Phantos LED PAR CAN User manual

LED PAR CAN
7X12W 6in1 LED+144X0.2W 3in1 LED
USER MANUAL
Thank you very much for choosing our product. For safety purpose, please
read this manual carefully before your operation. This manual included
installation and using information. Please install and operate it according to
this manual.

1
Part 1 Product
1.1 Product introduction
This product is designed for indoor use. Suitable applications include wash or
effect lighting for architectural, stage or nightclub applications. This product
can also be installed for use in signage and advertising using the dynamic
functions available with DMX512 control. Direct input of DMX512 signal
allows the units to be controlled from any DMX512 controller. This product
can be operated as a single unit or in multiple units for large applications.
1.2 Technical Specifications
Voltage: AC100-240V, 50/60Hz
Power: 200W
Light Source: 7X12W RGBWA+UV 6in1 ultra bright LED+144X0.2W RGB
3in1 LED
Lifespan: around 50,000-100,000 hours
Control: DMX 512,16/28channels
Control mode: DMX 512, Auto mode, Master/Slave, Sound active
Beam angle: 25 º
Net Weight：4.5Kg
1.3 Safety Warning
IMPORTANT:
ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE
CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS
THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA.
●This product must be installed by a qualified professional.
●Always operate the equipment as described in the user manual.
●A minimum distance of 0.5m must be maintained between the equipment
and combustible surface.
●The product must always be placed in a well ventilated area.
●Always make sure that the equipment is installed securely.
●DO NOT stand close to the equipment and stare directly into the LED light
source.
●Always disconnect the power supply before attempting and maintenance.
●Always make sure that the supporting structure is solid and can support
the combined weight of the products.
●The earth wire must always be connected to the ground.
●Do not touch the power cables if your hands are wet.

2
ATTENTION:
●This product left the place of manufacture in perfect condition. In order to
maintain this condition and for safe operation, the user must always follow
the instructions and safety warnings described in this user manual.
●Avoid shaking or strong impacts to any part of the equipment.
●Make sure that all parts of the equipment are kept clean and free of dust.
●Always make sure that the power connections are connected correct and
secure.
●If there is any malfunction of the equipment, contact your distributor
immediately.
●When transferring the product, it is advisable to use the original packaging
in which the product left the factory.
●Shields, lenses or ultraviolet screens shall be changed if they have
become damaged to such an extent that their effectiveness is impaired.
●The lamp (LED) shall be changed if it has become damaged or thermally
deformed.
PART 2 INSTALLATION
2.1 Mounting:
2.1-1 Hanging
The product can be mounted in a hanging position using the supporting
bracket. The bracket should be secured to the mounting truss or structure
using a standard mounting clamp. Please note that when hanging the unit a
safety cable should also be used
.
2.1-2 Upright
The product can be mounted in an upright or sitting position using the
supporting brackets.
NOTE:
The product can be mounted at any angle and in any position. It is possible to
further adjust the angle of the product using the two adjustment knobs located
on the side of the fixture.
2.2 Special construction for DMX connection.
☆At last fixture, the DMX cable has to be terminated with a terminator to
reduce signal errors. Solder a 120-ohm 1/4W resistor between pin
2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the
DMX-output of the last fixture.

3
☆If the controller is 5-pin output, it’s necessary to use an adaptor to transfer
signal from 5-pin output to 3-pin XLR-plug or you can connect cables as
following:
PART 3 Display Panel Operation
3.1 Display panel menu instruction
[MENU] menu selection or return to previous menu.
[UP] press [UP] through the menu list to increase/change the value of the
current function.
[DOWN] press [DOWN] through the menu list to decrease/change the value
of the current function.
[ENTER] confirm & quit out current function setting.
3.2 Display panel operation instruction

4
3.3 DMX Channel instruction
16CH
28CH
Function
Value
Instruction
CH1
CH1
Master
Dimmer
0-255
Master Dimmer, Dark to Bright
CH2
CH2
In-Dimmer
0-255
Inner Dimmer,Dark to Bright
CH3
CH3
Ex-Dimmer
0-255
External Dimmer,Dark to Bright
CH4
CH4
Strobe
0-19
No function
20-199
Normal strobe
200-249
Random strobe
250-255
No function
CH5
CH5
In-Auto
0-31
No funciton
32-63
Auto 1, speed from slow to fast
64-95
Auto 2, speed from slow to fast
96-127
Auto 3, speed from slow to fast
128-159
Auto 4, speed from slow to fast
160-191
Auto 5, speed from slow to fast

5
192-223
Auto 6, speed from slow to fast
224-255
Sound,Sensitivity low to high
CH6
CH6
Ex-Auto
0-31
No Fuction
32-63
Auto 1, speed from slow to fast
64-95
Auto 2, speed from slow to fast
96-127
Auto 3, speed from slow to fast
128-159
Auto 4, speed from slow to fast
160-191
Auto 5, speed from slow to fast
192-223
Auto 6, speed from slow to fast
224-255
Auto 7, speed from slow to fast
CH7
CH7
In-Red
0-255
Inner Red Dimming,Dark to Bright
CH8
CH8
In-Green
0-255
Inner Green Dimming,Dark to
Bright
CH9
CH9
In-Blue
0-255
Inner Blue Dimming,Dark to
Bright
CH10
CH10
In-White
0-255
Inner Red Dimming,Dark to Bright
CH11
CH11
In-Amber
0-255
Inner Red Dimming,Dark to Bright
CH12
CH12
In-UV
0-255
Inner Red Dimming,Dark to Bright
CH13
CH13
Ex1-macro
color
0-9
No Function
10-29
R up/G 0%/B 0%
30-49
R 100%/G up/B 0%
50-69
R down/G 100% /B 0%
70-89
R 0% /G 100%/B up
90-109
R 0% /G down/B 100%
110-129
R up /G 0%/B 100%
130-149
R 100%/G 0%/B down
150-169
R 100%/G up/B up
170-189
R down/G down/B 100%
190-209
R 100%/G 100%/B 100%

6
210-229
White 1:3500K
230-249
White 2:6500K
250-255
White 3:10000K
CH14
CH14
Ex2-macro
color
***
Same as above
CH15
CH15
Ex3-macro
color
***
Same as above
CH16
CH16
Ex4-macro
color
***
Same as above
CH17
Ex1-Red
0-255
External 1, Red dimming, dark to
bright
CH18
Ex1-Green
0-255
External 1, Green dimming, dark
to bright
CH19
Ex1-Blue
0-255
External 1, Blue dimming, dark to
bright
CH20
Ex2-Red
0-255
External 2, Red dimming, dark to
bright
CH21
Ex2-Green
0-255
External 2, Green dimming, dark
to bright
CH22
Ex2-Blue
0-255
External 2, Blue dimming, dark to
bright
CH23
Ex3-Red
0-255
External 3, Red dimming, dark to
bright
CH24
Ex3-Green
0-255
External 3, Green dimming, dark
to bright
CH25
Ex3-Blue
0-255
External 3, Blue dimming, dark to
bright
CH26
Ex4-Red
0-255
External 4, Red dimming, dark to
bright
CH27
Ex4-Green
0-255
External 4, Green dimming, dark

7
to bright
CH28
Ex4-Blue
0-255
External 4, Blue dimming, dark to
bright
Part 4, Troubleshooting
4.1 Troubleshooting list for some common electrical
problems may happen during use:
Phenomenon
Solution
* The fixture does not
work
* No light out
* Check main power fuse & power cable
connection
* Measure main voltage on the main connector
* No display
* Check connection of display PCB
* Replace a new display
* No responding to
DMX
controller
* Check working mode setting on display is DMX
mode or not
* Check whether the unit be set as SLAVE
* Check DMX address settings
* Check DMX cable and it’s connection
* Try to use another DMX console
* Signal error while use
DMX
* Check whether DMX cables be connected well or
not
* Check whether the DMX cable has to be
terminated with a terminator to reduce signal
errors. If not, please Solder a 120-ohm 1/4W
resistor between pin 2(DMX-) and pin 3(DMX+)
into a 3-pin XLR-plug and plug it in the
DMX-output of the last fixture
4.2 Checking steps about why LED lamp not light
(Example: Red led lamp not light)
Step 1: Disassemble lighting fixture and use multi-meter to measure input
voltage between R+/ R- on main PCB. There should have DC48V.
☆If there no 48V voltage, please check the electro circuit and parts such as
CQ12, R39, R37, Q3 and etc.
☆If there have 48V voltage, please go to step 2.
Step 2: Check voltage between R+ and R- on LED lamp PCB and it should be
48V.
☆If there has voltage, but LED lamp not work, the reason may be LED lamp

8
short circuit or burnt. Use a metal cable connect the two points which be
marked with correspondent color such as R+, R-, G+, G-, B+, B- to check
whether it is short circuit one by one.
☆If there is no voltage, that’s mean the connection cable between lamp
PCB and main PCB is short circuit and just need to replace that
connection cable.
☆If there has voltage and no LED lamp burnt, the problem might be some
LED lamps on LED PCB not be welded well. Check every led lamp and use a
solder to re-weld those not be welded led lamp
Part 5, Maintenance
The cleaning of internal must be carried out periodically to optimize light
output. Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or particularly dirty surrounding can cause greater
accumulation of dirt on the fixture’s optics.
●Clean with soft cloth using normal glass cleaning fluid.
●Always dry the parts carefully.
●Clean the external optics at least every 20 days.
●Clean the internal optics at least every 30/60 days –Up to vary products.
Please ask professional technical to clean waterproof products and make
sure the fixture will be reassembled well for waterproof.
