Phantom Cure Station User manual

High performance base treatment to improve gliding surfaces.
i
!
EN
Update: July 2022
Apply once, glide forever.
INSTRUCTIONS

PHANTOM Cure Station
Model:
Serial #:
PHANTOM requires specic UV light and temperature conditions to cure properly. We recommend a professional application where possible. PHANTOM erfordert
bestimmte UV-Licht- und Temperaturbedingungen, um richtig auszuhärten. Wir empfehlen, wenn möglich, eine professionelle Anwendung. PHANTOM nécessite
une lumière UV et des conditions de température spéciques pour bien durcir. Nous recommandons une application professionnelle lorsque cela est possible.
Per una polimerizzazione corretta, PHANTOM richiede condizioni speciche di luce UV e temperatura. Si raccomanda un’applicazione professionale, ove
possibile. PHANTOM nécessite des conditions spéciques de température et de lumière UV pour durcir correctement. Nous vous recommandons une application
professionnelle lorsque cela est possible. PHANTOMは、適切にキュアするために特定のUV光と温度条件を必要とします。できる限り、プロによる施工をされるようお勧め
します。PHANTOM을이용하여 올바르게 관리하려면 특정 UV 조명 및온도 조건이 필요합니다. 당사는 가능하면 전문적인 적용을 추천합니다. PHANTOM trenger et bestemt
UV-lys og riktige temperaturforhold for korrekt herding. Vi anbefaler at dette gjøres av en profesjonell der det er mulig. PHANTOM kräver specika UV-ljus- och
temperaturförhållanden för att härda ordentligt. Vi rekommenderar en professionell applicering när det är möjligt.
Warning: Flammable liquid and vapor. Keep away from heat, hot surfaces, sparks, open ames and other ignition sources. Liquid can cause eye and skin
irritation. Use in a well ventilated area and wear protective gloves, eye and face protection. Please read all instructions and warnings before starting. Once cured
on a ski or snowboard, this is an inert material that is non-hazardous and emits no vapors. Warnung: Flüssigkeit und Dampf sind brennbar. Von Wärme, heißen Flächen,
Zündfunken, offenem Feuer und anderen Zündquellen fernhalten. Flüssigkeit kann zu Augen- und Hautreizungen führen. In gut belüfteten Bereichen verwenden
und Schutzhandschuhe, Augen- und Gesichtsschutz tragen. Bitte lesen Sie vor Beginn alle Anweisungen und Warnhinweise. Nach dem Aushärten auf dem Ski
oder Snowboard ist das Material inaktiv und ungefährlich und emittiert keine Dämpfe. Avertissement : Liquide et vapeurs inammables. Tenir à l’écart de la chaleur, des
surfaces chaudes, des étincelles, des ammes vives et autres sources de combustion. Le liquide peut provoquer une irritation des yeux et de la peau. Utilisez-
le dans un endroit bien ventilé et portez des gants de protection, un appareil de protection des yeux et du visage. Veuillez lire toutes les instructions et tous
les avertissements avant de commencer. Une fois durci sur un ski ou un snowboard, il s’agit d’un matériau inerte, non dangereux et n’émettant aucune vapeur. Attenzione:
Liquido e vapore inammabili. Tenere lontano da calore, superci calde, scintille, amme libere e altre fonti di accensione. Il liquido può causare irritazioni agli
occhi e alla pelle. Utilizzare in un’area ben ventilata e indossare guanti protettivi e protezioni per occhi e viso. Leggere tutte le istruzioni e le avvertenze prima di
iniziare. Una volta polimerizzato su uno sci o uno snowboard, questo materiale è inerte, non pericoloso e non emette vapori. Avertissement : Liquide et vapeur inammables.
Tenir à l’écart de la chaleur, des surfaces chaudes, des étincelles, des ammes nues et autres sources d’inammation. Le liquide peut provoquer une irritation
des yeux et de la peau. Utilisez dans un endroit bien ventilé et portez des gants et un appareil de protection pour les yeux et le visage. Veuillez lire toutes les
instructions et tous les avertissements avant de commencer. Une fois durci sur un ski ou une planche à neige, ce matériel est inerte, non dangereux et n’émet aucune vapeur.
警告：可燃性の液体および蒸気。熱、高温の表面、火花、裸火、その他の発火源から遠ざけてください。液体は、目や皮膚の炎症を引き起こす可能性があります。換気の
良い場所で使用し、保護手袋、目および顔の保護具を着用してください。開始する前に、説明書と警告をすべてお読みください。不活性材料ですから、一旦、スキーやスノ
ーボードへのキュア施工をした後は、無害となり、蒸気を放出することはありません。경고: 가연성 액체 및증기. 열, 뜨거운 표면, 스파크, 불꽃 및기타 점화원으로부터 멀리
떨어져 있어야 합니다. 액체는 눈과 피부를 자극할 수있습니다. 환기가 잘되는 곳에서 사용하고 보호 장갑, 눈및얼굴 보호구를 착용해야 합니다. 시작하기 전에 모든 지침 및
경고를 읽어 보십시오.󼔐󺨟󼔐 󼔘󻂄 󼁀󼹀󺸴󾘥󼁀󺼔󻪐󻉸󼍬󻺸󾘥󺩙󽏰󻆴󻠐󾘥󼒠󽍴󽋴󼝜󾘥󼋦󺩼󾘥󻾴󼜹󺯌󻜘󾘥󻧌󼬸󽋴󼝜󾘥󼋦󻀰󾘥󻯠󽏸󻻍󾘥󻣘󼝤󼔡󻁤󻂀Advarsel: Brannfarlig væske og damp. Hold
unna varme, varme overater, gnister, åpen ild og andre antennelseskilder. Væske kan forårsake øye- og hudplager. Bruk i et godt ventilert område og ha på deg
vernehansker, -briller og -maske. Less alle instruksjonene og advarslene før du starter. Når herding er utført på ski eller snowboard, er dette et inert materiale som er
ufarlig og ikke avgir noen avgasser. Varning: Brandfarlig vätska och ånga. Håll borta från värme, heta ytor, gnistor, öppna lågor och andra antändningskällor. Vätskan
kan orsaka ögon- och hudirritation. Använd på en välventilerad plats och bär skyddshandskar, ögon- och ansiktsskydd. Läs alla instruktioner och varningar innan
du börjar. När det väl har härdat på en skida eller snowboard är detta ett trögt material som är ofarligt och inte avger några ångor.
In the event of a medical or chemical emergency contact ChemTel, North America [phone] or Worldwide [phone]. All other non-emergency
inquiries about the product should be directed to DPS Skis: [phone] or Toll Free DPS Skis, North America +1-833-DPS-SKIS ([phone]) or
[email protected]. Bei einem medizinischen oder chemischen Notfall kontaktieren Sie bitte ChemTel, in Nordamerika [phone] oder
weltweit [phone]. Alle sonstigen nicht dringenden Anfragen zum Produkt richten Sie bitte an DPS Skis: [phone] oder gebührenfrei an DPS
Skis, Nordamerika +1-833-DPS-SKIS ([phone]) oder an [email protected]. En cas d’urgence médicale ou chimique, contactez ChemTel,
depuis l’Amérique du Nord au [phone] ou depuis le reste du monde au (+01)-1-813-248-0585. Toutes les autres questions non urgentes concernant
le produit doivent être adressées à DPS Skis : (+01)-1-801-413-1737 ou le numéro gratuit de DPS Skis, depuis l’Amérique du Nord +1-833-DPS-SKIS (+1-833-
377-7547) ou via e-mail à [email protected]. In caso di emergenza medica o chimica, contattare ChemTel, America Settentrionale +1-800-255-
3924 o Resto del mondo [phone]. Tutte le altre richieste di informazioni non urgenti sul prodotto devono essere indirizzate a DPS Skis: +1-801-413-
1737 o Numero Verde DPS Skis, America Settentrionale +1-833-DPS-SKIS ([phone]) o [email protected]. En cas d’urgence médicale
ou chimique, contactez ChemTel, Amérique du Nord [phone] ou dans le monde entier [phone]. Toutes les autres questions non urgentes
concernant le produit doivent être adressées à DPS Skis : [phone] ou le numéro gratuit de DPS Skis, Amérique du Nord +1 833 DPS-SKIS (+1 833 377-
7547) ou à l’adresse : [email protected]. 医学的または化学的緊急事態が発生した場合は、北米のChemTel+1-800-255-3924ま た は ワ ー ルドワ イドの
[phone]に 連 絡 してくだ さ い 。製品に関するその他の緊急ではないお問い合わせはすべて、DPSス キ ー 宛 て に お 願 い 致 し ま す：[phone]また はフリー ダイ
ヤルDPSス キ ー 、北 米 + 1-833-DPS-SKIS（+ 1-833-377-7547）または[email protected]。의료 또는 화학적 응급 상황이 발생할 경우 ChemTel, +1-800-
255-3924(북미) 또는 [phone](전세계)로문의하십시오. 제품에 대한 기타 비상시 문의는 모두 아래와 같이 DPS Skis로전화나 이메일로 문의해야 합니다. +1-801-
413-1737 또는 Toll Free DPS Skis, 북미 +1-833-DPS-SKIS([phone]) 또는 [email protected]. Ved en medisinsk eller kjemisk nødssituasjon,
kontakt ChemTel, Nord-Amerika [phone] eller resten av verden [phone]. Alle andre henvendelser om produktet skal reddes til DPS Skis: +1-
801-413-1737 eller avgiftsfritt DPS Skis, Nord-Amerika +1-833-DPS-SKIS ([phone]) eller [email protected]. I händelse av en medicinsk
eller kemisk nödsituation, kontakta ChemTel, Nordamerika [phone] eller internationellt [phone]. Alla andra icke-brådskande förfrågningar om
produkten bör riktas till DPS Skis: [phone] eller gratis DPS Skis, Nordamerika +1-833-DPS-SKIS ([phone]) eller phantom.support@dpsskis.
com.
Contains: Organometallic Compounds. Enthält: Organometallische Verbindungen. Contient : Composés organométalliques. Contiene: Composti
Organometallici. Contient : Composés organométalliques. 含まれるもの：有機金属化合物。포함: 유기금속 화합물. Inneholder: Organometalliske forbindelser.
Innehåller:Organometalliska föreningar.

EN
OVERVIEW
PHANTOM Cure Station™ and PHANTOM Glide™ are designed to work together in a shop environment to provide
consistent and rapid UV cure for skis and snowboards. The formula has been specically designed and tested with
the temperature and UV concentration and combinations of wavelengths created by this equipment. No processes
other than using the cure station as described, or following the instructions for natural outdoor strong sunlight cure,
should be attempted.
Please read the PHANTOM Glide™bulk application instructions and warnings before beginning.
Minimum recommended shop temperature is 58°F/15°C for a reasonable 15-30 minute cure station preheat. Longer
preheat may be required at lower starting ambient temperatures.
Refer to Storage and Handling instructions (pg 12) for correct care of your PHANTOM Glide™.
Each bulk bottle contains 300ml of PHANTOM Glide™liquid.
Disposal: If entire contents of individual packets or bulk containers are not used up, remaining liquid can be poured into
absorbent cloth or paper and disposed of once entirely dry.
Please contact DPS Skis at +1.801.413.1737 or [email protected] if you have any troubles or questions
regarding the PHANTOM Cure Station™ or PHANTOM Glide™.
Manufacturer:
Drake Powderworks, Inc.
DBA: DPS Skis
647 South 600 West
Salt Lake City, UT 84101
USA
Phone: [phone]
Email: [email protected]
Website: www.phantomglide.com
Voltage: 110 VAC
Nominal Current: 6 A
Frequency: 60 Hz
Made in: Salt Lake City, Utah, U.S.A.
Voltage: 220 VAC
Nominal Current: 3 A
Frequency: 50 Hz
Made in: Salt Lake City, Utah, U.S.A.
Flammable
Denitions of symbols:

EN
Caution:
•Two Person Lift Required. PHANTOM Cure Station™is a long, heavy object.
• Hot Surface. Do not touch the internal heating unit during or after operation.
• Disconnect PHANTOM Cure Station™from power source when servicing.
Cleaning Information
Over time moisture or evaporative residue may build up inside of the station. Wear appropriate gloves and wipe down
rst with a damp absorbent cloth or paper and then give a nal wipe down with a dry absorbent cloth or paper.
IMPORTANT Power Cable Information
Please, ensure that your PHANTOM Cure Station™is electrically rated to operate with the AC power available in your
location. North America voltage: 110 VAC. Europe and Japan voltage: 220 VAC.
• Only use the power cable that was provided with your PHANTOM Cure Station™.
• Do not plug the equipment power cable into an electrical outlet if the power cable is damaged.
• To prevent electric shock, plug the equipment power cable into properly grounded electrical outlets. If the equip-
ment is provided with a 3-prong power cable, do not use adapter plugs that bypass the grounding feature, or remove
the grounding feature from the plug or adapter.
• Connect the power cable to a grounded electrical outlet only.
• If you use an extension power cable, ensure that the total ampere rating of the products plugged in to the extension
power cable does not exceed the ampere rating of the extension cable.
• If you must use an extension cable or power strip, ensure the extension cable or power strip is connected to a wall
power outlet and not to another extension cable or power strip. The extension cable or power strip must be designed
for grounded plugs and plugged into a grounded wall outlet.
• If you are using a multiple-outlet power strip, use caution when plugging the power cable into the power strip.
Some power strips may allow you to insert a plug incorrectly. Incorrect insertion of the power plug could result in
permanent damage to your equipment, as well as risk of electric shock and/or re. Ensure that the ground prong of
the power plug is inserted into the mating ground contact of the power strip.
• Be sure to grasp the plug, not the cable, when disconnecting equipment from an electric socket.

EN
Power Cord Inlet/Main Power Switch
Preheat
Start
Cancel
Saw Horse
Door Limit Switch
OPERATION

EN
Attach the supplied power cord to A.
NOTE: If a rmware update is required, you will be sent an email with a zipped rmware code. You then install
the cord into the slot in the back left side of the display screen (B) and follow the emailed instructions to install.
To switch between Fahrenheit and Celsius, at initial power up press “cancel” to toggle between Fahrenheit (F) or
Celsius (C).
Pushing cancel at initial power up will display current installed rmware version, i.e. 2.49 Fahrenheit (F).
The door limit switch (G) may need to be adjusted in/out to ensure switch activation, while not creating a
signicant gap in the door seal. Do this by adjusting the order of the nuts holding the switch onto the metal tab.
If any issues persist please contact us.
90º
INITIAL CURE STATION SET UP
Install the 4 custom UV light bulbs into the light clips. Insert with pins vertical and rotate 90° until “click”.
A. Best if done by two people to securely insert each end to the light clips.
B. UV light is directional. Make sure the bulb logo faces down once installed.
STEP 1
STEP 2
STEP 3

EN
HOW TO OPERATE CURE STATION
Turn on the main power switch on the back left (A).
Triple display button (Cure Station version 2 and up):
a. With the door closed, press Preheat once. Both the heater and fan and the 4 UV lights should be on
during Preheat.
i. After temperature is reached, the station will maintain this temperature for a maximum of two
hours and will automatically shut off if there is no activity.
b. Insert the gear base side up centered under the lights, close the door, and press the Start button.
The cure cycle timer will only be initiated at this point if ‘Ready to Cure’ is displayed. Have the
door open for minimum time to retain heat and ensure efcient curing.
c. To cancel at anytime during Preheat, or a cure cycle, press Cancel.
NOTE:
• Initial preheat can take up to 30 minutes depending on ambient temperatures.
• The station is not designed for shop temperature below 58°F/14°C or may take longer to preheat.
• The rst few heat cycles may have a slight burning odor while the heating elements clean off any
manufacturing oils or dust.
STEP 1
STEP 2

EN
HOW TO APPLY PHANTOM GLIDE™
*
*
*
STEP 1
New Skis
Thoroughly clean the factory wax from the base using an industry
approved citrus base cleaner. Do not use unapproved solvent
based cleaners.
Allow the base to dry completely and wipe with a clean paper
towel to remove any remaining residue or dust.
Clean the base either by a fresh stone-grind or a thorough
base cleaning.
Used Skis
Thoroughly clean any wax from the base using an industry
approved citrus base cleaner. Do not use unapproved solvent
based cleaners.
Allow the base to dry completely and wipe with a clean paper
towel to remove any remaining residue or dust.
Repair any base damage with P-tex or base welds where
necessary.
A stone grind is the most efcient way to restore structure or to
remove abrasion, oxidation and/or damage due to use, and is
critical to ensure good PHANTOM Glide™performance.
If the bases are in good shape use a citrus base cleaner (solvent-
based cleaners are not recommended.
If a stone grind is not possible, and the base is particularly
abraded, oxidised or dirty; brush it out with a stiff roto or hand
brush and then repeat the base cleaning process.
IMPORTANT: PHANTOM Glide™should be at ambient room temperature (65°F - 85°F / 18°C - 30°C).
With the lid closed, thoroughly shake the bulk bottle container before each use. Meter out the correct amount of PHANTOM
Glide™per the size chart by administering the recommended number of sprays. For nearly all bases, this is between 2 and
4 full sprays. Applying light pressure with non-absorbent pad, spread evenly between the contact points, working from the
center of the base out to the edges (to minimize mess and clean-up later). Spread PHANTOM Glide™out to tips and tails,
trying to minimise run off. Wipe off any excess PHANTOM Glide™that spills over onto the top sheet. Continue to work
PHANTOM Glide™into the base until the surface has an even, thin polished sheen along the entire length of the running
surface. Make sure to close the spray nozzle after each use.
Prepare Equipment Surface
Apply PHANTOM Glide™Formula
STEP 2
NOTE: These instructions are only applicable to PHANTOM Glide™, a spray-on product released in Winter of 2021/2022.
PHANTOM 2.0 from 2018 is a two-part process requiring a Part A cure and a Part B cure.
PHANTOM CSF from 2019 is offered in bulk bottles for shops and demo needs and is a one-part process with a single cure.
Instructions for both PHANTOM 2.0 and PHANTOM CSF have key differences, and can be found at:
CSF: https://csf.phantomglide.com
DIY: https://diy.phantomglide.com

EN
Once the surfaces have been prepared as described in Step 2, the equipment is ready to go directly into the cure station.
Ensure the bases have an even, thin polished sheen, with no excess PHANTOM Glide™anywhere along the running surface.
NOTE: Bases should be treated at a minimum shop temperature of 58°F/15°C. For optimum results bases should be at 75 -
100 F prior to applying PHANTOM Glide™.
NOTE: PHANTOM Glide™no longer produces a white residue or matte nish. A glossy residue may exist but it should not be
wet or pooled on the base. Once polished, the base will have a high performance sheen. Properly cured PHANTOM Glide™
is essential to long-term performance and you should be sure this step is completed prior to moving onto step 5.
STEP 3
With any binding brakes securely strapped at, or snowboard bindings off, insert into the cure station on the supplied stands
with tips facing the heater (to improve cure efciency) and close the door. Minimize time the door is open to retain internal
Cure Station heat.
A. UV lights will NOT come on unless the door is closed and the limit switch in the upper left corner
is activated.
B. If the internal temperature is below a threshold the cure station may go through a pre-heat period
before the timer begins the countdown.
Once the cure cycle is done, remove the equipment from the cure station and allow it to return to room temperature. The
base should be dry with a nice polished appearance. If any signicant wetness exists, wipe off with a paper towel and
continue curing for another 5-10 minutes. A small amount of residue is OK. Once the base is properly cured, you can move
onto the nishing process described below in Step 5.
STEP 4
IMPORTANT: It is important to use the recommended volume
of PHANTOM Glide™during the application process to ensure
efcient curing and peak performance.
Put Equipment into Cure Station
Run Cure Station Cycle

EN
Wear appropriate eyewear and mask anytime you are brushing winter sports equipment. Using a nylon roto brush, or hand
brush, brush the base(s) from tip to tail. A single pass with the brush is generally sufcient. At this point, the surface will
have a polished sheen and is ready for use!
NOTE: Any tools used to further polish the base (i.e. horsehair or felt brushes) may be used at this point but are not
necessary. Take care to move the brush quickly along the bases in order to not cause friction burn.
STEP 4 STEP 5Brush Skis
A PHANTOM Glide™treated base will continue to have consistent and fast glide as long as the base is kept in good
condition. In practice, this means that some maintenance is required at regular intervals.
When the bases begin to look dry/white, this is a sign that abrasion has formed micro-hairs on the base. Regular dry
polishing using the PHANTOM GlideTM polishing pad and intermittent polishing with water will help keep bases clean
and maintain glide performance. For hard to remove adhesives and residue such as skin glue, use a citrus base cleaner or
rubbing alcohol.
Dirt and grease may also need to be cleaned off periodically. In this case, use a citrus base cleaner, and follow up with
polishing. After using any solvents on the gliding surface, always make sure bases are completely dry before thoroughly
polishing.
If the structure of the bases becomes damaged or severely abraded, a base grind is recommended. A base grind should
always be followed by polishing.
Inspect the remaining equipment surfaces for PHANTOM Glide™residue. Wipe off the edges, sidewalls and topsheet.
Visually inspect to make sure that everything looks clean.
Place PHANTOM Glide™sticker on each ski or snowboard topsheet.
STEP 4 STEP 6Final Inspection
STEP 4 STEP 7Continued Maintenance
