N37347 Chapter 1
Page 1
Introduction
The Perkins M92B marine engine is the latest development from Perkins Engines Company Limited together
with Wimborne Marine Power Centre. The engine is designed specically for use in commercial and pleasure
boat applications.
Over sixty years of diesel production experience, together with the latest technology, have been applied to the
manufacture of your engine to give you reliable and economic power.
Danger is indicated in the text by two methods:
Warning! This indicates that there is a possible danger to the person.
Caution: This indicates that there is a possible danger to the engine.
Note: Is used where the information is important, but there is not a danger.
General information

Chapter 1 N37347
Page 2
How to care for your engine
Warning! Read the “Safety precautions” and remember them. They are given for your protection and must be
applied at all times.
Caution: Do not clean an engine while it runs. If cold cleaning uids are applied to a hot engine, certain
components on the engine may be damaged.
This handbook has been written to assist you to maintain and operate your engine correctly.
To obtain the best performance and the longest life from your engine, you must ensure that the maintenance
operations are done at the intervals indicated in “Preventative maintenance”. If the engine works in a very
dusty environment or other adverse conditions, certain maintenance intervals will have to be reduced. Renew
the lter canister and lubricating oil regularly in order to ensure that the inside of your engine remains clean.
Ensure that all adjustments and repairs are done by personnel who have had the correct training. Perkins
distributors have this type of personnel available. You can also obtain parts and service from your Perkins
distributor. If you do not know the address of your nearest distributor, enquire at www.perkins.com/Marine.
The “left side” and “right side” of the engine apply when the engine is seen from the reverse gearbox end.

N37347 Chapter 1
Page 3

Chapter 1 N37347
Page 4
General safety precautions
These safety precautions are important.You must refer also to the local regulations in the country of use.
Some items only apply to specic applications.
• Only use these engines in the type of application for which they have been designed.
• Do not change the specication of the engine.
• Do not smoke when you put fuel into the tank.
• Clean away fuel which has been spilt. Material which has been contaminated by fuel must be moved to a
safe place.
• Do not put fuel into the tank while the engine runs (unless it is absolutely necessary).
• Do not clean, add lubricating oil, or adjust the engine while it runs (unless you have had the correct
training; even then extreme care must be used to prevent injury).
• Do not make adjustments that you do not understand.
• Ensure that the engine does not run in a location where it can cause a concentration of toxic emissions.
• Other persons must be kept at a safe distance while the engine, auxiliary equipment or boat is in
operation.
• Do not permit loose clothing or long hair near moving parts. Warning: Some moving parts cannot be
seen clearly while the engine runs.
• Keep away from moving parts during engine operation.
• Do not operate the engine if a safety guard has been removed.
• Do not remove the ller cap or any component of the cooling system while the engine is hot and while
the coolant is under pressure, because dangerous hot coolant can be discharged.
• Do not use salt water or any other coolant which can cause corrosion in the closed circuit of the cooling
system.
• Disconnect the battery terminals before a repair is made to the electrical system.
• Only one person must control the engine.
• Ensure that the engine is operated only from the control panel or from the operators position.
• If your skin comes into contact with high-pressure fuel, obtain medical assistance immediately.
• Diesel fuel and lubricating oil (especially used lubricating oil) can damage the skin of certain persons.
Protect your hands with gloves or a special solution to protect the skin.
• Do not wear clothing which is contaminated by lubricating oil. Do not put material which is contaminated
with oil into the pockets of clothing.
• Discard used lubricating oil in accordance with local regulations to prevent contamination.
• Ensure that the control lever of the transmission drive is in the “out-of-drive” position before the engine is
started.
• Use extreme care if emergency repairs must be made at sea or in adverse conditions.
• The combustible material of some components of the engine (for example certain seals) can become
extremely dangerous if it is burned. Never allow this burnt material to come into contact with the skin or
with the eyes.
• Always close the seacock before the removal of any component of the raw water circuit.
• Always use a safety cage to protect the operator when a component is to be pressure tested in a
container of water. Fit safety wires to secure the plugs which seal the hose connections of a component
which is to be pressure tested.
• Do not allow compressed air to contact your skin. If compressed air enters your skin, obtain medical help
immediately.
• Turbochargers operate at high speed and at high temperature. Keep ngers, tools and debris away from
inlet and outlet ports of the turbocharger and prevent contact with hot surfaces.
• Do not clean an engine while it runs. If cold cleaning uids are applied to a hot engine, certain
components on the engine may be damaged.
• Fit only genuine Perkins parts.

N37347 Chapter 1
Page 5
Engine guarantee
If a claim under guarantee is necessary, the boat owner should make a guarantee claim on the nearest Perkins
marine distributor or an approved dealer.
If it is difcult to nd a Perkins distributor or an approved dealer, consult the Service Department of Wimborne
Marine Power Centre, Wimborne.
M92B engine - identication letters RE
The engine identication number is shown at two locations on the engine: stamped on a plate at the right side
of the cylinder block (C1) and shown on a label (D1) tted to the front of the timing case.
An example of an engine number is: RE51267U123456L.
The components of the engine number are as follows:
RE51267U123456L
RE Type code letters
51267 Build list number
U Built in the UK
123456 Engine serial number
L Year of manufacture
If you need parts, service or information for your engine, you must give the complete engine number to your
Perkins distributor.

Chapter 1 N37347
Page 6
Perkins companies
Australia
Perkins Engines Australia Pty. Ltd,
Suite 4, 13A Main Street,
Mornington 3931, Victoria, Australia.
Telephone: [phone]
Telex: Perkoil AA30816
Fax: [phone]
France
Perkins France S.A.S,
“Parc des reets”
165 Avenue Du Bois de la Pie
95700 Roissy Charles de Gaulle, France.
Telephone: [phone]
Fax: [phone]
Germany
Perkins Motoren GmbH,
Saalaeckerstrasse 4,
63801 Kleinostheim,
Germany.
Telephone: [phone]
Fax: [phone]
Italy
Motori Perkins S.p.A.,
Via Socrate 8,
22070 Casnate con Bernate (Como), Italy.
Telephone: [phone]
Fax: [phone] / 396001
Japan
Perkins Engines, Inc.,
Address Building, 8th Floor,
2-2-19 Akasaka, Minato-ku,
Tokyo 107-0052, Japan.
Telephone: [phone]
Fax: [phone]
Singapore
Perkins Engines (Asia Pacic) pte Ltd
20 Harbour Drive
#07-06A, PSA Vista
Singapore 117612
Telephone: [phone]
Fax: [phone]

N37347 Chapter 1
Page 7
United Kingdom
Perkins Engines Company Ltd,
Easteld, Peterborough PE1 5NA,
England.
Telephone: [phone]
Telex: 32501 Perken G
Fax: [phone]
United States of America
Perkins International - North America,
26200 Town Center Drive,
Suite 280,
Novi, Michigan 48375
USA
Telephone: [phone]
Fax: [phone]
Perkins Engines Latin America Inc,
Suite 620,
999, Ponce de Leon Boulevard,
Coral Gables,
Florida 33134, U.S.A.
Telephone: [phone]
Telex: 32501 Perken G
Fax: [phone]
In addition to the above companies, there are Perkins distributors in most countries. Perkins Engines Company
Ltd., Peterborough or one of the above companies can provide details.
The managers of the marine business for Perkins are:
Wimborne Marine Power Centre,
Ferndown Industrial Estate,
Wimborne,
Dorset BH21 7PW,
England.
Telephone: [phone]
Fax: [phone]

Chapter 1 N37347
Page 8

N37347 Chapter 2
Page 9
Engine views
Introduction
Perkins engines are built for specic applications and the views that follow do not necessarily match your
engine’s specication.
Location of engine parts
Front and left side view (A) of the engine
1. Air cleaner
2. Electric fuel pump
3. Fuel lter canister
4. Heat exchanger
5. Gearbox oil cooler
6. Dipstick
7. Fuel inlet hose
8. Fuel return hose
9. Belt cover
10. Raw water pump
11. Calorier tting (return)
12. Oil ller cap
13. Fresh water pump
14. Header tank
15. Oil ller cap
16. Fresh water ller cap

Chapter 2 N37347
Page 10
Rear and right side view (B) of the engine
17. Front lifting eye
18. Calorier tting (feed)
19. Alternator
20. Exhaust elbow
21. Oil lter
22. Starter
23. Lubricating oil sump
24. Sump pump
25. Exhaust manifold
26. Air lter

N37347 Chapter 3
Page 11
Operation instructions
How to start the engine
The instrument control panel for single and twin engine installations is shown in gure (A). The switches are
protected from the entry of water, but if the control panel is in an exposed location, it should be protected by a
cover when not in use.
Below is a description of the instruments and switches on the main panel.
Panel illumination: the gauges are always illuminated, press the button (A1) to adjust the level of
illumination.
Engine electrical system / stop switch (A5), which has two positions:
• OFF: Move the switch lever up to switch off the electrical system
• ON: Move the switch lever down to energise the electrical system.
Heat / start switch (A4), which is held up to energise the cold start aid (if one is tted), or held down to
energise the starter motor.
Stop button (A6) press the button to stop the engine.
Warning lamp (A2) to indicate that there is no electrical charge from the alternator.
Voltmeter (A3) to indicate the condition of the batteries and of the alternator.
Warning lamp (A10) for high coolant temperature
Gauge (A9) to indicate coolant temperature.
Tachometer (A12) to indicate the engine speed.The tachometer also has an hourmeter, this can be used to
ensure that the engine is maintained at the correct intervals.
Warning lamp (A8) for low lubricating oil pressure.
Gauge (A7) to indicate the lubricating oil pressure of the engine.
Warning lamp (A11) for water in the fuel.
Audible warning device, which operates if the engine has low lubricating oil pressure or high coolant
temperature. The audible warning device is situated behind the control panel.
Caution: If the audible warning device operates, the warning light(s) on the relevant main panel will indicate
the engine affected. Reduce the speed of the engine affected to idle and, if necessary, stop the engine.

Chapter 3 N37347
Page 12
Basic control panel
The basic control panel shown in gure (B). The switches are protected from the entry of water, but if the
control panel is in an exposed location, it should be protected by a cover when not in use.
Below is a description of the instrument and switches on the auxiliary panel.
Caution: If the audible warning device operates, the warning light(s) on the relevant main panel will indicate
the engine affected. Reduce the speed of the engine affected to idle and, if necessary, stop the engine.
Audible warning device, which operates if the engine has low lubricating oil pressure or high coolant
temperature.
Engine electrical system / stop switch (B5), which has two positions:
• OFF: Move the switch lever up to switch off the electrical system
• ON: Move the switch lever down to energise the electrical system.
Tachometer (B7) to indicate the engine speed.
Heat / start switch (B4), which is held up to energise the cold start aid (if one is tted), or held down to
energise the starter motor.
Stop button (B6) press the button to stop the engine.
Warning lamp (B3) to indicate that there is no electrical charge from the alternator.
Warning lamp (B2) for high coolant temperature.
Warning lamp (B1) for low lubricating oil pressure.
