Perfect Aire ProAire PROCD150 User manual

150 PINT
Before using your
commercial dehumidifier,
please read this manual
carefully and keep it
for future reference,
along with your receipt.
FOR MODEL:
PROCD150
COMMERCIAL
DEHUMIDIFIER
USER MANUAL

-1-
General Information.................................................................................. 1
Important Safety Instructions.................................................................... 2
Structure Diagram .................................................................................... 3
Setup Instructions................................................................................ 4 – 5
Control Panel....................................................................................... 6 – 7
Operating Instructions .............................................................................. 8
Maintenance...................................................................................... 9 – 10
Troubleshooting...................................................................................... 11
Error Codes ............................................................................................ 12
Purchase/Maintenance Records ............................................................ 13
• Please DO NOT dispose of any packaging until you have
checked that the appliance is operational.
• After removing the packaging, ensure the contents are intact
and complete. In the unlikely event of missing parts, contact
Consumer Services at 844-472-2473.
• DO NOT leave children unattended with any of the packaging
as it is a potential source of danger.
• Disposal of all packaging must be carried out responsibly,
safely, and in accordance with your local regulations.
• ALWAYS recycle the packaging material where possible.
• When using any electrically powered product, basic safety
precautions should always be followed.
• Please read these instructions carefully and in full before using
the product.
TABLE OF CONTENTS
GENERAL INFORMATION

-2-
WARNING - to reduce the risk of re, electrical shock or
injury to persons or property:
1. Always operate the product from a power source of the same
voltage, frequency and rating as indicated on the product
identication plate.
2. To minimize shock and re hazards, proper grounding is important.
The power cord is equipped with a three-prong grounding plug for
protection against shock hazards. Never cut off the third prong.
3. Your unit must be used in a properly grounded wall receptacle. If
the wall receptacle you intend to use is not adequately grounded or
protected by a time delay fuse or circuit breaker, have a qualied
electrician install the proper receptacle.
4. Do not use extension cords or an adapter plug with this unit. If it is
necessary to use an extension cord, use an approved heavy duty
extension cord only (available at most local hardware stores).
5. Do not operate this product with a damaged power cord plug. If
the supply cord is damaged it must be replaced by qualied repair
person in order to avoid hazard.
6. To reduce the risk of electric shock, do not expose the unit or power
cord to moisture of any kind.
7. Turn off and unplug from the power socket when not in use, before
assembling or before cleaning.
8. The dehumidier is not intended for use by young children without
supervision. Young children should be supervised to ensure that they
do not play with the dehumidier.
9. Disabled persons and the elderly may require assistance with set up
and usage.
10. Do not place objects on the product or allow objects to obstruct the
inlet or outlet openings; do not operate in close proximity to walls,
curtains, etc.
11. Use of attachments or accessories not recommended or sold by the
product distributor may cause injury to persons or damage to property.
12. This product is intended for normal, light commercial use only.
13. Contact a qualied service technician for repair or maintenance of
this unit. Do not attempt to dismantle the appliance.
14. Do not operate the appliance on a metal surface.
15. Do not use the appliance in articially hot or humid conditions or
allow it to be used in a hazardous environment.
16. Do not clean the appliance with organic solvent.
17. This instruction manual is an integral part of the appliance and
should be stored for future reference. It must accompany the unit in
event of ownership transfer or for reference by a service engineer.
IMPORTANT SAFETY INSTRUCTIONS

-3-
DO NOT OBSTRUCT THE AIR INLET OR OUTLET.
WARNING
1. Metal handle
2. Control panel
3. Wheels
4. Drain hose bracket
5. Air outlet grille
6. Air inlet grille
7. Power cord
8. Drain hose
STRUCTURE DIAGRAM
NOTE: You will need to install the handle.
Six bolts are included for the installation.

-4-
IMPORTANT
Place dehumidier in the upright position. When transporting a
dehumidier to site, allow the dehumidier to stand upright for
30 minutes before switching ON. This is necessary to allow the
refrigerant system to stabilize and avoid system damage.
SETTING UP THE DEHUMIDIFIER:
Operate the dehumidier in an enclosed area as this creates a drying
chamber. Close all doors, windows and areas that open to external areas
to maximize the dehumidier’s water removal efciency. Keep trafc
through the drying chamber to a minimum. Place the dehumidier in the
center of the room, away from walls and furnishings. DO NOT allow the
airow to be obstructed.
Illustration of correct positioning for best performance.
SETUP INSTRUCTIONS

-5-
NOTE: The drain hose for the ejector pump is 40 ft long and can drain
up to 16 ft vertically. Attempting to push water vertically more than 16
ft vertically may cause water backup in the pump, which can result in
leakage. See image above.
DRAINAGE:
The dehumidier pump connects to a plastic drainage hose. The hose
is stored on the back of the appliance. Uncoil the entire hose, ensuring
there are no kinks or restrictions, and place the unattached end into a
drain or run outdoors.
Ensure that draining running to the outdoors does not create a hazard
that could cause someone to slip.
Water drains MUST be checked regularly when used.
SETUP INSTRUCTIONS (continued)

-6-
ON/OFF: Press the key to turn the unit ON or OFF.
PURGE: Press the key to empty water from the pump reservoir.
During normal operation the pump purges automatically when the
reservoir is full. Use “PURGE” before moving the machine to avoid
water spillage. The pump will close automatically after 40 seconds of
continuous operation.
and : Press and keys to set or adjust humidity in the
range of 26% and 90%. When the environmental humidity is below 26%,
“CO” will be displayed.
Defrost Indicator: The unit begins to defrost when the defrost indicator
illuminates; the unit has stopped defrosting when the light is no longer
illuminated. When defrosting is complete, the unit begins to dehumidify
again automatically.
1. ON/OFF Key
2. UP and DOWN Keys
3. Purging Indicator
4. Defrosting Indicator
CONTROL PANEL
5. PURGE Key
6. HUMIDITY and TIME Display
7. TIME Key
8. Operating Indicator

-7-
TIME: Press this to display working hours and total working time.
• Once the unit is running, the display will show the humidity setting
(left) and current humidity (right). Humidity setting can be changed by
pressing “Up” or “Down.”
• Time settings are based on minutes. For example, if the display shows
“0000:50,” this means that the unit has worked for 50 minutes since
powered on. If you want to view the total working time, press “T” again
and the display will show this for 10 seconds, then return automatically
to the original working hours. (Pressing “T” before the 10 seconds will
return the display to the original working hours.)
• If the unit is powered on but not in operation, the LED will not display
anything. If “T” is pressed once, the working hours from the previous
time the unit ran will display for 10 seconds. Within the 10 seconds, if
“T” is pressed again, the total working time will display for 10 seconds.
If there is no action within those 10 seconds, the LED will automatically
shut off.
• If “T” is pressed when LED displays the total working time, the LED
will shut off immediately. The current working time will be deleted by
pressing and holding down “T” for 5 seconds; the time will be reset, but
the deleted time will be added into the total working time.
NOTE: The total working time cannot be deleted. If the time is beyond
the range of what the LED can show, it will be deleted and restart
from zero.
NOTE: If a power outage occurs while the unit is powered on, the unit
automatically resumes operation at the most recent settings when power
is restored.
Error Messages (E1, E2, E3, E4): See the troubleshooting guide at the
back of this manual for meanings/assistance.
CONTROL PANEL (continued)

-8-
General Use:
Press the ON/OFF key to turn the unit on. It will begin working
automatically.
After use, press ON/OFF key to turn the unit off. Water pump will turn
on automatically for 40 seconds to drain the remaining water in the unit,
then turn off automatically.
Key Lock Function
If the keys of “T” and “P” are pressed for 2 seconds simultaneously, the
operation light will continue to illuminate at the speed of 50 Hz and all
of the keys on the control panel will lock. The control panel can then be
unlocked by pressing the “T” and “P” keys together again for 2 seconds.
Vent Hose Function
To speed up drying in very damp place, use a plastic pipe (vent hose)
with a diameter larger than 6.7 inches. Attach the vent hose to the
exhaust ring (see below) to expedite drying by directing the heat
(exhaust) toward the wet area.
OPERATING INSTRUCTIONS
Vent Hose
(not included)
ATTENTION:
• DO NOT switch the power OFF by disconnecting at the main
socket outlet.
•To avoid water spillage, DO NOT move the dehumidier for at least
3 minutes after turning the power OFF.

-9-
To clean the air lter:
Ensure the dehumidier is turned OFF and the plug is removed from the
power outlet before performing maintenance.
The working performance of the dehumidier will be greatly reduced if
the lter becomes blocked.
1. Remove the lter as shown in the diagram below.
2. Vacuum any debris from the lter using the vacuum hose and nozzle
attachment.
3. Using lukewarm water and a mild detergent, wash the lter and allow
to air dry completely.
4. Once completely dry, re-install the lter into the dehumidier.
MAINTENANCE
Lift upwards to remove
filter for cleaning
Air Filter

-10-
MAINTENANCE (continued)
The battery allows the user to check the total working time of the unit
even when the unit is powered off. (Press the “T” button to check this.)
1. Remove the screws in
the four corners of the
control panel.
2. Once the screws are
removed, carefully lift the
control panel to access
the PCB.
3. On the PCB is a 6F22
9V battery. Remove the
battery and replace with
a new battery.
4. Ret the control panel
onto the PCB.
5. Replace the four screws.
• Check the electrical cord for damage before each use.
• Additionally, it is a good practice to check the drain hose on a
monthly basis for any obstructions. Disconnect and clear any debris
present, then reconnect the hose.
• When cleaning the surface of the unit, do not use any harsh or
abrasive cleaners. Additionally, do not expose the power cord/plug,
control panel, and/or motor to direct moisture.
Battery (6F22 9V)
Changing the battery:
Maintenance Notes:

-11-
Please check the following troubleshooting tips before
calling for assistance.
NOTE: If you have tried the above troubleshooting and need additional
assistance, contact Consumer Services at 844-472-2473.
PROBLEM CAUSE SOLUTION
Dehumidier
does not operate
No power to appliance. Connect plug to power
outlet.
Power not turned on. Switch power on.
E4 error is displayed. Check drainage ow.
Dehumidier
collects little/no
water
Insufcient working time Allow more working time
Filter is blocked Clean lter
Low ambient
temperature
Increase ambient
temperature
Condensate hose is
blocked
Check hose for
restrictions
Difference between set
humidity and current
actual humidity is
minimal
Adjust humidity setting to
a lesser setting
Humidity is too low for
the unit to run.
No need to run the unit.
Dehumidier
is operating
but room is not
drying
Doors and windows are
open
Seal room from external
areas by closing doors,
windows, etc.
TROUBLESHOOTING

-12-
WARNING: DO NOT attempt to rectify errors using unqualied personnel.
To remedy the following errors, a qualied professional is required.
NOTE: With any error code, it is suggested to turn the unit off, wait ve
minutes, and then turn the unit on again. If the error code is still present, a
qualied professional is required to x the problem.
CODE MEANING DISPLAY
READING SOLUTION*
E1 Coil sensor
error
Flashes every
30 seconds
Replace coil sensor. Call for
replacement part.
E2 Humidity
sensor error
Flashes every
30 seconds
Replace humidity sensor. Call
for replacement part.
E3 Low or no
refrigerant
Flashes
continually
Turn the unit off, wait 5
minutes, and power the unit
ON. If E3 shows again within
15 mins after turning the unit
back on, then we can conrm
the unit refrigerant leak
requires professional repair.
Call your local HVAC repair
shop for assistance.
E4 Water pump
fault or
blockage
Flashes
continually
Dehumidier will turn OFF
automatically. Check for
blockages in the water hose. If
there are no visible blockages,
the pump or water pipe may
need to be replaced.
ERROR CODES
*NOTE: If the error occurs within one year from the date of purchase,
contact Consumer Services at 844-472-2473 for warranty assistance
prior to contacting a repair person. You must have the original
purchase receipt for warranty assistance.

-13-
PURCHASE RECORD
MAINTENANCE RECORD
Purchase Date:
Serial Number:
Distributor: Tel.
DATE SERVICE PERFORMED PERFORMED BY

Distributed by:
Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
Specification and performance data is subject to change without notice.
Printed in China
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
PA/PROCD150Manual/06082018

70 LITRES / 95 LITRES
MODÈLE:
PROCD150
PROCD200
DESHUMIDIFICATEUR
D'AIR MOBIL
PROFESSIONNEL
MANUEL D'INSTALLATION
& D'UTILISATION
PROCD150
PROCD200

INFORMATIONS GENERALES 


 
 


 
 


 
2

 INSTRUCTIONS IMPORTANTES 
 

 
 

 
 


 


  
 




 
 
 






 


 

  


3

 INSTRUCTIONS IMPORTANTES 
 

 
 

 
 


 


  
 




 
 
 






 


 

  


3

5
8
6
6
8
5
DY-65L
DY-85L
