Perrin & Rowe Georgian U.3783L Operation manual

CARE & MAINTENANCE
Occasional cleaning with warm soapy water followed by a polish with a soft cloth is all that is required to keep the
plated finish in good condition.
Do not use proprietary abrasive liquids, powders, or pads to clean the product. You will damage the
plated finish and void your guarantee.
SPARE PARTS & SERVICE
3 Parker
Irvine
CA 92618
[phone]
www.rohlhome.com
The Georgian Bathroom Collection
Installation & User Guide
ROHL WARRANTY POLICY
All products supplied by ROHL carry warranties against manufacturing defects.
Perrin & Rowe products carry a Limited Lifetime Warranty.
ROHL LLC will provide free of charge as its options replacement part(s) or product (or a comparable alternative
product) to replace those which have proven defective in materials or workmanship.
For full ROHL LLC WARRANTY please contact ROHL or visit www.rohlhome.com
Perrin & Rowe products are manufactured in the UK using the latest
technology and built to the highest quality standards.
We would like to thank you for purchasing a Perrin & Rowe product and take
this opportunity to invite you to look at other luxury products by us. Please
contact us to receive our latest product catalogue.
* Where indicated please specify color
Perrin & Rowe is a registered trademark of Avilion Ltd. 903783U Issue 3
SPARES
3 Hole Wall Mounted Tub
3 Hole Wall Mounted Lav
Temp Range:
Min 1°C/34°F
Max 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal hot & cold pressures.
• U.3783L
• U.3784X
• U.3787
• U.3793L
• U.3794X
• U.3797
9.13501/Left
9.13500/Right
9.18230*
9.21197*/Hot
9.21197*/Cold
9.21197*/Plain
9.24194*
9.26760*
9.18256* 9.20783*
9.17374*
9.13145/Right
9.13146/Left
9.18710*
9.15401
9.12230*
9.12710*
9.15401
9.21197*/Hot
9.21197*/Cold
9.21197*/Plain
9.24194*
9.26760*
9.20793*
9.17793*
9.18380*
INLET
3/4" NPT
INLET
3/4" NPT INLET
1/2" NPT
INLET
1/2" NPT
Nozzle Reach 8 1/4"
3/4" NPT
1/2" NPT
Rosette Ø2 3/8"
Rosette Ø2 11/16"
Nozzle Reach 7"
Rosette Ø2"
Rosette Ø2 3/8"
9.13501
9.13146
3 HOLE WALL MOUNTED
TUB & LAV SET
9.01797*/Hot
9.01797*/Cold
9.01797*/Plain
9.01797*/Hot
9.01797*/Cold
9.01797*/Plain
• U.3605
Nozzle Reach 8 3/8"
3/4" NPT
Rosette O 2 3/4"
WALL TUB SPOUT
9.18256* 9.20801*
9.17374*
Wall Tub
Spout
9.25256

The Georgian Bathroom Collection
Installation & User Guide
Preparation for Installer
Flush the plumbing system before
installing the bathroom product.
Once unpacked remove Trim Kit ready for
installation.
Congratulations on the purchase of your Perrin & Rowe Bathroom Product. Correctly installed and with sensible
care, this product will give you many years of trouble free service.
IMPORTANT IN ORMATION
Before you proceed... We recommend you engage the services of a registered plumber to install this
product.
In addition to the guide below it is essential that the written information overleaf is carefully read and
understood.
BE ORE USE
• Carefully check the installation for leaks.
• If further building work is to be carried out in the vicinity cover the tap with a plastic bag to avoid damaging the
finish.
• Please ensure that the installation complies with the local plumbing codes.
OPERATION
Ceramic disc valves are fitted as standard to the
Wall Valves. Flow from FULLY OFF to FULLY ON is
achieved by rotating the handles a quarter turn.
• Follow placement dimensions supplied for
installation.
• When installing products make sure allowance
is made for tiles etc.
• Cavity should be sufficent to allow for
servicing of valves.
• Assemble nozzle rosette fitting base seal
supplied between rosette and wall finish.
• Fit nozzle onto shank using thread sealing
materials sparingly.
OPEN OPEN
CLOSED CLOSED
Special Note for Installing the Lever Wall Valves
LEFT
VALVE
RIGHT
VALVE
No
Groove Groove
1
O
3/4"
3 "
1 O 1/2"
Hole
3 /4" NPT
1
O
1/2"
Hole
3/4"
NPT
1 1/4" MAX WALL
THICKNESS
Base Seal
Rosette
Rough
Trim
2MIN 3/8"
MAX 3 1/8"
1 O 1/2"
Hole
1
O
1/2"
Hole
1/2"
NPT
1 1/4" MAX WALL
THICKNESS
Rough
Base Seal
Rosette
Trim
Nozzle
•U.3783L •U3784X •U.3787
Concealed Wall Valve
Ensure the handle is vertical when the valve is in
the 'off' position.
• Assemble trim to rough ensuring handle is
aligned correctly. If it is not remove and turn
a few splines until correct alignment can be
achieved.
Use the above instructions to install the 3
Hole Lav Set on the next page.
•U.3793L •U.3794X •U.3797
Nozzle
1 /2" NPT
2MIN 1/8"
MAX 2 3/4"
3 "
1
O
3/4"
1 1/4" MAX WALL
THICKNESS
3/4" NPT
1
O
1/2"
Hole
Base
Seal Rosette
Nozzel
•U.3605

The Georgian Bathroom Collection
Installation & User Guide
Preparation for Installer
Flush the plumbing system before
installing the bathroom product.
Once unpacked remove Trim Kit ready for
installation.
Congratulations on the purchase of your Perrin & Rowe Bathroom Product. Correctly installed and with sensible
care, this product will give you many years of trouble free service.
IMPORTANT IN ORMATION
Before you proceed... We recommend you engage the services of a registered plumber to install this
product.
In addition to the guide below it is essential that the written information overleaf is carefully read and
understood.
BE ORE USE
• Carefully check the installation for leaks.
• If further building work is to be carried out in the vicinity cover the tap with a plastic bag to avoid damaging the
finish.
• Please ensure that the installation complies with the local plumbing codes.
OPERATION
Ceramic disc valves are fitted as standard to the
Wall Valves. Flow from FULLY OFF to FULLY ON is
achieved by rotating the handles a quarter turn.
• Follow placement dimensions supplied for
installation.
• When installing products make sure allowance
is made for tiles etc.
• Cavity should be sufficent to allow for
servicing of valves.
• Assemble nozzle rosette fitting base seal
supplied between rosette and wall finish.
• Fit nozzle onto shank using thread sealing
materials sparingly.
OPEN OPEN
CLOSED CLOSED
Special Note for Installing the Lever Wall Valves
LEFT
VALVE
RIGHT
VALVE
No
Groove Groove
1
O
3/4"
3 "
1 O 1/2"
Hole
3 /4" NPT
1
O
1/2"
Hole
3/4"
NPT
1 1/4" MAX WALL
THICKNESS
Base Seal
Rosette
Rough
Trim
2MIN 3/8"
MAX 3 1/8"
1 O 1/2"
Hole
1
O
1/2"
Hole
1/2"
NPT
1 1/4" MAX WALL
THICKNESS
Rough
Base Seal
Rosette
Trim
Nozzle
•U.3783L •U3784X •U.3787
Concealed Wall Valve
Ensure the handle is vertical when the valve is in
the 'off' position.
• Assemble trim to rough ensuring handle is
aligned correctly. If it is not remove and turn
a few splines until correct alignment can be
achieved.
Use the above instructions to install the 3
Hole Lav Set on the next page.
•U.3793L •U.3794X •U.3797
Nozzle
1 /2" NPT
2MIN 1/8"
MAX 2 3/4"
3 "
1
O
3/4"
1 1/4" MAX WALL
THICKNESS
3/4" NPT
1
O
1/2"
Hole
Base
Seal Rosette
Nozzel
•U.3605

CARE & MAINTENANCE
Occasional cleaning with warm soapy water followed by a polish with a soft cloth is all that is required to keep the
plated finish in good condition.
Do not use proprietary abrasive liquids, powders, or pads to clean the product. You will damage the
plated finish and void your guarantee.
SPARE PARTS & SERVICE
3 Parker
Irvine
CA 92618
[phone]
www.rohlhome.com
The Georgian Bathroom Collection
Installation & User Guide
ROHL WARRANTY POLICY
All products supplied by ROHL carry warranties against manufacturing defects.
Perrin & Rowe products carry a Limited Lifetime Warranty.
ROHL LLC will provide free of charge as its options replacement part(s) or product (or a comparable alternative
product) to replace those which have proven defective in materials or workmanship.
For full ROHL LLC WARRANTY please contact ROHL or visit www.rohlhome.com
Perrin & Rowe products are manufactured in the UK using the latest
technology and built to the highest quality standards.
We would like to thank you for purchasing a Perrin & Rowe product and take
this opportunity to invite you to look at other luxury products by us. Please
contact us to receive our latest product catalogue.
* Where indicated please specify color
Perrin & Rowe is a registered trademark of Avilion Ltd. 903783U Issue 3
SPARES
3 Hole Wall Mounted Tub
3 Hole Wall Mounted Lav
Temp Range:
Min 1°C/34°F
Max 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal hot & cold pressures.
• U.3783L
• U.3784X
• U.3787
• U.3793L
• U.3794X
• U.3797
9.13501/Left
9.13500/Right
9.18230*
9.21197*/Hot
9.21197*/Cold
9.21197*/Plain
9.24194*
9.26760*
9.18256* 9.20783*
9.17374*
9.13145/Right
9.13146/Left
9.18710*
9.15401
9.12230*
9.12710*
9.15401
9.21197*/Hot
9.21197*/Cold
9.21197*/Plain
9.24194*
9.26760*
9.20793*
9.17793*
9.18380*
INLET
3/4" NPT
INLET
3/4" NPT INLET
1/2" NPT
INLET
1/2" NPT
Nozzle Reach 8 1/4"
3/4" NPT
1/2" NPT
Rosette Ø2 3/8"
Rosette Ø2 11/16"
Nozzle Reach 7"
Rosette Ø2"
Rosette Ø2 3/8"
9.13501
9.13146
3 HOLE WALL MOUNTED
TUB & LAV SET
9.01797*/Hot
9.01797*/Cold
9.01797*/Plain
9.01797*/Hot
9.01797*/Cold
9.01797*/Plain
• U.3605
Nozzle Reach 8 3/8"
3/4" NPT
Rosette O 2 3/4"
WALL TUB SPOUT
9.18256* 9.20801*
9.17374*
Wall Tub
Spout
9.25256
