Magnetventil
Solenoid valve
MVR 3“
ZW01 99545

TDP045d+e.doc Seite/Page 15 / 28
Perrot Regnerbau Calw GmbH Industriestraße 19-27 / D-75382 Althengstett / Germany
Telefon : [phone] / Fax : [phone]
E-mail : per[email protected] / E-mail Konstruktion : [email protected]e
Contents:
1. General
2. Safety
3. Operating data / Pressure drop
4. Installation
5. Commissioning
6. Maintenance
7. Troubleshooting
8. Spare parts list
1. General
We assume that you are familiar with the general issues of irrigation. This manual is
therefore brief and contains only information, which needs to be at hand during system
operation.
Warranty claims may only be made if the controller has been operated according to
instructions set forth in this manual and if the fault occurs during the warranty period.
1.1. Application
The valve is used, for a controlled switching on and off, of the water flow from a water
source to the sprinkler.
Water temperature max.: 40oC.
Ambient temperature max: 60oC
1.2 Warranty Information
Regnerbau Calw GmbH guaranties to the product owners that all their new products
are free of material and/or workmanship faults. The provided product is used for
irrigation, in accordance with recommendations as specified by the producer, for the
duration of the warranty period specified hereinafter. The warranty does not cover
valves faults caused by act of God (storms, floods, etc.)

TDP045d+e.doc Seite/Page 16 / 28
Perrot Regnerbau Calw GmbH Industriestraße 19-27 / D-75382 Althengstett / Germany
Telefon : [phone] / Fax : [phone]
E-mail : per[email protected] / E-mail Konstruktion : [email protected]e
During the warranty period, Regnerbau Calw GmbH will repair or replace all faulty
parts, at their own discretion, but they limit their liability to defective components
only. Any other explicit and/or implied warranties are excluded.
In the unlikely case of a claim, please return the faulty component to your local
supplier or contact our customer service department at: Regnerbau Calw GmbH,
Industriestrasse 19-29, D-75382 Althengstett, Germany.
This warranty does not cover valves used and/or installed and/or modified in
contravention of the technical data or operating/installation instructions as issued by
Regnerbau Calw GmbH.
Regnerbau Calw GmbH waives any liability for indirect or subsequent damage
incurred in connection with using the valves, including but not limited to damage
to plant material, cost of technology/service replacement; incurred during the
existence of the fault or due to the valves being out of operation; damage to other
property; injuries to the operator(s) caused by negligence or by other reasons.
All automatic guarantees, including guarantees for typical quality or suitability of
the merchandise are limited to the warranty period as specified by the law.
2. Safety
This operation & safety manual contains the basic instructions for installation, operation,
maintenance and repair to the valves. It is absolutely necessary that the professional
installation technician and the qualified staff/operator study this manual thoroughly prior
to initiating the valve installation and commissioning it into operation.
Please follow both the general safety instructions specified in this chapter, and the
particular safety warnings pointed out in other chapters.
2.1. Marking of Instructions in the Operation Manual
Safety instructions, non-compliance with which could lead to risking people's health
are marked with the "danger" symbol:
"Warning" is printed next to instructions where non-compliance may represent a risk
to the valve and/or its operation.
WARNING

TDP045d+e.doc Seite/Page 17 / 28
Perrot Regnerbau Calw GmbH Industriestraße 19-27 / D-75382 Althengstett / Germany
Telefon : [phone] / Fax : [phone]
E-mail : per[email protected] / E-mail Konstruktion : [email protected]e
2.2. Risk in Case of Ignoring the Safety Instructions
Not respecting the safety instructions may result in serious injuries, damage to the
environment and/or the valve. Not respecting the safety instructions may waive
liability for all and any claims for covering damage.
3. Description / Operating Data
Materials Cover and housing: grey cast iron, plastic coated
Membrane: full moulded diaphragm
Recommended operating pressure: 4 to 8 bar
Permitted operating pressure:: 10 bar
the static pressure on the valve should not
exceed over 16 bar
Operating pressure: max 10 bar
Connecting thread: G3 FT
Liquids: water
Pressure drop: see specification sheet (page 5)
Liquids temperature: max 45 °C
Ambient temperature: max 60 °C
Kv - value: 75 m3/h
Operating voltage: 24V AC / 50 Hz
Inrush current: 0,28 A
Holding current: 0,14 A
WARNIN
G

TDP045d+e.doc Seite/Page 18 / 28
Perrot Regnerbau Calw GmbH Industriestraße 19-27 / D-75382 Althengstett / Germany
Telefon : [phone] / Fax : [phone]
E-mail : per[email protected] / E-mail Konstruktion : [email protected]e
4. Installation
 Before installation of the valves the pipes are to be flushed proper
until the pipes are clean.
 For sealing of the thread use hemp and sealing compound, for example use
Fermit special
 Respect direction flow:
The arrow on the valve body shows the correct direction of flow
 Position of installation as desired. However pay attention that a complete drain is
only possible if the installation is horizontal.
 To avoid mechanical strength from the pipes to the valve, a tube loop should
always be installed in front and behind of the valve, to avoid mechanical tension,
which takes effect on the valve. (see sketch 1)
 The cable connection from coil to the control cable must be watertight. (e.g. with
cable connector DBY)
sketch 1
WARNIN
G

TDP045d+e.doc Seite/Page 19 / 28
Perrot Regnerbau Calw GmbH Industriestraße 19-27 / D-75382 Althengstett / Germany
Telefon : [phone] / Fax : [phone]
E-mail : per[email protected] / E-mail Konstruktion : [email protected]e
4.1. Installation dimensions

TDP045d+e.doc Seite/Page 20 / 28
Perrot Regnerbau Calw GmbH Industriestraße 19-27 / D-75382 Althengstett / Germany
Telefon : [phone] / Fax : [phone]
E-mail : per[email protected] / E-mail Konstruktion : [email protected]e
5. Commissioning / preparation for hibernation
5.1. Commissioning
a) Examine electrical functions:
Before opening water supply to the valve, the coil must be activated through a control
module. With help of an acoustic „click“ on the coil, the correct electrical function
can be found out. (The click occurs when pulling the plunger)
b) Make sure that <manual opening> stands on AUTO
In that position it is guaranteed, that the valve closes after water supply in case it is
de-energized (see sketch 2).
c) Open slowly water supply to the valve until operating pressure is available. Possibly
