Pet-tek G-SDD User manual

&
DESIGNED IN NEW ZEALAND
INSTALLATION INSTRUCTIONS FOR ALL PET DOORS

2
GLASS FITTING PET DOORS
IMPORTANT INFORMATION FOR GLASS FITTING MODELS
Installing a pet door into glass must be done by a glass specialist as cutting holes in
glass can be both hazardous and costly, if not done by a glass professional.
You must not try to cut a hole in either toughened glass or double glazed glass
because of their special properties. For these types of glass the hole must be cut
prior to manufacture.
No screw holes are required in the glass as the screws are connected to both the
internal and external sections within the cut out area.
G-CD Glassttingcatdoor diameterrequired245mm suitableforglass3-10mmthick
G-SDD Glassttingmaxidualglaze diameterrequired267mm suitableforglass3-28mmthick
G-SDDSLGlassttingmaxislim diameterrequired267mm suitableforglass3-20mmthick
G-DD GlassDogdoor  diameterrequired385mm suitableforglass3-32mmthick
G-DDSLGlassDogdoorslim diameterrequired385mm suitableforglass3-20mmthick
G-MCD Glassttingmultimagnetic diameterrequired245mm suitableforglass3-26mmthick
A circular cut-out is required for the following models, details below:
Do not install a pet door in any area leading directly into a pool.
Check with your local council.
!
3
MEASURING AND MARKING THE LOCATION OF YOUR GLASS FITTING
PET DOOR
Glass tting doors must to be installed by a glazier or glass specialist.
A circular cut-out is required for the following models, details below:
Measurethebelly(stomach)heightofyourpet.Forcats,itisnormally100-
150mm.Dogscanvarygreatlysoitneedstobeaheightthatyourdogcan
access easily. Belly height is the guide along with the practicality of location.
Markthisheightontotheglassyouareinstallinginto.Thiswilldeterminethe
bottom of your cut-out. Scribe a circle (according to the recommendation of
the door model) to the outside of your door or window.
Thiswillthenbethecutout.Referpicturesbelow.
Next, slip the external frame (main body) into the hole from the outside.
Next,sliptheinternalframeoverthemainframe.Thisisaslipjointwhich
allows the frame to be compressed against the glass. Cut the screws to length
asnecessary.Screwupthefourscrewsrmlybutdonotovertighten.
FOUR-WAY LOCKING SYSTEM
Allofourpetdoorshaveafour-waylockingsystemtoallowyoutocontrol
yourpet’smovements.Optionsare:
NB: For Multi-magnetic models, a collar magnet is also required for operation of
the door.
Entry Only Exit Only Entry and Exit Locked both
directions
1 2
!

2
GLASS FITTING PET DOORS
IMPORTANT INFORMATION FOR GLASS FITTING MODELS
Installing a pet door into glass must be done by a glass specialist as cutting holes in
glass can be both hazardous and costly, if not done by a glass professional.
You must not try to cut a hole in either toughened glass or double glazed glass
because of their special properties. For these types of glass the hole must be cut
prior to manufacture.
No screw holes are required in the glass as the screws are connected to both the
internal and external sections within the cut out area.
G-CD Glassttingcatdoor diameterrequired245mm suitableforglass3-10mmthick
G-SDD Glassttingmaxidualglaze diameterrequired267mm suitableforglass3-28mmthick
G-SDDSLGlassttingmaxislim diameterrequired267mm suitableforglass3-20mmthick
G-DD GlassDogdoor  diameterrequired385mm suitableforglass3-32mmthick
G-DDSLGlassDogdoorslim diameterrequired385mm suitableforglass3-20mmthick
G-MCD Glassttingmultimagnetic diameterrequired245mm suitableforglass3-26mmthick
A circular cut-out is required for the following models, details below:
Do not install a pet door in any area leading directly into a pool.
Check with your local council.
!
3
MEASURING AND MARKING THE LOCATION OF YOUR GLASS FITTING
PET DOOR
Glass tting doors must to be installed by a glazier or glass specialist.
A circular cut-out is required for the following models, details below:
Measurethebelly(stomach)heightofyourpet.Forcats,itisnormally100-
150mm.Dogscanvarygreatlysoitneedstobeaheightthatyourdogcan
access easily. Belly height is the guide along with the practicality of location.
Markthisheightontotheglassyouareinstallinginto.Thiswilldeterminethe
bottom of your cut-out. Scribe a circle (according to the recommendation of
the door model) to the outside of your door or window.
Thiswillthenbethecutout.Referpicturesbelow.
Next, slip the external frame (main body) into the hole from the outside.
Next,sliptheinternalframeoverthemainframe.Thisisaslipjointwhich
allows the frame to be compressed against the glass. Cut the screws to length
asnecessary.Screwupthefourscrewsrmlybutdonotovertighten.
FOUR-WAY LOCKING SYSTEM
Allofourpetdoorshaveafour-waylockingsystemtoallowyoutocontrol
yourpet’smovements.Optionsare:
NB: For Multi-magnetic models, a collar magnet is also required for operation of
the door.
Entry Only Exit Only Entry and Exit Locked both
directions
1 2
!

4
ADDITIONAL SECURITY FOR GLASS FITTING DOG DOORS
Models : G-SDD and G-SDDSL
TheG-SDDandG-SDDSLmodelsofsmalldog
door include a security pin in addition to its four
waylockingsystem.Thiscanbeusedwhenthepet
doorisinthefullylockedpositiononly.Theimage
adjacentshowswherethepinisinsertedinto.
Models G-DD and G-DDSL
ThemodelsG-DDandG-DDSLcomewithalockingclipfeatureinadditionto
itsfourwaylockingdials.Twosecurityclipscanbeattachedtothelockingdials
whenthedoorisinthefullylockedpositiononly.
Thediagramsbelowshowhowtheclipsareused.
1.Clip about to go on 2.Clip going on
3.Clip in place 4.Removing clip from pet door
5
WOOD FITTING DOORS
IMPORTANT INFORMATION FOR WOOD FITTING MODELS
An appropriate template is supplied for the above doors.
MEASURING AND MARKING THE LOCATION OF YOUR WOOD
FITTING PET DOOR
Measurethebelly(stomach)heightofyourpet.Forcatsitisnormally100-
150mm.Dogsvarygreatlysoitneedstobeaheightthatyourdogcanaccess
easily. Belly height is the guide along with practicality of location.
Please note the W-DD has its own specic installation instructions that are on page 7.
W-CD Woodttingcatdoor(slimline) suitableforwoodpanels11 - 3 0 m m thick
W-CDTWoodttingcatdoortunnel  suitableforwoodpanels11 - 52 m m thick
W-SDDWoodttingsmalldogdoor(slimline) suitableforwoodpanels11 - 3 0 m m thick
W-SDDTWoodttingsmalldogdoortunnel suitableforwoodpanels11- 5 2 m mthick
W-UCDWoodttingupgradeablecatdoor suitableforwoodpanels11- 52 m m thick
W-MCDWoodttingmulti-magneticcatdoor suitableforwoodpanels11 - 5 2 m m thick
Do not install a pet door in any area leading directly into a pool.
Check with your local council.
!

4
ADDITIONAL SECURITY FOR GLASS FITTING DOG DOORS
Models : G-SDD and G-SDDSL
TheG-SDDandG-SDDSLmodelsofsmalldog
door include a security pin in addition to its four
waylockingsystem.Thiscanbeusedwhenthepet
doorisinthefullylockedpositiononly.Theimage
adjacentshowswherethepinisinsertedinto.
Models G-DD and G-DDSL
ThemodelsG-DDandG-DDSLcomewithalockingclipfeatureinadditionto
itsfourwaylockingdials.Twosecurityclipscanbeattachedtothelockingdials
whenthedoorisinthefullylockedpositiononly.
Thediagramsbelowshowhowtheclipsareused.
1.Clip about to go on 2.Clip going on
3.Clip in place 4.Removing clip from pet door
5
WOOD FITTING DOORS
IMPORTANT INFORMATION FOR WOOD FITTING MODELS
An appropriate template is supplied for the above doors.
MEASURING AND MARKING THE LOCATION OF YOUR WOOD
FITTING PET DOOR
Measurethebelly(stomach)heightofyourpet.Forcatsitisnormally100-
150mm.Dogsvarygreatlysoitneedstobeaheightthatyourdogcanaccess
easily. Belly height is the guide along with practicality of location.
Please note the W-DD has its own specic installation instructions that are on page 7.
W-CD Woodttingcatdoor(slimline) suitableforwoodpanels11 - 3 0 m m thick
W-CDTWoodttingcatdoortunnel  suitableforwoodpanels11 - 52 m m thick
W-SDDWoodttingsmalldogdoor(slimline) suitableforwoodpanels11 - 3 0 m m thick
W-SDDTWoodttingsmalldogdoortunnel suitableforwoodpanels11- 5 2 m mthick
W-UCDWoodttingupgradeablecatdoor suitableforwoodpanels11- 52 m m thick
W-MCDWoodttingmulti-magneticcatdoor suitableforwoodpanels11 - 5 2 m m thick
Do not install a pet door in any area leading directly into a pool.
Check with your local council.
!

6
INSTALLING YOUR WOOD FITTING PET DOOR
Position the template at the appropriate height with the bottom of the pet
doorlevel(wherepractical)withthepet’sstomach.Tapethetemplateto
thedoororpanelthatyouareinstallinginto.Ensurethetemplateislevel.
Withapenciltracethelinetobecut.Fig.1below.
Cuta10mmholeontheinsideedgeofthemarkedcutout.
Carefullycutalongthemarkedlinewithyourjigsaw.Fig.2below.
Next put the external frame (main body into the hole
from the exterior. Place the internal frame from inside
onto the external frame.
Theunitusesaslipjointwhichallowstheframesto
becompressedtotthedoor/panelthickness.Drill
a4mmholethrougheachofthefourcornersofthe
internalframeontothedoor/panel.
Removetheinternalandexternalframesandopen
eachoftheholesoutto7mm.Thiswillallowsufcient
clearance for the fastening screws to be aligned.
Replacetheexternalandinternalframesback
through and fasten together using the cut to length
screws.
Ensurethescrewsprovidedarecuttothecorrect
length.Thecorrectscrewlengthispanelthickness
plus18mm.
1 2
7
IMPORTANT INSTALLATION INSTRUCTIONS FOR:
W-DD Wood tting dog door suitable for wood panels 5-36mm
An appropriate template is supplied for this model
MEASURING AND MARKING THE LOCATION OF YOUR
WOOD FITTING PET DOOR
Measurethebelly(stomach)heightofyourpet.Dogsvarygreatlysoit
needs to be a height that your dog can access easily. Belly height is the guide
along with practicality of location.
Position the template at the appropriate height with the
bottomofthepetdoorlevel(wherepractical)withthe
pet’sstomach.Tapethetemplatetothedoororpanel
thatyouareinstallinginto.Ensurethetemplateislevel.
With a pencil trace the line to be cut.
Drillfour10mmholesinthecornersasperthediagram
shown,makingsurethatthecornersarethecentre
point of the hole.
Carefullycutalongthemarkedlinesthatyouhave
markedaroundthetemplate.Youwillendupwiththe
shape as shown.
Do not install a pet door in any area leading directly into a pool.
Check with your local council.
!

6
INSTALLING YOUR WOOD FITTING PET DOOR
Position the template at the appropriate height with the bottom of the pet
doorlevel(wherepractical)withthepet’sstomach.Tapethetemplateto
thedoororpanelthatyouareinstallinginto.Ensurethetemplateislevel.
Withapenciltracethelinetobecut.Fig.1below.
Cuta10mmholeontheinsideedgeofthemarkedcutout.
Carefullycutalongthemarkedlinewithyourjigsaw.Fig.2below.
Next put the external frame (main body into the hole
from the exterior. Place the internal frame from inside
onto the external frame.
Theunitusesaslipjointwhichallowstheframesto
becompressedtotthedoor/panelthickness.Drill
a4mmholethrougheachofthefourcornersofthe
internalframeontothedoor/panel.
Removetheinternalandexternalframesandopen
eachoftheholesoutto7mm.Thiswillallowsufcient
clearance for the fastening screws to be aligned.
Replacetheexternalandinternalframesback
through and fasten together using the cut to length
screws.
Ensurethescrewsprovidedarecuttothecorrect
length.Thecorrectscrewlengthispanelthickness
plus18mm.
1 2
7
IMPORTANT INSTALLATION INSTRUCTIONS FOR:
W-DD Wood tting dog door suitable for wood panels 5-36mm
An appropriate template is supplied for this model
MEASURING AND MARKING THE LOCATION OF YOUR
WOOD FITTING PET DOOR
Measurethebelly(stomach)heightofyourpet.Dogsvarygreatlysoit
needs to be a height that your dog can access easily. Belly height is the guide
along with practicality of location.
Position the template at the appropriate height with the
bottomofthepetdoorlevel(wherepractical)withthe
pet’sstomach.Tapethetemplatetothedoororpanel
thatyouareinstallinginto.Ensurethetemplateislevel.
With a pencil trace the line to be cut.
Drillfour10mmholesinthecornersasperthediagram
shown,makingsurethatthecornersarethecentre
point of the hole.
Carefullycutalongthemarkedlinesthatyouhave
markedaroundthetemplate.Youwillendupwiththe
shape as shown.
Do not install a pet door in any area leading directly into a pool.
Check with your local council.
!

8
Slip the external pet door frame (main body) into the
holefromtheoutside.Nextsliptheinternalframeover
theexternalmainframe.Thisisaslipjoint,whichallows
theframetobecompressedtotthedoorthickness.
Ensurethescrewsprovidedarecuttothecorrectlength.
Thecorrectlengthisdoorpanelthicknessplus12mm.
Now screw the internal and external frames
together.
ADDITIONAL SECURITY FOR THE WOOD FITTING DOG DOOR
Thewoodttingdogdoorhasasecuritycoverwhichcanbeusedwhen
additionalsecurityisrequired.Thesecuritycoverisdesignedtobeusedwhen
thedoorisinthefullylockedposition.
W-DD Wood tting dog door installation instructions (cont)
9
TRAINING YOUR PET TO USE A PET DOOR
IMPORTANT! DO NOT force your pet to use the door
or frighten your pet whilst training it. It is important that your pet
does not associate the pet door with fear or being punished.
!
Ifyourpethasnotpreviouslyusedapetdooritmustbetrainedinorder
forthemtobecomeaccustomedtoit.Ingeneralthiscantakeseveralweeks
andvariesaccordingtotemperament.Mostpetshoweverarehappytohave
freedom of access and will learn to use a pet door.
TIPS FOR TRAINING
• Alwayshaveafewtreatsonhandwhentrainingyourpet
• Takeadvantageofmealtimeswhennaturalinstincthelpsand
place its food bowl so it can see it through the pet door.
• Yourpetdoorhasafourwaylockingsystem,trytointroduce
yourpetslowly.Tr ytoavoiditrunningintothedoorwhenit
islocked.
• Ifyourpetistimidtryopeningtheapslightlyforyourpet
while it gets used to using the door.
• Always reward your pet during training with a caress or treat
when it uses the pet door.

9
TRAINING YOUR PET TO USE A PET DOOR
IMPORTANT! DO NOT force your pet to use the door
or frighten your pet whilst training it. It is important that your pet
does not associate the pet door with fear or being punished.
!
Ifyourpethasnotpreviouslyusedapetdooritmustbetrainedinorder
forthemtobecomeaccustomedtoit.Ingeneralthiscantakeseveralweeks
andvariesaccordingtotemperament.Mostpetshoweverarehappytohave
freedom of access and will learn to use a pet door.
TIPS FOR TRAINING
• Alwayshaveafewtreatsonhandwhentrainingyourpet
• Takeadvantageofmealtimeswhennaturalinstincthelpsand
place its food bowl so it can see it through the pet door.
• Yourpetdoorhasafourwaylockingsystem,trytointroduce
yourpetslowly.Tr ytoavoiditrunningintothedoorwhenit
islocked.
• Ifyourpetistimidtryopeningtheapslightlyforyourpet
while it gets used to using the door.
• Always reward your pet during training with a caress or treat
when it uses the pet door.
8
Slip the external pet door frame (main body) into the
holefromtheoutside.Nextsliptheinternalframeover
theexternalmainframe.Thisisaslipjoint,whichallows
theframetobecompressedtotthedoorthickness.
Ensurethescrewsprovidedarecuttothecorrectlength.
Thecorrectlengthisdoorpanelthicknessplus12mm.
Now screw the internal and external frames
together.
ADDITIONAL SECURITY FOR THE WOOD FITTING DOG DOOR
Thewoodttingdogdoorhasasecuritycoverwhichcanbeusedwhen
additionalsecurityisrequired.Thesecuritycoverisdesignedtobeusedwhen
thedoorisinthefullylockedposition.
W-DD Wood tting dog door installation instructions (cont)
9
TRAINING YOUR PET TO USE A PET DOOR
IMPORTANT! DO NOT force your pet to use the door
or frighten your pet whilst training it. It is important that your pet
does not associate the pet door with fear or being punished.
!
Ifyourpethasnotpreviouslyusedapetdooritmustbetrainedinorder
forthemtobecomeaccustomedtoit.Ingeneralthiscantakeseveralweeks
andvariesaccordingtotemperament.Mostpetshoweverarehappytohave
freedom of access and will learn to use a pet door.
TIPS FOR TRAINING
• Alwayshaveafewtreatsonhandwhentrainingyourpet
• Takeadvantageofmealtimeswhennaturalinstincthelpsand
place its food bowl so it can see it through the pet door.
• Yourpetdoorhasafourwaylockingsystem,trytointroduce
yourpetslowly.Tr ytoavoiditrunningintothedoorwhenit
islocked.
• Ifyourpetistimidtryopeningtheapslightlyforyourpet
while it gets used to using the door.
• Always reward your pet during training with a caress or treat
when it uses the pet door.

10
MULTI-MAGNETIC MODELS
(Collar Key)
Information regarding use of multi-magnetic models
Tousethemultimagneticmodelsyourcatneedstohaveamagneticcollarclip
locatedcentrallyonitspetcollar.Thecollarkeyactivatesthemulti-magnetic
systemwithinthecatdoor.Nobatteriesarerequired.Thelockinglatch
depresses and allows entry by your cat, then automatically repositions itself
afteryourcathasentered.Thecollarkeyneedstobeattacheddirectlyonto
your pet’s collar. Do not attach rings to your cat’s collar.
Whenusingthemulti-magneticdooryourcatneedstoalsopushtheapof
thecatdoorjustinthesamemannerasthemanualmodels.
Magnetic cat doors are recommended for cats from 9 months or older. Do not
useonsmallkittens.
Training Tips for the Multi-magnetic models
TheMulti-magneticpetdoormakesaslightsoundwhenactivated.Ifyourcat
is timid and not familiar with using a pet door you can temporarily tape down
the magnetic latch until the cat becomes accustomed to the pet door. Ensure to
removeanyadhesiveresiduebeforere-activatingthemagneticmechanismto
ensure it does not affect the door action.
Multi-magneticpetdoorsoperatewhenthemagneticcollarkeyiswithinthe
magneticeldrangeofuptoapproximately25mm.Anyfurtherthanthisand
themagneticdoorwillnotoperate.Thepetdoorneedstobepositionedatan
easily accessible height so that your cat can enter it from a horizontal position.
Itcanbeadvantageoustoinitiallycoverthetop25%oftheclearap,justwhile
yourcatgetsfamiliarwithusingthedoor.Thiswilllimitthecat’svisionthrough
theapandshewilldropherheadtoseethroughtheremainingpart,thus
ensuringthecollarkeyiswithintheactivationzone.
Ensure that your pet is trained to enter through the centre of the door and
notatanangle,toensurethatthemagneticeldisactivated.Youcancreatea
tunnel effect by temporarily placing a pot plant either side of the pet door to
ensure your pet enters the door straight on.
11
www.catwalk-petdoors.comwww.catwalkpetdoors.co.uk
[e-mail]
Buyers name
Date of
Purchase
Address
Province
Country
Purchased
from
PET-TEK WARRANTY
ThankyouforchoosingaPet-tekpetproduct.Allproductsarecarefullyinspected
priortoleavingthemanufacturingplant.Wetrustthatyouwillhavemanyyearsof
trouble free use of your pet door.
CatwalkandDogwalkpetdoorscomewithathreeyearmanufacturer’swarranty
against product malfunction due to manufacturing or parts defects, but not failure
as a result of accidental damage, mishandling or abuse. Normal wear and tear is
notcoveredunderwarranty.Shouldreplacementwovenpileberequireditcan
bepurchasedviayoursupplier.
Thewarrantyisnotvalidwithoutaproofofpurchase.Faultygoodsshouldbe
returned to where you purchased the product so that it can be assessed and
where appropriate replaced.

10
MULTI-MAGNETIC MODELS
(Collar Key)
Information regarding use of multi-magnetic models
Tousethemultimagneticmodelsyourcatneedstohaveamagneticcollarclip
locatedcentrallyonitspetcollar.Thecollarkeyactivatesthemulti-magnetic
systemwithinthecatdoor.Nobatteriesarerequired.Thelockinglatch
depresses and allows entry by your cat, then automatically repositions itself
afteryourcathasentered.Thecollarkeyneedstobeattacheddirectlyonto
your pet’s collar. Do not attach rings to your cat’s collar.
Whenusingthemulti-magneticdooryourcatneedstoalsopushtheapof
thecatdoorjustinthesamemannerasthemanualmodels.
Magnetic cat doors are recommended for cats from 9 months or older. Do not
useonsmallkittens.
Training Tips for the Multi-magnetic models
TheMulti-magneticpetdoormakesaslightsoundwhenactivated.Ifyourcat
is timid and not familiar with using a pet door you can temporarily tape down
the magnetic latch until the cat becomes accustomed to the pet door. Ensure to
removeanyadhesiveresiduebeforere-activatingthemagneticmechanismto
ensure it does not affect the door action.
Multi-magneticpetdoorsoperatewhenthemagneticcollarkeyiswithinthe
magneticeldrangeofuptoapproximately25mm.Anyfurtherthanthisand
themagneticdoorwillnotoperate.Thepetdoorneedstobepositionedatan
easily accessible height so that your cat can enter it from a horizontal position.
Itcanbeadvantageoustoinitiallycoverthetop25%oftheclearap,justwhile
yourcatgetsfamiliarwithusingthedoor.Thiswilllimitthecat’svisionthrough
theapandshewilldropherheadtoseethroughtheremainingpart,thus
ensuringthecollarkeyiswithintheactivationzone.
Ensure that your pet is trained to enter through the centre of the door and
notatanangle,toensurethatthemagneticeldisactivated.Youcancreatea
tunnel effect by temporarily placing a pot plant either side of the pet door to
ensure your pet enters the door straight on.
11
www.catwalk-petdoors.comwww.catwalkpetdoors.co.uk
[e-mail]
Buyers name
Date of
Purchase
Address
Province
Country
Purchased
from
PET-TEK WARRANTY
ThankyouforchoosingaPet-tekpetproduct.Allproductsarecarefullyinspected
priortoleavingthemanufacturingplant.Wetrustthatyouwillhavemanyyearsof
trouble free use of your pet door.
CatwalkandDogwalkpetdoorscomewithathreeyearmanufacturer’swarranty
against product malfunction due to manufacturing or parts defects, but not failure
as a result of accidental damage, mishandling or abuse. Normal wear and tear is
notcoveredunderwarranty.Shouldreplacementwovenpileberequireditcan
bepurchasedviayoursupplier.
Thewarrantyisnotvalidwithoutaproofofpurchase.Faultygoodsshouldbe
returned to where you purchased the product so that it can be assessed and
where appropriate replaced.

www.catwalk-petdoors.comwww.catwalkpetdoors.co.uk
[e-mail]
