Perel Perel GZB5PRO User manual

GZB5 PRO
GAZEBO - 3 m x 3 m
TONNELLE - 3 m x 3 m
ZONNETENT - 3 m x 3 m
GARTENPAVI LLI ON - 3 x 3 m
CEN ADOR - 3 x 3 m
TOLDO – 3 X 3 m
USER MANUAL 3
NOTI CE D’EMPLOI 5
GEBRUI KERSHANDLEIDI NG 7
MANUAL DEL USUARI O 9
BEDIENUNGSANLEITUNG 11
MANUAL DO UTILI ZADOR 13

GZB5 PRO
00 (13/ 01/ 2012) ©Vellem an nv
2
Figure 1

GZB5 PRO
00 (13/ 01/ 2012) ©Vellem an nv
3
User m anual
1 . I ntroduction
Thank you for choosing Perel! I f t he package was dam aged in t ransit , do not inst all or use it and
contact your dealer.
2 . Safety I nstructions
Follow these instructions carefully to avoid hands/ fingers injury due to m oving parts.
Set up and break down requires two adult persons.
Make sure the weather conditions are suitable (e.g. not too windy) for setting up or
breaking down the gazebo.
The cover material of this gazebo is flam m able. DO not make open fires (e.g.
barbeque) under or near the gazebo.
Dam age caused by disregard of certain guidelines in this m anual is not covered by the warranty
and the dealer will not accept responsibility for any ensuing defects or problems.
3 . General guidelines
Protect the gazebo from shocks and abuse. Avoid brute force when deploying, folding up or during
usage.
Only use the gazebo for its intended purpose. Using the gazebo in an unauthorised way will void
the warranty.
NEVER store the gazebo unless it is com pletely dry. Storing when damped allows the formation
of m old and m ildew, which will rot natural fibers, dam age the coating to the fabric and leave
indelible stains.
4 . Features
foldable and easy to set up
cover in waterproof nylon
5 . Setting up
Refer to the illustrations on page 2 of this m anual.
1. Place the gazebo at the centre of the chosen location. Rest the gazebo on its feet and remove
the carry bag.
Lift the gazebo by the four legs and m ove the legs as far as possible apart.
2. Hold the gazebo at opposite legs, lift and slowly step backwards until fully opened. A yoke slides
up over the leg; be careful not to get hands or fingers injured by this yoke or any other hinging
joints.
3. Secure the sliding yoke at each corner. Place one hand on top of the leg to hold it down and
push the yoke up with the other hand until the spring-loaded button snaps into place. Do this for
all 4 corners.
4. Hold two adjacent legs of the gazebo. Sim ultaneously place a foot on the foot plate to hold the
inner leg down and gently lift the gazebo until the spring-loaded button snaps into place. Repeat
this step for the other two legs.
Make sure the legs of the gazebo form a square and fold the Velcro tabs located at the bottom
side of the top cover around the fram e.
Depending on the environm ental conditions, secure the gazebo to the ground by putting stakes
(not incl.) through the bases of the legs. Drive a stake (incl.) into the ground at every corner, tie
guy-ropes (incl.) to the top of each of the 4 corners and connect the other end tightly to the
stakes.

GZB5 PRO
00 (13/ 01/ 2012) ©Vellem an nv
4
6 . Breaking dow n
Refer to the illustrations on page 2 of this m anual.
Rem ove any guy-ropes and stakes that were used to hold the gazebo in place.
5. Hold two adjacent legs of the gazebo. Sim ultaneously press on the spring-loaded buttons and
slide the inner legs into the outer legs. Repeat this step for the other two legs.
6. Release the sliding yoke at each corner. Push the sliding yoke slightly upwards and press on the
spring-loaded button. Slide the yoke down past the spring-loaded button. Do this for all 4
corners.
7. Hold the gazebo at opposite legs, lift and slowly step forwards until nearly closed. Shake the
canopy gently to facilit ate folding. The yoke slides down over the leg; be careful not to get hands
or fingers injured by this yoke or any other hinging joints.
8. Close the gazebo com pletely by lifting and pulling the adjacent legs together.
Make sure the gazebo is com pletely dry before placing it inside the storage bag!
7 . Technical specifications
GZB5 PRO
aluminium legs 32 x 32/ 28 x 28mm
thickness 1mm
aluminium roof frame 23 x 14mm
thickness 0.9m m
peak height 3.50m
cover waterproof nylon
Use this device w ith original accessories only. Vellem an nv cannot be held responsible in
the event of dam age or injury resulted from ( incorrect) use of this device.
For m ore info concerning this product , please visit our w ebsite w w w .perel.eu.
The inform ation in this m anual is subject to change w it hout prior not ice.
© COPYRI GHT NOTI CE
The copyright to this m anual is ow ned by Vellem an nv.
All worldwide rights reserved.
No part of this manual or may be copied, reproduced, translated or reduced to any electronic
medium or otherwise without the prior written consent of the copyright holder.

GZB5 PRO
00 (13/ 01/ 2012) ©Vellem an nv
5
NOTI CE D’EMPLOI
1 . I ntroduction
Nous vous remercions de votre achat ! Lire la présente notice attentivement avant la m ise en
service de l’appareil. Si l’appareil a été endom m agé pendant le transport, ne pas l’installer et
consulter votre revendeur.
2 . Consignes de sécurité
Suivre les instructions dans cette notice pour éviter les blessures causées par des
pièces mobiles. Il est conseillé de m onter et de dém onter la tonnelle à deux.
Monter et de dém onter la tonnelle dans des conditions m étéorologiques favorables.
Ne jam ais utiliser la tonnelle par grand vent.
La bâche n’est pas ignifuge. Ne jam ais faire de feu ni de barbecue sous ou à
proxim ité de la tonnelle.
La garantie ne s’applique pas aux dom mages survenus en négligeant certaines directives de
cette notice et votre revendeur déclinera toute responsabilité pour les problèm es et les défaut s
qui en résultent.
3 . Directives générales
Protéger la tonnelle les chocs et la traiter avec circonspection pendant l’installation et l’opération.
N’utiliser la tonnelle qu’à sa fonction prévue. Un usage im propre annule d'office la garantie.
Ne jam ais ranger la tonnelle avec une bâche hum ide. Une bâche humide favorise la formation de
moisissures qui pourront endom m ager les fibres et form er des taches.
4 . Caractéristiques
repliable, facile à m onter
bâche en nylon hydrofuge
5 . Montage de la tonnelle
Consulter les illustrations à la page 2 de cette notice.
1. Choisir un endroit approprié pour la tonnelle. Sortir la tonnelle du sac de rangem ent et la placer
sur les pieds. Soulever légèrement la tonnelle et déplier au m axim um sans forcer.
2. Maintenir la tonnelle par deux pieds opposés. Soulever légèrement la tonnelle et ouvrir
entièrement la tonnelle. L’étrier de verrouillage glisse sur le pied. Procéder prudem ment afin
d’éviter de coincer les doigts entre l’étrier et le pied.
3. Verrouiller l’étrier au haut de chaque pied : maintenir en place le haut du pied avec la m ain et
faire coulisser l’étrier vers le haut jusqu’à à ce qu’il soit verrouillé. Procéder pour les quatre
pieds.
4. Maintenir la tonnelle par deux pieds d’un mêm e côté. Bloquer la partie inférieure du pied avec
votre pied et soulever la tonnelle afin de glisser cette partie inférieure hors du pied. Verrouiller
l’ensem ble. Procéder pour les quatre pieds.
Placer les pieds de m anière à ce qu’ils forment un carré. Replier les bandes scratch autour de
l’armature afin de fixer la bâche.
Si nécessaire, fixer la tonnelle en sécurisant chaque pied utilisant un hauban (incl.) ancré à un
piquet (incl.) enfoncé dans le sol.
