Performance Tool W5193 User manual

METAL STORAGE BIN RACK
Item Number W5193
OWNER’S MANUAL
LIMITED WARRANTY
PERFORMANCETOOLextendsonlythefollowingwarranties,andonlytooriginalretailpurchasers.Thesewarrantiesgive
specificlegalrights.Exceptwhereprohibitedbylocallaw,thelawoftheStateofWashingtongovernsallwarrantiesandall
exclusions and limitations of warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCETOOLwarrantstheproducttobefreefromdefectsinmaterialsandworkmanshipundernormaluseand
service.Adefectiveproductmaybereturnedforafreereplacementwithin90daysfromthedateofpurchase,providedthat
productisreturnedtoplaceofpurchaseimmediatelyafterdiscoveryofdefect.After90daysandupto1yearfromdateof
purchase,PERFORMANCETOOLwillreplaceatnochargeanypartswhichourexaminationshalldisclosetobedefectiveand
underwarranty.Thesewarrantiesshallbevalidonlywhenasalesreceiptshowingthedateofpurchaseaccompaniesthe
defectiveproductordefectivepart(s)beingreturned.Forpart(s)after90days,pleaseremityourrequest,postageprepaidto:
PERFORMANCE TOOL, P.O. Box 24086 Seattle, WA 98124
Thesewarrantiesexcludeblades,bits,punches,dies,bulbs,fuses,andotherconsumableswhichmustbereplacedunder
normaluseandservice.Thesewarrantiesshallnotapplytoanyproductorpartwhichisusedforapurposeforwhichitisnot
designed,orwhichhasbeenrepairedoralteredinanywaysoastoaffectadverselyitsperformanceorreliability,norshallthese
warrantiesapplytoanyproductorpartwhichhasbeensubjecttomisuse,neglect,accidentorwearandtearincidenttonormal
use and service.
PERFORMANCETOOLdoesnotauthorizeanyotherpersontomakeanywarrantyortoassumeanyliabilityinconnectionwith
its products.
Exceptforwarrantiesoftitleandthelimitedexpresswarrantiessetforthabove,PERFORMANCETOOLmakesnoexpressor
impliedwarrantiesofanykindwithrespecttoitsproducts.Inparticular,PERFORMANCETOOLmakesnoimpliedwarrantyof
merchantabilityandnoimpliedwarrantyoffitnessforanyparticularpurpose,exceptthatforgoodspurchasedprimarilyfor
personal,familyorhouseholduseandnotforcommercialorbusinessuse,PERFORMANCETOOLmakesanimpliedwarrantyof
merchantability(and,ifotherwiseapplicable,animpliedwarrantyoffitnessforaparticularpurpose),butonlyfortheparticular
qualitiesorcharacteristics,andfortheduration,expresslywarrantedabove.Thelawsonlimitationofimpliedwarrantiesmay
differ from state to state, so the above limitations may not apply in all cases.
PERFORMANCETOOLshallnotbeliableforconsequential,incidentalorspecialdamagesresultingfromorinanymanner
relatedtoanyproduct,ortothedesign,use,oranyinabilitytousetheproduct.Thesoleandexclusiveremedyforadefective
productorpartshallbe the repair,or replacement thereof asprovidedabove.The laws on limitationofremediesor on
consequential,incidentalorspecialdamagesmayvaryfromstatetostate,sotheabovelimitationsmaynotapplyinallcases.
Copyright © 2015 PERFORMANCE TOOL – All rights reserved
FOR YOUR SAFETY,
please read these instructions carefully and retain them for future use.
If you encounter any problems or difficulties, please contact our
customer service department at:
1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.

PARTS LIST
TOOLS REQUIRED
ASSEMBLY INSTRUCTIONS
10
6
1
3
2
5
4
7
8
9
1.Placethetoptrayupsidedownonaatsurface.
2. Position one of the L-bar frame legs on the inside of the brackets on the
 tray.NOTE:Theteardropshapedholesshouldbeonthelongersideofthe
 tray,withthelargercircleportionoftheopeningsfacingdown.
3. Usealargescrew,washerandnuttofastentheL-barframelegstothetoptray
 bracketsonbothsides.
4. Placethebaseontheendofthelegs,withthelegsinsidethebracketsonthe
 base,andfastenwithalargescrew,washerandnut.
5. Placethebottombinsupportbracketonthebottomsetofholesinthelegs.
6. Aligntheholesinthebasesupportbracketswiththethreadedholesonthe
 base,andholesinthelegs.Fastenthetopholeswithalargescrew,washer
 andnut.Fastenthebottomholeswithtwosmallmachinescrews.
7. Insertremainingbinsupportbracketsontothelegs.Makesurethe3holesin
 thesupportbracketareclosertothetop.
8. Alignthe vertical support bracket with thebolts on back of the binsupport
 brackets,andlockintoplace.
No. Description Qty.
1 Base 1
2 BaseSupportBrackets 2
3 L-BarFrameLegs 2
4 BinSupportBrackets 7
5 VerticalSupportBracket 1
SPECIFICATIONS
NOTE:Specicationsaresubjecttochangewithoutnotice.
SmallRedBins:........................................................ 32(5-1/2x3-1/4in.)
LargeBlueBins:.............................................................. 15(8-1/4x5in.)
RackHeight:............................................................................... 45in.Tall
RackWidth:............................................................................. 37in.Wide
RackDepth:.............................................................................12in.Deep
Construction:...........................................................Powder Coated Steel
ReplacementPartsNo.W5193HW............... Hardwarekit(Nuts&Bolts)
No. Description Qty.
 6 TopTray 1
 7 LargeMachineScrews 18
8 Round Washers 18
9 HexNuts 18
10 SmallMachineScrews 2
•#2Phillipsheadscrewdriver
•10mmwrenchorsocketandratchet
