ADTRAN NetVanta SHDSL User manual

NetVanta SHDSL Network Interface Module (NIM) P/N 1200867L1
For more detailed documentation, visit us online at www.adtran.com.
Quick Start Guide
®
Quick Start Guide, 61200867L1-13C, July 2005 ADTRAN Technical Support [phone] Copyright © 2005 ADTRAN, All Rights Reserved
WAN-SHDSL DBU
INSTALLATION INSTRUCTIONS
1. Remove power from the base unit.
2. Slide the option module into the option slot until the module is firmly
seated against the chassis.
3. Secure the pins at both edges of the module.
4. Connect the cables to the associated device(s).
5. Complete installation of the base unit.
6. Restore power to the base unit.
NetVanta modules should be installed only in
NetVanta Series products.
WAN-SHDSL NETWORK (RJ-45) PINOUTS
Pin Name Description
1-3 — Unused
4TNetwork-Tip
5 R Network - Ring
6-8 — Unused
An optional Dial Backup Interface Module (DIM) is
required for dial backup applications.
For a description of the DBU pinouts, refer to the
Quick Start Guide included with your DIM shipment.
Important: For additional details on product features,
specifications, installation, and safety, refer to the
appropriate Hardware Installation Guide on the
ADTRAN OS System Documentation CD shipped
with the base unit and available online at
www.adtran.com.
SPECIFICATIONS
Operating Modes Line termination (CO), network termination (CPE)
SHDSL Interface Supported Standards: ITU-T G.991.2 SHDSL
Line Rate: 200 to 2312 kbps in 64k increments
Line Code: TC-PAM
Connector: RJ-45
Clock Source CO Operating Mode: Internal
CPE Operating Mode: Network
Diagnostics Test Pattern Generation and Detection: 215 - 1
Network loopbacks (local and remote)
Alarm generation and detection
Programmable alarm threshold settings for loop
attenuation and signal-to-noise ratio margin
Compliance FCC Part 15 Class A, EN 55022 Class A,
EN 55024, EN 61000-3-2, EN 61000-3-3
AS/ACIF S043
EN 60950, AS/NZS 60950
Physical Dimensions: 2.75-inch W x 4.25-inch D
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 70°C
Relative Humidity: Up to 95 percent,
noncondensing

NetVanta SHDSL Network Interface Module (NIM) P/N 1200867L1
For more detailed documentation, visit us online at www.adtran.com.
Quick Start Guide
®
Quick Start Guide, 61200867L1-13C, July 2005 ADTRAN Technical Support [phone] Copyright © 2005 ADTRAN, All Rights Reserved
SHDSL NIM COMMANDS
alarm-threshold [loop-attenuation | snr-margin]
Sets thresholds for specific alarm conditions. Use the no form of this command to
disable threshold settings.
loop-attenuation <value> Specifies a loop-attenuation threshold value from
1 to 127 dB. If signal energy loss on the loop
exceeds the configured value, the router issues an
alarm.
snr-margin <value> Specifies a value for signal-to-noise ratio (SNR)
margin from 1 to 15 dB. If the difference in amplitude
between the baseband signal and the noise exceeds
the configured value, the router issues an alarm.
boot alternate-image
Executes new code after a firmware upgrade.
equipment-type [co |cpe*]
Determines the operating mode for the SHDSL interface.
co Use this option only in a campus environment when
operating two SHDSL NIMs back-to-back. In this
setup, configure the master NIM to co and the slave
NIM to cpe.
cpe* Use this option when interfacing directly with your
service provider or when acting as the slave NIM in
a campus environment.
inband-detection
Enables inband loopback pattern detection on the SHDSL interface. Use the no form
of this command to disable inband-detection.
inband-protocol [pn127 | v54]
Designates the inband loopback pattern to send/detect on the SHDSL interface. Use
the no form of this command to return to default.
pn127 Selects PN127 as the inband loopback pattern to
send/detect.
v54 Selects V.54 as the inband loopback pattern to
send/detect.
linerate <value>
Defines the line rate for the SHDSL interface (the value includes 8 kbps of framing
overhead). This command is functional only in co operating mode (see the description
for the equipment-type command). The default for this command is 2056 kbps. The
first two selections listed (72 and 136 kbps) are not supported by this unit.
<value> Specifies the line rate in kbps. Range: 200 to
2312 kbps in 64k increments.
loopback network
Initiates a loopback test on the SHDSL network on the SHDSL interface, looping the
data toward the network. Use the no form of this command to deactivate the
loopback.
loopback remote
Sends a loopback request to the remote unit. This command is functional only in co
operating mode (see the description for the equipment-type command). Use the no
form of this command to send a loopdown code to the remote unit to deactivate the
loopback.
loopback remote inband
Injects the selected inband loop-up pattern into the data stream to cause a loopback
at the far end. Use the no form of this command to inject a loop-down pattern into the
data stream to cause an existing inband loopback at the far end to cease.
outage-retrain
Causes the SHDSL interface to force the SHDSL retrain sequence (which takes the
line down temporarily) if the interface detects more than ten consecutive errored
seconds. A retrain is forced in hopes that the newly retrained line will perform better.
Use the no version of the command to disable this feature.
test-pattern [clear | insert | p215]
Activates the built-in pattern generator and begins sending the selected test pattern
toward the network. Can be used to verify a data path when used in conjunction with
an active loopback. Use the no form of this command to cease pattern generation.
clear Clears the test pattern error count.
insert Inserts a single error into the currently active test
pattern.
p215 Generates a pseudorandom test pattern sequence
based on a 15-bit shift register.
*Indicates default values.
