA1.36.DE* (x 4)
■Earth bar for surge protectors ACC–LBF–EB.4
PROFINET IO
PROFIBUS PA
Power
4 x PA Fieldbus Trunk
Coupling Segment Supply
PROFIBUS
Power Hub

PROFINET IO Power Hub
Product Specifications
2016-06
13
2.4 Component Overview
Figure 2.3 MB-FB-GTR1* component identity
MB-FB-GTR1* Component Overview
1Motherboard MB-FB-GTR1*
2Gateway HD2-GTR-4PA.PN
3Connections: Volt-free contact alarm and diagnostic bus. 
Diagnostic link cable ACC-MB-HDC, optional accessory
4Sub-D interface for the connection of Power Hub motherboards
5Rotary switches for gateway addressing, x1, x10, x100
6Earth connection
7Mounting slot for DIN mounting rail
7
4
5
3
1
2
6

2016-06
14
PROFINET IO Power Hub
Product Specifications
Figure 2.4 HD2-GTR-4PA.PN component identity
2.5 Technical Data
System Overview
HD2-GTR-4PA.PN Component Overview
1Ethernet port 1
2Ethernet port 1 LED 
- Yellow: Communication activity status
3Ethernet port 1 LED 
- Green: Link status:
4Ethernet port 2
5Ethernet port 2 LED
- Yellow: Communication activity status
6Ethernet port 2 LED
- Green: Link status
7LED Seg 1 ... Seg 4: 
- Red: PROFIBUS PA segment 1 …4 status
8LED Red.: Redundancy status
9LED ERR: Error status
10 LED PWR: Power status
PN/PA
Linking
Device
HD2-
GTR-
4PA.PN
Seg4
Seg3
Seg2
Seg1
PWR
Red.
ERR
8
9
10
7
4
6
5
1
3
2
Ambient conditions
Ambient temperature -40 ... 60 °C (-40 ... 140 °F) vertically mounted , -40 ... 70 °C
(-40 ... 158 °F) horizontally mounted
Storage temperature -40 ... 85 °C (-40 ... 185 °F)
Relative humidity < 95 % non-condensing
Shock resistance 15 g 11 ms
Vibration resistance 1 g , 10 ... 150 Hz
Pollution degree max. 2, according to IEC 60664
Corrosion resistance acc. to ISA-S71.04-1985, severity level G3
Mechanical specifications
Degree of protection IP20

PROFINET IO Power Hub
Product Specifications
2016-06
15
HD2-GTR-4PA.PN
MB-FB-GTR1*
Mounting motherboard mounting
Standard conformity
Electromagnetic compatibility NE 21:2011
Degree of protection IEC 60529
Fieldbus standard IEC 61158-2
Shock resistance EN 60068-2-27
Vibration resistance EN 60068-2-6
Data for application in connection with Ex-areas
Statement of conformity TÜV 15 ATEX 7735 X
Group, category, type of
protection, temperature class II 3 G Ex ec IIC T4 Gc
Directive conformity
Directive 2014/30/EU EN 61326-1:2013
International approvals
IECEx approval IECEx TUR 16.0007X
Approved for Ex ec IIC T4 Gc
Supply
Rated voltage 19.2 ... 35 V SELV/PELV
Rated current typ. 135 mA
Power dissipation approx. 3.5 W
Fieldbus interface
Fieldbus type PROFIBUS PA
Number of segments 4
Number of devices per segment max. 36, physical connections, depending on the device
couplers used
Electrical isolation
CH/PROFIBUS DP functional insulation acc. to IEC 61010, rated insulation
voltage 50 Veff
PROFIBUS DP/Supply
CH/CH
CH/Ethernet
All circuits/FE
Ethernet/Supply
Supply
Rated voltage 19.2 ... 35 V SELV/PELV
Rated current 2 ... 3 A
Indicators/operating means
Fault signal VFC alarm output via connectors
Rotary switch bus addressing, gateway-specific

2016-06
16
PROFINET IO Power Hub
Product Specifications
2.6 Dimensions
Figure 2.5 All dimensions in millimeters and without tolerance indication.
Accessories
ACC-MB-HDC Diagnostic link cable, length 6 cm
ACC–MB–HGC Sub-D cable, 9 pins for connecting the gateway
motherboard and Power Hub motherboard. Included in the
delivery of gateway motherboards.
Overview of Ordering Information
HD2–GTR–4PA.PN PROFINET to PROFIBUS PA gateway module,
4 PROFIBUS PA segments.
MB-FB-GTR1* Motherboard for gateway redundancy, slots for 2 gateway
modules.
Component Dimensions
39 mm
(1.5") 169 mm (6.6")
135 mm (5.3")
150 mm (5.9")

PROFINET IO Power Hub
PROFINET System Integration
2016-06
17
3 PROFINET System Integration
3.1 PROFINET IO Communication Profile
The HD2-GTR-4PA.PN is compatible with PROFINET communication profile CP3/5 according
to IEC/EN 61784–2:2015. This communication profile describes the performance
characteristics capabilities of a PROFINET device.
Important PROFINET/PA Performance Characteristics
3.2 Gateway Device Model
The PROFINET/PA gateway is based on the PROFINET IO device model and represents a
modular device that can be used for process data addressing.
The gateway complies with “PROFIBUS Integration in PROFINET IO, Amendment 1 to
Fieldbus Integration into PROFINET IO”.
According to the PROFINET IO device model, each device has slots for inserting modules.
Each module consists of subslots for inserting submodules.
Parameter Characteristics
Conformance class CC B, process automation
Application class Supports process-automation-specific requirements
Communication class Supports PROFINET RT communication
Communication relationship Supports 1 IO AR with 1 input CR and 1 output CR with
1440 bytes each
Physical layer 100Mbit/s, 10Mbit/s full duplex with auto crossover and
auto negotiation
Bridging internal switch 4 priority queues, cut-through switching is not supported
Bridging VLAN Supports virtual local area network (VLAN) priority
handling
Precision time synchronization Not supported
Media redundancy Supports loop prevention, ring redundancy, MRP.
Device redundancy Single gateway, redundant controller, NAP S2
Communication features Fast startup, supervisor AR, implicit AR
SNMP Supports SNMPv1, SNMPv2c
LLDP Supports neighborhood discovery
Configuration in run Not supported
SNTP Support of time synchronization
Shared device Not supported

2016-06
18
PROFINET IO Power Hub
PROFINET System Integration
Mapping PROFIBUS PA Device Data to PROFINET
All information provided by the gateway is accessible using a fixed slot/subslot addressing.
Most of the accessible data is handled by system-specific software. Therefore, no detailed
knowledge on data mapping is required.
* Addresses 50 …126 are not used
Slot 0 contains the “device access point”(DAP) with
all gateway-specific information, including
information on the 2 Ethernet ports.
Slots 1 …4containthe“fieldbus access point”(FAP) with
all PROFIBUS-PA-specific information, such
as, e.g., master parameters.
Slots 053 …099 contain PROFIBUS PA device data from PA
segment 1, device address 3 …49*
Slots 103 …149 contain PROFIBUS PA device data from PA
segment 2, device address 3 …49*
Slots 153 …199 contain PROFIBUS PA device data from PA
segment 3, device address 3 …49*
Slots 203 …249 contain PROFIBUS PA device data from PA
segment 4, device address 3 …49*
Slot 0, subslot 0x8002, Ethernet port 002
Slot 0, subslot 0x8001, Ethernet port 001
Slot 0, subslot 0x8000, Interface
Slot 0, subslot 0x0001, gateway data
Slot 54, subslot 1 PA device 4 slot 0
...
Slot 53, subslot 2 PA device 3 slot 1
Slot 53, subslot 1 PA device 3 slot 0
...
Slot 3 FAP, PA segment3, PA3
Slot 2 FAP, PA segment2, PA2
Slot 1 FAP, PA segment1, PA1
Slot 0 DAP, gateway-specific slot
Slot 153-199, device data PA3
Slot 103-149, device data PA2
Slot 053-099, device data PA1
Slot 4 FAP, PA segment4, PA4
Slot 203-249, device data PA4

PROFINET IO Power Hub
PROFINET System Integration
2016-06
19
3.3 Gateway Management Function
The gateway supports SNMPv1 and SNMPv2c to exchange gateway and network-specific
management information with dedicated tools. The data content is defined in various
specifications and allows mainly to monitor the health status of network components, provided
that information is organized in so–called management information bases (MIBs) that various
standards define. Supported MIBs are:
■MIB-II
■LLDP-MIB
■LLDP-EXT-DOT3-MIB
■LLDP-EXT-PNIO-MIB
The gateway supports mandatory information defined in the specific standard.
3.4 Supported PROFIBUS PA Device Features
PROFIBUS PA devices complying with PROFIBUS DP-V0 and DP-V1 are supported. The
gateway supports following PROFIBUS PA communication features:
■SET_PRM
■SET_CFG
■C2 communication
■Diagnostics, including structured diagnostics
■Module PRM parameters for PROFIBUS PA devices not supporting structured PRM
■PROFIBUS I&M functions
■RD_INPUT
■RD_OUTPUT
■GET_CFG
■Acyclic C1 communication
■Set_Slave_Address
The following PROFIBUS features are not supported because PROFIBUS PA devices cannot
support them:
■Alarms
■EXT_PRM
■Module PRM parameters for PROFIBUS PA devices using structured PRM
■PROFIBUS PA channel diagnostics
3.5 Cyclic IO Data of the PROFIBUS PA Devices
The PROFIBUS PA device slot data is mapped into gateway subslots.
For each PROFIBUS PA segment a maximum of 46 devices can be addressed, each
supporting 246 bytes of input and output data. The device address range is defined from
3 …49. For each PROFIBUS PA segment, a fixed slot cluster is defined with a length of
46 slots. For more information, see chapter 3.2.
Example: Device data of PROFIBUS PA device address 5 in segment 3 is available in slot 155.
3.6 PROFIBUS PA Device Diagnostics
PROFIBUS PA SLAVE_DIAG data is mapped to PROFINET diagnostics alarms as defined in
the PROFIBUS PA GSD file. Channel-specific diagnostics for PROFIBUS PA devices is not
supported.

2016-06
20
PROFINET IO Power Hub
Installation and Commissioning
4 Installation and Commissioning
In the following section you find information on how to install and commission the device in your
fieldbus topology.
4.1 Mounting and Dismounting
Danger!
Explosion hazard from exposure to potentially explosive gas atmosphere
If the device is installed in Zone 2 without mounting it in a sufficiently suitable enclosure, gas,
dust, water or other external interferences can cause the live device to spark. The sparks can
ignite the surrounding potentially explosive atmosphere.
Only mount the device in an enclosure with degree of protection IP54 according to
IEC/EN 60529. The enclosure must have an EU declaration of conformity according to the
ATEX Directive for at least equipment category 3G.
Danger!
Explosion hazard from exposure to potentially explosive dust atmosphere
If the device is installed in Zone 22 without mounting it in a sufficiently suitable enclosure, dust,
water or other external interferences can cause the live device to spark. The sparks can ignite
the surrounding potentially explosive atmosphere.
Only mount the device in a suitable enclosure. The enclosure must have an EU declaration of
conformity according to the ATEX Directive for at least equipment category 3D.
Danger!
Explosion hazard from live wiring
If you connect or disconnect energized non-intrinsically safe circuits in a potentially explosive
atmosphere, sparks can ignite the surrounding atmosphere.
Only connect or disconnect energized non-intrinsically safe circuits in the absence of a
potentially explosive atmosphere.
Note!
Read the instruction manual first!
Before you install and commission this product: Read the instruction manual for this product
carefully. Make sure you have understood all information that is relevant for your application.
Danger!
Danger to life from wrong mounting and installation
Incorrect mounting and installation of the device can compromise its function and its electrical
safety.
■Observe the safety instruction in the instruction manual.
■Observe the information in the manual.
