PERTRONIC INDUSTRIES LTD
Pertronic Conventional Indicating MCP (CPPIN-3T)
PERTRONIC INDUSTRIES LTD 0720 Indicating MCP Installation Note Issue 8, Mar 2010
Product Overview:
The Pertronic Indicating Manual Call-Point is a high-reliability conventional Fire Alarm activation
device with a compact, aesthetically pleasing, low profile design.
Features:
- High reliability Fire Alarm activation device.
- Safe Secure Commissioning without the need to remove the Snapglaze.
- Push button latching switch with inbuilt LED indicator.
- Can be installed into a standard single gang flush box fitting.
- Low Profile Design.
- Electronic components protected from damage.
- ‘Snapglaze’ frangible element for improved user safety (Patent NZ Number: 272427).
- Terminals accept 0.5mm2 to 1.5mm2 cables.
- Bi-directional circuit connection terminals
- The MCP clamps the circuit voltage at 2.3Vdc
- Compatible with 12V Bell reversal of F4-2W and F1-2W systems.
- For non-2W panels, reversal of the MCP causes a High Defect – the M-Level reached depends upon
the number of devices on the circuit and the number reverse-connected.
- Fully complies with NZS 4512:2003
Specifications:
- Dimensions: 115mm(height) x115mm(width) x 15mm(depth above flush-box)
Designed to fit into a standard flush-box fitting
- Electrical: Operating Voltage 10 to 30Vdc
Quiescent Current 0mA
Alarm Current Panel Dependent
- MCP Indicators MCP Poll Switch Illuminates and flashes Red
MCP Activated Switch Illuminates and latches Red
- Environmental: Operating Temperature 0 to 40C
Humidity 10 to 95% RH (non-condensing)
Compatibility:
Indicating Manual Call-Points are compatible with the following products:
Product MCP Hardware Version Panel Software Version Release Date
F1 v1.0 & above v2.3 & above November 2003
F1-2W v6.0 & above v9.04 & above March 2007
F4 v1.0 & above v2.26 & above November 2003
F4-2W v6.0 & above v9.0 & above March 2007
F16 v1.0 & above v7.0 & above November 2003
F16e v1.0 & above v1.10N & above June 2004
Loop Responder v1.0 & above v3.00N & above May 2004
Apartment
Module v1.2 & above v1.00N & above Feb 2006

PERTRONIC INDUSTRIES LTD
Pertronic Conventional Indicating MCP (CPPIN-3T)
PERTRONIC INDUSTRIES LTD 0720 Indicating MCP Installation Note Issue 8, Mar 2010
Manual Call-Point Connections:
To prevent damage to the PCB, care MUST be taken to ensure cables do NOT come between
the PCB and the back of the enclosure.
Manual Call-Point Wiring:
- Ensure rear-entry holes are drilled outside the ‘PCB Area’ to avoid damaging the PCB.
- After terminating the cables, ensure that any excess cable is outside the indicated ‘PCB Area’ to
prevent damaging the PCB when the Manual Call-Point is assembled.
- Keep cable length inside the enclosure to a maximum length of 150mm (6 inches). Alternately,
push excess cable into the cavity outside the enclosure.
Commissioning:
To ease the commissioning process, a custom made key is available that enables 100% functional
testing of the MCP.
To test the MCP, simply insert the Key in the hole located beneath the MCP (First ensure the Panel is
in the ‘Walk Test’ mode). Push the key up into the hole until the key paddle lines up with the push
button switch. Turn the key anticlockwise to activate the MCP into Alarm. The Key has been designed
so that it can also be used when the MCP is flush mounted.
Once the MCP has been tested, repeat the above step to return the switch and MCP to normal.
Product Code:
Description Code
Conventional Indicating Call-Point CPPIN-3
Replacement ‘Snapglaze’ Window
(Press In Push Switch) text CPPSGWT
Activation Key (Approved Agents only) CPPTK
Replacement Glass
(Break Glass Push Switch) text CPGT
Spare Keyhole Bung CPKHBUNG
RED BL
K
RED BL
K
RED BL
K
RED BL
K
To Fire Alarm
Panel To next device or 10k eol resisto
r
+
M+
M
53mm
MCP Surface Mount Base Surface Mounting Flush Mounting
1
1
5
.
0
0
m
m
115.00 mm 32mm 15mm
Insert Key Here
Press In
Push Switch
No Glass Snapglaze
NZ Patent 272427
DIAL 111
FIRE
